Walker Edison DBM1 User manual

Item #: DBM1
Assembly Instructions
For our most current instructions, to request missing, lost or broken parts, or for any other Customer
Service issues, please visit our website at www.walkeredison.com or call us at 877-207-5906.
Revised 12/2011

General Assembly Guidelines
I. Insure that all parts and hardware are available before beginning assembly.
II. Follow each step carefully to insure the proper assembly of this product.
III. Two people are recommended for ease in the assembly of this product.
IV. The main types of hardware used to assemble this product are wood dowels, nuts, bolts
and washers.
V. Power tools should not be used to assemble this product.
P.2

Parts List

Hardware List
Wrench

Insert dowels (A) into crossbars (3).
Insert nuts (C) into crossbars (3). Attach crossbars (3) to leg piece (2) using bolts (B). Tighten bolts (B) with
wrench (G). Bolts (B) will screw directly into nuts (C).

Insert nuts (C) into opposite ends or crossbars (3). Attach crossbars (3) to second leg piece (2) using bolts (B).
Tighten bolts (B) with wrench (G). Bolts (B) will screw directly into nuts (C).
Insert end caps (4) into leg pieces (2) using pre-inserted dowels as guides.

Attach leg pieces (2) to bench top (1) using bolts (D), spring washers (E) and washers (F). Tighten all bolts (D)
with wrench (G).
