GE lp33 20 series User manual

Critical Power
Installation Guide
Uninterruptible Power Supply
GE Consumer & Industrial SA
General Electric Company
CH –6595 Riazzino (Locarno)
Switzerland
T +41 (0)91 / 850 51 51
F +41 (0)91 / 850 52 52
www.gecriticalpower.com
imagination at work
LPS33U_020-030_S2_UPS_GE_01

Critical Power
Modifications reserved
Page 2/43
GE_UPS_ISG_LPS_3UL_20K_30K_2US_V010.docx
Installation Guide LP33 Series 20 & 30 UL S2
Model:
LP33 Series 20 & 30 UL S2
Issued by:
Product Document Department –Riazzino - CH
Approved by:
R & D Department –Riazzino - CH
Date of issue:
04/22/2016
File name:
GE_UPS_ISG_LPS_3UL_20K_30K_2US_V010
Revision:
1.0
Identification No.:
1024203
Up-dating
Revision
Concerns
Date
COPYRIGHT © 2016 by GE Critical Power
All rights reserved.
The information contained in this publication is intended solely for the purposes indicated.
The present publication and any other documentation supplied with the UPS system is not to be
reproduced, either in part or in its entirety, without the prior written consent of GE.
The illustrations and plans describing the equipment are intended as general reference only and are
not necessarily complete in every detail.
The content of this publication may be subject to modification without prior notice.

Critical Power
Modifications reserved
Page 3/43
GE_UPS_ISG_LPS_3UL_20K_30K_2US_V010.docx
Installation Guide LP33 Series 20 & 30 UL S2
Dear Customer,
We thank you for selecting our products and are
pleased to count you amongst our very valued
customers at GE.
We trust that the use of the LP33 Series 20 & 30
Uninterruptible Power Supply system, developed
and produced to the highest standards of
quality, will give you complete satisfaction.
Please read carefully the Installation Guide,
which contains all the necessary information and
describes all you need to know about the
installation of the UPS.
Thank you for choosing GE !
START-UP AND COMMISSIONING
A GE Critical Power Field Services Engineer must perform start-up and
commissioning of the UPS.
Please Contact GE Services at least two weeks prior to schedule start-up and
commissioning at 1-800-637-1738, or by E-mail at 1H[email protected].
Distributed in the USA by:
Your service contact:
g
GE Consumer & Industrial SA
General Electric Company
CH –6595 Riazzino (Locarno)
Switzerland
www.gecriticalpower.com
g
GE Energy Connections
Critical Power
3100 Technology –Suite 200
Plano, TX 75074
T: [phone]
E: [email protected]
www.geindustrial.com/products/
critical-power
g
GE Energy Connections
Critical Power
601 Shiloh Road
Plano, TX 75074
24/7 T: [phone]
24/7 F: [phone]
E: [email protected]

Critical Power
Modifications reserved
Page 4/43
GE_UPS_ISG_LPS_3UL_20K_30K_2US_V010.docx
Installation Guide LP33 Series 20 & 30 UL S2
Preface
Congratulations on your choice of a LP33 Series 20 & 30 Uninterruptible Power Supply
(UPS).
It will help eliminate load disturbances due to unexpected power problem.
This Installation Guide describes how to prepare the installation site, and it provides
weight and dimensions and procedures for moving, installing and connecting the UPS.
While every care has been taken to ensure the completeness and accuracy of this manual,
GE assumes no responsibility or liability for any losses or damages resulting from the use
of the information contained in this document.
WARNING !
LP33 Series 20 & 30 is a product that needs to be installed by a licensed and
knowledgeable contractor.
We recommend that this manual be kept next to the UPS for future references.
If any problems are encountered with the procedures contained in this manual, please
contact your Service Center before you proceed.
This document shall not be copied or reproduced without the permission of GE.
Some of the information contained in this manual may be changed without notice to
reflect technical improvements.
Safety instructions
Read the safety instructions contained on the following pages carefully before the
installation of the UPS, options and battery system.
Pay attention to the rectangular boxes included in the text:
They contain important information and warning concerning electrical connections and
personnel safety.
Parallel version secured with RPA
When included in the text, this symbol refers to operation needed
only for Parallel System.

Critical Power
Modifications reserved
Page 5/43
GE_UPS_ISG_LPS_3UL_20K_30K_2US_V010.docx
Installation Guide LP33 Series 20 & 30 UL S2
Table of contents Page
1SAFETY RULES ................................................................................................................................................. 6
2LAYOUT........................................................................................................................................................... 10
2.1 LAYOUT LP33 SERIES 20 & 30................................................................................................................................................................10
3ENVIRONMENT.............................................................................................................................................. 11
3.1 RECYCLING INSTRUCTIONS.....................................................................................................................................................................11
4INSTALLATION............................................................................................................................................... 12
4.1 TRANSPORT.....................................................................................................................................................................................................12
4.1.1 Dimensions and weights .......................................................................................................................................................................... 13
4.2 DELIVERY ..........................................................................................................................................................................................................14
4.3 STORAGE ..........................................................................................................................................................................................................14
4.3.1 Storage of the UPS ...................................................................................................................................................................................... 14
4.3.2 Storage of the battery ............................................................................................................................................................................... 14
4.4 PLACE OF INSTALLATION .........................................................................................................................................................................15
4.5 VENTILATION AND COOLING .................................................................................................................................................................18
4.6 UNPACKING ....................................................................................................................................................................................................18
4.7 ELECTRICAL WIRING...................................................................................................................................................................................21
4.7.1 Utility input connection ............................................................................................................................................................................. 21
4.7.2 Input/output over current protection and wire sizing................................................................................................................. 22
4.7.3 Battery over current protection and wire sizing............................................................................................................................ 23
4.7.4 General data table for current protection and wire sizing........................................................................................................ 24
4.8 WIRING CONNECTION...............................................................................................................................................................................27
4.8.1 Power connections...................................................................................................................................................................................... 27
4.9 ELECTRICAL CONNECTIONS....................................................................................................................................................................29
4.9.1 Common input utility.................................................................................................................................................................................. 29
4.9.2 Dual input utility (option)........................................................................................................................................................................... 30
4.9.3 Battery connection...................................................................................................................................................................................... 31
4.9.4 RPA Parallel System - Control bus connection ............................................................................................................................... 32
4.9.5 UPS functioning as frequency converter .......................................................................................................................................... 34
5CUSTOMER INTERFACE................................................................................................................................ 35
5.1 SERIAL PORT J27 - RS232 ........................................................................................................................................................................36
5.2 RELAY CARD....................................................................................................................................................................................................37
5.3 EPO (EMERGENCY POWER OFF)............................................................................................................................................................38
5.4 CUSTOMER INTERFACE BOARD (OPTION) ........................................................................................................................................39
6OPTIONS......................................................................................................................................................... 42
6.1 TOP ENTRY CABLES CABINET.................................................................................................................................................................42
7NOTES............................................................................................................................................................. 43
7.1 NOTES FORM ..................................................................................................................................................................................................43

Critical Power
Modifications reserved
Page 6/43
GE_UPS_ISG_LPS_3UL_20K_30K_2US_V010.docx
Installation Guide LP33 Series 20 & 30 UL S2
1SAFETY RULES
With this document, GE gives to the user all the necessary information about the correct use of the UPS.
Please read carefully this Installation Guide before installing the UPS.
We recommend that this manual be kept next to the UPS for future references.
If any problems are encountered with the procedures contained in this manual, please contact the
nearest Service Center before you proceed.
All UPS installation, maintenance and service work should be performed by QUALIFIED SERVICE
PERSONNEL only.
The KNOWLEDGE and the FULL compliance of the safety instructions and
warnings contained in this manual are
THE ONLY CONDITION
to avoid any dangerous situations during installation, operation,
maintenance work, and to preserve the maximum reliability of the UPS
system.
NOTE !
LP33 Series 20 & 30 is an FCC Class A-UPS Product.
While every care has been taken to ensure the completeness
and accuracy of this manual, GE assumes no responsibility or
liability for any losses or damages resulting from the use of the
information contained in this document.
GE
Refuses any responsibility in case of non-observance,
unauthorized alterations or improper use of the delivered UPS.

Critical Power
Modifications reserved
Page 7/43
GE_UPS_ISG_LPS_3UL_20K_30K_2US_V010.docx
Installation Guide LP33 Series 20 & 30 UL S2
IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS
This manual contains important instructions for UPS LP33 Series 20 & 30 that should be
followed during installation and maintenance of the UPS and battery.
GENERAL
- Move the UPS in an upright position in its original package to the final destination room.
To lift the cabinets, use a forklift or lifting belts with spreader bars.
- Check for sufficient floor and elevator loading capacity.
- Check the integrity of the UPS equipment carefully.
If you notice visible damage, do not install or start the UPS.
Contact the nearest Service Center immediately.
- WARNING! RISK OF ELECTRICAL SHOCK:
Do not remove covers, there are no user serviceable parts inside.
- After switching off takes 5 minutes for the DC capacitors to discharge because a lethally high voltage
remains at the terminals of the electrolytic capacitors.
- UPS’s and battery system require a 12 months periodic maintenance to operate reliably and safely.
This should be performed by qualified service personnel.
The UPS contains its own energy source (battery).
- The field-wiring outlets may be electrically live, even when the UPS is disconnected from the utility.
- Dangerous voltages may be present during battery operation.
- The battery must be disconnected during maintenance or service work.
- This UPS contains potentially hazardous voltages.
- Be aware that the inverter can restart automatically after the utility voltage is restored.
- End user must follow applicable regional occupational safety codes/regulations during installation,
operation and equipment maintenance. This may require additional field marking or labeling defining
appropriate level of PPE (Personal Protection Equipment) to reduce the risk of Arc-flash related injuries.
Contact our Technical Support for product specific information.
INSTALLATION
- This UPS must be installed and connected only by trained personnel.
- Verify accurately during Commissioning and Maintenance of the UPS, for the following:
Damaged components, squeezed wires and cables, or not correctly inserted plugs.
- After removing the sidewalls of the UPS, make sure that all earth connections when reassembling, are
correctly reattached.
- This UPS is intended for use in a controlled indoor environment free of conductive contaminants and
protected against animals intrusion.
- WARNING! HIGH EARTH LEAKAGE CURRENT:
Earth connection is essential before connecting to AC input!
- Switching OFF the unit does not isolate the UPS from the utility.
- Do not install the UPS in an excessively humid environment or near water.
- Avoid spilling liquids on or dropping any foreign object into the UPS.
- The unit must be placed in a sufficiently ventilated area; the ambient temperature should not exceed 104F
(40°C).
- Optimal battery life is obtained if the ambient temperature does not exceed 77°F (25C).
- It is important that air can move freely around and through the unit. Do not block the air vents.
- Avoid locations in direct sunlight or near heat sources.
STORAGE
-Store the UPS in a dry location; storage temperature must be within -13°F (-25°C) to 131°F (+55C).
-The optimal temperature for Battery storage is 68°F (20°C) to 77°F (25°C) and shall never exceed the range -
4°F (-20°C) to 104°F (40°C).
- If the unit is stored for a period exceeding 3 months, the battery must be recharged periodically (time
depending on storage temperature).
BATTERY
- The battery-voltage is dangerous for person’s safety.
- When replacing the battery, use the same cells number, voltage (V), capacity (Ah).
All the battery used, shall be of the same manufacturer and date of production.
- Proper disposal or recycling of the battery is required.
Refer to your local codes for disposal requirements.
- Never dispose of battery in a fire: they may explode.
- Do not open or mutilate battery: their contents (electrolyte) may be extremely toxic.
If exposed to electrolyte, wash immediately with plenty of water.
- Avoid charging in a sealed container.
- Never short-circuit the batteries.
When working with batteries, remove watches, rings or other metal objects, and only use insulated tools.
- In case of air shipment, the cables +/- going to the battery fuses/terminals shall be disconnected and isolated.

Critical Power
Modifications reserved
Page 8/43
GE_UPS_ISG_LPS_3UL_20K_30K_2US_V010.docx
Installation Guide LP33 Series 20 & 30 UL S2
Safety instructions when working with battery
THE BATTERY MUST BE INSTALLED AND CONNECTED TO THE UPS BY QUALIFIED
SERVICE PERSONNEL.
INSTALLATION PERSONNEL MUST READ THIS ENTIRE SECTION AND REFER TO THE
BATTERY MANUFACTURERS INSTALLATION MANUAL BEFORE HANDLING THE UPS
AND BATTERY.
DANGER!
Full voltage and current are always present at the Battery Terminals.
The Battery used in this system can provide dangerous voltages, extremely high currents and a risk of
electric shock.
They may cause severe injury if the terminals are shorted together or to ground.
You must be extremely careful to avoid electric shock and burns caused by contacting Battery Terminals
or shorting terminals during battery installation.
Do not touch un-insulated Battery Terminals.
A qualified service person that is familiar with Battery systems and required precautions must install
and service the Battery.
The installation must conform to national and local codes.
Keep unauthorized personnel away from Battery.
The qualified service person must take these precautions:
1Wear protective clothing, such as rubber gloves and boots and protective eye wear.
Batteries contain caustic acids and toxic materials and can rupture or leak if mistreated.
Remove rings and metal wristwatches or other metal objects and jewelry.
Do not carry metal objects in your pockets where the objects can fall into the Battery Cabinet.
2Tools must have insulated handles and must be insulated so that they will not short Battery
Terminals.
Do not allow a tool to short between individual or separate Battery Terminals or to the cabinet or
rack.
Do not lay tools or metal parts on top of the Battery, and do not lay them where they could fall onto
the Battery or into the cabinet.
3Install the Battery as shown on the drawing provided with the Battery.
When connecting cables, never allow a cable to short across a Battery’s Terminals, the string of
batteries, or to the cabinet or rack.
4Align the cables on the Battery Terminals so that the cable lug will not contact any part of the
cabinet or rack, even if the Battery is moved.
Keep the cable away from any sharp metal edges.
5Install the Battery Cables so the UPS or Battery Cabinet Doors cannot pinch them.
6Do not connect the Battery Terminal to Ground.
If any Battery Terminal is inadvertently grounded, remove the source of the ground.
Contacting any part of a grounded Battery can cause a risk of electric shock.
7To reduce the risk of fire or electric shock, install the Battery in a temperature and humidity
controlled indoor area, free of contaminants.
8Battery System Chassis Ground (earth) must be connected to the UPS chassis ground (earth).
If you use conduit, this ground conductor must be routed in the same conduit as the Battery
Conductors.
9Where conductors may be exposed to physical damage, protect the conductors in accordance with
all applicable codes.
10 If you are replacing Battery or repairing Battery Connections, shut OFF the UPS and remove the
Battery Fuses or open the Battery System disconnect.

Critical Power
Modifications reserved
Page 9/43
GE_UPS_ISG_LPS_3UL_20K_30K_2US_V010.docx
Installation Guide LP33 Series 20 & 30 UL S2
Safety symbols and warnings
Safety warnings
The text of this manual contains some warnings to avoid risk to personnel and to avoid damage to the
UPS system and the supplied critical loads.
The non-observance of warnings could result in human injury and equipment damages.
Please pay attention to the meaning of the following warnings and symbols.
Throughout this manual the following symbols are defined:
WARNING, if instruction is not followed injury or serious equipment damage may
occur!
CAUTION, internal parts have dangerous voltage present.
Risk of electric shock!
PE (Earth) –GND (Ground)
PROTECTIVE GROUNDING TERMINAL:
A terminal which must be connected to earth ground prior to making any other
connection to the equipment.
A terminal to which or from which an alternating (sine wave) current or voltage
may be applied or supplied.
A terminal to which or from which a direct current or voltage may be applied or
supplied.
This symbol indicates the word “phase”.
This symbol indicates the principal on/off switch in the on position.
This symbol indicates the principal on/off switch in the off position.

Critical Power
Modifications reserved
Page 10/43
GE_UPS_ISG_LPS_3UL_20K_30K_2US_V010.docx
Installation Guide LP33 Series 20 & 30 UL S2
2LAYOUT
2.1 LAYOUT LP33 SERIES 20 & 30
Fig. 2.1-1 General view
Fig. 2.1-2 General view with open door
Fig. 2.1-3 General view without protection panels
1
Opening for input and output of cables
CI
Customer Interface Board (optional)
Q1
UPS output switch
Q2
Manual bypass switch
RC
Relay card
RPA
RPA parallel board (optional)
SNMP
3-ph SNMP/WEB plug-in adapter (option)
X1
Terminals for common mains input connection
(rectifier + bypass)
X2
Terminals in case of dual mains input (optional)
X3
Terminals for load output connection
X4
Terminals for external battery connection
LPS33U_020-030_S2_UPS_GE_01
LPS33U_020-030_S2_UPS_GE_02
Q2 Q1
LPS33U_020-030_S2_UPS_GE_03
SNMP
CI
RS232
RC
SNMP
CI
RS232
RC
Q1
Q2
X1
X4 1X2 X3

Critical Power
Modifications reserved
Page 11/43
GE_UPS_ISG_LPS_3UL_20K_30K_2US_V010.docx
Installation Guide LP33 Series 20 & 30 UL S2
3ENVIRONMENT
3.1 RECYCLING INSTRUCTIONS
NOTE !
This product has been designed to respect the
environment, using materials and components respecting
eco-design rules.
It does not contain CFCs (Carbon Fluor Clorid) or HCFCs
(Halogen Carbon Fluor Clorid).
PACKING MATERIAL RECYCLING
GE, in compliance with environment protection, uses only
environmentally friendly material.
UPS packing materials must be recycled in compliance with
all applicable regulations.
RECYCLING AT THE END OF SERVICE LIFE !
GE, in compliance with environment protection
recommends to the User that the UPS equipment, at the
end of its service life, must be recovered conforming to
the local applicable regulations.
WARNING !
Leads contained in the batteries is a dangerous substance
for the environment, therefore it must be correctly
recycled by specialized companies!

Critical Power
Modifications reserved
Page 12/43
GE_UPS_ISG_LPS_3UL_20K_30K_2US_V010.docx
Installation Guide LP33 Series 20 & 30 UL S2
4INSTALLATION
4.1 TRANSPORT
The UPS is fixed on transport socket suitable for forklift, which includes a special layer of Ethafoam to
protect the equipment against the transport shock.
Normally the UPS is packaged with a carton box.
On request the equipment can be packaged in a wooden crate.
Move the UPS in its original package to the final destination room.
Do not stack other package on top: they could damage the upper side of the cabinet.
NOTE !
When moving the UPS, pay attention to:
Forklift
Crane
Fig. 4.1-1 LP33 Series 30 & 40 lifting
Forklift
The UPS may be lifted with a forklift in upright
position from right and left side.
Take note of the center of gravity marked on
the package.
NOTE !
Check for sufficient floor and elevator
loading capacity.
Transport UPS only in upright position.
Do not stack other package on top of the
UPS.
Crane
If the UPS has to be lifted by crane, use
suitable carrying belts taking note of the
center of gravity marked on the package.
Take all necessary precautions to avoid
damage to the cabinet while hoisting the
UPS
WARNING !
When loading / downloading and when
moving the UPS, it is forbidden:
When loading / downloading and when
moving the UPS, pay attention to:
FRAGILE
SENSITIVE
TO DAMPNESS
TO HEAT
SENSITIVE
TO FROST
SENSITIVE

Critical Power
Modifications reserved
Page 13/43
GE_UPS_ISG_LPS_3UL_20K_30K_2US_V010.docx
Installation Guide LP33 Series 20 & 30 UL S2
4.1.1 Dimensions and weights
Fig. 4.1.1-1 Dimensions LP33 Series 20 & 30
LP33 Series
20 kVA
30 kVA
Dimensions (W x D x H)
23.62” x 29.32” x 75.00”
600 x 745 x 1905 mm
23.62” x 29.32” x 75.00”
600 x 745 x 1905 mm
UPS floor loading
97 lbs/sq.ft / 472 kg/m2
103 lbs/sq.ft / 499 kg/m2
UPS with standard shipping
827 lbs / 375 kg
871 lbs / 395 kg
NOTE !
The weight of each single piece is marked outside the package!
LPS33U_020-030_S2_UPS dimensions_01
0.52"
13.3mm
28.54"
29.32"
725mm
744.8mm
23.62"
600m
75.00"
1905mm
CENTER OF GRAVITY
37.13"
943.1mm
CENTER
OF
GRAVITY
11.8"
300m
13.7"
349m

Critical Power
Modifications reserved
Page 14/43
GE_UPS_ISG_LPS_3UL_20K_30K_2US_V010.docx
Installation Guide LP33 Series 20 & 30 UL S2
4.2 DELIVERY
When delivered, check carefully the package integrity and the physical conditions of the UPS
equipment.
In case of any damage sustained during transport, immediately inform the carrier and contact your
local Service Center.
A detailed report of the damage is necessary for any insurance claim.
NOTE !
A damaged UPS must never be installed or connected to utility or battery!
4.3 STORAGE
The equipment is carefully packed for transport and storage
so that it is in a perfect condition when eventually installed.
Never leave a UPS outside the building and do not store the
UPS one on top of the other.
It is recommended to store the UPS in its original package in a
dry, dust free room and far away from chemical
substances, with temperature not exceeding -13°F to 131°F
(-25°C to 55°C).
4.3.1 Storage of the UPS
Some important functions of the UPS, such as the customized functions, are defined by parameters
stored in a RAM memory.
The RAM is supplied by a small backup battery located on the Control Unit board.
If the storage time of the UPS exceeds 1 year, these functions should be verified by an authorized
Service Center before putting the UPS into operation.
NOTE !
In case of storage of the UPS pay attention to:
4.3.2 Storage of the battery
In case of extended storage, when the delivery includes maintenance free batteries, keep in mind that
they are subject to auto-discharging process
To avoid permanent damages to the battery, you must observe the following instructions:
The storage time without charging the battery depends on the ambient temperature of the storage area.
The optimal ambient temperature for the batteries is 68°F (20°C).
For storage temperature higher than 68°F (20°C), the storage time will decrease.
Each additional 18°F (10°C) over the nominal temperature of 68°F (20°C) will decrease the storage
time, without freshening charge, by half.
In case of a maintenance free battery, the storage time without charging the battery is
approximately:
6 months with storage temperature 68°F (20°C)
3 months with storage temperature 86°F (30°C)
2 months with storage temperature 95°F (35°C)
NOTE !
In case of battery storage pay attention to:
FRAGILE
SENSITIVE
TO DAMPNESS
TO HEAT
SENSITIVE
TO FROST
SENSITIVE
FRAGILE
SENSITIVE
TO DAMPNESS
TO HEAT
SENSITIVE
TO FROST
SENSITIVE

Critical Power
Modifications reserved
Page 15/43
GE_UPS_ISG_LPS_3UL_20K_30K_2US_V010.docx
Installation Guide LP33 Series 20 & 30 UL S2
4.4 PLACE OF INSTALLATION
The UPS should be installed in a restricted area where only qualified personnel should be admitted.
The place of installation should be clean, dust-free, and provided with proper ventilation or air-
conditioning.
Verify for sufficient floor load capacity (see Section 4.1.1).
We strongly advice that the ambient temperature should not exceed 68° - 77°F / 20° - 25°C (max. 104°F
/ 40°C). See Section 4.5.
Positioning of the UPS LP33 Series 20 & 30
Fig. 4.4-1 Positioning LP33 Series 20 & 30
The rear panel of the UPS may be mounted flush to a
wall or other structure.
Clearance around the front of the unit should be
sufficient to enable free passage of personnel with the
doors fully open, and to allow sufficient airflow to the
door vents.
To guarantee proper cooling air exhaust, the
recommended minimum clearance between ceiling
and top of the UPS is 16” (400mm).
Battery cabinets must be placed beside the left side of
the UPS cabinet.
A single-phase power outlet (208Vac) should be
provided near the UPS for connection of power tools,
test equipment or connectivity devices.
This outlet must be grounded.
The LP33 Series 20 & 30 UPS can radiate radio frequency energy.
Although some RFI (Radio Frequency Interference) filtering is inherent to the UPS there is no guarantee that
the UPS will not influence sensitive devices such as cameras and monitors that are positioned close by.
If interference is expected, the UPS should be moved away from the sensitive equipment.
NOTE !
Operating temperature is very important for valve regulated battery (maintenance
free).
Operation at temperatures higher than 68°F (20°C) will reduce life expectancy.
Follow the recommendations of the battery supplier and other local standards.
The installation and cabling of the battery must be done by qualified people.
Min.
16" / 400mm
LPS33U_020-030_S2_UPS disposition_GE_01
Min.
32" / 800mm

Critical Power
Modifications reserved
Page 16/43
GE_UPS_ISG_LPS_3UL_20K_30K_2US_V010.docx
Installation Guide LP33 Series 20 & 30 UL S2
Opening for input and output cable connections LP33 Series 20 & 30
Fig. 4.4-2 Opening on the bottom of the cabinet for input and output cables
LP33 Series 20 & 30 opening is provided on the bottom of the UPS for the connection of input and
output cables.
Pay attention to the position of this opening, when choosing the placement of the UPS.
The UPS cabinet is free standing and normally does not require to be bolted to the floor.
The UPS cabinet can be fixed however to the floor by bolting it to the floor with provided seismic
brackets in the anchor locations show.
Positioning of the UPS cabinet
Fig. 4.4-3 Bolts for stabilizing the cabinet
LP33 Series 20 & 30 is equipped with wheels for
easy placement of the UPS.
To make the UPS movable on wheels, the bolts
on each leg of the cabinet have to be turned
counter-clockwise, until they are free from the
floor and thus the cabinet supported on wheels.
After having positioned the UPS at its final
location, the cabinet has to be secured by
rotating the bolts on each leg clockwise, but the
wheels must still touch the floor.
LPS33U_020-030_S2_UPS view bottom_01
Front ANCHOR LOCATIONS
9.50"
241.3mm
4.25"
107.9mm
18.0"
457.2mm
2.81"
71.4mm
Ø 0.75"
Ø19.05mm
2.00"
50.8mm
2.00"
50.8mm
Ø 0.75"
Ø19.05mm
4.96"
126mm
7.70"
195.5mm
20.16"
512mm
1.73"
44mm
24.56"
623.7mm
4X LIVELLING FEET
ANCHOR LOCATIONS
BOTTOM CABLE ENTRY
AREA 100 SQ IN (64500 SQ mm
ANCHOR LOCATIONS
1.14"
28.9mm
LPS33U_020-030_S2_UPS wheels_GE_01

Critical Power
Modifications reserved
Page 17/43
GE_UPS_ISG_LPS_3UL_20K_30K_2US_V010.docx
Installation Guide LP33 Series 20 & 30 UL S2
Positioning of the LP33 Series 20 & 30 Parallel System
Fig. 4.4-4 RPA Parallel System disposition
In case of Parallel System, try to place the UPS modules in sequence of their
numbers (marked on the packing).
If the units are positioned “side by side”, the side panels must be mounted on
all units.
LPS33U_020-030_S2_RPA disposition_GE_01
1234

Critical Power
Modifications reserved
Page 18/43
GE_UPS_ISG_LPS_3UL_20K_30K_2US_V010.docx
Installation Guide LP33 Series 20 & 30 UL S2
4.5 VENTILATION AND COOLING
The heat produced by the UPS is transferred to the environment by its internal fan(s).
Fig. 4.5-1 Airflow through the LP33 Series 20 & 30
Airflow through the UPS
It is important that the cooling air can freely flow
through the air inlets and outlets of the UPS.
NOTE !
Insufficient distances on both sides of the
UPS could increase the temperature inside
the UPS.
Do not put any object on the top of the
cabinet: it might obstruct the air flow.
Heat evacuation from UPS
room
The heat must be evacuated
from the environment with a
proper cooling / ventilation
system provided by the user.
Fig. 4.5-2 Heat evacuation from UPS room
Air volume and losses of the UPS
The approximate minimum air volume needed to evacuate the heat generated by the UPS, for inlet
temperature max. 35°C (95°F), for the standard version at inverter nominal load with PF = 0.8 lag. and
battery charged, are the following:
UPS model
Losses
Cooling air flow
VFI Mode
ECO Mode
VFI Mode
ECO Mode
LP33 Series 20
6,380 BTU/hr
1.87 kW
1,392 BTU/hr
0.41 kW
324 CFM
550 m3 /h
71 CFM
120 m3 /h
LP33 Series 30
9,656 BTU/hr
2.83 kW
2,088 BTU/hr
0.61 kW
490 CFM
833 m3 /h
106 CFM
180 m3 /h
NOTE !
Even when ECO Mode option is available, the ventilation and cooling system shall be
rated as for operation in VFI mode.

Critical Power
Modifications reserved
Page 19/43
GE_UPS_ISG_LPS_3UL_20K_30K_2US_V010.docx
Installation Guide LP33 Series 20 & 30 UL S2
4.6 UNPACKING
Move the equipment in it’s original packing, carton box or wooden case, until the place of installation
and remove the packing and the transport sockets only just before installing the UPS.
1
Procedure for the unpacking of the UPS:
Make sure to have sufficient space
around the UPS before you start
unpacking.
Cut the two straps “A”fixing the
carton box.
2
Remove package “B and C”.
Remove the protection “D” outside
the cabinet and the accessories bag.
3
Fig. 4.6-1 LP33 Series 20 & 30 unpacking sequence
Use a forklift to raise the UPS from the
floor.
Remove the two wooden plates “E”.
NOTE !
Be aware of the heavy
weight of the UPS, in
particular if already
equipped with
Batteries.
Included in the delivery you can find the following parts:
Control Bus cables (only for RPA Parallel System)
CD-ROM connectivity
An accessories bag
NOTE !
The wheels are designed only for limited movements on the installation site.
LPS33U_030-040_Unpacking_02
GRAVITY
CENTER
of
of
GRAVITY
CENTER
D
UL
C
B
EE
E
LPS33U_030-040_Unpacking_03

Critical Power
Modifications reserved
Page 20/43
GE_UPS_ISG_LPS_3UL_20K_30K_2US_V010.docx
Installation Guide LP33 Series 20 & 30 UL S2
White colour =without any anomaly
Red colour =anomaly evidence
The package of the LP33 Series 20 & 30 is
equipped with ShockWatch (indicator for
shock), and TiltWatch (indicator for
overthrow) on the outside.
These devices indicate an eventual shock
or overthrow during transport.
Whenever these devices show a
possible anomaly, the UPS shall not be
commissioned.
Please contact your “GE Service
Center”.
Fig. 4.6-2 ShockWatch device
Fig. 4.6-3 TiltWatch device
NOTE !
A damaged UPS must never be installed or connected to utility or battery!
In case of any damage sustained during the transport, immediately inform the
shipping agent!
A detailed report of the damage is necessary for any indemnity claim.
PACKING MATERIAL RECYCLING
GE, in compliance with environment protection, use only environmentally
friendly material.
UPS packing materials must be recycled in compliance with all applicable
regulations.
