Wampat W01E3157R User manual

W01E3157R W01E3158W
Assembly Instructions

1-2

1
1
2
3
4
5
6
7
10
15
8
9
11
12
12
13
14
15
16
x 4
17
18
19
20
21

２
Tools Required
(Not included)
Shelf support pin
Screw Screw
Screw
ABCD
I
FGH
E
N
K L M
R
O
Q
J
S
Cam lock
Cam bolt Wooden dowel
Plastic wedge
with screw PVC nail with pin
Handle with bolt
Wrench Wrench
Drawer slider
Cam lock
x 42 x 26 x 29 x 4
x 24
x 10 x 6 x 4
x 1
x 16
x 1 x 1 x 2
x 8
x 48
x 2
x 4
x 2
Handle with screws
Px 4

３
1
· Screw cam bolts (A) into panels (1,2,9).
A
A
2
1
9
Ax 20

4
2
x 4
· Screw cam bolts (A) into panels (3,4,5,6,17).
3
4
5
6
17
A
A
x 22

5
3
x 8
· Separate the slide bracket from the slide arm as per diagram.
Step 1
Step 2
R
R
R2
R1
Slider arm
Slider bracket
x 8

4
6
· Attach Slider arms to panels (3,4,5,6) with screws (O) correctly.
3
4
5
6
O
O
Mounting holes
OPEN
x 24

5
7
· Screw parts (H) to panel (13) using parts (K,L) .
HH1 H2 H3 H4
K
L
H1
H2
H3
H4
13
14
H K L
x 4 x 1 x 1

6
8
· Insert dowels (C) into panels (12).
· Attach panels (12) to panels (3,4,5,6).
· Insert and secure cam locks (B) to panels (12) to lock it.
B
C
3
5
6
4
12
12
CB
x 4 x 4
1 2 3

7
9
· Insert dowels (C) into part (13).
· Attach part (13) to parts (3,4).
· Insert and secure cam locks (B) to part (13) to lock it.
3
5
6
4
13
B
C
CB
x 2 x 2
1 2 3

8
10
· Insert dowels (C) into panels (3,4,5,6).
· Attach panel (2) to panels (3,4,5,6) with screws (E).
C
3
5
6
4
2
E
E
CE
x 8 x 8

1 2 3
9
11
· Insert dowels (C) into panels (7,8).
· Attach panel (9) to panels (7,8).
· Insert and secure cam locks (B) to panels (7,8) to lock it.
9
7
8
CB
B
C
x 2 x 2

1 2 3
10
12
· Insert dowels (C) into panels (2).
· Attach panels (7,8,9) to part (2).
· Insert and secure cam locks (B) to panels (7,8,9) to lock it.
· Knock pins (G) into panels (7,8,9).
8
7
9
2
B
C
CB
G
G
x 4 x 8 x 6

11
13
· Carefully slide part (15,16) into place along the back of the assembly.
15
16
15

1 2 3
12
14
· Insert dowels (C) into panels (3,4,5,6,13).
· Attach panel (1) to panels (3,4,5,6,13).
· Insert and secure cam locks (B) to panels (3,4,5,6,13) to lock it.
1
4
3
5
6
13
B
C
CB
x 9 x 10

13
15
· Secure parts (F1) with screws (F2) as per diagram.
F
F1 F2
F2 F1
x 10

14
16
· Attach panels (18,19) to panel (20) with screws (I).
· Carefully slide panel (21) into place along the bottom of the assembly.
x 4
20
18
19
I
I
21 19
x 16

15
17
x 4
· Attach parts (P1) to panels (17) with screws (P2).
The slot is on
the lower side.
P
17
P1
P2
x 4

1 2 3
16
18
x 4
· Attach part (17) to panels (18,19).
· Insert and secure cam locks (N) to panels (18,19) to lock it.
N
17 19
18
Nx 16
