Walker Edison D44VET2DR User manual

P.1
Copyright
202
0b
y
Walker Edison Furniture Co., LLC. All rightsreserved.
Please visit our websitefor the most current instructions, assemblytips, report damage,
or request parts. www.walkeredison.com
Revised 24/04/2020 (E)
Walker Edison
TM
AssemblyInstructions
Item#:D44VET2DR

P.2
Copyright
2020
b
y
Walker Edison Furniture Co., LLC. All rightsreserved.
GeneralAssembly Guidelines
I.Ensure thatallpartsandhardware are available beforebeginning assembly.
II.Followeachstepcarefullytoensure theproper assembly of this product.
21
III.Twopeoplearerecommendedfor easeintheassembly of this product.
IV.Thethreemaintypesofhardwareusedtoassemble this product are: wood
dowels,screwsandbolts.
V.Theprovidedglueistosecurewooddowelsin place.Whenfirstinserting dowels ,
locatetheappropriatehole forthedowel,placeasmallamount of glue inthe hole
andinsertthedowel .Wipeawayexcessglue immediately.
Infutureassemblystepswhendowelsarenecessary toattachassembly parts
together,placeasmall amountofglue on theendof the dowelbeforeattaching
partstogether.Wipeawayexcessglueimmediately.
VI.APhillipsheadscrewdriverisrequiredfortheassemblyofthis product .
VII.Powertoolsshouldnotbeusedtoassemblethis product .

P.3
Parts List
1
Copyright
2020
b
y
Walker Edison Furniture Co., LLC. All rightsreserved.
2
2
4
3
5

P.4
Copyright
2020
b
y
Walker Edison Furniture Co., LLC. All rightsreserved.
HardwareList
The hardware quantities listed above are required for proper assembly.
Someextrahardware may also have been included.
Philipsheadscrewdriverrequiredforassembly
(notincluded)
A
B
C
D
Ø6x33mm Bolt
E
8pcs
M4 Hexkey 1 pc
Ø6x19mm Bolt 4 pcs
Flatwasher 4 pcs
Ø4x30mm Screw 4 pcs
FLockwasher 4 pcs

P.5
Copyright
2020
b
y
Walker Edison Furniture Co., LLC. All rightsreserved.
Step 1
B
D
2
2
3
4
5
Using bolt (B) attach parts (3,5) to parts (2,4) with Hex key (D) as per diagram.

P.6
Copyright
2020
b
y
Walker Edison Furniture Co., LLC. All rightsreserved.
Step 2
A
C
D
E
E
E
E
1
2
2
3
5
F
Using bolt (A) attach lock washer (F) and flat washer (C) into parts (3,5) to part (1) with
Hex key (D) ,then using screw (E) secure part (2) to part (1) with Philips head screwdriver as per
diagram.

Step 3
P.7
Copyright
2020
b
y
Walker Edison Furniture Co., LLC. All rightsreserved.
If you need to remove the drawer, please pull the drawer forward and turn the plastic stopper to
left or right side ,then you can take drawer out easily as per diagram.

Step 4
P.8
Copyright
2020
b
y
Walker Edison Furniture Co., LLC. All rightsreserved.
FinalAssembly
