Walker Edison BWTLD46 User manual

Item #: BWTLD46
Assembly Instructions
For our most current instructions, to request missing, lost or broken parts, or for any other Customer
Service issues, please visit our website at www.walkeredison.com or call us at 877-207-5906.
Revised 07/2012

Instruction Manual
IMPORTANT INFORMATION
READ BEFORE ASSEMBLING THIS PRODUCT
Follow the information on the warning labels found on the bunk bed and on the packaging.
Do not remove the warning label from the bed.
Use only a mattress with the dimensions 74-75 in.L x 37.5-38.5 in.W x 9 in.H on the upper
bunk.
The surface of the mattress must be at least 5 in. (127mm) below the upper edge of the
guardrails. Mattress must not exceed the maximum thickness of 9 in.
Always use the recommended size of mattress or mattress support, or both, to help prevent
the likelihood of entrapment or falls.
The use of a water or sleep flotation mattress is prohibited.
Replacement parts, including additional guardrails, may be obtained from any of Walker
Edison Furniture Company’s dealers or by contacting us online at www.walkeredison.com.
DO NOT use substitute parts. Contact the manufacturer or dealer for replacement parts.
Always use guardrails on the upper bunk. If the bunk bed will by placed next to a wall, the
guardrail running the full length of the bed should by placed against the wall to prevent
entrapment between the bed and the wall.
Periodically check that the guardrails, ladders and other components of the bed are in their
proper position, free from damage, and that all connectors are tight.
Always use the ladder to access the upper bunk.
DO NOT allow children under 6 years of age to use the upper bunk.
DO NOT allow horseplay on or under the bed. Prohibit jumping on the bed.
Prohibit more than one person on the upper bunk.
The use of a night light may provide an added safety precaution for a child using the upper
bunk.
STRANGULATION HAZARD – Never attach or hang items to any part of the bunk bed that
are not designed for use with the bed; including but not limited to hooks, belts and jump
ropes.
Keep these instructions for future reference.

Parts List

Hardware List

Assembly Options
Option A - Ladder Right
To build this option follow Steps 1-6,
Steps 7A-14A and Steps 15-24.
Option B - Ladder Left
To build this option follow Steps 1-6,
Steps 7B-14B and Steps 15-24.

Insert dowels (A) into guardrails (3,4,5,6,7,8) and shelf supports (18).
Insert dowels (A) into slats (1,2) and self supports (16,17). Screw cam bolts (J) into shelf supports (16,17).

Attach second set of slats (1,2) to legs (11,12) using dowels as guides. Secure slats (1,2) to legs (11,12)
using screws (D). Tighten screws (D) with wrench (N).
Attach slats (1,2) to legs (9,10) using dowels as guides. Secure slats (1,2) to legs (9,10) using screws (D).
Tighten screws (D) with wrench (N).

Attach shelf supports (16,17) to shelf (19) using cam bolts and dowels as guides. Insert cam locks (K) into
shelf (19) and tighten with a screwdriver. Repeat this step for second shelf.
Attach shelf support (18) to shelf (19) using screws (H). Tighten screws (H) with a screwdriver. Repeat this
step for second shelf.

Insert barrel nuts (C) into guardrails (3,4). Attach guardrails
(3,4) to leg set (11,12) using bolts (B). Bolts (B) will screw
directly into barrel nuts (C). Hold barrel nuts (C) in place
with a screwdriver as you tighten bolts (B) with wrench (N).
Secure guardrails (5,6) to leg (11) using screws (D).
Tighten screws (D) with wrench (N).
Attach guardrail supports (28) to guardrails (3,7,8) and guardrails (4,5,6) using bolts (G). Tighten bolts (G)
with wrench (N).

Insert barrel nuts (C) into guardrails (3,4). Attach guardrails
(3,4) to leg set (9,10) using bolts (B). Bolts (B) will screw
directly into barrel nuts (C). Hold barrel nuts (C) in place with
a screwdriver as you tighten bolts (B) with wrench (N). Secure
guardrails (5,6) to leg (10) and guardrails (7,8) to leg (9) using
screws (D). Tighten screws (D) with wrench (N).
Attach six of the seven mattress support slats (13) to the bed frame using screws (H). Use wood blocks
(29) as guides for proper spacing of mattress support slats. See Step 14A for placement of final mattress
support slat.

Attach shelves (19) to the bed frame using screws (D). Tighten screws (D) with wrench (N).
Attach shelf support legs (14,15) to shelves (19) using screws (E). Tighten screws (E) with wrench (N).

Secure shelf support legs (14,15) to the bed frame using screws (F). Tighten screws (F) with wrench (N).
Attach final mattress support slat (13) to the bed frame using screws (H). Tighten screws (H) with a
screwdriver.
Option A
Final Assembly of Bed Frame

Insert barrel nuts (C) into guardrails (3,4). Attach guardrails
(3,4) to leg set (9,10) using bolts (B). Bolts (B) will screw
directly into barrel nuts (C). Hold barrel nuts (C) in place
with a screwdriver as you tighten bolts (B) with wrench (N).
Secure guardrails (5,6) to leg (9) and guardrails (7,8) to leg
(10) using screws (D). Tighten screws (D) with wrench (N).
Attach guardrail supports (28) to guardrails (3,7,8) and guardrails (4,5,6) using bolts (G). Tighten bolts (G)
with wrench (N).

Insert barrel nuts (C) into guardrails (3,4). Attach guardrails
(3,4) to leg set (11,12) using bolts (B). Bolts (B) will screw
directly into barrel nuts (C). Hold barrel nuts (C) in place with
a screwdriver as you tighten bolts (B) with wrench (N). Secure
guardrails (5,6) to leg (12) using screws (D). Tighten screws
(D) with wrench (N).
Attach six of the seven mattress support slats (13) to the bed frame using screws (H). Use wood blocks
(29) as guides for proper spacing of mattress support slats. See Step 14B for placement of final mattress
support slat.

Attach shelves (19) to the bed frame using screws (D). Tighten screws (D) with wrench (N).
Attach shelf support legs (14,15) to shelves (19) using screws (E). Tighten screws (E) with wrench (N).

Secure shelf support legs (14,15) to the bed frame using screws (F). Tighten screws (F) with wrench (N).
Attach final mattress support slat (13) to the bed frame using screws (H). Tighten screws (H) with a
screwdriver.
Option B
Final Assembly of Bed Frame

Insert dowels (A) into desk supports (25,26,27).
Screw casters (L) into desk legs (21,24) and casters (M) into desk legs (22,23).

Attach second set of desk supports (27) to desk legs (23,24) using dowels as guides. Secure desk
supports (27) using screws (E). Tighten screws (E) with wrench (N).
Attach desk supports (27) to desk legs (21,22) using dowels as guides. Secure desk supports (27) using
screws (E). Tighten screws (E) with wrench (N).

Attach leg set (23,24) to desk top (20) using screws (D). Tighten screws (D) with wrench (N).
Attach desk supports (25) to desk top (20) using screws (I). Tighten screws (I) with a screwdriver.

Attach leg set (21,22) to the desk assembly using screws (D). Tighten screws (D) with wrench (N).
Attach desk support (26) to desk leg (23) using screw (D). Tighten screw (D) with wrench (N).
