WaterLogic WL250 Operating instructions

WL250Manual Page68‐Revision:12‐12‐2018
HOTWATERTROUBLESHOOTINGINDEX

Hot Water Problems
1. HotWaterisnotHot85°C+/‐15°C(185°F+/‐5°F)

AlsoincludesrelatedinstructionsforResettingtheHotTankOverloadorHigh
LimitSafety


HotWaterisnotHot85+/‐15°C(185°+/‐5°F)

NOTE:TheWL250WaterTreatmentSystemdoesNOThaveSleeporPowerSavingModeand
thehotwatershouldbeaof85+/‐15°C(185°+/‐5°F)undernormaloperatingconditions.

TheHottemperaturesetpointis85°C+/‐15°C(185°F+/‐5°F)andiscontrolledbyathermostat
onthesideofthetank.

Thereisaresettableoverloadorhighlimitsafetyabovethethermostatonthesideofthetank
thatwilltriptopreventdamagetotheunitifthetankisdryheated(turnedonwithoutwaterin
it).

TheWL250WaterTreatmentdoesNOThaveExtraHotcapabilityandthemaximumhot
temperatureis87°C(189°F).

Ittypicallytakes10minutesforthe500Wtoheatthe1.6Literofroomtemperature(ambient)
watertothe85°C(185°F)setpoint.

PossibleReason Solution
Nopowertoheaterelements
CheckthattheRedHeaterandCompressor
switchison.

TurnRedHeaterandCompressorSwitchon.
I=ON
HotTankOverloadTripped

Overloadisasafetyfeatureto
ensurethetankdoesnot
overheat.
Overloadwill“click”whenpushed.Theoverloadis
automaticallyresetwhenpressed.

SeeResettingtheHotTankOverloadorHighLimitSafety
Instructionsthatareincludedfurtherbelowinthis
TroubleshootingSection
Thermostatoroverload
“open”onHotTank
TurnPoweroff.CheckOHM’sresistanceacrossterminalson
eachThermostatandOverloadseparately.


WL250Manual Page69‐Revision:12‐12‐2018
Goodcomponentswillindicateaclosedcircuitorzero
OHM’sonthemeter.

Replacecomponentsasnecessary.
HeatingCoilNotWorking
TurnPoweroff;Drainhottank;Usemulti‐metertocheck
heaterelementforapproximately26OHM’sresistance.

HotTankmustbeemptyifyouarecheckingforcontinuity.

ReplaceHotTankasnecessary.
Looseorimproperly
connectedwire(s)tothe
HeatingElement/HotTank.
Visuallyinspectwireleadsgongtothehottank;confirm
properconnectionstotheheatingelements.

Hottanklifeis3‐5years,dependingonusage.

*Typically,dealersswapouttheHotTankatsite,takeback
totheshoptorepair.


WL250Manual Page70‐Revision:12‐12‐2018
RESETTINGTHEHOTTANKOVERLOADORHIGHLIMITSAFETY


 
1.

RedHeaterandCompressorSwitchmustbeintheOFFposition

O=OFF

2. UnplugthePowerCordfromrearofWL250WaterTreatmentSystem.
3.
TowerModel:RemovetheLowerFrontPanelbyremovingthePhillipsHeadScrews
underneaththeLowerFrontPanel.

CounterTopModel:RemovetheSidePanelbyremovingPhillipsHeadScrewsfromSide
Panel.
4.






LocatetheprotectivemetalboxontherearoftheHotTank.

Asyoulookthroughthecondensercoilsontherearofthe
unit,youwillseetheHotTanklocatedontheright‐handside.






WL250Manual Page71‐Revision:12‐12‐2018
5.
ReachupbehindtheHotTankandtakeholdoftheProtective
MetalBoxcoveringtheThermostatandOverloadontheHot
Tank.

TherearenutsthatsecurethemetalboxtotheHotTank.
However,thenutsarelooseenoughtoallowyoutoremove
themetalbox.

Ifthenutsonthemetalboxaretootight,loosenthenuts
securingtheHotTanktotheupperbaseoftheunitandlower
thehottanksoyoucanremovethemetalbox.

Fordemonstrativepurposes,photosbelowhaveloweredthe
HotTankfromtheunit. 
6.
Presstheresetbutton

7.






Reattachthemetalboxbydepressingthetopflapofthe
MetalBoxsoitsnapsbackintoitsoriginalpositiononthe
HotTank. 

WL250Manual Page72‐Revision:12‐12‐2018
8. ReplacePanelonunitusingPhillipsheadscrews.
9. PluginthePowerCord.
10
MakesuretheHotandColdTanksarefilledwithwaterBEFOREturningontheRedHeaterand
CompressorSwitch.

Verifythecoolerisfullyoperationalbeforeinstallingitatthecustomers’site.


