Walker Edison BTOT Series User manual

ITEM#: BTOT
Assembly Instructions
  
 
Revised 03/2017
Copyright © 2009, by Walker Edison Furniture Co., LLC. All rights reserved. P.1

Secure these parts together using screws (1) and washers (2). Be sure to tighten firmly using
wrench (11).
Assembly the four support posts by combining parts B, C, and A; then parts E, C, and D as
shown in the illustration.

Place guardrails (P) between the assembled support posts as shown in the illustration.
Secure guardrails to the support posts using screws (1) and washers (2) as shown in the
illustration. Be sure to tighten firmly using wrench (11).

Attach legs (N) to the lower cross bars (G, I) using screws (1) and washers (2) as shown in
the illustration. Tighten screws using hex wrench (11).

Attach lower cross bars (G, I) and upper cross bars (F, H) to the end supports in Step 3 using
washers (2) and screws (1) as shown in the illustration. Ensure the slots on the cross bars are
facing inward as shown in the illustration. Be sure to tighten all screws firmly using wrench (11).

Attach another end supports assembled in Step 3 to bed frame using washers (2) and screws
(1) as shown in the illustration. Ensure the slots on the cross bars are facing inward as step 6.
Be sure to tighten all screws firmly using wrench (11).

Insert mattress support bars (O) into the slots on the cross bars as shown in the illustration.
Snap plastic tab locks (8) into each slot to lock the mattress support bars in place.Snap plastic
links (9) into the middle of the mattress support bars as shown in the illustration.

Insert mattress support bars (O) into the slots on the cross bars as shown in the illustration.
Snap plastic tab locks (8) into each slot to lock the mattress support bars in place. Snap
plastic links (9) into the middle of the mattress support bars as shown in the illustration.

Attach the ladder steps (M) to the ladder support posts (L) using screws (5) and washers (6)
as shown in the illustration.

Attach open guardrail (K) to the upper cross bar using screws (4) and washers (3), then attach
upper guardrail (K) to the support post using screw (1) and washer (2) as diagram shown. Be
sure to tighten all screws firmly.
Attach ladder support posts to the lower cross bar using screws (4) and washers (3) as shown
in the illustration
Attach ladder frame assembly to the upper cross bar on the right side using screw (1) and
washer (2) on the left side using screw (3) and washer (4) as shown in the illustration.
Note the ladder and open guardrail on the left side.

Attach back upper guardrail (J) to the back frame support beams using screws (1) and washer
(2) as shown in the illustration. Attach guardrail to cross bar (F) using screws (4) and washers
(3), tighten with wrench (12). Be sure to tighten all screws firmly.

Place plastic plugs (10) into the holes in the front cross bars as shown in the illustration.
Snap plastic links (9) into the middle of the mattress support bars as shown in the illustration

Note the ladder and open guardrail on the right side.
Attach open guardrail (K) to the upper cross bar using screws (4) and washers (3), then attach
upper guardrail (K) to the support post using screw (1) and washer (2) as diagram shown.
Be sure to tighten all screws firmly.
Attach ladder support posts to the lower cross bar using screws (4) and washers (3) as shown
in the illustration
Attach ladder frame assembly to the upper cross bar on the right side using screw (1) and
washer (2) on the left side using screw (3) and washer (4) as shown in the illustration.

Attach back upper guardrail (J) to the back frame support beams using screws (1) and washers
(2) as shown in the illustration. Attach guardrail to cross bar (F) using screws (4) and washers
(3), tighten with wrench (12). Be sure to tighten all screws firmly.

Place plastic plugs (10) into the holes in the front cross bars as shown in the illustration.
Snap plastic links (9) into the middle of the mattress support bars as shown in the illustration.
