Walker Edison BR3DNS User manual

BR3DNS
Assembly Instructions
P.1
Keep these instructions for future reference.
Revised 03/2018

P.2

P.3
1
7
2
3
4
5
6
8
8
9
9
10
11
12
13
14
3x
Right side panel
Top panel
Back panel
Upper front crossbeam
Left side panel
Bottom front crossbeam
1
2
3
4
5
6
7
01 pcs Right foot
Left foot
Front drawer
Left side drawer
8
9
10
11
Drawer bottom
Right side drawer
12
13
Drawer back
14
Back crossbeam
01 pcs
01 pcs
01 pcs
01 pcs
01 pcs
02 pcs
02 pcs
02 pcs
03 pcs
03 pcs
03 pcs
03 pcs
03 pcs

P.4
A
B
C
D
E
F
G
H
I
J
K
Ø8*30mm Wooden dowel 28 pcs
Ø3,0*14mm Screw
Glue
18 pcs
Ø6,0*10mm Screw 12 pcs
Ø4,0*30mm Screw 37 pcs
Screw 03 pcs
Ø4,5*45mm Screw 12 pcs
Ø10*10 Nail 16 pcs
300mm Right Slide 03 pcs
300mm Left Slide 03 pcs
Knob 03 pcs
01 pcs
M4*22mm
Hammer
recommended for assembly
(not included)

P.5
Step 1
Step 2
A
Please assemble on
a clean soft surface
to avoid damage.
2
6
4
5
12
3x
A
11
3x
3
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
C
C
C
C
C
C
C
C
C
C
C
C
Please assemble on
a clean soft surface
to avoid damage.
I
I
I
H
H
H
Pre-Drilled holes
3
C
I
The wheel to
the Front
C
H
The wheel to
the Front
2
A
Ø8*30mm
28
C
H
Ø6,0*10mm
12
Right slide 300mm
03
I
Left slide 300mm
03
K
Glue tube
01

P.6
Step 3
Step 4
D
5
4
3
2
6
D
DD
1
D
D
D
D
D
Ø4,0*30mm
04
D
Ø4,0*30mm
06
K
Glue tube
01
K
Glue tube
01

P.7
Step 5
Step 6
D
9
8
D
DD
F
F
F
F
F
F
F
F
8
9
D
Ø4,0*30mm
03
F
Ø4,5*45mm
12
F
F
F
K
K
Glue tube
01
1º 2º
Apply glue to leg
contact surfaces

P.8
Step 7
Step 8
G
7
G
G
G
G
G
G
G
G
G
G
G
G
G
DD
D
D
B
B
B
B
E
J
I
H
B
10
12
11
13
14
3x
The wheel to
the Back
Bottom
DD
DD
3x
3x
3x
G
Ø10*10
16
E
H
03
Right slide 300mm
03
I
J
Left slide 300mm
03
03
B
D
Ø3,0*14mm 12
Ø4,0*30mm 24
BM4x22mm

Step 9
To adjust the drawer front position:
Loosen the screw (part C) you used to
install the drawer runner (either parts H
or I) in step 2, to the side panel
(parts 02 or 03), depending on the side
(left or right), as shown.
With the screw (part C) loosened, you
can make the necessary slight
adjustments (up or down) to the drawer
runner to achieve the proper drawer
alignment.
Once the drawer alignment is square, secure
the position of the drawer runners (parts H &
I) to the side panels (parts 02 & 03) by re-
tightening the part C screw and adding the
part B screw as shown.
BØ3,0*14mm 06
P.9
C
C
B
