Model 1036C
CHEESEMELTERS
QUARTZ HEATER ELECTRIC CHEESEMELTER
Model 1036W
CHEESEMELTERS Quartz Heater Electric Cheesemelter
SPECIFICATIONS:
Quartz heated, cheesemelter, (counter) (wall mount) Vulcan-Hart
Model No. _________ . Stainless steel front, sides, top and interior.
Insulated with 1" on top and sides. Backs have 1" of insulation
on counter and wall mount models. Rack activated micro switch
power heaters to 100% when product is placed on the rack. Idles
at 25% heat when master power switch is “On” and there is no
product on the rack. Solid state controls with cooling fan. Top
mounted energy efficient quartz heaters snap in for easy instal-
lation. Requires 208 volt or 240 volt single phase.
CSA design certified. NSF listed. U L listed.
MODEL WIDTH SUFFIX
1024 27" C = Counter
1036 361⁄2"
1048 50" W = Wall Mount
STANDARD FEATURES
■Stainless steel top, inside, sides and all fasteners.
■Top, sides, and back are insulated with 1" of insulation.
■Controls are solid state.
■Electrical compartment is fan cooled.
■Inputs are as follows: 1024 models - 2.4 KW
1036 models - 3.6 KW
1048 models - 4.8 KW
■Master switch when “On” causes unit to idle at 25% heat.
■100% power “On” results from placing product on the rack.
■Rack adjustable to any one of four rack positions.
■Clearance to the top from each rack position: Position 1, 2";
Position 2, 31⁄2"; Position 3, 43⁄4"; Position 4, 6".
■Both 1024 and 1036 models have a single “On-Off” switch
and red signal light.
■1048 modelshaveasingle“On-Off” switchwitha red signallight
as well as right and left heater “On” switches and lights.
■Instant “On”, instant “Off” even heating, top quartz heaters.
■Energy efficient snap in heaters for easy installation.
■Available 208 or 240 volt, 1 phase.
■Field wiring connection on left side.
■4' adjustable legs (counter models only).

VULCAN-HART COMPANY, P.O. BOX 696, LOUISVILLE, KY 40201, TEL. [phone]
502-778-2791 QUOTE & ORDER FAX: [phone]
NOTE: In line with its policy to continually improve its products, Vulcan-Hart Company reserves the right to change materials and
specifications without notice.
F-31622 (04-07)
CHEESEMELTERS
QUARTZ HEATER ELECTRIC CHEESEMELTER
(Measurements in parenthesis in millimeters)
*Leave 3" clearance on the left side for fan air movement.
Rack Sizes: (1024) 20" x 131/2", (1036) 30" x 131/2", (1048) 42" x 131/2".
Interior Dimensions: 91/2" high, 141/4" deep. Width (1024) 21", (1036) 31", (1048) 44".
A B
Model inches mm inches mm
1024 27" 686 25" 635
1036 361⁄2" 927 341⁄2" 876
1048 50" 1270 48" 1219
