Wacker Neuson BS 60-4s User manual

0170873en 001 0410
0170873EN
Operator’s Manual
Rammer
BS 60-4s

Copyright
notice
© Copyright 2010 by Wacker Neuson Corporation.
All rights, including copying and distribution rights, are reserved.
This publication may be photocopied by the original purchaser of the machine. Any
other type of reproduction is prohibited without express written permission from
Wacker Neuson Corporation.
Any type of reproduction or distribution not authorized by Wacker Neuson Corporation
represents an infringement of valid copyrights. Violators will be prosecuted.
Trademarks All trademarks referenced in this manual are the property of their respective owners.
Manufacturer Wacker Neuson Corporation
N92W15000 Anthony Avenue
Menomonee Falls, WI 53051 U.S.A.
Tel: [phone] · Fax: [phone] · Tel: [phone]
www.wackerneuson.com
Original
instructions
This Operator’s Manual presents the original instructions. The original language of this
Operator’s Manual is American English.

Foreword
wc_tx001489gb.fm 3
Foreword
Machines
covered by
this manual
Machine
documentation
Keep a copy of the Operator’s Manual with the machine at all times.
Use the separate Parts Book supplied with the machine to order replacement
parts.
Refer to the separate Repair Manual for detailed instructions on servicing and
repairing the machine.
If you are missing any of these documents, please contact Wacker Neuson
Corporation to order a replacement or visit www.wackerneuson.com.
When ordering parts or requesting service information, be prepared to provide
the machine model number, item number, revision number, and serial number.
Expectations
for
information in
this manual
This manual provides information and procedures to safely operate and
maintain the above Wacker Neuson model(s). For your own safety and to
reduce the risk of injury, carefully read, understand, and observe all instructions
described in this manual.
Wacker Neuson Corporation expressly reserves the right to make technical
modifications, even without notice, which improve the performance or safety
standards of its machines.
The information contained in this manual is based on machines manufactured
up until the time of publication. Wacker Neuson Corporation reserves the right
to change any portion of this information without notice.
CALIFORNIA
Proposition
65 Warning
Engine exhaust, some of its constituents, and certain vehicle components, contain
or emit chemicals known to the State of California to cause cancer and birth
defects or other reproductive harm.
Laws
pertaining to
spark
arresters
NOTICE: State Health Safety Codes and Public Resources Codes specify that in
certain locations spark arresters be used on internal combustion engines that use
hydrocarbon fuels. A spark arrester is a device designed to prevent accidental dis-
charge of sparks or flames from the engine exhaust. Spark arresters are qualified
and rated by the United States Forest Service for this purpose. In order to comply
with local laws regarding spark arresters, consult the engine distributor or the local
Health and Safety Administrator.
Manufacturer’s
approval
This manual contains references to approved parts, attachments, and
modifications. The following definitions apply:
Machine Item Number
BS 60-4s 0620073
0620813
0620323
0620387
0620388
0620816
0620819
0620820

Foreword
4 wc_tx001489gb.fm
Approved parts or attachments are those either manufactured or provided by
Wacker Neuson.
Approved modifications are those performed by an authorized Wacker
Neuson service center according to written instructions published by Wacker
Neuson.
Unapproved parts, attachments, and modifications are those that do not
meet the approved criteria.
Unapproved parts, attachments, or modifications may have the following
consequences:
Serious injury hazards to the operator and persons in the work area
Permanent damage to the machine which will not be covered under warranty
Contact your Wacker Neuson dealer immediately if you have questions about
approved or unapproved parts, attachments, or modifications.

BS 60-4s Table of Contents
wc_bo0170873en_001TOC.fm 5
Foreword 3
1 Emission Control System Information 7
2 Safety Information 14
2.1 Signal Words Found in this Manual .................................................... 14
2.2 Machine Description and Intended Use ............................................. 15
2.3 Operating Safety ................................................................................ 16
2.4 Operator Safety while using Internal Combustion Engines ................ 18
2.5 Service Safety .................................................................................... 19
3 Labels 22
3.1 Label Locations .................................................................................. 22
3.2 Label Meanings .................................................................................. 23
4 Lifting and Transporting 27
4.1 Lifting and Transporting the Machine ................................................. 27
5 Operation 28
5.1 Preparing the Machine for First Use ................................................... 28
5.2 Recommended Fuel ........................................................................... 28
5.3 Position of the Operator ..................................................................... 29
5.4 Before Starting ................................................................................... 30
5.5 To Start ............................................................................................... 30
5.6 To Stop ............................................................................................... 31
5.7 Low Oil Shutoff Switch ....................................................................... 32
5.8 Emergency Shutdown Procedure ....................................................... 32

Table of Contents BS 60-4, BS 60-4s
6 wc_bo0170873en_001TOC.fm
6 Maintenance 33
6.1 Periodic Maintenance Schedule ..........................................................33
6.2 Servicing Air Cleaner ...........................................................................34
6.3 Engine Oil ............................................................................................35
6.4 Checking and Changing the Ramming System Oil .............................36
6.5 Shoe Hardware ...................................................................................38
6.6 Long-Term Storage .............................................................................39
7 Basic Troubleshooting 41
8 Tech Data 43
8.1 Rammer ...............................................................................................43
8.2 Sound Measurements .........................................................................44
8.3 Vibration Measurements .....................................................................44
8.4 Dimensions ..........................................................................................45

Emission Control System Information
wc_tx000369gb.fm 7
1 Emission Control System Information
Source of Emissions
The combustion process produces carbon monoxide, oxides of
nitrogen, and hydrocarbons. Control of hydrocarbons and oxides of
nitrogen is very important because, under certain conditions, they
react to form photochemical smog when subjected to sunlight. Carbon
monoxide does not react in the same way, but it is toxic.
Wacker Neuson utilizes lean carburetor settings and other systems to
reduce the emissions of carbon monoxide, oxides of nitrogen, and
hydrocarbons.
The U.S. and California Clean Air Acts
EPA and California regulations require all manufacturers to furnish
written instructions describing the operation and maintenance of
emission control systems.
The following instructions and procedures must be followed in order to
keep the emissions from your Wacker Neuson engine within the
emissions standards.
Tampering and Altering
Tampering with or altering the emission control system may increase
emissions beyond the legal limit. Among those acts that constitute
tampering are:
•Removal or alteration of any part of the intake, fuel, or exhaust
systems.
•Altering or defeating the speed-adjusting mechanism to cause the
engine to operate outside its design parameters.
Problems That May Affect Emissions
If you are aware of any of the following symptoms, have your engine
inspected and repaired by your servicing dealer.
•Hard starting or stalling after starting.
•Rough idle.
•Misfiring or backfiring under load.
•Afterburning (backfiring).
•Black exhaust smoke or high fuel consumption.

Emission Control System Information
8 wc_tx000369gb.fm
Replacement Parts
The emission control systems on your Wacker Neuson engine were
designed, built, and certified to conform with EPA and California
emissions regulations. We recommend the use of genuine Wacker
Neuson parts whenever you have maintenance done. These original-
design replacement parts are manufactured to the same standards as
the original parts, so you can be confident of their performance. The
use of replacement parts that are not of the original design and quality
may impair the effectiveness of your emission control system.
A manufacturer of an aftermarket part assumes the responsibility that
the part will not adversely affect emission performance. The
manufacturer or rebuilder of the part must certify that use of the part
will not result in a failure of the engine to comply with emission
regulations.
Maintenance
Follow the maintenance schedule. Remember that this schedule is
based on the assumption that your machine will be used for its
designed purpose. Sustained high-load or high-temperatureoperation,
or use in unusually wet or dusty conditions, will require more frequent
service.
OXYGENATED FUELS
Some conventional gasolines are being blended with alcohol or an
ether compound. These gasolines are collectively referred to as
oxygenated fuels. To meet clean air standards, some areas of the
United States and Canada use oxygenated fuels to help reduce
emissions.
If you use an oxygenated fuel, be sure it is unleaded and meets the
minimum octane rating requirement.
Before using an oxygenated fuel, try to confirm the fuel’s contents.
Some States / Provinces require this information to be posted on the
pump.
The following are EPA-approved percentages of oxygenates:
ETHANOL - (ethyl or grain alcohol) 10% by volume. You may use
gasoline containing up to 10% ethanol by volume. Gasoline containing
ethanol may be marketed under the name “Gasohol”. E85 fuel should
never be used, as it is an alternative fuel containing 85% ethanol, 15%
gasoline.
MTBE - (methyl tertiary butyl ether) 15% by volume. You may use
gasoline containing up to 15% MTBE by volume.

Emission Control System Information
wc_tx000369gb.fm 9
METHANOL - (methyl or wood alcohol) 5% by volume. You may use
gasoline containing up to 5% methanol by volume, as long as it
contains cosolvents and corrosion inhibitors to protect the fuel system.
Gasoline containing more than 5% methanol by volume may cause
starting and/or performance problems. It may also damage metal,
rubber, and plastic parts of your fuel system.
If you notice any undesirable operating symptoms, try another service
station, or switch to another brand of gasoline.
Fuel system damage or performance problems resulting from the use
of an oxygenated fuel containing more than the percentages of
oxygenates mentioned above are not covered under warranty.

Emission Control System Information
10 wc_tx000369gb.fm
EMISSIONS COMPONENT DEFECT WARRANTY COVERAGE
This emission warranty is applicable in all States.
Wacker Neuson Corporation, N92 W15000 Anthony Avenue,
Menomonee Falls, WI 53051-1504, (herein "Wacker Neuson")
warrant(“s”) to the initial retail purchaser and each subsequent owner,
that this non-road engine (herein "engine") has been designed, built,
and equipped to conform at the time of initial sale to all applicable
regulations of the U.S. Environmental Protection Agency (EPA), and
that the engine is free of defects in materials and workmanship which
would cause this engine to fail to conform with EPA regulations during
its warranty period.
For the components listed under PARTS COVERED, the service
dealer authorized by Wacker Neuson will, at no cost to you, make the
necessary diagnosis, repair, or replacement necessary to ensure that
the engine complies with applicable U.S. EPA regulations.
EMISSISON COMPONENT DEFECT WARRANTY PERIOD
The warranty period for this engine begins on the date of sale to the
initial purchaser and continues for a period of 2 years.
