Walker Edison D56FUL2DG User manual

P.1
Copyright
201
9, by Walker Edison Furniture Co., LLC. All rightsreserved.
Please visit our websitefor the most current instructions, assemblytips, report damage,
or request parts. www.walkeredison.com
Revised 09/10/2019(L)
Walker Edison
TM
D56FUL2DG

VIII.Drillmaybeneededforsecuringproduct towall.
GeneralAssembly Guidelines
I. Ensure thatallpartsandhardware are available beforebeginning assembly.
II.Followeachstepcarefullytoensure theproper assembly of this product.
21
III.Twopeoplearerecommendedfor easeintheassembly of this product.
IV.Thethreemain typesofhardware usedtoassemblethis product are: wood
dowels,screwsandbolts.
V.Theprovidedglueistosecurewooddowelsin place.Whenfirst inserting dowels,
locatetheappropriatehole forthedowel,placeasmallamount of glue inthe hole
andinsertthedowel.Wipeawayexcessglueimmediately.
Infutureassemblystepswhendowelsarenecessary toattachassembly parts
together,placeasmallamountofglueonthe endofthedowelbeforeattaching
partstogether.Wipeawayexcessglueimmediately.
VI.APhillipsheadscrewdriverisrequiredfortheassemblyofthis product .
VII. Power toolsshould notbeusedtoassemblethis product.
Copyright
201
9, by Walker Edison Furniture Co., LLC. All rightsreserved.
P.2

Parts List
P.3
Copyright
201
9, by Walker Edison Furniture Co., LLC. All rightsreserved.
1
2
3
4
4
6
78
9
10
5
5
5
5
12 12
11
11
14
15
16
17
13
14
15
16
17
13

P.4
The hardware quantities listed above are required for proper assembly.
Someextrahardware may also have been included.
8x30mm Woodendowel 19 pcs
Philipsheadscrewdriverrequiredforassembly
(notincluded)
A
Copyright
©
201
9, by Walker Edison Furniture Co., LLC. All rightsreserved.
8x35mm Cambolt 24 pcs B
15x11mm Camlock 24 pcs
C
Sticker
D
6x50mm Screw
24 pcs
E16 pcs
F
G
H
Handle 2 pcs
J
4x22mm Bolt 2 pcs
K
4mm HexKey 1 pc
L
M
Screw 8 pcs
N
Screw 24 pcs
P
Q
4x32mm
3x12mm
Bolt
1/4"x25mm
HardwareList
Glasspads
12 pcs
Bolt
1/4"x10mm 16 pcs
2
*Note:Thispiece comes preassembled for
shippingpurposesand must bedisassembled
tocompleteassembly.
Drawerslider Set
8pcs
Gluetube 1 pc

P.5
Step 1
Copyright
201
9, by Walker Edison Furniture Co., LLC. All rightsreserved.
Sliderbracket
Sliderarm
Sliderbracket
Sliderarm
Q
Q
Pick up the Ball Bearing Slides (Q) and separate the slide Runner for the following Steps.
Extend the Slide Runner all the way forward,press the plastic release lever of the ball bearing
Slides up and pull the Slide Runner Complete out .

P.6
Step 2
Copyright
201
9, by Walker Edison Furniture Co., LLC. All rightsreserved.
QQ
14x2pcs 15x2pcs
17x2pcs
L
LL
L
LL
F
B
B
B
B
G
Secure cam bolt (B) into part (17) ,then using bolt (G) attach handle (F) into part (17) and using
screw (L) attach slider (Q) into parts (14,15),with Philips head screwdriver as per diagram.

Step 3
P.7
Copyright
201
9, by Walker Edison Furniture Co., LLC. All rightsreserved.
Q
Q
L
L
L
L
L
L
L
L
L
L
L
L
78
69
Finished edge
Use screw (L) attach slider (Q) into parts (6,7,8,9),with Philips head screwdriver as per diagram.

Step 4
P.8
Copyright
201
9, by Walker Edison Furniture Co., LLC. All rightsreserved.
78
69
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
B
B
B
B
Finished edge
Insert wooden dowel (A) into parts (6,7,8,9,) ,then secure cam bolt (B) into parts (6,9) with Philips
head screwdriver as per diagram.

P.9
Step 5
Copyright
201
9, by Walker Edison Furniture Co., LLC. All rightsreserved.
3
10
BB
B
B
B
B
BB
B
B
B
B
A
A
A
Insert wooden dowel (A) into part (10) ,then secure cam bolt (B) into part (3) with Philips head
screwdriver as per diagram.

P.10
Step 6
Copyright
201
9, by Walker Edison Furniture Co., LLC. All rightsreserved.
2
5
NN
H
2
Using bolt (N) attach part (5) into part (2) with hex key (H) as per diagram.
Note: Do not tighten all bolts.

Step 7
P.11
Copyright
201
9, by Walker Edison Furniture Co., LLC. All rightsreserved.
H
M
3
2
5
5
5
5
M
M
M
Using bolt (M) attach part (3) into part (5) with hex key (H) as per diagram.

Step 8
P.12
21 3
Copyright
201
9, by Walker Edison Furniture Co., LLC. All rightsreserved.
6
9
10
C
C
C
C
Using cam lock(C) secure parts (6,9) into part (10) with Philips head screwdriver as per diagram.

Step 9
P.13
Copyright
201
9, by Walker Edison Furniture Co., LLC. All rightsreserved.
E
E
E
E
H10
7
8
Using screw (E) attach part (10) into parts (7,8) with hex key (H) as per diagram.

Step 10
P.14
21 3
Copyright
201
9, by Walker Edison Furniture Co., LLC. All rightsreserved.
3
6
7
8
9
10
C
C
C
CC
C
C
CC
C
CC
Using cam lock(C) secure parts (6,7,8,9,10) into part (3) with Philips head screwdriver as per
diagram.

Step 11
P.15
Copyright
201
9, by Walker Edison Furniture Co., LLC. All rightsreserved.
6
7
8
9
6
4
4
E
HE
E
EE
E
E
E
E
EE
E
Using screw (E) attach part (4) into parts (6,7,8,9,10) with hex key (H) as per diagram.

Step 12
P.16
Copyright
201
9, by Walker Edison Furniture Co., LLC. All rightsreserved.
12
11
M
MH
9
2
NN
11
9
M
MNN
H
2
Using bolts (M,N) attach parts (11,12) into parts (2,9) with hex key (H) as per diagram.

Step 13
P.17
Copyright
201
9, by Walker Edison Furniture Co., LLC. All rightsreserved.
H
NN
M
M
6
12
2
H
M
MNN
12
11
6
2
Using bolt (M,N) attach parts (11,12) into parts (6,2) with hex key (H) as per diagram.
Tighten all the bolts.

Step 14
P.18
Copyright
201
9, by Walker Edison Furniture Co., LLC. All rightsreserved.
x2
16
15
14
14
15
13
K
K
K
K
Using screw (K) attach parts (14,15) into part (16) with Philips head screwdriver ,then put part (13)
as per diagram.

Step 15
P.19
2
1
3
Copyright
201
9, by Walker Edison Furniture Co., LLC. All rightsreserved.
x2
14
15
17
C
C
C
C
Using cam lock(C) secure part (17) into parts (14,15) with Philips head screwdriver as per diagram.

Step 16
P.20
Copyright
201
9, by Walker Edison Furniture Co., LLC. All rightsreserved.
D
D
D
D
Place sticker (D) cover the holes as per diagram .
