Wampat A-SCT0891W User manual

A-SCT0891W
Assembly Instructions
All manuals and user guides at all-guidesbox.com
all-guidesbox.com

All manuals and user guides at all-guidesbox.com

1
2
3
4
5
6
7
8
12
11
9
10
13
7
10
10
12
13
１
All manuals and user guides at all-guidesbox.com

1 2
1 2
● The provided glue(I) is to
secure wood dowels(A) in place .
When first inserting dowels,
locate the appropriate hole for
the dowel , place a small amount
of glue in the hole and insert the
dowel . Wipe away excess glue
immediately.
● In future assembly steps when
dowels are necessary to attach
assembly parts together,place a
small amount of glue on the end
of the dowel before attaching
parts together. Wipe away
excess glue immediately.
Wooden dowel
Ø8x30mm
A x 20
Cam bolt
Ø6x35mm
B x 16 C x 16
Cam lock
Ø15x11mm
D x 16
Sticker
E x 2
Plate
F x 6
G x 12 H x 4
Screw
Ø4x15mm
Shelf support pin
Ø8x5x16mm
Bolt Glue tube
I x 1
Ø4x50mm
J x 6 K x 8
Plastic wedge
L x 8
Flat-head screwScrew
Ø3x17mm
Hexagon socket key
M 4
M x 1
Ø6x13mm
N x 16 O x 2 P x 2
Pulley
Bolt
Philips head screwdriver
required for assembly
(not included)
Ø6x13mm
Q x 1 R x 1
S x 1 T x 1
Handle bolt
Ă4x19mm Handle Screw Ø4x12mm
Screw
Ø4x25mm
U x 1
Plastic strap Nut
２
All manuals and user guides at all-guidesbox.com

Ø6x35mm
· Screw parts (B) into panels (8,9).
9
8
B
B x 8
３
All manuals and user guides at all-guidesbox.com

1 2 3
Ø8x30mm Ø15x11mm
· Insert dowels(A) into panels(3,5).
· Attach panel (9) to panel (5).
Attach panel (8) to panel (3).
· Insert and secure cam lock (C) to panels
(3,5) to lock it.
5
9
3
8
A C A x 4 C x 6
４
All manuals and user guides at all-guidesbox.com
all-guidesbox.com

Ø8x30mm Ø15x11mm
A x 2 C x 2
1 2 3
3
5
6
A
C
· Insert dowels(A) into panels(3,5).
· Attach panel (6) to panels (3,5).
· Insert and secure cam lock (C) to panel
(6) to lock it.
５
All manuals and user guides at all-guidesbox.com

Ø4x50mmØ8x30mm
J
3
5
4
· Insert dowels(A) into panels(3,4,5).
· Attach panels (3,4,5) to panel (2)
using screws(J).
2
A
A x 6 J x 6
６
All manuals and user guides at all-guidesbox.com

13
12 13
12
N
· Attach parts (12) to parts (13)
using Bolts(N).
M 4 Ø6x13mm
M x 1 N x 8
７
All manuals and user guides at all-guidesbox.com

Ø6x13mm
· Attach parts(12,13) to panel(2) using Bolts(N). N x 8
2
N
12
12
13
13
８
All manuals and user guides at all-guidesbox.com

H x 4
Ø6x13mm
O x 2 P x 2 Q x 1
Ă4x19mm
· Attach parts(O) to panel (11) using
bolts(H).
· Attach part(Q) to panels(11) using
bolts(P).
９
H O
11
P
Q
All manuals and user guides at all-guidesbox.com
all-guidesbox.com

１０
· Slide panel (11) into designated area.
6
11
All manuals and user guides at all-guidesbox.com

１１
Ø4x15mm
E F
· Attach parts(E) to back of panel (11)
using screws(F) as shown. 11
5
3
E x 2 F x 6
All manuals and user guides at all-guidesbox.com

１２
·Carefully slide panels (7) into place
along the back of the assembly.
7
7
All manuals and user guides at all-guidesbox.com

１３
Ø6x35mm
· Screw parts (B) into panel (1).
B x 8
B
1
All manuals and user guides at all-guidesbox.com

１４
1 2 3
Ø8x30mm Ø15x11mm
· Insert dowels(A) into panels(3,4,5,6).
· Attach panel (1) to panels (3,4,5,6).
· Insert and secure cam lock (C) to panels
(3,4,5,6) to lock it.
A x 8 C x 8
1
6
5
4
3
A
C
All manuals and user guides at all-guidesbox.com
all-guidesbox.com

１５
Ø3x17mm
K
L
· Secure parts(K) using Screws(L).
7
7
K x 8 L x 8
All manuals and user guides at all-guidesbox.com

１６
Ø8x5x16mm
· Attach panel(10) to panels(4,5) using parts(G).
Finished edge
G x 4
G
5
10
All manuals and user guides at all-guidesbox.com

１７
Ø8x5x16mm
· Attach panels (10) to panels(3,4) using parts(G).
Finished edge
Finished edge G x 8
3
G
10
10
4
All manuals and user guides at all-guidesbox.com

１８
1 2 3
WARNING
Ø4x12mm Ø4x25mm
Wall
R x 1 S x 1 T x 1 U x 1
Serious or fatal injuries can occur from furniture tipping over. To prevent the furniture from
tipping over we recommend that it is permanently fixed to the wall. Wall anchor and
hardware are included with this product. Please make sure hardware is suitable for your
walls before installing, as different wall materials may require different types of anchors.
S
1T
R
U
All manuals and user guides at all-guidesbox.com
