Installation and
Operation Manual
This equipment must be installed and serviced by a qualified technician.
Improper installation may result in property damage, serious injury or death.
Improper installation and/or operation will void the warranty.
Notice to Installer
This manual contains important information about the installation, operation and
safe use of this product. Once the product has been installed this manual must
be given to the owner/operator of this equipment.

SAFETY INFORMATION
1. The Waterco MultiCyclone lters are designed to work with water at a temperature > than
0ºC and < than 45ºC. The lter should never be operated outside of these temperatures or
damage may occur.
2. The installation should be carried out in accordance to local safety standards and bylaws.
3. Any modication of the lter requires the prior consent from Waterco. Original replacement
parts and accessories authorised by the manufacturer ensure a high level of safety. Waterco
assumes no liability for the damage and injuries caused by unauthorised replacement parts
and accessories.
4. The user should make sure that the installation is carried out by qualied authorised persons
and that these persons have rst carefully read the following instructions.
5. The operating safety of the lter is only guaranteed if the installation and operation
instructions are correctly followed.
6. In the event of defective operation or fault, contact Waterco or its nearest authorised service
agent.
7. To reduce the risk of injury, do not permit children to use this product.
8. Incorrectly installed equipment may fail, causing severe injury or property damage.
9. Chemical spills and fumes can weaken Swimming Pool / Spa equipment. Corrosion can
cause lters and other equipment to fail, resulting in severe injury or property damage. Do
not store pool chemicals near your equipment.
SAFTEY INFORMATION ------------------------------------------ 01
MULTICYCLONE -------------------------------------------------- 02
MULTICYCLONE TOTAL HEAD LOSS CURVE ------------------ 04
INSTALLATION ---------------------------------------------------- 04
START UP PROCEEDURES -------------------------------------- 08
MULTICYCLONE FILTER MAINTENANCE ----------------------- 09
INSUFFICIENT WATER PRESSURE ------------------------------ 10
GENERAL MAINTENANCE GUIDE ------------------------------ 11
WINTERISING ----------------------------------------------------- 12
TROUBLESHOOTING GUIDE ------------------------------------ 13
WARRANTY ------------------------------------------------------- 13
I pg 01
MultiCyclone

I pg 03
MultiCyclone
MULTICYCLONE
MultiCyclone is a brilliant preltration device that can save
water and minimise pool lter maintenance. Based on
the principals of centrifugal water ltration, MultiCyclone
lters up to 80% of the pool’s dirt load before it reaches
the pool lter and only requires 15 litres (4 gallons) of water
to cleanse.
• Minimisesltermaintenanceandsaveswater.
• Noltermediatocleanorreplace.
• Multiplehydrocyclones.
• Suitablefornewandexistinginstallations.
Centrifugal Water Filtration
Incoming water tangentially enters its multiple hydrocyclones, generating a strong centrifugal
effect. Approximately 80% of the incoming dirt load is spiralled down to its clear sediment
chamber. The outgoing water is piped to the nally polished via the pools ltration system.
Simple maintenance
The MultiCyclone sediment chamber is easily cleaned by opening its purge valve. Only 15 litres
(4 gallons) of water is discharged.
Minimise Sand Filter Backwash Frequency
The installation of a MultiCyclone as a pre-lter to a sand lter can reduce its backwash
frequency to once per year, resulting in a saving of up to 7000 litres (1850 gallons) of water per
year for an average domestic sized swimming pool.
Minimise Filter Cartridge Cleaning and Replacement
The installation of a MultiCyclone as a pre-lter to a cartridge lter can reduce lter cartridge
cleaning and replacement to once per swimming season and even up to once per year,
depending on the size of the cartridge lter.
Air Release Valve
MultiCyclone Housing Lid
Clear Poly Carbonate
Sediment Chamber
Water Flow
M/C 12: 40mm/50mm (EU)
1 ½” Quick Fit Union.
M/C 16: 50mm/63mm (EU)
2” Quick Fit Union.
12 / 16 Hydrocyclones
Filter Housing Retaining Clamp Band
25mm / 32mm (EU)
1” Purge Valve
M/C 12: 40mm/50mm (EU)
1 ½” Quick Fit Union.
M/C 16: 50mm/63mm (EU)
2” Quick Fit Union.
The accumulation of sediment can be visibly monitored through the MultiCyclone clear sediment
chamber. The Multicyclone sediment chamber is cleaned by simply opening the purge valve.
Only 15 litres (4 gallons) of water is discharged to clean the Multicyclone of sediment
Note: The MultiCyclone centrifugal section is designed to lter sediment that is heavier than
water; oating debris cannot be ltered out by centrifugal ltration.
Model Connection Ports Minimum Flow Maximum Flow Max. Pressure
MultiCyclone 12 40mm / 50mm (EU) /
1 1/2” Quick Fit Union
40lpm / 2.4 m3/hr /
11gpm
300lpm / 18m3/hr /
79gpm 350 kPa (50psi)
MultiCyclone 16 50mm / 63mm (EU) /
2” Quick Fit Union
50lpm / 3 m3/hr /
13gpm
500lpm / 30m3/hr /
132gpm 350 kPa (50psi)

I pg 05
MultiCyclone
INSTALLATION
Be sure to comply with the local plumbing codes.
Be sure that all provisions for wastewater disposal meet local, state or national codes. Do not
discharge water where it will cause ooding or damage.
If the incoming water pressure is higher than the maximum operating pressure of 350kPa /
3.5Bar / 50psi, a Pressure Regulating Valve (PRV) must be installed upstream of the lter inlet.
ThePRVshouldbesetto90%ofthemaximumoperatingpressureofthetank.
If the incoming water ow is less than the lter’s minimum ow requirements, the lter’s ltration
efciency will be affected, please consult Waterco.
Typical Installation
1. Position the lter as close to the Swimming Pool / Spa as possible.
2. Position the lter so that it is free from ooding, away from sumps, guttering, garden hollows,
etc.
3. Position the lter so that the piping connections purge valve and air release valve is
convenient and accessible for operation, servicing and winterising.
4. Ensure that the compliance label is facing the front to allow easy identication.
5. The lter should be placed on a level concrete slab, very rm ground, or equivalent. Ensure
that the ground will not subside, preventing any strain from the attached plumbing.
6. Ensure that there is no movement of the lter during operation of the Purge valve.
7. Allow sufcient clearance around the lter to permit visual inspection of the entire system.
Typical Installation with a Sand Filter Typical Installation with a Cartridge Filter
MultiCyclone 12 MultiCyclone 16
0
1
2
3
4
5
6
7
8
9
0 100 200 300 400 500 600 700
Head Loss (m)
Flow lpm
MultiCyclone Head Loss Curve
MULTICYCLONE PLUS TOTAL HEAD LOSS CURVE

I pg 07
MultiCyclone
Optional Mounting Stand (200373)
An optional mounting stand is also available for situations where the MultiCyclone cannot be
installed directly above your pool pump.
Installation with optional Mounting Stand
Screw the supplied half barrel unions and tails onto the inlet and outlet before gluing the UPVC
piping onto the lter.
Use only recommended glue for connection pipe and fittings
Cut and t the pipe and ttings onto the MultiCyclone and the pump. Refer to Pump Installation
Manual for correct pump plumbing procedures.
It is best practice to t all the cut pipe and ttings onto the ltration system before gluing; this
will ensure that the system has been aligned correctly.
Glue the pipe and ttings onto the pump, lter and pool return lines and allow the glue to set
for 24 hours before commissioning the system.
Plumbing Connection
1. Ensure that a foot valve / non return valve is installed if the pump is installed 500mm / 20”
above the water level.
2. If the lter is installed below the water level or connected to mains water, isolation valves
should be installed at the inlet and outlet of the lter. This will prevent water ow during any
routine maintenance.
3. Minimise the length of pipe and the number of ttings to minimise restrictions to water ow.
4. ConnectthepipeextendingfromthepumpoutlettotheinletoftheMultiCyclone.
5. ConnectfromthepipeextendingfromtheoutletoftheMultiCyclonetothenextcomponent
in line with the ltration system.
6. Glue all plumbing to barrel union ttings in accordance with glue (solvent) manufactures
specicationsandallow24hourstoset.Ensureglue(solvent)isnotexcessivelyappliedto
ttings as this could run onto “o”-rings and create sealing problems.
Note: Waterco recommends that a shut off valve be installed after the MultiCyclone on the pool
return line to assist with ushing out the collected debris. Please refer to “Insufcient Water
Pressure”.
7. Connect to Waste Line. Glue the plumbing from the Sediment Purge Valve to a waste line,
drain or suitable drainage area.
8. Turn on pool pump. Be sure to check that there are no leaks from the connectors. If required,
tighten by hand.
!
Plumbing
1. Check that the incoming water pressure is within the lter’s recommended working pressure
and ensure that a pressure limiting valve is installed if using mains water or a high pressure
pump.
2. Ensure that a foot valve / non return valve are installed if the pump is installed 500mm / 20”
above the water level.
3. If the lter is installed below the water level or connected to mains water, isolation valves
should be installed at the inlet and outlet of the lter. This will prevent water ow during any
routine maintenance.
4. Minimise the length of pipe and the number of ttings to minimise restrictions to water ow.
5. Ensure that all plumbing connections are glued and tightened securely to prevent leaking.
6. Ensuresolventsarenotexcessivelyappliedtottingsasthiscouldruninto“o”-ringsand
create sealing problems.
7. Do not over tighten ttings or adapters.

I pg 09
MultiCyclone
START UP PROCEEDURE
The MultiCyclone is an advanced and highly efcient lter system that will provide years of
trouble free service if the following maintenance procedures are maintained.
Tostartuptheltrationsystemeitherfromneworaftercleaningisexactlythesame.
1. Ensure that the MultiCyclone is plumbed correctly.
2. Ensure that all valves installed before and after the MultiCyclone are open.
3. Loosen the air release valve on top of the MultiCyclone lter.
4. Prime the swimming pool pump. (Refer to the pump installation and operation manual).
5. Turnontheswimmingpoolpumpandallowthepumptorununtilalltheairhasbeenexpelled
from the MultiCyclone. Water will run from the air release valve.
6. Re-tighten the air release valve.
7. The lter is primed and ready for operation.
Note: In some cases this may be required to be done a few times before the unit will remain
primed and be fully operational.
Do not stand over the top of the MulitCyclone whilst adjusting the air release valve to
purge the system of air.
Injury may occur if air release valve becomes loose.
!
MULTICYCLONE FILTER MAINTENANCE
The MultiCyclone Plus lter maintenance is determined by the following conditions:
1. The sediment chamber is half lled with sediment. This accumulation of sediment can be
visibly monitored through the MultiCyclone clear sediment chamber. The MultiCyclone is
cleaned by simply opening the purge valve. Only 15 litres (4 gallons) of water is discharged
to clean the MultiCyclone of sediment.
Flush out the sediment chamber
With pump running:
Whilst the water pump is running simply open the sediment purge valve until the sediment has
been ushed out. This is visible through the clear sediment chamber. Once the sediment has
been ushed out, close the purge valve.
Without pump running:
Alternatively, switch the pump, off. Open the air release valve and then open the purge valve.
The water will drop through the MultiCyclone ushing out most of the debris from the sediment
chamber. Then close the air release valve and turn on the pump and the turbulence of the
water entering the sediment chamber will ush out the rest of the sediment. Once the sediment
chamber has been cleansed, close the purge valve, start the pump and close the air release
valve once water is owing out through the air release valve.

I pg 11
MultiCyclone
Do not close the 2 way valve prior to opening the purge valve and do not close the purge
valve while the 2 way valve is closed or partially closed. Both valves should never be
closed or partially closed at the same time.
If the MultiCyclone is installed as a pre-lter to a sand lter, water ow to the sand lter can be
closed via the sand lter’s multiport valve.*
Installation with 2 way shut off valve Cartridge Filter
*NOTE: This position is
not available on 4-Way
Multiport Valves.
INSUFFICIENT WATER PRESSURE
In situations where the water ow from the pump is not powerful enough purge the sediment
out of the sediment chamber. Waterco recommends tting a 2 way valve after the MultiCyclone
on the pool water return line.
The 2 way valve is used to throttle the ow of water out of the MultiCyclone, increasing water
turbulence through the sediment chamber and improving its purging action.
Whilst the pump is operating, open the purge valve, and then partially close the 2 way valve,
throttling the water ow sufciently to purge the sediment chamber of trapped sediment. Once
the sediment chamber is clean, open the 2 way valve and then close the purge valve.
!
GENERAL MAINTENANCE GUIDE
ToensurethemaximumlifeoftheMultiCyclone,pleasefollowtheproceduresbelow:
1. Visually monitor through the MultiCyclone clear sediment chamber. Clean sediment chamber
when accumulated sediment is half full.
2. Maintain a correct chemical balance of your pool / spa water. The chemical balance of water
is a relationship between its pH, total alkalinity, calcium hardness and water temperature.
The water must be maintained at all times to the following:
PHLEVEL  :BETWEEN7.2&7.8.
TOTALALKALINITY :BETWEEN80&150ppm.
CALCIUMHARDNESS :BETWEEN150&300ppm.
Also,withinthesetolerancesbebalancedtotheLangelierSaturationIndexwithinarangeof
-0.2 to +0.2.
Note: Testing kits are available to test the water yourself or alternately bring a sample of the
water to a professional pool and spa shop.
3. Mains water and rural water supplies need to be monitored. Saturation (life) in mains water
or bore (rural) will vary depending on water quality.
4. To prevent damage to the pump and lter and for proper operation of the system, clean
pump strainer and skimmer baskets regularly.
5. Replace the pressure gauge if faulty readings are observed.

I pg 13
MultiCyclone
WARRANTY
MultiCyclone is covered by a 2 year warranty and 1 year warranty on labour. Commercial
installations are covered by a 1 year warranty.
Please refer to Waterco’s warranty terms and conditions.
TROUBLESHOOTING GUIDE
Symptoms Possible Problems / Solutions
WaterIsNotClear
Insufcient disinfectant level.
Incorrect pool chemistry.
Heavy bathing and/ or dirt loads.
Incorrect ow.
Insufcient running times. (Increase pump run time.)
Filter is dirty. (Clean per instructions.)
Hole in lter element.
Air leak on suction line
Pump impeller vanes blocked
Other restrictions include (pool suction cleaners) resistance from other inline
equipment such as strainers.
Pump not primed.
Low Water Flow
Check strainer baskets for debris.
Check for air leaks on suction side.
Check for restrictions or blockage in either suction or return lines.
System lter needs to be cleaned or replaced.
Pool water level too low.
Pump not primed.
Pump impeller vanes blocked.
Strainer baskets not being used and/ or not being cleaned regularly.
Pump operating under speed (low voltage).
Short Filter Cycles
Presence of algae, check disinfectant content.
Check pH and total alkalinity.
Pumpoutputexceedsdesignowrateoflter,checkpumpperformance.
Ineffective cleaning, check conditionsof sediment chamber.
High Pressure on
Start Up
Small eyeball tting in Pool/ Spa.
Partially closed valve on return line.
Too large of pump, check selection.
WINTERISING
Proper winterising procedures should always be taken in order to protect your lter in cold
climates (temperatures below freezing point).
1. Switch off the Pump / Close the inlet valve.
2. Open the air release valve and open the purge vale to allow water to ow out of the
MultiCyclone.
a. Sand Filter, move the Multi Port Valve handle to the winterise position
(between lter and waste).
b. Cartridge Filter, open air release valve.
This will allow air to through to all ports.
3. Remove any drain plugs from the pump.
4. Drain water from the pipe work.
