Vulcan-Hart K12ETT ML-136068 User manual

This Manual is prepared for the use of trained Vulcan Service
Techniciansandshouldnotbeusedbythosenotproperlyqualified.
This manual is not intended to be all encompassing. If you have not
attendedaVulcan ServiceSchoolforthisproduct,youshouldread,
in its entirety, the repair procedure you wish to perform to
determine if you have the necessary tools, instruments and skills
requiredtoperformtheprocedure.Proceduresforwhichyoudonot
have the necessary tools, instruments and skills should be
performed by a trained Vulcan Service Technician.
Reproduction or other use of this Manual, without the express
written consent of Vulcan, is prohibited.
K12ETT ON STAND
SERVICE MANUAL
ELECTRIC COUNTER TOP
TILTING KETTLES
K6ETT ML-136067
K12ETT ML-136068
K20ETT ML-136069
For additional information on Vulcan-Hart or to locate an authorized parts and
service provider in your area, visit our website at www.vulcanhart.com.
A product of VULCAN-HART LOUISVILLE, KY 40201-0696
F35496 (August 2009)

ELECTRIC COUNTER TOP TILTING KETTLES
TABLE OF CONTENTS
GENERAL ................................................................................3
Introduction ............................................................................3
Tools.................................................................................3
Specifications ..........................................................................4
REMOVALANDREPLACEMENTOFPARTS ....................................................5
Covers and Panels .....................................................................5
Electrical Panel Components - Water Level Control, Transformer, Contactors and Temperature Control . . . 5
Bottom Components - Water Level Probe (LLCO), Temperature Sensor and Pressure Switch ...........6
Potentiometer..........................................................................6
HeatingElement........................................................................7
KettleAssembly ........................................................................8
Bearings .............................................................................11
ShaftSeal............................................................................12
PivotStopPin.........................................................................13
SERVICEPROCEDURESANDADJUSTMENTS.................................................14
TemperatureControllerTest .............................................................14
PotentiometerTest.....................................................................15
Thermocouple Test .....................................................................15
HeatingElements......................................................................16
Venting ..............................................................................17
Filling the Reservoir Jacket ..............................................................17
ELECTRICALOPERATION..................................................................19
Component Function ...................................................................19
Component Location ...................................................................20
WaterLevelControl(WLCLLCO) .........................................................22
Sequence of Operation ..................................................................23
SchematicDiagram ....................................................................24
WiringDiagrams.......................................................................25
TROUBLESHOOTING......................................................................27
© VULCAN 2009
F35496 (August 2009) Page 2 of 28

ELECTRIC COUNTER TOP TILTING KETTLES - GENERAL
GENERAL
INTRODUCTION
General
The procedures in this manual apply to all models
unless otherwise specified. The pictures and
illustrations are of a model K6ETT countertop tilting
kettle unless otherwise noted. All information and
specifications contained in this manual are based on
the latest product information available at the time of
printing.
Countertop Tilting Kettles
The electric countertop tilting kettles are self
contained two thirds jacketed kettles. The lower two
thirds of the kettle bowl is a double wall stainless
steel construction that provides a reservoir for a
solution of heat transfer fluid and distilled water for
improved heating of the kettle contents. The kettles
are used to prepare a variety of liquid or semi-liquid
food products such as soups, stews and sauces.
MODELS COVERED
The 6 and 12 gallon kettles can be mounted to a
counter top or optional stand. The 20 gallon kettle is
a floor model mounted to its own stand.
Electric Countertop Tilting Kettles
K6ETT - 6 gallon
K12ETT - 12 gallon
K20ETT - 20 gallon
CONTROL PANEL
TOOLS
Standard
• Standard set of hand tools.
• Pipe thread sealant.
• VOM with an AC current tester (meter sensitivity
should be at least 20,000 ohms per volt).
• Temperature meter (thermocouple type). Use
for checking kettle temperature.
• 2 gallon container to hold drained reservoir
jacket fluid.
Special
• Torque wrench (ft-lbs) for tightening heating
element mounting bolts.
• Lubriplate 630-AA Part No. 501687 for
lubrication of tilt lock pivot stop pin.
• Loctite® ODC-Free Cleaner & Degreaser
(McMaster-Carr Part No. 66415A21) or
equivalent fast drying, no residue cleaner.
• Loctite® 7471™ Primer N™ Part No. 544434-2.
• Loctite® 242™ Part No. 520228.
F35496 (August 2009)
Page 3 of 28

ELECTRIC COUNTER TOP TILTING KETTLES - GENERAL
SPECIFICATIONS
Reservoir Jacket Fluid
• Water - Use only distilled water for partial re-filling of the jacket (purchase locally).
• Dowfrost heat transfer fluid Part No. 558038 (5 gallon). Use during a complete re-fill of the jacket with new
fluid. Refer to service procedures for volumes.
Electric
The kettle models listed in this manual, with exception of 480V steamers, are shipped pre-wired for 208/60/3
operation. Kettle heating element wiring change is required if connecting to 208/60/1, 240/60/1 or 240/60/3
electrical service.
ELECTRICAL SPECIFICATIONS
Volts Phase
K6ETT*K12ETT K20ETT
Total
KW Amps Total KW Amps Total KW Amps
208 1 7.50 36 12 58 12 58
240 1 10.0 42 16 67 16 67
208 3 7.5 22 12 33 12 33
240 3 10.0 26 16 39 16 39
480 3 7.50 9 12 14 12 14
*K6ETT only - Heating elements on 208/240VAC three phase machines are
not wired as a balanced load.
F35496 (August 2009) Page 4 of 28

ELECTRIC COUNTER TOP TILTING KETTLES - REMOVAL AND REPLACEMENT OF PARTS
REMOVAL AND REPLACEMENT OF PARTS
COVERS AND PANELS
Control Box Cover
Bottom Cover
ELECTRICAL PANEL
COMPONENTS - WATER LEVEL
CONTROL, TRANSFORMER,
CONTACTORS AND
TEMPERATURE CONTROL
1. Remove CONTROL BOX COVER.
2. Disconnect lead wires from component being
replaced.
3. Remove screws securing the component to
panel.
4. Reverse procedure to install and check for
proper operation.
F35496 (August 2009)Page 5 of 28

ELECTRIC COUNTER TOP TILTING KETTLES - REMOVAL AND REPLACEMENT OF PARTS
BOTTOM COMPONENTS -
WATER LEVEL PROBE (LLCO),
TEMPERATURE SENSOR AND
PRESSURE SWITCH
1. Open pressure relief valve until reservoir jacket
is completely vented.
2. Remove BOTTOM COVER.
3. Disconnect lead wires from component being
replaced.
4. If removing pressure switch:
A. Disconnect compression fitting from elbow
near the pressure switch.
B. Remove top nut on brass fitting to remove
pressure switch from mounting bracket.
5. Remove component from bottom of kettle.
6. Reverse procedure to install.
7. Remove air from reservoir jacket as outlined
under VENTING procedure.
8. Check for proper operation.
NOTE: Pressure switch setting is fixed and should
not be adjusted. Clean threads and apply pipe thread
sealant when replacing pressure switch, water level
probe or temperature sensor.
POTENTIOMETER
1. Remove CONTROL BOX COVER.
2. Disconnect potentiometer wire from
temperature control.
3. Pull temperature dial from potentiometer shaft
and remove seal nut.
4. Remove potentiometer from control panel.
5. Reverse procedure to install and check for
proper operation.
NOTE: When installing, ensure potentiometer
alignment tab is seated in positioning bracket.
F35496 (August 2009) Page 6 of 28

ELECTRIC COUNTER TOP TILTING KETTLES - REMOVAL AND REPLACEMENT OF PARTS
HEATING ELEMENT
1. Open pressure relief valve until reservoir jacket
is completely vented.
2. Tilt kettle to expose the heater access cover.
3. Remove three screws where indicated. Loosen
remaining screw and allow cover to rotate out of
way.
4. Note lead wire locations and disconnect wires
from heating element.
5. Remove mounting bolts securing heating
element to kettle.
6. Reverse procedure to install. Use a new heating
element seal whenever installing heating
element. Torque mounting bolts to 40 ft-lbs and
tighten in an alternating pattern.
7. Remove air from reservoir jacket as outlined
under VENTING.
8. Check for proper operation and leaks around
heating element.
NOTE: On K6ETT only, element lengths are
staggered to fit the contour of the kettle bottom.
Install with the shortest element toward the bottom of
kettle.
F35496 (August 2009)Page 7 of 28

ELECTRIC COUNTER TOP TILTING KETTLES - REMOVAL AND REPLACEMENT OF PARTS
KETTLE ASSEMBLY
Removal
1. Place kettle in full upright position.
2. Support kettle using 2x4 blocks of wood.
3. Remove CONTROL BOX COVER.
4. Disconnect thermocouple lead wires from
temperature control and the 4 pin wiring
harness connector.
5. Note lead wire locations and disconnect from
load side of contactors.
6. Remove wire tie securing lead wire bundle to
control box.
7. Remove three set screws on pivot stop collar.
Access third screw thru the slot in top of control
box.
8. Remove outer bearing from support shaft.
9. On K20ETT only.
A. Remove two bolts securing kettle tilt stop
to base.
B. Remove kettle support cover.
F35496 (August 2009) Page 8 of 28

ELECTRIC COUNTER TOP TILTING KETTLES - REMOVAL AND REPLACEMENT OF PARTS
C. Remove kettle support and bearing
housing assembly from support shaft.
10. Pull kettle assembly away from control box to
disengage support shaft from inner bearing and
pivot stop collar. Slide kettle onto the 2x4
blocks.
A. Pull lead wire bundle thru inner bearing
and pivot stop collar during removal.
NOTE: If support shaft of kettle assembly does
not easily disengage, apply force between
control box housing and kettle assembly to
release pivot stop collar. The support shaft
should slide out of inner bearing easily.
11. If re-installing kettle assembly, proceed to
Installation in this section. If installing a
replacement kettle assembly, remove
components as outlined below from old kettle
assembly for re-use.
A. Open pressure relief valve until reservoir
jacket is completely vented.
B. Place kettle on floor with the pressure relief
valve and reservoir jacket fill elbow facing
up.
C. Remove BOTTOM COVER.
D. Remove WATER LEVEL PROBE.
E. Position kettle assembly to drain fluid into
container. Remove 1/2" pipe plug from the
reservoir jacket fill elbow to facilitate
draining.
F. Remove TEMPERATURE SENSOR AND
PRESSURE SWITCH including
condensate coil.
G. Remove pressure relief valve assembly
plumbing and reservoir jacket fill elbow.
H. Remove HEATING ELEMENT.
I. Install all removed components onto
replacement kettle. Clean threads and
apply sealant before re-installing pipe
fittings.
Installation
NOTE: Bearings and shaft seal are self aligning for
easy installation. Bearings do not require lubrication.
1. Place kettle assembly on 2x4 blocks and align
support shaft to shaft seal. Pull lead wire bundle
thru shaft seal and inner bearing.
2. Push kettle assembly support shaft thru shaft
seal and inner bearing.
F35496 (August 2009)Page 9 of 28

ELECTRIC COUNTER TOP TILTING KETTLES - REMOVAL AND REPLACEMENT OF PARTS
3. Square the kettle assembly to control box
housing. Maintain squareness during
adjustments.
4. On K6ETT and K12ETT only.
A. Ensure the pour stop pin on kettle
assembly engages with tilt stop on control
box housing. Approximately 3/16" spacing
should be maintained between the pour
stop pin and control box housing. Adjust
kettle assembly position as necessary.
NOTE: The kettle assembly may drop slightly
after 2x4 blocks are removed and when fully
loaded. The spacing of pour stop pin will
prevent it from rubbing the control box during
tilt.
5. Insert lead wire bundle thru pivot stop collar.
Position pivot stop collar as shown in the picture
below. Set screws should remain out of collar.
A. Slide pivot stop collar onto support shaft.
Operate tilt lock then slide collar against
inner bearing. Hold the collar in position
and release tilt lock. Verify pivot stop pin
fully engages with the slot in pivot stop
collar for the tilt lock as shown. Adjust
kettle assembly position as necessary.
NOTE: The pin location shown will lock the
kettle fully upright. When the kettle is tilted, the
pin engages with the slot near the top to lock
the kettle in position.
6. Insert lead wire bundle thru the outer bearing.
Slide bearing onto support shaft and position it
against pivot stop collar. Install bolts and tighten
to secure the bearing.
7. Apply Lubriplate 630-AA to mating surfaces on
pivot stop pin. Ensure pivot stop pin fully
engages with the slot in pivot stop collar and
does not catch or bind when tilt lock is operated.
8. Clean threads (screw & hole) with cleaner &
degreaser. Apply Loctite 7471 Primer N and
Threadlocker 242 to set screws and threaded
holes on pivot stop collar.
F35496 (August 2009) Page 10 of 28

ELECTRIC COUNTER TOP TILTING KETTLES - REMOVAL AND REPLACEMENT OF PARTS
NOTE: Allow cleaner to fully evaporate before
applying primer. Spay primer on the threads and
allow to dry for 60 seconds. Shake Loctite 242 bottle
thoroughly to mix then apply several drops of the
threadlocker to threads. Do not allow the tip of bottle
to touch a primed surface as it will activate the
Loctite 242 in the bottle.
9. Install set screws on pivot stop collar. Hold the
collar against inner bearing and tighten set
screws to secure.
10. On K20ETT only.
A. Install kettle support to shaft and base.
B. Install kettle support cover and tilt stop to
base.
11. Remove 2x4 blocks from underneath kettle
assembly.
A. With kettle in full vertical position, verify tilt
lock operation. The pivot stop pin should
engage with the slot in pivot stop collar and
not catch or bind when operated.
B. Tilt kettle to horizontal position and verify
pivot stop pin engages with the next slot in
pivot stop collar.
C. Return kettle to full vertical position. Verify
the kettle pour stop pin engages properly
to prevent backwards tilt.
D. Tilt kettle and verify pour stop pin does not
rub against control box housing.
12. Connect lead wires to contactors and
temperature control then connect 4 pin wiring
harness.
13. Secure lead wire bundle to control box with wire
tie then install cover.
14. If re-installing kettle assembly, verify the
reservoir jacket is maintaining a vacuum as
outlined under VENTING. If a replacement
kettle assembly was installed, fill the reservoir
jacket as outlined under FILLING THE
RESERVOIR JACKET.
15. Connect power to machine and check for proper
operation.
BEARINGS
1. Remove KETTLE ASSEMBLY (procedure
includes outer bearing removal).
2. Remove inner bearing from control box housing.
3. On K20ETT Only.
A. Remove bearing housing assembly from
kettle support.
4. Install replacement bearing.
5. Install KETTLE ASSEMBLY.
F35496 (August 2009)Page 11 of 28

ELECTRIC COUNTER TOP TILTING KETTLES - REMOVAL AND REPLACEMENT OF PARTS
SHAFT SEAL
All Models
1. To access shaft seal between kettle and control
box housing, remove KETTLE ASSEMBLY.
2. Remove shaft seal from control box housing.
3. Clean mounting surface on control box housing
then install replacement shaft seal.
4. Install KETTLE ASSEMBLY.
K20ETT only
1. Support kettle using 2x4 blocks of wood.
2. Remove kettle support cover.
3. Remove kettle support and bearing housing
assembly from support shaft.
4. Remove shaft seal from kettle support.
5. Clean mounting surface on kettle support then
install replacement shaft seal.
F35496 (August 2009) Page 12 of 28

ELECTRIC COUNTER TOP TILTING KETTLES - REMOVAL AND REPLACEMENT OF PARTS
6. Reverse procedure to complete the installation
and check for proper operation.
PIVOT STOP PIN
1. Remove CONTROL BOX COVER.
2. Remove retaining ring from pivot stop pin.
3. Reverse procedure to install.
NOTE: When installing, apply Lubriplate 630-AA to
mating surfaces on pivot stop pin. Ensure pivot stop
pin fully engages with the slot in pivot stop collar and
does not catch or bind when tilt lock is operated. The
picture below is shown with outer bearing removed
for clarity.
K20ETT WITH SHAFT SEAL INSTALLED
F35496 (August 2009)Page 13 of 28

ELECTRIC COUNTER TOP TILTING KETTLES - SERVICE PROCEDURES AND ADJUSTMENTS
SERVICE PROCEDURES AND ADJUSTMENTS
TEMPERATURE CONTROLLER
TEST
1. Place kettle in full upright position.
2. Set temperature dial to lowest setting. Kettle
must be below 110°F before verifying the
potentiometer output to the controller is good
over the full range of temperature dial travel.
3. Access the temperature controller as outlined in
REMOVAL AND REPLACEMENT OF PARTS.
4. Check all lead wires for secure connections to
the controller terminals. Wiring harness lead
wires must be connected to T1-T2 and T3-T4
for proper input to controller.
5. Re-connect power to the machine.
6. Turn power switch on.
7. Verify temperature controller is receiving
120VAC at terminals T1-T2 and T3-T4 and
machine is properly grounded.
8. Slowly turn temperature dial to the highest
setting and monitor heat light over the full range
of travel.
A. Verify heat light (amber) comes on and
heating element is energized.
B. If heat light does not remain on or flashes
momentarily as temperature setting is
slowly increased, verify condition of
potentiometer as outlined under
POTENTIOMETER TEST.
NOTE: Temperature controller will de-energize
internal relay and turn off the output status LED if the
circuitry detects an open thermocouple. LED will
begin to flash 3 times, pause, then repeat the flash
sequence to indicate the open thermocouple
condition.
C. If heat light and heating element do not
turn on.
1) Verify condition of thermocouple as
outlined under THERMOCOUPLE
TEST.
2) Verify output from terminal T8 on
controller as outlined in the steps
below.
9. Disconnect lead wire from terminal T7 on the
controller.
A. Verify 120VAC between lead wire from T7
and X1 on the output of main transformer.
If correct, re-connect lead wire to terminal
T7 and continue with procedure.
B. If incorrect, check pressure switch (1PS)
and water level controller (WLC LLCO).
10. Verify 120VAC between T8 and X1 on the
output of main transformer. If correct, output
from controller is functioning properly.
A. If incorrect, install a replacement
temperature controller and check for
proper operation.
F35496 (August 2009) Page 14 of 28

ELECTRIC COUNTER TOP TILTING KETTLES - SERVICE PROCEDURES AND ADJUSTMENTS
POTENTIOMETER TEST
1. Remove potentiometer from control panel as
outlined in REMOVAL AND REPLACEMENT
OF PARTS.
2. Turn potentiometer shaft fully counterclockwise
to the lowest setting.
3. Set VOM to measure resistance.
4. Connect meter leads to the white and black lead
wires on potentiometer terminals.
A. Resistance should measure approximately
zero ohms.
5. Slowly turn potentiometer shaft clockwise over
the full range of travel and monitor resistance
change on the meter.
A. Resistance should measure 800 to 1200
ohms with shaft turned fully clockwise.
B. If the resistance value increased smoothly
without sudden drops or spikes and the full
travel resistance value is within tolerance
then potentiometer is functioning properly.
C. If the resistance value did not increase
smoothly but had drops or spikes over the
full travel range then potentiometer is not
functioning properly. Install a replacement
potentiometer and check for proper
operation.
THERMOCOUPLE TEST
1. Access the temperature controller as outlined in
REMOVAL AND REPLACEMENT OF PARTS.
2. Remove thermocouple lead wires from
temperature controller.
3. Check the thermocouple for a measurable
resistance (approximately 5 to 10 ohms at room
temperature). If meter reads an overload (OL)
condition (open), or zero ohms (short) replace
the thermocouple and check temperature
controller for proper operation.
F35496 (August 2009)Page 15 of 28

ELECTRIC COUNTER TOP TILTING KETTLES - SERVICE PROCEDURES AND ADJUSTMENTS
HEATING ELEMENTS
1. Access heating element as outlined in REMOVAL AND REPLACEMENT OF PARTS.
2. Measure voltage at heating element terminals and verify it against the data plate voltage.
A. If voltage is incorrect, find the source of the problem.
3. If voltage is correct, check current draw (amps) through the heating element lead wires. If current draw is
correct then heating element is ok. See table below for proper values.
NOTE: Checking current draw is the preferred method over a resistance check when an amp clamp meter is
available.
A. If current draw is not correct then, replace heating element.
4. Check for proper operation.
MODEL VOLTAGE ELEMENT NO. KW PER
ELEMENT
CURRENT PER
ELEMENT RESISTANCE PER
ELEMENT (OHMS)
K6ETT
2081, 2 1 2.2 10.5 19.8
2 2.6 12.3 17.0
3 2.8 13.3 15.6
2401, 2 1 2.9 12.1 19.8
2 3.4 14.1 17.0
3 3.7 15.3 15.6
4803- 2.5 9.0 30.7
K12ETT
and
K20ETT
2081- 4.0 19.2 10.8
2401- 5.3 22.2 10.8
4802- 4.0 14.4 19.2
1Dual voltage elements.
2Element lengths are staggered to fit the contour of the kettle bottom. Element number 1 is the
shortest.
3480V elements are connected in Wye configuration for 277V across each element.
NOTE: Values in table are nominal. Tolerance is ±10 %.
F35496 (August 2009) Page 16 of 28

ELECTRIC COUNTER TOP TILTING KETTLES - SERVICE PROCEDURES AND ADJUSTMENTS
VENTING
NOTE: This procedure outlines venting the reservoir
jacket to remove air for proper heat transfer to the
kettle contents.
1. With the kettle at room temperature, verify
pressure gauge is in the vacuum zone and
reading 25 to 30 in. Hg.
A. If vacuum is below minimum listed, air
must be removed from reservoir jacket.
Continue with procedure to vent as
necessary.
2. Place kettle in full upright position.
3. Turn power switch on.
4. Set temperature dial to highest setting. Allow
kettle to heat until the heat indicator light turns
off.
5. Open pressure relief valve for approximately 10
seconds.
6. Turn power switch off and allow kettle to cool
(room temperature).
7. Verify pressure gauge reading is within the
correct vacuum range.
A. If reading is below minimum listed or will
not maintain proper vacuum, check all
threaded fittings extending from the kettle
couplings (right and rear) for leaks and
tightness.
1) Check pressure relief valve for leaks
from poor valve seating or built up
debris. Manually operate the valve
several times to reseat. Repeat
venting procedure.
2) If pressure relief valve is
malfunctioning, install a replacement
and check for proper operation.
FILLING THE RESERVOIR
JACKET
NOTE: The reservoir water level must be maintained
high enough to submerge the heating element. If low
water light comes on during use, the level may be
below water level probe (LLCO) and must be
replenished before heating can continue. The low
water light will come on when kettle is tilted.
When filling reservoir jacket, use only
distilled water.
Partial Refill
1. Place kettle in full upright position.
2. Turn power switch on. If low water light is on,
continue with procedure.
3. Set temperature dial to lowest setting.
4. Open pressure relief valve until reservoir jacket
is completely vented.
5. Remove 1/2" pipe plug from the reservoir jacket
fill elbow at back of kettle.
A. Insert funnel into the opening and slowly
add water until low water light turns off
(LLCO probe is satisfied).
B. Turn power switch off.
C. Continue adding water to bring fluid to the
proper operating level per the amount
listed in table below.
Model Add Water for Proper
Operating Level (Qt)
K6ETT 0.5
K12ETT 1.6
K20ETT 2.25
6. Clean pipe plug threads and apply thread
sealant. Install pipe plug and tighten to prevent
leaks.
7. Turn power switch on and verify low water light
is off. If low water light is on, there may be a
problem with the water level control circuit. See
troubleshooting.
8. Remove air from reservoir jacket as outlined
under VENTING.
9. Check kettle for proper operation.
F35496 (August 2009)Page 17 of 28

ELECTRIC COUNTER TOP TILTING KETTLES - SERVICE PROCEDURES AND ADJUSTMENTS
Complete Draining and Refill
NOTE: Appearance of fluid will no longer be clear
after usage in kettle.
1. Turn power switch off and set temperature dial
to lowest setting.
2. Open pressure relief valve until reservoir jacket
is completely vented.
3. Remove bottom cover as outlined under
COVERS AND PANELS.
4. Remove water level probe (LLCO) from kettle
as outlined in REMOVAL AND REPLACEMENT
OF PARTS.
5. Place kettle in full upright position and allow
fluid to drain into container. Remove 1/2" pipe
plug from reservoir jacket fill elbow (rear of
kettle) to facilitate draining and provide opening
for re-fill.
NOTE: Clean threads and apply sealant before re-
installing pipe fittings.
6. Tilt kettle and re-install water level probe.
7. To Refill.
A. Place kettle in full upright position.
B. Remove pressure gauge to allow reservoir
jacket to vent during fill procedure.
C. Insert funnel into the reservoir jacket fill
elbow. Slowly fill the jacket according to
the volumes listed in the table below.
RESERVOIR JACKET VOLUME
Model Total Fluid
Volume (Qt) Water (Qt) Heat Transfer Fluid (Qt)
K6ETT 4.0 3.0 1.0
K12ETT 7.2 5.4 1.8
K20ETT 8.0 6.0 2.0
8. Install pipe plug and pressure gauge. Tighten to
prevent leaks.
9. Turn power switch on and verify low water light
is off. If low water light is on, there may be a
problem with the water level control circuit. See
troubleshooting.
10. Remove air from reservoir jacket as outlined
under VENTING.
11. Check kettle for proper operation and leaks.
12. Install covers.
F35496 (August 2009) Page 18 of 28

ELECTRIC COUNTER TOP TILTING KETTLES - ELECTRICAL OPERATION
ELECTRICAL OPERATION
COMPONENT FUNCTION
WaterLevelControl(WLCLLCO).......... Low water level control. Monitors condition of the WLC LLCO
water level probe. Protects kettle from a low water condition in
the reservoir jacket and removes power from heating circuit
when kettle is tilted.
Probe,WaterLevel (LLCO) .............. Low Level Cut-Off (LLCO) probe connected to WLC (LLCO).
Controls power to heating circuit.
Contactor(1CON)Limiting ............... Connects one side of heating element to power. Energized
whenever WLC (LLCO) coil is energized.
Contactor(2CON)Regulating ............. Connects heating element to power. On constantly when
temperature controller is calling for heat.
Element,Heating ....................... Heats reservoir jacket fluid. The heat in the fluid is then
transferred to kettle.
Fuse,(1FU&2FU)....................... Slow blow 3A fuse. Located on primary side of main transformer
(1T). Protects control circuitry from over-currents.
Switch (1PAS), Pressure ................. Pressure cut-out protection for the reservoir jacket. Range is
between 38 to 42 PSI. Removes power from control circuit if
pressure in the jacket rises above switch setting.
Transformer(1T),Main .................. Step down transformer from line voltage to 120VAC control
circuit voltage.
Switch(1S),Power ..................... Controls 120VAC to kettle control circuit
TemperatureController .................. Cycles power to regulating contactor (2CON) to maintain the set
point temperature. An external set point potentiometer is used
for temperature adjustments.
Lamp(1LT),Power ..................... Amber (AM) colored lamp. On when power switch is on.
Lamp(2LT),LowWater .................. Red (RD) colored lamp. On when water level in the reservoir
jacket drops below water level (LLCO) probe.
Lamp(3LT),Heat ....................... Amber (AM) colored lamp. On when temperature controller is
calling for heat.
F35496 (August 2009)
Page 19 of 28

ELECTRIC COUNTER TOP TILTING KETTLES - ELECTRICAL OPERATION
COMPONENT LOCATION
F35496 (August 2009) Page 20 of 28
