Walker Edison W52NORGS User manual

Item # : W52NORGS
Assembly Instructions
  
 

    P.1

Secure legs (11,12) to bottom panel (2) with bolt (K).
Secure cam bolt (C) to top panel (1).
Insert wooden dowel (A) into side panel (3,4,5).
Secure hinge (H) to door (6) with screw (J), secure handle (E) to door (6) with bolt (F).

Insert side panel (3,4,5) into bottom panel (2) and use wrench (P) to secure them with bolt (G).
Slide back panel (9,10) into grooves.

Insert top panel (1) into side panel (3,4,5), then insert and secure cam lock (B) to side panel
(3,4,5) to lock it.
Secure plastic wedges (L) to back panel (9,10) with screw (M).

Place sticker (Q) over holes as per diagram.
Assemble shelf support pin (D) to side panel (3,5), then place shelf (7) on top of the support
pin (D). Assemble shelf support pin (R) to side panel (4,5), then place glass shelf (8) on top
of the support pin (R) carefully.

Secure hinge (H) to side panel (3) with screw (J) to holding door (6).
