WL2FL MANUAL
Congratulations on your choice of the Waterlogic WL2FL Water Treatment System. The WL2FL
Water Treatment System model dispenses cold, and hot. Every WL2FL Water Treatment System
includes:
High Performance Multi-Stage Filtration
Bio-Cote Anti-Microbial Protection
Firewall Advanced Purification
The Waterlogic WL2FL Water Treatment System provides exceptional quality and great tasting
water with every use.
INTRODUCTION
Carefully read and follow all instructions to ensure proper and efficient operation of your Water
Purification System. Contact Waterlogic or an Authorized Waterlogic Dealer if you have any
questions.
Waterlogic and Authorized Waterlogic Dealers employ trained service personnel who are
experienced in the installation, function and repair of Waterlogic equipment. This publication is
written for use by these qualified individuals. Waterlogic encourages users to learn about products,
however, we believe that product knowledge and service is best obtained by consulting Waterlogic
or an Authorized Waterlogic Dealer.
Waterlogic Water Purification Systems should be combined with selected water treatment
components to create a system specifically tailored for each application by trained and qualified
personnel.
Products manufactured and marketed by Waterlogic and its affiliates are protected by patents.
Waterlogic reserves the right to change the specifications referred to in this Literature at any time,
without prior notice. Changes or modifications not expressly approved by Waterlogic could void the
warranty and user’s authority to operate the equipment.
Waterlogic technical manuals cover voltages of both 120v and 220v for all our markets. Please
ensure that you carefully read the information in this manual and for any parts specific to any
market, refer to your technical agreement or specific part listing.

WL2FL User Manual
Page 3 –Revision EU19-09-2020
TABLE OF CONTENTS
USER GUIDE
•Safety Alert Symbols................................................................4
•Safety Precautions ...................................................................4
•Features and Benefits .............................................................. 7
•Certifications............................................................................8
•Model Designations and General Specifications ..................... 9
•Electrical and Shipping Specifications....................................10
•Operating Instructions...........................................................11

WL2FL User Manual
Page 4 –Revision EU19-09-2020
SAFETY ALERT SYMBOLS
Read and follow all safety information carefully. The signal words used in this manual are selected as
shown below and based on an assessment of the degree of potential injury or damage (severe or
minor) and the occurrence of injury (definitely occurs or has the potential to occur) when the
warning is ignored:
DANGER!
Indicates a situation which, when not avoided, results in death or severe injury.
WARNING!
Indicates a situation which, when not avoided, has the potential to result in death or severe
injury; and/or severe property damage.
CAUTION!
Indicates a situation which, when not avoided, results or has the potential to result in minor
injury; and/or minor property damage.
SAFETY PRECAUTIONS
Basic safety precautions should be followed, including the following:
Ensure all local, state,and federal laws and codes including health and safety guidelines are met
when installing Waterlogic Equipment. Only qualified service technicians should attempt
installation and service of Waterlogic Equipment. Always read the entire operating
instructions beforeusing the appliance and save these instructions for future use.
DANGER! This product can cause death or severe injury if incorrectly operated, installed or
maintained. The installation, maintenance, sanitizing and any repair must be performed by
qualified persons trained by Waterlogic International or their approved distributors only. Do not
remove any panel or cover to protect against electrical shock and exposure to UVradiation.
DANGER! ELECTRICAL SHOCK HAZARD. Always use a dedicated and properly earthed outlet.
Unit should be protected by ground-fault circuit interrupter (GFCI) or residual current device (RCD)
having a rated residual operating current not exceeding 30mA. Use only Waterlogic supplied
power cord. Never use extension cords or power strips to connect unit. Do not use if the power
supply cord is damaged. Always unplug from power supply prior to servicing.
WARNING! AUTHORIZED USE ONLY. This appliance is to be used for its intended purpose as described
in this manual, and untrained individuals who use this manual assume the risk of any resulting property
damage or personal injury. This appliance can be used by children aged from 8 years and above and
persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they
have been given supervision or instruction concerning use of the appliance in a safe way and understand
the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall not
be made by children without supervision. This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction concerning use of the appliance by a person
responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.

WL2FL User Manual
Page 5 –Revision EU19-09-2020
WARNING! SUPERVISE CHILDREN. Keep appliance and cord out of reach of children under the
age of 8years. Children under the age of 8 years must not use or play with theappliance.
WARNING! UV-C EMITTER (UV LAMP). This appliance contains a UV-C emitter (UVLamp).
UV-C radiation may, even in little doses, cause harm to the eyes and skin. Unintended use or
damage to the housing may result in the escape of dangerous UV-C radiation. Never operate the
UV-C emitter if damaged or removed from enclosure. Do not touch or look directly into the faucet.
Appliances that are obviously damaged must not be operated. Replacement of the UV-C emitter can
not be conducted by the user, please contact Waterlogic for assistance or help finding an Authorized
Service Representative.
Read the maintenance instructions before opening the appliance.
Appliance must be disconnected from the supply before replacing the UV-C emitter.
WARNING: Do not operate the UV-C emitter when it is removed from the appliance enclosure.
WARNING! This appliance is intended to be used in household and similar applications such as:
staff kitchen areas in shops, offices and other working environments;
farm houses and by clients in hotels, motels and other residential type environments;
bed and breakfast type environments;
catering and similar non-retail applications.
WARNING! Caution with cooling fluid: Do not damage the cooling circuit, Waterlogic machines
use both R134a and R600a (market dependent) as cooling gas. R600a is a flammable gas,
precaution is required, and only qualified and certified personnel should empty, replace or fill the
machines with R134a and R600a refrigerant gases.
Ensure always the proper management and transportation of the machine to avoid damaging the
refrigerant fluid and causing a dangerous leak.
Discarded appliance should be isolated from fire sources and cannot be burned.
Please transfer the appliance to qualified professional recycling companies for processing to avoid
damages to the environment or other hazards.
WARNING! –Keep ventilation openings, in the appliance enclosure or in the built-in structure,
clear of obstruction.
WARNING! –Do not damage the refrigerant circuit.
WARNING! –Do not use electrical appliances inside the food storage compartments of the
appliance, unless they are of the type recommended by the manufacturer.
Do not store explosive substances such as aerosol cans with a flammable propellant in this
appliance.
WARNING! DO NOT OPERATE IF DAMAGED. Unplug for safety. Contact Waterlogic or
authorized dealer for repair, service, and installation to avoid hazards.
WARNING! HOT WATER. Unit produces Hot Water in excess of 87oC. Water above 52oC can
cause severe burns or scalding. Keep unauthorized people and children away from the unit to
avoid accidental dispensing of hot water.
WARNING! CONNECT TO POTABLE WATER SUPPLY. This system is to be used for water only

WL2FL User Manual
Page 6 –Revision EU19-09-2020
and is not intended for use where water is microbiologically unsafe or with water of unknown
quality without adequate disinfection. System is designed for the supplemental bactericidal
treatment of public drinking water, or other drinking water, which has been tested and deemed
acceptable for human consumption by the state or local health agency having jurisdiction. The
system is designed to reduce normally occurring non-pathogenic or nuisance microorganisms only.
System is not intended for treatment of contaminated water.
WARNING! TIP HAZARD. Dispenser could tip or fall causing serious injury. Always install unit on
a firm, flat, and level surface and secure the WL3 FW Water Treatment System to the base cabinet
with the screw provided to lock the components together. Secure unit to cabinet, wall, or floor if
needed.
Never place heavy items on top of unit and never climb, stand, or hang on unit or storage cabinet
to prevent injury and damage.
WARNING! UNIT IS HEAVY. TWO PERSON LIFT REQUIRED. Transport unit empty and always
use material handling equipment or two people with proper lifting technique to reduce injury risk.
WARNING! STORE AND TRANSPORT UNIT EMPTY. ALWAYS SANITIZE BEFOREUSE.
The unit must be completely drained and sealed before storing to avoid stagnation and reduce
microbiological contamination (potential bacterial growth). Sanitize before use to eliminate any
potential microbiological contaminates
CAUTION! INDOOR USE ONLY. Intended for household use only. Never expose to direct
sunlight, heat sources, or ambient air temperature above 32°C (90°F) or below 2°C (35°F). Install
indoors and keep unit away from humidity levels above 65%. Never expose to freezing
temperatures. Ensure there is adequate clearance around the unit to allow refrigeration system
condenser to dissipate heat. Warmer environments require more clearance around the unit.
Minimum clearance around all surfaces of the machine is 50mm. Installs where the ambient
temperature exceeds 25°C, require a minimum of 100mm clearance for proper heat dissipation and
efficientoperation.
CAUTION! USE A WATER PRESSURE REGULATOR. Waterlogic will not be responsible for injury
or damage caused by excessive water pressure. Input or feed pressure must be 2.5 bar (36 psi) to
3.5 bar(51 psi). Be aware of any potential pressure surges caused by building/municipal pumping
stations. Water block devices and external leak detectors are strongly recommended. Locate the
unit as close to the water supply and the electrical connections as possible to minimize risk.
CAUTION! USE PROPER SUPPLY LINES AND FEED WITH POTABLE AMBIENT WATER ONLY.
Feed water over 32°C (90°F) may damage the treatment components. Always use supply lines with
adequate pressure rating and UV resistance. Close water supply valve and contact service
representative if a leak is noticed.
Contact Waterlogic for assistance or help finding an Authorized Service Representative.

WL2FL User Manual
Page 7 –Revision EU19-09-2020
WL2FL FEATURES AND BENEFITS
Ambient, Cold and Hot Water
Cold and Hot Selections, which can be changed to Ambient and Cold settings to meet a wide range of
customer demands.
High Volume Storage and Water Capacity
Free standing model has 4 Litres of Cold Water Capacity and 1.5 litres of Hot Water.
Mini model has 2 Litres of Cold Water Capacity and 1.5 litres of Hot Water.
BioCote®Anti-Microbial Protection
Certain plastic, silicon, and painted surfaces surrounding the dispensing areas and
drip try are infused with an exclusive additive called BioCote®. BioCote® provides
an effective barrier against microbes like bacteria and mould, which may cause
odours or staining.
Large Dispense Area with Recessed Faucet
200mm dispense height with BioCote® recessed faucet to protect from cross-contamination.
Child Safeguard
WL2FL Water Treatment Systems requires Hot Water selection followed by main dispense for Hot
Water, and defaults back to cold selection after 3 seconds of inactivity to prevent accidental
dispensing of hot water.
Energy Saving Sleep Mode
Energy Saving Sleep Mode can be programmed to turn off heater after 3 hours of inactivity.
Firewall™
Firewall is proprietary technology that places the UV lamp at the point of
dispense. This point of dispense purification keeps the dispense nozzle free
from external contamination as well as purifying the water, making the
freshest water possible.

WL2FL User Manual
Page 8 –Revision EU19-09-2020
WL2FL CERTIFICATIONS
Waterlogic Water Treatment Systems have been tested, approved, and certified by the world’s top
standards bodies such as NSF and ANSI. These organizations set and regulate national standards. We
believe that performance testing and certifications validate Waterlogic as a world-leader in water
treatment systems.
WL2FL Water Treatment System Certifications Include
.
This system is certified by IAPMO R&T according to NSF/ANSI 42, NSF/ANSI 53*,
NSF/ANSI 55 Class A, NSF/ ANSI P231, US EPA Guide Standard and Protocol for Testing
Microbiological Water Purifiers for the reduction of the contaminants on the
Performance Data Sheet, NSF/ANSI 372 for lead free compliance.
See the performance data sheet for specific reduction claims.
System claims vary depending on filters used within the system.
*when using Waterlogic 1 Micron CBC Filter (FT-0065 or FT-0034).
UL399 –Certified Drinking Water Cooler
Intertek Labs (ETL) Certified the WL2FL Water Treatment System to ANSI/UL 399 Standard for
Drinking Water Coolers.
BPA Free - Waterlogic tests for BPA and declares that all of its products are Bisphenol-A FREE
and contain no harmful BPA plastics.
Energy Star Certified
The WL2FL Water Treatment Systems, have been tested and certified to the Energy Star,
a US Environmental Protection Agency (EPA) program that helps our customers save
money and protect our climate through superior energy efficiency.
Waterlogic is certified to ISO 9001:2008 –Quality Management Systems (certified by
Intertek). ISO 9001 is the internationally accepted standard for well managed
organizations that have adopted the key quality management principles to its operations
to bring consistent quality products and a culture of continuous improvement.

WL2FL User Manual
Page 9 –Revision EU19-09-2020
MODEL/PART DESIGNATIONS
BRAND NAME
DESCRIPTION
MODEL –PART NUMBER
WL2FL Free Standing
Waterlogic WL2FL Free Standing - Cold and Hot
F-2FW-FS-HC
WL 2FW FS
Waterlogic WL2FL Free Standing - Cold and
Ambient F-2FW-FS-CA
Waterlogic WL2FL Free Standing –Cold
F-2FW-FS-C
WL2FL Mini
Waterlogic WL2FL Mini - Cold and Hot
F-2FW-M-HC
WL 2FW M
Waterlogic WL2FL Mini - Cold and Ambient
F-2FW-M-CA
Waterlogic WL2FL Mini - Cold
F-2FW-M-C
SPECIFICATIONS
ITEM
WL2FL Mini
WL2FL Free Standing
Power Supply
220V/50Hz or 120V/60Hz
Water Connection
¼” Quick Connect
Cold Water Temperature
Cold Water Temperature –Factory Set Point 5°C (41°F)
Cold Tank Size
Mini - 2 Litres
Free standing –4 Litres
Hot Water Temperature
85°C (185°F)
Hot Tank Size
1.5 litres
Hot Water Manual Reset
Overheat
105°C (221°F)
Recommended Incoming
Feed Pressure
2.7Bar –4Bar –Use Pressure Regulator
Maximum Service Pressure
6.5Bar (100 psi) –Use Pressure Regulator
Rated Service Flow Out
1.89 Litres per Minute –Firewall Purification
Environmental Temperature
2°- 37°C (35°- 100°F)
UV Lamp
15 Watts
15 Watts
Heater
500 W
Refrigerant Gas
R600a 20g
R600a 20g

WL2FL User Manual
Page 10 –Revision EU19-09-
2020
SHIPPING SPECIFICATIONS
ITEM
WL2FL Mini
WL2FL Free Standing
Width/Depth/Height
34cm x 37cm x 45cm
13.5” x 14.5” x 17.75” *
34cm x 41cm x 104cm
13.5” x 14.5 x 41”
Weight (dry)
26.3 kg (58 pounds)
30 kg (66 pounds)
ELECTRICAL SPECIFICATIONS
ELECTRICAL SUPPLY
220V/50Hz or 120V/60Hz
13 Amp Service 220V/50Hz
15 Amp Service 120V/60Hz
COMPONENT
POWER (approximate)
AMP DRAW (approximate)
Heater
500 Watts
2.2 Amps
4.16 Amps
Compressor
100 Watts
0.45 Amps
0.83 Amps
UV Lamp System
15 Watts
0.06 Amps
0.125 Amps
WL2FL TOTAL
615 Watts
2.71 Amps
5.12 Amps

WL2FL User Manual
Page 11 –Revision EU19-09-
2020
OPERATING INSTRUCTIONS
The above picture shows front LCD display and control panel for the Waterlogic WL2FL.
For Cold Water: Press Cold Water Select Button followed by the Dispensing Button (within3
seconds).
For Ambient Water: Press Ambient Water Select Button followed by theDispensing Button (within
3 seconds).
For Hot Water: Press Hot Water Select Button followed by the Dispensing Button (within3
seconds).
NOTE: Default selection mode is Cold Water. Selection will return to default after 3 seconds of
inactivity.
NOTE: Selection indication light will turn Red when the Hot Water Select button is pressed, and will
switch back to the default green within 3 seconds after dispensing the hot water.
Temperature Indicator Light
