Operator’s Manual
Vibroplate
VPY70
EN
50 00403286
5000403286 05 1118

Copyright
notice
Trademarks All trademarks referenced in this manual are the property of their respective owners.
www.wackerneuson.com
Original
instructions
This Operator’s Manual presents the original instructions. The original language of this
Operator’s Manual is American English.
Any type of reproduction or distribution not authorized by Wacker Neuson
Machinery (China) Co., Ltd. represents an infringement of valid copyrights.
Violators will be prosecuted.
Manufacturer Wacker Neuson Machinery (China) Co., Ltd.
No. 1688 Xinkai Road, Pinghu Economic Development Zone,
Pinghu City, Zhejiang Province, P.R. China.
© Copyright 2018by Wacker Neuson Machinery (China) Co., Ltd.
All rights, including copying and distribution rights, are reserved.
This publication may be photocopied by the original purchaser of the machine.
other type of reproduction is prohibited without express written permission
from Wacker Neuson Machinery (China) Co., Ltd.

Foreword VPY70
wpm_tx004314gb.fm 3
Foreword
SAVE THESE INSTRUCTIONS—This manual contains important instructions for
the machine models listed below. These instructions must be followed during
installation and maintenance of the machine (and battery, if equipped).
Machines
covered in
this manual
Machine
identification
A nameplate listing the model number, item number, revision number, and serial
number is attached to this machine. The location of the nameplate is shown above.
Serial number
(S/N)
For future reference, record the serial number in the space provided below. You will
need the serial number when requesting parts or service for this machine.
Machine
documentation
Keep a copy of the Operator’s Manual with the machine at all times.
If you are missing any of these documents, please contact Wacker Neuson to
order a replacement or visit www.wackerneuson.com.
When ordering parts or requesting service information, be prepared to provide
the machine model number, item number, revision number, and serial number.
wpm_gr013519
Serial Number:
Machine Item Number
VPY70 5000007001
From this point forward in this documentation, Wacker Neuson Machinery
(China) Co., Ltd. will be referred to as Wacker Neuson.

Foreword VPY70
wpm_tx004314gb.fm 4
Expectations
for
information in
this manual
This manual provides information and procedures to safely operate and
maintain the above Wacker Neuson model(s). For your own safety and to
reduce the risk of injury, carefully read, understand, and observe all instructions
described in this manual.
Wacker Neuson expressly reserves the right to make technical modifications,
even without notice, which improve the performance or safety standards of its
machines.
The information contained in this manual is based on machines manufactured
up until the time of publication. Wacker Neuson reserves the right to change
any portion of this information without notice.
The illustrations, parts, and procedures in this manual refer to Wacker Neuson
factory-installed components. Your machine may vary depending on the
requirements of your specific region.
CALIFORNIA
Proposition
65 Warning
Combustion exhaust, some of its constituents, and certain vehicle components
contain or emit chemicals known to the State of California to cause cancer and
birth defects or other reproductive harm.
Laws
pertaining to
spark
arresters
NOTICE: State Health Safety Codes and Public Resources Codes specify that in
certain locations spark arresters be used on internal combustion engines that use
hydrocarbon fuels. A spark arrester is a device designed to prevent accidental dis-
charge of sparks or flames from the engine exhaust. Spark arresters are qualified
and rated by the United States Forest Service for this purpose. In order to comply
with local laws regarding spark arresters, consult the engine distributor or the local
Health and Safety Administrator.
Manufacturer’s
approval
This manual contains references to approved parts, attachments, and modifica-
tions. The following definitions apply:
Approved parts or attachments are those either manufactured or provided by
Wacker Neuson.
Approved modifications are those performed by an authorized Wacker
Neuson service center according to written instructions published by Wacker
Neuson.
Unapproved parts, attachments, and modifications are those that do not
meet the approved criteria.
Unapproved parts, attachments, or modifications may have the following conse-
quences:
Serious injury hazards to the operator and persons in the work area
Permanent damage to the machine which will not be covered under warranty
Contact your Wacker Neuson dealer immediately if you have questions about
approved or unapproved parts, attachments, or modifications.

wpm_bo5000403286_03TOC.fm 5
Table of Contents
VPY70
Foreword 3
1 Safety Information 7
1.1 Signal Words Used in this Manual ....................................................... 7
1.2 Machine Description and Intended Use ............................................... 8
1.3 Operating Safety .................................................................................. 9
1.4 Operator Safety while Using Internal Combustion Engines ............... 11
1.5 Service Safety .................................................................................... 12
2 Labels 14
2.1 Label Locations .................................................................................. 14
2.2 Label Meanings .................................................................................. 15
3 Lifting and Transporting 16
4 Operation 17
4.1 Preparing the Machine for First Use ........................................................17
4.2 Recommended Fuel ................................................................................17
4.3 Application ...............................................................................................18
4.4 Before Starting the Machine ....................................................................18
4.5 Starting the Machine .................................................................................19
4.6 Stopping the Machine ...............................................................................19
4.7 Operation ..................................................................................................20

6 wpm_bo5000403286_03TOC.fm
Table of Contents VPY70
5 Maintenance 21
7 Technical Data 28
6 Troubleshooting 27
8 Dimensions 30
5.1 Maintaining the Emission Control System .........................................21
5.2 Periodic Maintenance Schedule........................................................21
5.3 Servicing the Air Cleaner ....................................................................23
5.4 Changing the Engine Oil .....................................................................24
5.5 Servicing the Drive Belt ......................................................................25
5.6 Cleaning the Plate .............................................................................26
5.7 Storage...............................................................................................26
7.1 Engine Data.........................................................................................28
7.2 Machine Data .......................................................................................29
7.3 Sound Measurements ..........................................................................29

wpm_si000994gb.fm 7
VPY70 Safety Information
1 Safety Information
1.1 Signal Words Used in this Manual
This manual contains DANGER, WARNING, CAUTION, NOTICE, and NOTE
signal words which must be followed to reduce the possibility of personal injury,
damage to the equipment, or improper service.
NOTICE: Used without the safety alert symbol, NOTICE indicates a situation
which, if not avoided, could result in property damage.
Note: A Note contains additional information important to a procedure.
This is the safety alert symbol. It is used to alert you to potential personal hazards.
fObey all safety messages that follow this symbol.
DANGER
DANGER indicates a hazardous situation which, if not avoided, will result in death
or serious injury.
fTo avoid death or serious injury from this type of hazard, obey all safety
messages that follow this signal word.
WARNING
WARNING indicates a hazardous situation which, if not avoided, could result in
death or serious injury.
fTo avoid possible death or serious injury from this type of hazard, obey all safety
messages that follow this signal word.
CAUTION
CAUTION indicates a hazardous situation which, if not avoided, could result in
minor or moderate injury.
fTo avoid possible minor or moderate injury from this type of hazard, obey all
safety messages that follow this signal word.

wpm_si000994gb.fm 8
VPY70 Safety Information
1.2 Machine Description and Intended Use
The Wacker Neuson vibratory plate offers functionality and performance. The
compact design allows for compaction of mixed soils in the narrowest of spaces—
even in extremely narrow trenches.
This machine is optimally suited for a variety of compaction applications with high
speed and simple maneuverability. It has:
Compact design with central mounted, fully closed exciter for an even spread of
compactive force over the whole base plate.
Sturdy 4-stroke petrol or diesel engine with recoil starter is isolated from
vibration by rubber dumpers.
Vibration isolated reversible handle with throttle control for ease of operation
and reduced operator fatigue.
This machine has been designed and built strictly for the intended use described
above. Using the machine for any other purpose could permanently damage the
machine or seriously injure the operator or other persons in the area. Machine
damage caused by misuse is not covered under warranty.
The following are some examples of misuse:
Using the machine as a ladder, support, or work surface
Using the machine to carry or transport passengers or equipment
Operating the machine outside of factory specifications
Operating the machine in a manner inconsistent with all warnings found on the
machine and in the Operator’s Manual.
This machine has been designed and built in accordance with the latest global
safety standards. It has been carefully engineered to eliminate hazards as far as
practicable and to increase operator safety through protective guards and labeling.
However, some risks may remain even after protective measures have been taken.
They are called residual risks. On this machine, they may include exposure to:
Heat, noise, exhaust, and carbon monoxide from the engine
Fire hazards from improper refueling techniques
Fuel and its fumes
Personal injury from improper lifting techniques
To protect yourself and others, make sure you thoroughly read and understand the
safety information presented in this manual before operating the machine.

wpm_si000994gb.fm 9
VPY70 Safety Information
1.3 Operating Safety
Operator
training
Before operating the machine:
Read and understand the operating instructions contained in all manuals
delivered with the machine.
Familiarize yourself with the location and proper use of all controls and safety
devices.
Contact Wacker Neuson for additional training if necessary.
When operating this machine:
Do not allow improperly trained people to operate the machine. People
operating the machine must be familiar with the potential risks and hazards
associated with it.
Only trained personnel are permitted to start, operate, and shut down the machine.
They also must meet the following qualifications:
have received instruction on how to properly use the machine
are familiar with required safety devices
The machine must not be accessed or operated by:
children
people impaired by alcohol or drugs
Application
area
Be aware of the application area.
Keep unauthorized personnel, children, and pets away from the machine.
Remain aware of changing positions and the movement of other equipment and
personnel in the application area/job site.
Be aware of the application area.
Do not operate the machine in areas that contain flammable objects, fuels, or
products that produce flammable vapors.
Safety
devices,
controls, and
attachments
Only operate the machine when:
All safety devices and guards are in place and in working order.
All controls operate correctly.
The machine is set up correctly according to the instructions in the Operator’s
Manual.
The machine is clean.
The machine’s labels are legible.
To ensure safe operation of the machine:
Do not operate the machine if any safety devices or guards are missing or
inoperative.
Do not modify or defeat the safety devices.
Only use accessories or attachments that are approved by Wacker Neuson.

wpm_si000994gb.fm 10
VPY70 Safety Information
Safe
operating
practices
When operating this machine:
Remain aware of the machine’s moving parts. Keep hands, feet, and loose
clothing away from the machine’s moving parts.
When operating this machine:
Do not operate a machine in need of repair.
Personal
Protective
Equipment
(PPE)
Wear the following Personal Protective Equipment (PPE) while operating this
machine:
Close-fitting work clothes that do not hinder movement
Safety glasses with side shields
Hearing protection
Safety-toed footwear
Transporting
and installing
the machine
Never allow untrained personnel to operate or service the vibratory plate.
Do not stand under the machine while it is being hoisted or moved.
Do not attach equipment to the machine when it is suspended.
Always transport the machine in an upright position.
Always position and operate the machine on a firm, noncombustible, level
surface.
Always make certain the machine is well-grounded and securely fastened to a
good earthen ground per national and local regulations.
General
Safety
Do not operate the machine when open containers of fuel, paint, or other
flammable liquids are near.
Do not operate the machine, or tools attached to the machine, with wet hands..
Do not enclose or cover the machine when it is in use or when it is hot.
Do not operate the machine in snow, rain, or standing water.
Do not stand on the machine.
Machine
vibration
Vibratory plate vibrate in normal use. During and after the use of the machine,
inspect the machine before storing it.
Have damaged items repaired or replaced as necessary.
After use Store the machine properly when it is not being used. The machine should be
stored in a clean, dry location out of the reach of children.
Cleaning When cleaning and servicing the machine:
Keep the machine clean and free of debris such as leaves, paper, cartons, etc.
Keep the labels legible.
When cleaning the machine:
Do not clean the machine while it is running.
Never use gasoline or other types of fuels or flammable solvents to clean the
machine. Fumes from fuels and solvents can become explosive.

wpm_si000994gb.fm 11
VPY70 Safety Information
1.4 Operator Safety while Using Internal Combustion Engines
Refueling
safety
When refueling the engine:
Do not smoke.
Do not refuel if the machine is sitting in a truck fitted with a plastic bed liner.
Static electricity can ignite the fuel or fuel vapors.
Do not refuel a hot or running engine.
Do not refuel the engine near an open flame.
When refueling the engine, always:
Refill the fuel tank in a well-ventilated area.
Reinstall the fuel tank cap after refueling.
Operating
safety
When operating the machine:
Check the fuel lines and the fuel tank for leaks and cracks before starting the
engine.
Do not run the machine if fuel leaks are present or the fuel lines are loose.
Do not run the engine near open flames.
Do not start the engine if fuel has spilled or a fuel odor is present. Move the
machine away from the spill and wipe it dry before starting.
Do not smoke while operating the machine.
WARNING
Internal combustion engines present special hazards during operation and fueling.
Failure to follow the warnings and safety standards could result in severe injury or
death.
fRead and follow the warning instructions in the engine owner’s manual and the
safety guidelines below.

wpm_si000994gb.fm 12
VPY70 Safety Information
1.5 Service Safety
Service
training
Before servicing or maintaining the machine:
Read and understand the instructions contained in all manuals delivered with
the machine.
Familiarize yourself with the location and proper use of all controls and safety
devices.
Only trained personnel shall troubleshoot or repair problems occurring with the
machine.
Contact Wacker Neuson for additional training if necessary.
When servicing or maintaining this machine:
Do not allow improperly trained people to service or maintain the machine.
Personnel servicing or maintaining the machine must be familiar with the
associated potential risks and hazards.
Precautions Follow the precautions below when servicing or maintaining the machine.
Read and understand the service procedures before performing any service to
the machine.
All adjustments and repairs must be completed before operating the machine.
Do not operate the machine with a known problem or deficiency.
All repairs and adjustments shall be completed by a qualified technician.
Turn off the machine before performing maintenance or making repairs.
Remain aware of the machine’s moving parts. Keep hands, feet, and loose
clothing away from the machine’s moving parts.
Re-install the safety devices and guards after repair and maintenance
procedures are complete.
Machine
modifications
When servicing or maintaining the machine:
Use only accessories/attachments that are approved by Wacker Neuson.
When servicing or maintaining the machine:
Do not defeat safety devices.
Do not modify the machine without the express written approval of Wacker
Neuson.
Replacing
parts and
labels
Replace worn or damaged components.
Replace all missing and hard-to-read labels.
When replacing electrical components, use components that are identical in
rating and performance to the original components.
When replacement parts are required for this machine, use only Wacker
Neuson replacement parts or those parts equivalent to the original in all types of
specifications, such as physical dimensions, type, strength, and material.

wpm_si000994gb.fm 13
VPY70 Safety Information
Cleaning When cleaning and servicing the machine:
Keep the machine clean and free of debris such as leaves, paper, cartons, etc.
Keep the labels legible.
When cleaning the machine:
Do not clean the machine while it is running.
Never use gasoline or other types of fuels or flammable solvents to clean the
machine. Fumes from fuels and solvents can become explosive.
Personal
Protective
Equipment
(PPE)
Wear the following Personal Protective Equipment (PPE) while servicing or
maintaining this machine:
Close-fitting work clothes that do not hinder movement
Safety glasses with side shields
Hearing protection
Safety-toed footwear
In addition, before servicing or maintaining the machine:
Tie back long hair.
Remove all jewelry (including rings).

wpm_si000995gb.fm 14
VPY70 Labels
2 Labels
2.1 Label Locations
C
B
F
A
D
E

wpm_si000995gb.fm 15
VPY70 Labels
2.2 Label Meanings
AWARNING!
Always wearing hearing and eye protection
when operating this machine.
BCAUTION
Hot Muffler can burn you. Stay away if engine
has been running.
D
C
Engine Warning Label.
FWacker Neuson Logo
A nameplate listing the model number, item
number, revision number, and serial number is
attached to each unit. Please record the
information found on this nameplate so it will
be available should the nameplate become lost
or damaged. When ordering parts or
requesting service information, you will always
be asked to specify the model number, item
number, revision number, and serial number of
the unit.
Lifting point
E

wpm_tx004315gb.fm
VPY70 Lifting and Transporting
3 Lifting and Transporting
Lifting the
Machine
This machine is heavy enough to cause injury if proper lifting techniques are not
used. Observe the following guidelines when lifting the vibroplate.
Do not attempt to lift the machine unassisted. Use appropriate lifting equipment
such as slings, chains hooks, ramps or jacks.
Make sure lifting equipment is attached securely and has enough weight-
bearing capacity to lift or hold the machine safely.
Remain aware of the location of other people nearby when lifting the machine.
Transporting
the Machine
Observe the following guidelines when transporting the vibroplate to and from the
job site.
Drain the fuel tank before transporting the machine.
Ensure that the machine is securely strapped down in the transport vehicle to
prevent it from sliding or tipping.
Do not refuel the machine in or on the transport vehicle. Move the machine to its
operating location and then fill the fuel tank.
wpm_gr013522
16

wpm_tx004316gb.fm
VPY70 Operation
4 Operation
4.1 Preparing the Machine for First Use
1. Make sure all loose packaging materials have been removed from the machine.
2. Check the machine and its components for damage. If there is visible damage,
do not operate the machine! Contact your Wacker Neuson dealer immediately
for assistance.
3. Take inventory of all items included with the machine and verify that all loose
components and fasteners are accounted for.
4. Attach component parts not already attached.
5. Add fluids as needed and applicable, including fuel, engine oil, and battery acid.
6. Move the machine to its operating location.
4.2 Recommended Fuel
The engine requires No. 2 diesel fuel. Use only fresh, clean fuel. Fuel containing
water or dirt will damage fuel system.
17

wpm_tx004316gb.fm
VPY70 Operation
4.3 Application
This plate is designed for compacting loose, granular soils and gravel. It is
intended to be used in confined areas and areas next to structures such as walls,
curbs, and foundations.
This plate is not recommended for compacting cohesive soils with a heavy clay
content. For cohesive soil, use a vibratory rammer or sheepsfoot roller.
4.4 Before Starting the Machine
Read and understand the safety and operating instructions at the beginning of this
manual.
Check Oil level in the engine
Fuel level
Condition of the air cleaner
Tightness of the external fasteners
Condition of the fuel lines
18

wpm_tx004316gb.fm
VPY70 Operation
4.5 Starting the Machine
Procedure Perform the procedures below to start the machine.
1. Open the fuel valve (a2).
2. Push the engine throttle lever to “RUN” (b2).
3. Pull out the starter handle until you feel strong resistance, then let it return
slowly.
4. Push the decompression lever (c) down.
NOTE: Lever will return automatically when the starter is pulled.
5. Pull the starter handle to start the engine. If the engine does not start, repeat
steps 3 and 4.
CAUTION: NEVER operate the engine without the air cleaner. Engine will
damage.
Result The machine is now ready
4.6 Stopping the Machine
Perform the following procedures to stop the engine.
Procedure 1. Place the engine throttle in the “Stop” position (c).
2. If engine keeps running, stop it by closing fuel valve (b1)
CAUTION: DO NOT stop engine using the decompression lever.
wpm_gr013523
c
a
2
a
1
b
1
b
2
19

wpm_tx004316gb.fm
VPY70 Operation
4.7 Operation
Run the engine at full throttle and allow the plate to pull itself along at its normal
speed. When operating on an incline, it may be necessary to assist the plate by
pushing it forward slightly. When operating downhill, hold the plate back slightly, if it
begins to pickup speed. Depending on the material being compacted, three or four
passes are recommended to achieve the best compaction.
While a certain amount of moisture in the soil is necessary, excessive moisture
may cause soil particles to stick together and prevent good compaction. If the soil
is extremely wet, allow it to dry somewhat before compacting.
If the soil is so dry as to create dust clouds while operating the plate, some
moisture should be added to the ground material to improve compaction. This will
also reduce service to the air filter.
For compacting asphalt, use a water tank to wet the asphalt and the underside of
the plate. This will prevent the asphalt material from sticking. Two passes are
usually sufficient to ensure good compaction.
When using the plate on paving stones, attach a pad to the bottom of the plate to
prevent chipping or grinding the stones. A special polyurethane pad designed for
this purpose is available as an optional accessory.
CAUTION: DO NOT operate the plate on concrete or on extremely hard, dry,
compacted surfaces. The plate will jump rather than vibrate and could damage
both the plate and the engine.
20
