WaterLogic infiniti Manual

Waterlogic
77 McCullough Drive – Suite 9
New Castle, DE 19720
[phone]
Tech Portal Website: www.techportal.waterlogic.com
infiniti
OPERATING, INSTALLATION, AND SERVICE MANUAL

infiniti Operating, Installation, and Service Manual Page 2 - Revision: 9-15-2016
Waterlogic infiniti OPERATING, INSTALLATION, AND SERVICE MANUAL
Congratulations on your choice of the Waterlogic infiniti Water Treatment System, water treatment
system. The infiniti Water Treatment System, model dispenses cold, and hot. Every infiniti Water
Treatment System, includes:
Bio-Cote Anti-Microbial Protection
Filter configuration can be optimized for all water conditions
The Waterlogic infiniti Water Treatment System, provides exceptional quality and great tasting
water with every use.
TABLE OF CONTENTS
•Features and Benefits ................................................................. 3
•Certifications............................................................................... 4
•Introduction and Safety Alert Symbols....................................... 5
•Safety Precautions ...................................................................... 6
•Model and Part Designations...................................................... 7
•Specifications .............................................................................. 7
•Operating Instructions ................................................................ 8
•Hot Tank Principles of Operation................................................ 9
•Flow Diagram ............................................................................ 10
•Programming – Disabling Sleep Mode...................................... 11
•Pre-Installation Procedures ...................................................... 12
•Draining Procedures.................................................................. 15
•Installation Procedures ............................................................. 18
•Cold Water Setting.................................................................... 20
•Replacement Components ....................................................... 21
•Hot Tank Descaling Instructions ............................................... 22
•Resetting the Overload or High Limit Safety ............................ 24
•Parts Drawings and Parts Lists .................................................. 26
•Electrical Diagram ..................................................................... 33
•Troubleshooting........................................................................ 34
•Warranty .................................................................................. 54

infiniti Operating, Installation, and Service Manual Page 3 - Revision: 9-15-2016
Waterlogic infiniti FEATURES AND BENEFITS
Ambient, Cold and Hot Water
Cold and Hot Selections, which can be changed to Ambient and Cold settings to meet a wide range of
customer demands.
High Volume Storage and Water Capacity
Tower Model has 4 liters of Cold Water Capacity and 1.6 Liters of Hot Water Capacity.
Counter Top has 2 liters of Cold Water Capacity and 1.6 Liters of Hot Water Capacity.
BioCote®Anti-Microbial Protection
Plastic surfaces surrounding dispensing areas and drip tray are infused with an
exclusive silver additive called BioCote®. Silver is a natural anti-microbial that
inhibits the growth of microorganisms providing additional surface protection.
Leak Detection
infiniti Water Treatment Systems are supplied with a Sensor in the Leak Tray that halts water supply
to prevent overflow and sounds alarm to reduce accident potential.
Energy Saving Sleep Mode
Energy saving Sleep Mode can be programmed to turn off heater after 3 hours of inactivity.
Large Dispense Area with Recessed Faucet
9.84 inch dispense height with BioCote® recessed faucet to protect from cross-contamination.
Child Safeguard
The infiniti Water Treatment System defaults to cold water selection. Hot water must be actively
selected along with the dispense button and then dispensed within 1.5 second and defaults back to
cold water selection. If both buttons are not pushed at the same time, hot water will not be
dispensed. This feature eliminates the accidental dispensing
of hot water.

infiniti Operating, Installation, and Service Manual Page 4 - Revision: 9-15-2016
Waterlogic infiniti CERTIFICATIONS
Waterlogic water treatment systems have been tested, and certified to rigorous NSF and UL
Standards. We believe that performance testing and certifications validate Waterlogic as a world-
leader in water treatment systems.
infiniti Water Treatment System, Certifications Include
UL399 – Certified Drinking Water Cooler
Intertek Labs (ETL) Certified the infiniti Water Treatment System, to ANSI/UL 399
Standard for Drinking Water Coolers.
BPA Free - Waterlogic tests for BPA and declares that all of its products are Bisphenol-A
FREE and contain no harmful BPA plastics.
NSF/ANSI-61 – Certified Drinking Water System Components
NSF / ANSI 372 – Drinking Water System Components – Lead Content
CSA B483.1 - Drinking Water Treatment Systems
This System has been tested and certified in accordance with NSF/ANSI-61 – Certified
Drinking Water System Components, NSF / ANSI 372 – Drinking Water System
Components for low Lead Content, and CSA B483.1 - Drinking Water Treatment
Systems by the Water Quality Association (WQA)
Energy Star Certified
The infiniti Water Treatment System, has been tested and certified to the Energy Star,
a US Environmental Protection Agency (EPA) program that helps our customers save
money and protect our climate through superior energy efficiency.
Waterlogic manufacturing is certified to ISO 9001 – Quality Management
Systems (certified by Moody International). ISO 9001 is the
internationally accepted standard for well managed organizations that
have adopted the key quality management principles to its operations to
bring consistent quality products and a culture of continuous
improvement.
Safe Drinking Water Act
Waterlogic water treatment systems conform to the Safe Drinking Water Act (SWDA) “lead-free”
amendment effective January 4, 2014.

infiniti Operating, Installation, and Service Manual Page 5 - Revision: 9-15-2016
INTRODUCTION
Carefully read and follow all instructions to ensure proper and efficient operation of your infiniti
Water Treatment System.Contact Waterlogic or an Authorized Waterlogic Dealer if you have any
questions.
Waterlogic and Authorized Waterlogic Dealers employ trained service personnel who are
experienced in the installation, function and repair of Waterlogic equipment. This publication is
written for use by these qualified individuals. Waterlogic encourages users to learn about products,
however, we believe that product knowledge and service is best obtained by consulting Waterlogic
or an Authorized Waterlogic Dealer.
Waterlogic water treatment systems should be combined with selected water treatment
components to create a system specifically tailored for each application by trained and qualified
personnel.
Products manufactured and marketed by Waterlogic and its affiliates are protected by patents
issued or pending in the United States and other countries.
Waterlogic reserves the right to change the specifications referred to in this literature at any time,
without prior notice. Changes or modifications not expressly approved by Waterlogic could void the
warranty and user’s authority to operate the equipment.
SAFETY ALERT SYMBOLS
Read and follow all safety information carefully. The signal words used in this manual are selected as
shown below and based on an assessment of the degree of potential injury or damage (severe or
minor) and the occurrence of injury (definitely occurs or has the potential to occur) when the
warning is ignored:
DANGER!
Indicates a situation which, when not avoided, results in death or severe injury.
WARNING!
Indicates a situation which, when not avoided, has the potential to result in death or severe
injury; and/or severe property damage.
CAUTION!
Indicates a situation which, when not avoided, results or has the potential to result in minor
injury; and/or minor property damage.

infiniti Operating, Installation, and Service Manual Page 6 - Revision: 9-15-2016
SAFETY PRECAUTIONS
Basic safety precautions should be followed, including the following:
DANGER!If incorrectly installed, operated or maintained, this product can cause death or
severe injury. Those who install, operate, or maintain this product should be trained in its proper use,
warned of its dangers, and should read the entire manual before attempting to install, operate, or
maintain this product.
WARNING! Unit is to be used for its intended purpose as described in this manual, and
untrained individuals who use this manual assume the risk of any resulting property damage or
personal injury.
WARNING!HOT WATER. Unit produces Hot Water up to 188oF. Water above 125oF can cause
severe burns or scalding. Keep unauthorized people and children away from the unit to avoid
accidental dispensing of hot water. Children should not use without supervision.
DANGER! ELECTRICAL SHOCK HAZARD. Always unplug from power supply prior to servicing
equipment to prevent electrical shock.
WARNING! This system to be used for water only and is not intended for use where water is
microbiologically unsafe or with water of unknown quality without adequate disinfection before or
after the system. The system is designed for the supplemental bactericidal treatment of either
treated and disinfected public drinking water, or other drinking water, which has been tested and
deemed acceptable for human consumption by the state or local health agency having jurisdiction.
The system is designed to reduce normally occurring non-pathogenic or nuisance microorganisms
only. System is not intended for treatment of contaminated water.
WARNING! Dispenser Could Tip or Fall causing serious injury. Always install unit on a firm, flat,
and level surface and secure the infiniti Water Treatment System, to the base cabinet with the screw
provided to lock the components together. Never place heavy items on top of unit and never climb,
stand, or hang on unit or storage cabinet to prevent injury and damage.
CAUTION! INDOOR USE ONLY.Do not install outdoors or where unit is in direct sunlight. Do not
install where ambient temperature goes below 50°F or above 97°F. Avoid high humidity and
moisture. Product life and performance will be impacted and warranty could be voided.

infiniti Operating, Installation, and Service Manual Page 7 - Revision: 9-15-2016
MODEL/PART DESIGNATIONS
BRAND NAME DESCRIPTION
MODEL -
PART NUMBER
infiniti Cold and Hot
Charcoal and Silver Tower
Waterlogic
infiniti
- Cold and Hot –Tower IIHCRC
F-5001-FS-HC-TT-CS-ION
infiniti Cold and Hot
Charcoal and Silver
Countertop
Waterlogic infiniti - Cold and Hot – Charcoal and Silver
Countertop
IIMHCRC
F-5001-M-HC-TT-CS-ION
SPECIFICATIONS
ITEM infiniti Hot and Cold infiniti Cold and Ambient
Water Connection ¼” Quick Connect
Cold Water Temperature
Cold Water Temperature – Factory Set Point 41° - 5°C
(Adjustable) 34° - 54° F. (1.1°- 12.2°C)
Hot Water Temperature Factory Set Point 185°F (85°C)
Hot Water Manual Reset
Overload
221°F (105°C)
Recommended Service
Pressure
40-60 psi (275-414 kPa) – Use Pressure Regulator
Maximum Service Pressure 100 psi (689 kPa) – Use Pressure Regulator
Rated Service Flow 0.5 gallons per minute (1.89 Lpm)
Environmental Temperature 35°- 100°F (2°- 37°C)
Heater 500 W
Refrigerant Gas R134a, 40g, 1.41 ounces R134a, 65g, 2.29 ounces
R134a Pressures High (230 psi), Low (90 psi)
SHIPPING SPECIFICATIONS
ITEM infiniti Counter Top infiniti Tower
Width/Depth/Height
13.75” x 15.25” x 19”#(35cm x 38.75cm
x 48.3cm)
13.5” x 14.5” x 40.5” (34cm x 41cm x
103cm)
Weight (dry)
42 pounds (19.5 kg)
58 pounds (26.5 kg)
ELECTRICAL SPECIFICATIONS
ELECTRICAL SUPPLY
120V/60Hz, 1PH
15 Amp Service
COMPONENT POWER (approximate) AMP DRAW (approximate)
Heater
800
6.6 Amps
Compressor 216 1.8 Amps
infiniti TOTAL
1016
8.4 Amps
#infiniti Counter Top is 19 inches. tall and may not fit between countertops and cabinets - Check installation to ensure adequate clearance.

infiniti Operating, Installation, and Service Manual Page 8 - Revision: 9-15-2016
OPERATING INSTRUCTIONS
The above picture shows front LED and control panel for the Waterlogic infiniti Water Treatment
System, water treatment systems.
Button Operational Use
Cold Water - Press Dispensing Button to start dispensing cold water until
desired fill. Cold Water is the Default Water Selection
Hot Water – Press and Release the Hot Water Selection Button followed
by pressing and holding the Dispense Button.
WARNING! Unit produces Hot Water up to 188°F (87°C). Water
above 125°F (52°C) can cause severe burns or scalding. Keep
unauthorized people and children away from the unit to avoid
accidental dispensing of hot water. Children should not use without
supervision.
Cold Water - Press and Release the Cold Water Selection Button followed
by pressing and holding the Dispense Button.
NOTE: Default selection mode is Cold Water. Selection will return to default after 3 seconds of
inactivity.

infiniti Operating, Installation, and Service Manual Page 9 - Revision: 9-15-2016
HOT TANK PRINCIPLES OF OPERATION
All Waterlogic Hot Tanks have a built in Vent or
Expansion Chamber in the top of the tank except for
WL270 (GF) units.
The Vent Chamber allows for expansion of the water
when it is heated.
The chambers are separated by a welded-in tank
baffle.
Water always flows into the bottom of the tank and
out the top to the faucet.
The hot tank outlet tube has a restrictor in its base.
This ensures the reservoir is always full by allowing
more water in than out.
There is a small hole in the side of the tank outlet tube
that allows air and water to pass into the vent
chamber as it is heated.
Water in the vent chamber is suctioned back through
the outlet tube vent hole when water is dispensed.
Expansion of water as it is heated in the reservoir will
push the water out the faucet when the outlet tube
vent hole becomes plugged with debris or scale.
The small Outlet Vent Hole is susceptible to scale build
up and is a key indicator that descaling is required.
It is critical to descale the hot tank through the vent
line and outlet line on a regular basis to prevent this
problem.
Descaling through the inlet and/or outlet lines only
will not clean the vent chamber and outlet vent hole
properly.

infiniti Operating, Installation, and Service Manual Page 10 - Revision: 9-15-2016
Waterlogic infiniti Water Treatment System, WATER FLOW DIAGRAM
Water In
Solenoid Valve
Water Out
Faucet
Condenser
Compressor
Filter Dryer
Cold
Tank
Hot Tank

infiniti Operating, Installation, and Service Manual Page 11 - Revision: 9-15-2016
PROGRAMMING INSTRUCTIONS
CHANGING ENERGY SAVER MODE TO NON ENERGY SAVING MODE
Infiniti UV Water Treatment System comes programmed to Energy Saver Mode. To turn off the
Energy Saving Mode, move the Jumper on CH6 from Pins 1-2 to Pins 2-3
Infiniti UV is programmed in Energy Saving Mode
from the factory
Jumper Pin Position – Pin 1 and 2
Turn off Energy Saving Mode
Jump Pin Position – Pin 2 and 3
Display PCB – P/N EN-0033-L00-00
Pin Numbers
1
2
3
Jumper Pin Part
Number EN-
6082
WLCP PN 20-
1005
1
2
3
2

infiniti Operating, Installation, and Service Manual Page 12 - Revision: 9-15-2016
PRE-INSTALLATION PROCEDURES
DANGER! ELECTRICAL SHOCK HAZARD.
Only qualified personnel who have read and understand this entire manual should attempt to
install, or service this unit, failure to do so could result in death or serious injury. DO NOT plug
into an electrical supply until specifically instructed.
WARNING! ALWAYS SANITIZE BEFORE USE.
Sanitize before use to eliminate any potential microbiological contaminates.
Materials Needed:
•Personal Protective Equipment. Rubber or Nitrile Safety Gloves and Protective Eyewear
•Phillips Screwdriver
•Temperature Gage
•Water Pitcher or Container to collect water from the faucet
•5-gallon container or drain basin
•Sanitizer - Household Bleach (5.25% Sodium Hypochlorite) or Citric Acid Based Cleaner
•Tapered Tip Squirt Bottle
•¼” Plastic Tubing, at least 4 feet in length, and assorted ¼” quick connect fittings
•TDS Meter and Test Strips for measuring chlorine - Optional
1. Unpack the Waterlogic infiniti Water Treatment System, and check exterior for damage.
Flush Filters
CAUTION! FILTER FLUSH REQUIRED.
infiniti Water Treatment Systems, are not supplied with filters. Filters should be configured to
optimize your system. Filters need to be configured and specified to do the job given the local
water conditions, usage, maintenance schedule, and placement restrictions.
In order for our filters to perform as represented and to provide the best quality water possible, it
is essential that filters be replaced periodically. The frequency of filter changes depends upon your
water quality and your water usage. For example, if there is a lot of sediment and/or particles in
your water, then you will have to change your filters more frequently than a location with little to
no sediment. Be sure to replace your filters whenever you notice a decline in the performance,
whether it is a drop in flow rate and/or pressure or an unusual taste in the water.
2. Flush thoroughly per filter manufacturers’ recommendation with fresh water to drain.
3. Once flushed, install the filters. Following the flow direction on the filter.
NOTE: Filters should not be flushed prior to 24 hours before installation to limit Microbial
Growth.

infiniti Operating, Installation, and Service Manual Page 13 - Revision: 9-15-2016
Sanitizing
Sanitize using a Household Bleach (5.25% Sodium Hypochlorite solution) or other approved
cleaner throughout the cold water circuit. Follow all instructions on the sanitizer and flush with
fresh water through the faucet until odor and taste is acceptable.
WARNING! USE PROPER PERSONAL PROTECTIVE EQUIPMENT
Always ensure proper ventilation and use proper personal protective equipment such as gloves
and eye protection when using chemicals. Refer to Material Safety Data Sheet for specific
requirements of each chemical product. Take all necessary precautions to prevent sanitizer from
contacting eyes, clothing, and any other surfaces in could damage (carpets).
4. Put sanitizer in the filter housing.
5. Turn off the water supply to the water cooler and release the internal water pressure by
depressing the dispense button momentarily and remove the water supply pipe.
6. Isolate the power to the water cooler.
7. Bypass the internal twist filters to avoid mixing sanitizing solution with the active carbon. This is
done by disconnecting the tubing to the inlet of the filters and attaching this tube to the inlet of
the solenoid valves.
8. Connect the outlet of the sanitizing filter housing to the inlet of the water cooler and connect the
supply water pipe to the inlet of the filter housing.
9. Turn on the power and water supply to the water cooler.
Fill the Cold Circuit with Sanitizer
10. Depress the cold water dispense button until the sanitization fluid starts to flow out of the faucet
nipple.
11. Allow the sanitization fluid to stand in the water cooler for 10 minutes. Do not let any
sanitization fluid enter the hot tank.
Flushing the Sanitizer from the Machine
12. Flush the cold water until the water runs clear of sanitizer.
13. Again isolate the water to the water cooler and release any internal water pressure.
14. Isolate the electrical power.
15. If this procedure is being done in conjunction with the annual service, change the filters.

infiniti Operating, Installation, and Service Manual Page 14 - Revision: 9-15-2016
WARNING! Use Personal Protective Equipment. Gloves and Eye Protection Required. The first
2 or 3 gallons of water will contain concentrated sanitizer. Use extreme care!
Fill the Hot Tank
16. Press the Hot Water Select Button, followed by the main dispensing button to fill the hot tank.
Water will dispense from the faucet once the hot tank is full. Flush until water is clear.
WARNING! HOT CIRCUIT IS NOT SANITIZED.
Water in the hot circuit is not sanitary until the temperature exceeds 171oF (77°C) for at least 5
minutes.
Heater Test
17. Always ensure tanks are full of water before turning on the heater or the overload (high limit) will
open and require manual reset. It will take the heater approximately 10 minutes to heat the
water from ambient 75°F (24°C) to the factory set point of 185°F (85°C). Dispense a cup of hot
water to ensure the temperature/odor/taste is acceptable.
WARNING! VERY HOT WATER CAN BURN OR SCALD.
Hot water should be dispensed carefully into insulated container to avoid injury.

infiniti Operating, Installation, and Service Manual Page 15 - Revision: 9-15-2016
Waterlogic infiniti COUNTER TOP DRAINING INSTRUCTIONS
Draining Notes
Drain the Waterlogic infiniti Water Treatment System for transportation.
WARNING! STORE UNIT EMPTY. ALWAYS SANITIZE BEFORE REUSE.
The unit must be completely drained and sealed before storing to avoid stagnation and reduce
microbial growth.
Prior to draining the hot tank, turn off the Red Heater and Compressor Power
Switch (O=OFF).
Allow Hot Water to cool off prior to draining.
WARNING! HOT WATER. The infiniti Water Treatment System produces Hot Water up to
188°F. Water above 125° can cause severe burns or scalding. Hot water should be dispensed
carefully into insulated container to avoid injury.
Disable Cold and Hot Tanks
1. Turn off the Red Heater and Compressor Power Switch (O-OFF) to disable the
heater and compressor.
Turn off Water Supply
2. Isolate the infiniti Water Treatment System from feed water by turning off the supply.
Drain the Cold Water Tank and Circuit
3. Remove the Front Cover.
4. Remove the Faucet, and move the Front Cover to the top of the infiniti Water
Treatment System to gain access to the draining tubes
5. Remove tubing from JG fittings, and
allow water to drain into drains,
catch basin, etc.
6. Reinstall tubing into JG fittings,
Faucet, and Front Cover

infiniti Operating, Installation, and Service Manual Page 16 - Revision: 9-15-2016
Waterlogic infiniti DRAINING TOWER INSTRUCTIONS
Draining Notes
Drain the Waterlogic infiniti Water Treatment System, for transportation.
WARNING! STORE UNIT EMPTY. ALWAYS SANITIZE BEFORE REUSE.
The unit must be completely drained and sealed before storing to avoid stagnation and reduce
microbial growth).
Prior to draining the hot tank, turn off the Red Heater and Compressor Power
Switch (O=OFF), and dispense 2 liters of hot water from the machine. As hot
water is dispensed from the faucet of the infiniti Water Treatment System,
colder water will be introduced into the hot tank. Since the Red Heater and
Compressor Power Switch is turned off, the heater will not energize and heat the
incoming tap water. Following this precaution prevents exposing personnel and equipment
(drains, catch basin, etc.) to scalding hot water.
Disable Cold and Hot Tanks
1. Turn off the Red Heater and Compressor Power Switch (O-OFF) to disable the
heater and compressor.
2. Dispense 2 liters of water through the hot tank to cool the water temperature
in the hot tank and avoid burns.
WARNING! HOT WATER.The infiniti Water Treatment System produces Hot Water up to 188°F.
Water above 125° can cause severe burns or scalding. Hot water should be dispensed carefully
into insulated container to avoid injury.
Turn off Water Supply and Bleed Water Pressure
1. Isolate the infiniti Water Treatment System from feed water by turning off the supply.
2. Dispense cold still water to relieve any pressure built up in the system.

infiniti Operating, Installation, and Service Manual Page 17 - Revision: 9-15-2016
Drain the Cold Water Tank and Circuit
3. Remove lower front panel to access tank feed lines.
4. Loosen the two screws holding the filter head
bracket to remove filter head bracket to access rear
of filter heads.
5. Disconnect tank line feed lines from hot and cold
inlet solenoids at rear of filter head fittings).
6. Catch hot (hot water should have cooled down after
dispensing 2 liters of water prior to the draining
process) and cold water drain into basin or catch.
7. Reconnect tubing into inlet elbows once drained, and reinstall
the filter head bracket.
8. Dry inside of unit if necessary.
9. Replace lower front panel.

infiniti Operating, Installation, and Service Manual Page 18 - Revision: 9-15-2016
INSTALLATION PROCEDURES
Safety and Installation Guidelines
Ensure all Local, State, and Federal Laws and Codes including health and safety guidelines are met
when installing Waterlogic Equipment. Only qualified service technicians should attempt
installation and service of Waterlogic Equipment.
WARNING!ELECTRICAL SHOCK HAZARD. Always unplug (isolate from power supply) to prevent
electrical shock except where electrical tests are specified.
WARNING! IMPROPER SUPPLY OR CONNECTION CAN RESULT IS RISK OF SHOCK.
Connect to a 15 amp 120V 60Hz properly grounded outlet (GFI is recommended). Ensure polarity is
correct and always use a 3-prong outlet.Consult a qualified electrician if you have any questions.
WARNING! USE ONLY Waterlogic SUPPLIED POWER CORD.Locate system within 5 feet of
power supply. Never use an extension cord or adapter. Do not use a damaged power cord or plug.
Keep power cord out of heavy traffic areas and away from heat sources. Do not, under any
circumstances, remove ground prong or alter the power cord. Never pull the power plug from the
outlet with a wet hand or allow the plug to get wet. Failure to use the supplied power cord will void
UL Certification and Warranty.
CAUTION! INDOOR USE ONLY. Never expose to direct sunlight, heat sources, or ambient air
temperature above 100°F (37°C) or below 35°F (2°C). Install indoors and keep unit away from
excessive humidity. Never expose to freezing temperatures. Ensure there is adequate clearance
around the unit to allow refrigeration system condenser to dissipate heat. Warmer environments
require more clearance around the unit. Minimum clearance around all surfaces of the machine is 2-
inches. Installs where the ambient temperature exceed 80F, require a minimum of 4-inches clearance
for proper heat dissipation and efficient operation.
CAUTION! USE A WATER PRESSURE REGULATOR. Waterlogic will not be responsible for injury or
damage caused by excessive water pressure. Operating pressure must be 40 psi to 60 psi. Be aware
any of potential pressure surges caused by building/municipal pumping stations.
CAUTION! USE UV STABILIZED SUPPLY LINES. Feed the unit with a potable ambient or cold
water supply only. Feed water over 100° F (37°C) can damage the treatment components. Water
block devices and external leak detectors are strongly recommended. Locate the unit as close to the
water supply and the electrical connections as possible.
WARNING! STORE AND TRANSPORT UNIT EMPTY. ALWAYS SANITIZE BEFORE USE.
The unit must be completely drained and sealed before storing to avoid stagnation and reduce
microbiological contamination (potential bacterial growth). Sanitize before use to eliminate any
potential microbiological contaminates
Pre-installation and sanitization procedures as prescribed in this manual must be performed before
installing the infiniti Water Treatment System,
Always install indoors and place the Waterlogic infiniti Water Treatment System, on a firm, flat and
stable surface.

infiniti Operating, Installation, and Service Manual Page 19 - Revision: 9-15-2016
1. Attach the water supply line to the 1/4” feed water inlet bulkhead fitting on the back of the unit.
Waterlogic requires the use of a water pressure regulator. Water feed pressure must be
between 40-60 psi.Turn on the water supply and check for leaks.
2. Check to ensure that the Red Heater Power Switch is the O=OFF position.
NOTE: Switches have internal LED that illuminates when placed in I=ON position.
3. Connect the power cord to the back of the Waterlogic infiniti Water Treatment System, and to a
120 Volt supply.
4. Fill the Cold Tank. Hold a container under the dispensing faucet, press and hold the main
dispensing button until a continuous flow of water is obtained. Once a continuous flow is
obtained, release the dispensing button. Cold tank is now full.
5. Fill the Hot Tank. Hold a container under the dispensing faucet. Press the Hot Select Button
followed by the main dispensing button until a continuous flow of water is obtained. Once a
continuous flow is obtained, release the main dispensing button. Hot tank is now full.
CAUTION! NEVER TURN ON HEATER BEFORE FILLING HOT TANK.
Red Heater Power Switch must be in the O=OFF position while the hot tank is empty. Damage
could occur within one minute and the overload (high limit) will require manual reset if heater is
turned on with an empty hot tank.
6. Move the Waterlogic infiniti Water Treatment System, into its final operating position. Be sure
that a minimum of 2” clearance is maintained around both the sides and the back of the unit.
This is important to allow proper airflow and heat exchange of refrigeration system.
7. Level unit using the adjustable feet to level if necessary. Never install on incline.
8. Turn the Red Heater Power Switch to I=ON position.
9. When the unit has reached its Hot Temp Set Point, the heater will cycle off. When the unit has
reached its Cold Temp Set Point Temperature, the compressor will cycle off.
10. Once the unit is at the target temperature(s), sample the water to ensure water meets
expectations and additional rinsing or adjustment is not required.
11. Check the unit for any leaks. External Leak Protection is always recommended.

infiniti Operating, Installation, and Service Manual Page 20 - Revision: 9-15-2016
ADJUSTING COLD SET POINT
Cold Water Temperature – Factory Set Point is 41°F (5°C) and can be adjusted to 34°F - 54°F (1.1°C to
12.2°C)
The cold set point can be adjusted by accessing the cold
thermostat adjustment screw under the decal at the rear of the
unit.
Remove the red portion of the Cold Tank Temperature label to
access the adjustment screw.
The factory set point is ~41°F and is indicated by the dot on
sheet metal.
Turning the adjustment screw clockwise to lower the set point
temperature.
Do not adjust past the “Max Cold” position at 3:00 position to
avoid freezing the cold tank.
Turning the adjustment screw counter-clockwise to raise the set
point temperature.
