Wano vG-BLreader 2 User manual

Remote reader vG-BLreader 2
User manual

Technical data
•Dimensions: 79 x 125 x 15.5 mm,
•Works for: PIN code, Mifare 13.56 MHz card,
emergency key, TTlock, TThotel or TTrenting
mobile application and fingerprint (optional)
•Material: aluminum, tempered glass,
•Reading range: 0-10 mm,
•Reading time: ~ 1.5s
•Internal memory for 20,000 users
•IP66 protection,
•Power supply 12V DC 500mA (not included)
•Relay for controlling the actuator (500mA) NC / NO,
•Working temperature: -20°C to + 70°C,
•Communication: Bluetooth 4.1
Page | 2 www.wano.pl

Page | 3
www.wano.pl
1 x remote reader vG-BLreader 2 1 x Wire
1 x Instruction
1 x Strike
1 x Mounting plate
Screws
Kit content
Scheme

www.wano.pl
Fix the mounting plate with 4 screws.
Page | 4
Drill a hole in the appropriate place to make
room for connecting the cable to the power
source.
Montage

Attach the clip to the mounting plate
with 2 screws.
Install the reader on the hook and attach it
to the mounting plate with the screw on
the bottom.
www.wano.pl
Page | 5

Page | 6
www.wano.pl
Wiring description
•+12V DC: Red
•GND : Black
•NC: Orange
•COM: Yellow
•NO: Green
•SW: Blue
•IN: Purple
•OUT: White
•BELL: Grey
•BELL: Brown

strona | 7
www.wano.pl
Connection diagram for the exit button

Page | 8
www.wano.pl
Diagram of connection of the NC aversive electric strike

Page | 9
www.wano.pl
Diagram of connection of the NO reverse electric strike

Pairing the reader with the application
Touch a panel to highlight it and activate the lock.
Activate the TTlock application after the voice
command "Add Bluetooth administrator".
Page | 10 www.wano.pl

Page | 11 www.wano.pl
Click icon “三” at the top left corner and select
"Add lock", and "All locks".
To add a reader, first wake up the device by touching
the keyboard. Thanks to this, the device will appear in
the application and it will be possible to assign it to our
account through the visible plus icon.

Page | 12www.wano.pl
Switching on permanent backlight
1. Turning on permanent backlight
To turn on permanent backlight it is necessary to
type in code *49#administrator code#1#
2. Turning off permanent backlight
To turn on permanent backlight it is necessary to
type in code *49#administrator code#0#

•WARRANTY FOR 24 MONTHS
•THE READER IS RESISTANT TO WEATHER CONDITIONS, IT IS USED FOR
INTERNAL AND EXTERNAL USE
•CLEANING WITH A SLIGHTLY HUMID CLOTH, OR WITH A LIQUID FOR
WINDOWS
•THE KEYBOARD MUST NOT BE EXPOSED TO MECHANICAL DAMAGES
•WHEN THE READER IS STRONGLY EXPOSED TO ADVERSE ATMOSPHERIC
CONDITIONS, A SPECIAL PROTECTIVE CANOP MUST BE APPLIED
•USE 12V POWER SUPPLIES WITH AMPERAGE EQUAL TO OR GREATER THAN
500mA
Warranty
ul.Jana III Sobieskiego 80B
62-030 Luboń, Polska
tel. [phone]
email: [email protected]
www.wano.pl
