Hardware Guide 1
Hardware Specifications
The WatchGuard® AP family of wireless access points provide secure, reliable, wireless communications while
delivering high performance and broad coverage—a perfect combination of services to meet the needs of
enterprise-level customers, small businesses, branch offices, campuses, and hotels alike.
Internal antennas, slim cases, minimalist labeling, and small LEDs, coupled with flexible mounting options,
make these devices ideal for low profile wireless deployment scenarios.
WatchGuard AP322 devices are intended for outdoor use and feature MIMO 802.11ac Wave 1 capability, and
dual radios that supports 2.4GHz (802.11b/g/n) and 5GHz (11a/n/ac) to provide wireless clients with enhanced
reliability and performance. Power can be provided by any Power over Ethernet (PoE+) power source.
There are two ways you can manage your AP322 device:
Total Wi-Fi and Secure Wi-Fi with WatchGuard Wi-Fi Cloud
A powerful cloud-based enterprise wireless management solution for AP configuration, security, and
monitoring.
Basic Wi-Fi with WatchGuard Firebox Gateway Wireless Controller
Local management, configuration, security, and monitoring of APs directly from your WatchGuard
Firebox. The WatchGuard Firebox requires Fireware v11.12.2 and higher.
For more information about how to set up and manage your WatchGuard AP, you can find documentation
online at: https://www.watchguard.com/help
Package Contents
WatchGuard AP
Quick Start Guide
Wall-mount and pole-mount accessories

2WatchGuard AP322
Hardware Specifications
About Your Hardware
Hardware Specifications
Environmental Requirements
To safely install your WatchGuard AP, we recommend that you:
Install the device indoors or outdoors, preferably under cover.
Make sure the device has adequate clearance for air flow and cooling.
Other environmental requirements:
AP322
Radio Type and
Frequency Band
2.4GHz, 802.11b/g/n. Max data rate: 450 Mbps
5GHz, 802.11a/n/ac. Max data rate: 1.3 Gbps
Antenna Six integrated omnidirectional antennas
EIRP 
(Effective Isotropic
Radiated Power)
28.77 dBm
Ethernet interface 1 x 10/100/1000 Mbps Gigabit Ethernet (LAN1)
802.3at PoE+
1 x 10/100/1000 Mbps Gigabit Ethernet (LAN2) for wired
extension. The LAN2 port cannot be used for link
aggregation.
Power Interface LAN1 PoE+: 19W (802.3at)
Power
Consumption
Max: 19 W
Min: 11W
Average: 16W
MTBF Rating 157,108 hrs at 50°C
531,809 hrs at 25°C
Dimensions 210mm × 210mm × 67mm
Weight 3.22 lb. (1.46 kg)
Operating temperature -20°C to 55°C (-4°F to 131°F)
Operating relative humidity 5% to 95% non-condensing
Non-operating temperature -40°C to 70°C (-40°F to 158°F)
Non-operating relative humidity 5% to 95% non-condensing

Hardware Guide 3
Hardware Specifications
Hardware Description
Device Connections and Buttons
Ethernet Network Interfaces
LAN1: Standard RJ45 connector that supports link speeds of 10/100/1000 Mbps and PoE+
connectivity. The WatchGuard AP322 can be powered by an 802.3at PoE+ connection on the LAN1
interface.
LAN2: Standard RJ45 connector that supports link speeds of 10/100/1000 Mbps. This interface can be
used as a wired extension for a wireless SSID that has NAT enabled. For more information on how to
configure NAT settings for an SSID, see the WatchGuard Wi-Fi Cloud Help. 
The LAN2 port cannot be used for link aggregation.
For APs managed locally by a Gateway Wireless Controller with Fireware v12.2.1 and higher, you can
bridge together the LAN ports on AP models that have two LAN interfaces. This enables you to extend
the wired network on the second LAN interface. For more information, see the Fireware Help.
Reset Button
Resets the WatchGuard AP to factory-default settings. You must use a paper clip or other small object
to press the reset button through the hole.
To reset the device to factory-default settings, power cycle the device (remove the power cable and
reconnect it again). While you reconnect the power source, press and hold the reset button for at
least 60 seconds until the power, LAN1, and 2.4 GHz indicators are green.

4WatchGuard AP322
Hardware Specifications
Device Indicators
The side of the WatchGuard AP322 has these status indicators:
AP Firmware 8.8.1 and Higher
LED
Status
Power LAN 1 and
LAN2
2.4 GHz and 5 GHz
Radios
Off Powered off. No Ethernet
link.
Radio inactive.
Green Powered on. Operating at normal
power and capabilities.
(PoE+ or DC power)
Connected at
10/100/1000
Mbps.
Radio active.
Flashing
Green
Not connected to Wi-Fi Cloud or
paired with a Gateway Wireless
Controller.
--
Orange Powered on. Operating at reduced
power and capabilities.
(For example:PoE 802.3af on PoE+
802.3at capable APs).
See AP Power Requirements.
- -
Flashing
Orange
No IP address received from DHCP. - -

Hardware Guide 5
Hardware Specifications
AP Firmware 8.8.0 and Lower
Device Indicators in AP Mode
Device Indicators in WIPS Mode
These indicators are active when the AP is set to dedicated WIPS (Wireless Intrusion Prevention System) mode.
For more information about WIPS mode, see the WatchGuard Wi-Fi Cloud help.
Power LAN1 LAN2 2.4 GHz 5 GHz Description
Solid green Solid green On/Off Any Any Powered on and operating
correctly. Connected to
WatchGuard Wi-Fi Cloud services.
Solid green Slow flash
green
On/Off Any Any Software upgrade in progress.
Solid amber Solid green On/Off Any Any No Ethernet link.
Solid amber Fast flash
green
On/Off Any Any Did not receive a valid IP address
from DHCP.
Solid amber Slow flash
green
On/Off Any Any Cannot connect to WatchGuard 
Wi-Fi Cloud services.
Off Off Off Off Off Not powered on or in startup
process.
Power LAN1 LAN2 2.4 GHz 5 GHz Description
Solid green Solid green On/Off Solid
green
Solid
green
Powered on and operating
correctly. Connected to
WatchGuard Wi-Fi cloud
services.
Solid green Slow flash
green
On/Off Slowflash
green
Any Software upgrade in process.
Solid amber Solid green On/Off Solid
green
Any No Ethernet link.
Solid amber Fast flash
green
On/Off Fast flash
green
Any Did not receive a valid IP
address from DHCP.
Solid amber Slow flash
green
On/Off Slowflash
green
Any C annot connect to
WatchGuard Wi-Fi Cloud
services.
Off Off Off Off Off Not powered on or in startup
process.
Solid green Solid green On/Off Solid
Green
Solid
green
Sensor is troubleshooting on
802.11b/g/n
Solid green Solid green On/Off Solid
Green
Fast flash
green
Sensor is troubleshooting on
802.11a/n/ac
Solid green Solid green On/Off Solid
Green
Fast flash
green
Sensor is troubleshooting on
both 802.11b/g/n and 802.11a/
n/ac
Solid green Solid green On/Off Solid
Green
Solid
green
Sensor is performing intrusion
prevention on 802.11b/g/n

6WatchGuard AP322
Hardware Specifications
Mounting Instructions
Your package includes the AP322 device, pole-mount, and wall-mount accessories.
Pole Mount Installation
Use the supplied pole-mounting accessories to install the AP322 on a pole.
The MAC address and serial number of your AP are printed on a label on the back of the device. 
Make sure you record this information before you mount the AP.
1. Place the AP on the pole.
2. Insert the straps in the slots on the AP and wrap around the pole.
3. Fasten the screws and make sure the AP is firmly attached to the pole.

Hardware Guide 7
Hardware Specifications
Wall Mount Installation
Use the supplied wall-mounting accessories to install the AP322 on a wall.
The MAC address and serial number of your AP are printed on a label on the back of the device. 
Make sure you record this information before you mount the AP.
1. Drill holes on the wall for the anchors.
2. Insert the four anchors.
3. Affix the mounting bracket to the wall.
4. Attach the AP to the mounting bracket.
5. Insert screws in the slots of the mounting bracket
6. Fasten the screws.

8WatchGuard AP322
Hardware Specifications
Connect the AP
You can power the WatchGuard AP322 with an 802.3at PoE+ connection.
To power on and connect the AP322 to the network with PoE+:
1. Connect one end of the network interface cable to the LAN1 port on the AP322.
2. Connect the other end of the network interface cable to an Ethernet jack that provides 802.3at PoE+
power.
