WaterLogic CUBE Operating instructions

CUBEManual Page86–Revision10‐8‐2018

HOTWATERTROUBLESHOOTING

1. HotWaterisnotHot187°F(86C°)

2. HotWaterisnotAvailable

ResettingHotTankOverloadandProgrammingtheDPSet‐UpforHotWater
TemperatureInstructionsareincludedinthisTroubleshootingsection.


1.HotWaterisnotHot187°F(86°C)+/‐5°F


PossibleReason Solution
NopowertoHotTank

CheckthattheGreenHeaterand
Compressorswitchison.

TurnGreenHeaterandCompressorSwitch
on.I=ON
TankhasrunoutofHotWater.

HotTankCapacityis1.3liters.
WaitforHotTanktoheatwatertotemperaturepriorto
dispensingmorehotwater.

GreaterWaterCapacityWaterlogicWaterSystemsare
available.
HotWaterTemperature
Programming
VerifythattheCUBEhasbeenprogrammedtodesired
temperature.SeeProgramming:HotWaterTemperatureDP
Set‐UpInstructionsinthisTroubleshootingSection.


2.HotWaterisnotAvailable


PossibleReason Solution
HotTankOverloadTripped
ResetHotTankOverload.

HotTankOverloadInstructionsinthisTroubleshooting
Section.



CUBEManual Page87–Revision10‐8‐2018


RESETTINGTHEHOTTANKOVERLOADORHIGHLIMITSAFETY

1. TurnoffboththeGreenHeater/Compressor
SwitchandtheRedPowerSwitcheslocatedon
backofunit

O=OFF
9. Unplugpowertounit.




10.  WithaPhillipsHeadScrewdriver,removethe
twoscrewsatbackoftheTopCoverifinstalled.


11. RemoveTopCoverbyplacingyourhands
onthetopandpushingtheTopCover
towardstherear.

Liftandremove.
12.  WithaPhillipsHeadScrewdriver,RemovethetwoscrewsontheRight‐SidePanel

RemoveRightSidePanel.


CUBEManual Page88–Revision10‐8‐2018

13.  ReachupbehindtheHotTankandtakeholdoftheprotectivemetalboxcoveringthe
overloadsontheHotTank.TherearenutsthatsecurethemetalboxtotheHotTank,
howeverthenutsarelooseenoughtoremovethemmetalbox.
14.  PressRedButtononeachoverloadtoreset(therearetworesetbuttons)

















15.  Reassembleunitbyusingtheseinstructionsinreverse.


Locationofthetwo
HotTankOverload
Buttons

CUBEManual Page89–Revision10‐8‐2018

PROGRAMMING:DPSET‐UPHOTWATERTEMPERATURE

CUBEMainPCB‐DPSwitch2













3=UP
4=DOWN
