Walker Edison W52AV2D User manual

Item # : W52AV2D
Assembly Instructions
  

Revised 04/2017
P.1

Secure cam bolt (B) to side panel faceplate (7,8) and top panel (1).
Insert wooden dowel (A) into side panel (3,4,5,6).

Insert side panel faceplate (7,8) into side panel (5,6), then insert and secure cam lock (C) to
side panel (5,6) to lock it.
Use wrench (R) to secure bottom panel (2) to side panel (3,4,5,6) with bolt (D).

Insert back panel (11,12) through side panel (3,4,5,6).
Insert top panel (1) into side panel (3,4,5,6), then insert and secure cam lock (C) to side panel
(3,4,5,6) to lock it.

Insert leg (15) into support bar (16), use wrench (R) to secure support bar (16) with washer (G)
and bolt (F).
Use wrench (R) to secure leg (15) and support bar (16) to bottom panel (2) with washer (G)
and bolt (E).

Secure plastic wedges (J) to back panel (11,12) with screw (K).
Place sticker (Q) over holes as per diagram.

Insert shelf support pin (H) to side panel (3,4,5,6), place shelf (9,10) on top of shelf support pin
(H).
Attach handle (N) to door (13,14) with bolt (P). Secure hinge (L) to door (13,14) with screw (M).

3
4
Secure hinge (L) to door (13,14) to side panel (3,4) with screw (M)
