Walker Edison BR3DBENNS User manual

P.1Assembly InstructionsPlease visit our website for the most current instructions, assembly tips, to report damageor request parts. www.walkeredson.comRevised 01/2021BR3DBENNS

P.2

P.3Right side panelTop panelFront Foot Side Foot Left side panelSmall Front crossbeam123456701 pcsDrawer Right SideDrawer bottom1011Drawer back1213Drawer runner01 pcs01 pcs02 pcs02 pcs06 pcs01 pcs03 pcs03 pcs03 pcs03 pcsDescriptionQtyPart#801 pcsFront Drawer903 pcsBack PanelDrawer Left Side1234455555566789101112133xDescriptionQtyPart#

P.4FEABCDØ8*30mmWooden dowel42pcs32pcsØ3,5*30mmScrew16pcsØ10*10Nail14pcs
Hammer
recommended for assembly
(not included)ScrewØ4,0*25mm12pcØ8*20mmWooden dowelGCorner02pcs04pcsØ3,5*14mmScrewJH03pcsScrewm4*22mm03pcsHandle

P.5Insert Wooden dowel (A) into part (4), (6), (10) and (11). Step 1Step 2Secure part secure part (5) to part (2) and (3) with screw (D). Insert Wooden dowel (A) into part (2) and (3). 23AInsert Wooden dowel (E) into part (5). 5D2xAAAAAAAAAAEE6x2x3x3xD5DD5DD5DDAAAAAAD5461110AE2412Ø8*30mmØ8*20mmAD0608Ø4*25mmØ8*30mm

P.6Step 3Step 5Secure part (4) to part (2) with screw (B). Secure part (1) to part (2) and (3) with screw (B). B02Ø3,5*30mmB04Ø3,5*30mmBBBBBStep 4BBBB4444322Secure part (4) to part (3) with screw (B). B02Ø3,5*30mm231

P.7Step 6Step 7DDDDSecure part (6) to part (2) and (03) with screw (D). CGCCGCCCGSecure part (7) to part (6) with hardware (G) and screw (C). 2666637DD04Ø4*25mmC04Ø3,5*14mmG02

P.8Step 8Step 9D5D5DDSecure part (5) to part (2) and (3) with screw (D). 23A5Insert Wooden dowel (A) into part (5). AA5A55AA5A5D04Ø4*25mmA06Ø8*30mm

P.9Step 10F90°!Secure back panel (8) to body with nails (F) Step 11FFFFFFFFFFFFFF3xBBBBBBBBBSecure part (10) and (11) to part (9) with screw (B).
Insert part (12) between parts (10) and (11)
Secure part (13) with screw (B). 8111091213F14Ø10*10mmB24Ø3,5*30mm

P.10Step 12Step 13Secure hardware (H) part (9) with screw (J).JH3xDrawer StopInsert wood dowel (A) on the inside of all drawers while drawer is inside the unit.Make sure dowel is flush with panel.AAAA9999H03J03ØM4*22mmA06Ø8*30mm

P.11Step 14 Maintenance Guide To maintain long term performance and easy gliding of your solid wood drawers, we recommend applying wax to the wooden guide rails.1. Bee's wax is recommended or Paraffin wax from a standard candle can be used. 2. Apply the wax by rubbing it on the wooden guide rails where there is wood-on-woodcontact when opening and closing the drawer. (Wax should be room temperature, do not melt the wax onto the wood)3. Wax should be applied every few months for the first year and then only when needed after that to keep the drawers sliding smoothly.Assembly Complete!75lbs
