Waferlock L310 User manual

L310 Parts List
1Outside Assembly with lever
7Latch
3Inner Lever
4Backplate
6Strike
5Rubber GasketX1
M3 Screw
9
8M3 Screws (Black)X3
2Inside Assembly
www.waferlock.com
10 Mounting Screws
Fixing Screws
for Strike PlateX2
12
Fixing Screws
for Latch SetX2
11
Battery(AAA)
16
15 Dismantling Lever/
Door Thickness Adjusting Tool
13 Keys
14 Inner Lever Handle Set

1. Install latch. The bevel must face toward the
door stop.
2. Place outside assembly on rubber gasket.
1. Attach the outside assembly to the door. Allow
the cables hang through the hole on the other
side.
2. Insert the outside assembly into door and be
sure to properly engage the lock body with the
latch by turning the spindle.
1. Take the backplate, gently thread the cables
from the outside assembly through the hole
located near the latch in the backplate.
1. Place the inner lever set over spindle on the
door with the embossed "arrow" to face the
latch direction.
2. Tap the cables down the notch of the inner
lever handle set to be sure the housing will not
pinch or cut before fastening bolts.
IMPORTANT
The cables must come through notch and
lie within the notch without pinched or cut.
1. Well connect the cables to the connectors
of inside assembly.
IMPORTANT
The cables must not be pinched or cut
during the process.
1. Install insdie assembly and tighten the fixing
screw from the bottom.
1. Tighten the fixing screws at the battery box of
the inner unit.
1. Install the inner lever and make sure the
lever is fixed on the lever handle set.
* To remove the lever, utilize the dismantling
Lever tool. Insert it into the lever hole and
simultaneously pull the lever.
1. Insert batteries and slide the battery cover
properly as the photo.
2. Tighten the M3 screw.
L310 Installation Manual www.waferlock.com
15
19
4 PIN 4 PIN
4 PIN
2 PIN
2 PIN
2 PIN
10
12
12
10
8
8
8
9V battery contact
view from inside of door
V02
notch
latch
retractor
lock body
4 PIN
2 PIN
