Vulcan-Hart VEC10 Manual

CATALOG OF
REPLACEMENT PARTS
ELECTRIC COUNTER TILTING
2/3 JACKETED KETTLES
VEC SERIES
MODELS
VEC6
VEC10
VEC20
Model VEC10
VULCAN-HART
DIVISION OF ITW FOOD EQUIPMENT GROUP, LLC
WWW.VULCANHART.COM
P.O. BOX 696, LOUISVILLE, KY 40201-0696
TEL. [phone]
FORM 37111 (6-07)
For additional information on Vulcan-Hart or to locate an authorized
parts and service provider in your area, visit our website at www.vulcanhart.com

– 2 –
REPLACEMENT PARTS VEC SERIES 2/3 JACKETED ELECTRIC KETTLES
REPLACEMENT PARTS LIST
ILLUS. PART NO. NAME OF PART AMT.
Figure 1
1 00-840468 Cover, Kettle Enclosure VEC6 ................................................................................. 1
00-840469 Cover, Kettle Enclosure VEC10 ............................................................................... 1
2 SC-041-09 Bolt, Enclosure Cover .............................................................................................. 1
* 3 00-881961 Air Vent 7/16", Assy. ................................................................................................. 1
4 00-881980 Valve, Pressure Relief (35 psi) ................................................................................. 1
00-844492 Valve, Pressure Relief (50 psi) ................................................................................. 1
* 5 00-840470 Handle, Tilt ............................................................................................................... 1
* 6 00-836964 Knob, Handle, Tilt ..................................................................................................... 1
* 7 00-881970 Switch, Power .......................................................................................................... 1
8 00-840471 Collar, Retaining ....................................................................................................... 1
9 00-881971 Switch, Interlock (Micro) ........................................................................................... 1
10 00-840472 Cover, Access, Element ........................................................................................... 1
11 00-840473 Cover, Box, Control .................................................................................................. 1
* 12 00-881960 Liquid Level Control .................................................................................................. 1
* 13 00-881975 Contactor (208/240V) (30-amp) ................................................................................ 1
* 14 00-881985 Section, Terminal Block ............................................................................................ 1
00-843969 End, Terminal Block .................................................................................................. 1
15 00-840501 Gasket, Element (VEC6) .......................................................................................... 1
00-881969 Gasket, Element (VEC10/VEC20) ............................................................................ 1

– 3 –
REPLACEMENT PARTS VEC SERIES 2/3 JACKETED ELECTRIC KETTLES
REPLACEMENT PARTS LIST
ILLUS. PART NO. NAME OF PART AMT.
Figure 1
* 16 00-881981 Probe, Water Level ................................................................................................... 1
17 FP-086-36 Connector 1/4 X 1/4 ................................................................................................. 1
18 00-522653-00002 Tube, Copper VEC6, 19" Long ................................................................................. 1
00-522653-00002 Tube, Copper VEC10, 22" Long ............................................................................... 1
19 00-881979 Gauge, Pressure ...................................................................................................... 1
20 00-836938 Plate, Mounting ........................................................................................................ 1
* 21 00-881995 Knob, Thermostat ..................................................................................................... 1
00-836968 Knob, Thermostat (for 00-881973) ........................................................................... 1
* 22 00-881993 Controller, Temperature (Thermostat) (VEC6, VEC10, VEC12) ................................ 1
00-881973 Thermostat (VEC20) ................................................................................................ 1
* 23 00-855254 Potentiometer, Remote ............................................................................................ 1
* 24 00-881994 Sensor, Temperature ................................................................................................ 1
* 25 00-881972 Light, Low Water ...................................................................................................... 1
* 26 00-881972 Light, Temperature .................................................................................................... 1
27 Elements, Heating VEC6
00-881986 208V, 7.5 Kw ....................................................................................................... 1
00-881989 220V or 380V, 7.5 Kw .......................................................................................... 1
00-881988 240V or 415V, 7.5 Kw .......................................................................................... 1
00-881990 480V, 7.5 Kw ....................................................................................................... 1
Elements, Heating VEC10/VEC20
00-881996 208V, 12 Kw ........................................................................................................ 1
00-881998 240V or 415V, 12 Kw ........................................................................................... 1
00-881997 220V or 380V, 12 Kw ........................................................................................... 1
00-881999 480V, 12 Kw ........................................................................................................ 1
28 Panel, Control
00-853159 Mylar Control Panel Overlay (VEC6, VEC10, VEC12) ........................................ 1
00-852055 Control Panel Overlay (VEC20) ........................................................................... 1
29 00-840475 Cover, Box, Trunnion (VEC10) ................................................................................. 1
00-840476 Cover, Box, Trunnion (VEC6) ................................................................................... 1
* 00-881978 Transformer (480V) .................................................................................................. 1
* 00-851762 Wiring Harness Thermostat (VEC6, VEC10) ............................................................ 1
* 00-851763 Wiring Harness Element (VEC6, VEC10) ................................................................. 1
* 00-854429 Wiring Harness (VEC20) .......................................................................................... 1
* 00-844531 Fitting Pressure Gauge to Kettle ............................................................................... 1
* 00-844528 Pressure Gauge Fitting ............................................................................................. 1
* 00-845592 Pressure Guage Tube (VEC10) ................................................................................ 1
* 00-836997 Contactor (208/240V, 24 Kw, 50-amp) ...................................................................... 1
* 00-840444 Contactor (208/240V, 33Kw, 63-amp) ....................................................................... 1
* 00-843777 Bearing (Outer) ......................................................................................................... 1
* 00-843778 Bearing (Inner) .......................................................................................................... 1
* 00-854047 Base (Only) (VEC10) ................................................................................................ 1
* 00-840511 Terminal Block Section ............................................................................................. 1
* 00-842778 Lift-off Cover (VEC10) ............................................................................................. 1
* 00-850431 Faucet Bracket ......................................................................................................... 1
* 00-851247 Bushing (Temperature Probe) ................................................................................... 1
* 00-851248 Connector (Temperature Probe) ............................................................................... 1
* 00-851332 Rubber Boot (Power Switch) .................................................................................... 1
* 00-836820 Element (240V 15Kw) (VEC20) ................................................................................ 1
* 00-850025 Fuse (3-amp) ............................................................................................................ 1
* 00-850489 Fuse Holder .............................................................................................................. 1
* 00-844401 Fitting (Thermostat to Bottom of Kettle) ................................................................... 1
* 00-840451 Suction Strainer ........................................................................................................ 1
* 00-836958 Flanged Foot, Adjustable .......................................................................................... 1
* 00-854018 Bottom Cover (VEC20) ............................................................................................ 1
* 00-851567 Gasket, Console Cover (VEC20) ............................................................................. 1
* Not Shown in Exploded View

– 4 –
REPLACEMENT PARTS VEC SERIES 2/3 JACKETED ELECTRIC KETTLES
RECOMMENDED SPARE PARTS
VEC10/20
PART NO. NAME OF PART AMT.
00-844492 Relief Valve (50 lb.) .................................................................................................. 2
00-881970 Power Switch ........................................................................................................... 2
00-881971 Interlock Switch ........................................................................................................ 2
00-881960 Liquid Level Control .................................................................................................. 2
00-881975 Contactor ................................................................................................................. 2
00-881969 Element Gasket ........................................................................................................ 2
00-881981 Probe ....................................................................................................................... 2
00-881993 Temperature Controller (VEC10) .............................................................................. 2
00-855254 Remote Potentiometer ............................................................................................. 2
00-881996 Element (208V) (12Kw) (VEC10/20) ......................................................................... 2
00-881998 Element (240V) (12Kw) (VEC10/20) ......................................................................... 2
00-881999 Element (480V) (12 Kw) (VEC10/20) ........................................................................ 2
00-881973 Thermostat (VEC20) ................................................................................................ 2
00-836968 Thermostat Knob ...................................................................................................... 2
00-881994 Temperature Sensor ................................................................................................. 2
