WaterLogic WL290 Operating instructions

WL290Manual Page57Revision9‐3‐2019
HOTWATERTROUBLESHOOTINGINDEX

1. HotWaterisnotHot85°C(185°+/‐5°F)

IncludedinthissectionaretheTwoResettableHotTankOverloads(HighLimitSafety)
Instructions.


1. HotWaterisnotHot85°C(185°+/‐5°F)


TheHottemperaturesetpointis85°C(185°F)andiscontrolledbyathermistorinthewellof
theHotTank.

TherearetwoHotTankOverloadDevices(HighSafetyLimit)onthesideoftheHotTankthat
willtriptopreventdamagetotheunitifthetankisdryheated(turnedonwithoutwaterin
it).


Ittypicallytakes10minutesforthe500Wtoheatthe1.6Literofroomtemperature
(ambient)watertothe85°C(185°F)setpoint.

PossibleReason Solution
Nopowertoheaterelements
CheckthattheRedHeaterandCompressor
switchison.

TurnRedHeaterandCompressorSwitchon.
I=ON
HotTankOverloadDevices
(HighSafetyLimit)tripped

HotTankOverloadDevices
(HighSafetyLimit)isasafety
featuretoensurethetankdoes
notoverheat.
HotTankOverloadDevices(HighSafetyLimit)will“click”
whenpushed.TheHotTankOverloadDevices(High
SafetyLimit)areautomaticallyresetwhenpressed.

SeeResetting HotTankOverloadDevices(HighSafety
Limit)Instructionsthatareincludedfurtherbelowinthis
TroubleshootingSection
HotTankOverloadDevices
(HighSafetyLimit)“open”on
HotTank
TurnPoweroff.

CheckOHM’sresistanceacrossterminalsoneachofthe
HotTankOverloadDevices(HighSafetyLimit)separately.
Goodcomponentswillindicateaclosedcircuitorzero
OHM’sonthemeter.

Replacecomponentsasnecessary.
Looseorimproperlyconnected
wire(s)totheheatingelement/
hottank.
Visuallyinspectwireleadsgongtothehottank;confirm
properconnectionstotheheatingelements.

Hottanklifeis3‐5years,dependingonusage.


WL290Manual Page58Revision9‐3‐2019
*Typically,dealersswapoutthehottankatsite,takeback
totheshoptorepair.
HeatingCoilNotWorking
TurnPoweroff;Drainhottank;Usemulti‐metertocheck
heaterelementforapproximately26OHM’sresistance.

Hottankmustbeemptyifyouarecheckingforcontinuity.

ReplaceHotTankasnecessary.




WL290Manual Page59Revision9‐3‐2019
RESETTINGTHETWOHOTTANKOVERLOADDEVICES(HIGHLIMITSAFETY)


 
1.


TurnoffRedHeaterandCompressorPowerSwitchO=OFFonrearofunit.
2. UnplugthePowerCordfromrearofunit. 
3.


Remove4PhillipScrewsfromtheAccessPanelonrearofunit
andLowerAccessPanel. 
4.

LocateprotectivemetalboxonrearofHotTank.Pushdownontopofmetalboxto
accessthetwoOverloadResetDevices.

5.
PresstheOverloadResetDevices.

6. Reattachthemetalboxbydepressingthetopflapofthemetalboxsoitsnapsbackinto
itsoriginalpositionontheHotTank.

WL290Manual Page60Revision9‐3‐2019
7.



ReplacetheAccessPaneland4Philipsscrews. 
8. PluginthePowerCord.
9. MakesurethehotandcoldtanksarefilledwithwaterBEFOREturningontheRed
HeaterandCompressorPowerSwitch

CAUTION!NEVERTURNONHEATERBEFOREFILLINGHOTTANK.
RedHeaterandCompressorPowerSwitchmustbeintheO=OFFposition
whiletheHotTankisempty.Damagecouldoccurwithinoneminuteand
theoverload(highlimit)willrequiremanualresetifheateristurnedon
withanemptyHotTank.

10. Verifythecoolerisfullyoperationalbeforeinstallingitatthecustomers’site.


