USE & CARE GUIDE
Waterwise 8800™
Countertop Water Purifier
®
SEE IT WORK
www.waterwise.com
See important safeguards on pages 2 and 3
An exclamation point within an equilateral triangle
is intended to alert user to the presence of important
operating and maintenance instructions in the literature
accompanying the appliance.
A lightning bolt within an equilateral triangle is intended
to alert user to risk of injury from electric shock.
Flame and steam vapor within an equilateral triangle
is intended to alert user to risk of injury from boiling
water and/or escaping steam.

IMPORTANT SAFEGUARDS
A person who has not read and understood all operating and safety
instructions is not qualified to operate this appliance. When using this
appliance, always adhere to basic safety precautions including:
READ ALL INSTRUCTIONS BEFORE USE.
FOR HOUSEHOLD USE ONLY.
1.UseINDOORS on a dry, level, well-supported, stable surface.
DO NOT use outdoors. DO NOT operate in a moving vehicle.
2.DO NOT allow children to be near Purifier without close super-
vision. Boiling water will scald if spilled on skin. Warn other users
of possible dangers from boiling water and/or escaping steam.
3.DO NOT remove kettle while Purifier is operating. Let cool at least
30 minutes after a cycle is finished. Boiling water or steam can cause
severeburns.
4.DO NOT change position or location of Purifier while it is operat-
ing or cooling. Wait at least one hour after a cycle is finished or in-
terrupted before moving Purifier. Boiling water or steam can cause
severeburns.
5.DO NOT place too near an edge of the supported surface where
Purifier can be bumped or be pulled down on someone. DO NOT
allow power cord or extension cord to hang over the edge of a coun-
ter or contact hot surfaces.
6. A short power supply cord is provided to reduce risks resulting from
becoming entangled in or tripping over a longer cord. If an exten-
sion cord must be used, its marked electrical rating should be at least
as great as the electrical rating of the Purifier. Electrical rating is
found on bottom of Purifier.
7. To protect against fire, electrical shock, and injury to persons,
DO NOT immerse power cord or Purifier in water or liquid.
8. DO NOT operate with a damaged cord or plug, after a malfunction,
or if the Purifier has been damaged in any manner. Return to
an authorized dealer or qualified service facility for examination
andrepair.
9.ThisPurifier is recommended for use with only potable water
supplies.DO NOT attempt to make safe drinking water from
nonpotable water sources. DO NOT use salt water as this will
damage certain components and will void warranty.
2Waterwise 8800 Purifier Use & Care Guide

Waterwise 8800 Purifier Use & Care Guide 3
10. Operate in a well-ventilated area away from other heat sources.
Provide adequate air space (at least 4 inches from walls or cabinets)
when in use. DO NOT place, store, or stack anything on top of or
against sides of Distiller while in operation. DO NOT place on or
near a hot gas or electric burner, or in a heated oven.
11. DO NOT operate without water in the kettle. Permanent damage
may occur.
12. DO NOT plug steam vent on top of kettle cover.
13. This Purifier requires no special care other than general cleaning
(page 9) and periodic filter replacement (page 7). If servicing becomes
necessary, please contact your authorized dealer or an authorized
service facility. DO NOT attempt to repair Purifier yourself. There
are NO user serviceable parts. See warranty for service details.
14. Unplug from wall outlet when not in use and before cleaning. Allow
to cool before putting on or taking off parts and before cleaning.
15. Make sure collection/storage carafe is properly placed for water
collection.
16. DO NOT FILL THE KETTLE ABOVE THE “MAX” LINES.
Overfilling the kettle will jeopardize water quality and may result in
damage to the Purifier that is not covered by the warranty.
17. DO NOT use appliance for other than intended use.
Plug Purifier into a GROUNDED 120 volt electrical outlet only. This
appliance has a polarized plug (one blade is wider than the other). To
reduce the risk of electrical shock, the plug will fit into a polarized outlet
only one way. If the plug does not fit fully into the outlet, reverse the plug.
If it still does not fit, contact a qualified electrician. DO NOT modify the
plug in any way.
CAUTION: NEVER REMOVE THE KETTLE WHILE THE FAN
MOTOR IS RUNNING, OR FOR 30 MINUTES AFTER IT STOPS.
SEVERE BURNS CAN RESULT FROM BOILING WATER OR
STEAM.
SAVE THESE INSTRUCTIONS

An interactive online guide for
programming, using, and main-
taining your purifier.
PRODUCT SPECIFICATIONS
Rating
120 VAC / 60 Hz / 800 W
Filling Volume
1 gallon
Production Capacity
.25 gallon/hour (1 liter/hour), 6 gallons/day
This product conforms to NSF/ANSI 62 for the specific performance
claims as verified and substantiated by test data.
The physiological effects of the operation of this appliance, beneficial or
otherwise, have not been investigated by Underwriters Laboratories Inc. See
Product Data Sheet for test data obtained from an independent laboratory.
Purifier will distill any amount up to 1 gallon per batch. If less than 1
gallon is wanted, fill kettle with desired amount. Purifier will automatically
shut off when no water remains in kettle.
ELECTRONICS
Control Buttons
From left to right the
control buttons are
“Start/Stop,” “Hour,”
“Minute,” and “De-
lay” (fig. A).
Setting the Time Display
Hours
To move the hours forward by one hour, press the “Hour” button quickly
once. To fast-forward the time, press for at least one second. After comple-
tion, the time display will blink for another five seconds before the time is
finally set.
4Waterwise 8800 Purifier Use & Care Guide
Figure A
SEE IT WORK
www.waterwise.com

Minutes
To move the minutes forward by one minute, press the “Minute” button
quickly once. To fast-forward the time, press for at least one second. After
completion, the time display will blink for another five seconds before the
time is finally set.
12-24 Hour Mode
Pressing the “Hour” and “Minute” buttons simultaneously for seven sec-
onds enables changeover from 12 hour mode to 24 hour mode (or from
24 hour mode to 12 hour mode). In 12 hour mode the display shows AM
or PM.
If power is interrupted the time will revert to 12:00 and will blink in the
display window. Clock will continue to run but must be reset to show cor-
rect time.
Setting the Display Function/Checking Delay Status
The Delay Function allows the Purifier to be programmed to start at a later
time.
Setting or Changing Delay Start Time
IMPORTANT: Determine desired Delay Start Time before setting
or changing.
Hours
Press “Delay” button once. Delay Start Time and “Delay” indicator appear
in the display window and Delay Start Time will show 12:00 (or last delay
time set).
Press the “Hour” button once, after which the hour figure blinks for three
seconds in the display window. During these three seconds, hours can be
forwarded by one hour by pressing the “Hour” button once. By continuous
pressing of the button, time can be fast-forwarded. After hour portion of
delay time is set, clock will revert to current time in three seconds.
Minutes
Press “Delay” button once. Delay Start Time and “Delay” indicator appear
in the display window and Delay Start Time will show 12:00 (or last delay
time set).
Press the “Minute” button once, after which the minutes figure blinks for
three seconds in display window. During these three seconds, minutes can
be forwarded by one minute by pressing the “Minute” button once. By
continuous pressing of the button, time can be fast-forwarded.
Waterwise 8800 Purifier Use & Care Guide 5

PM
ON
Start/Stop Hour Minute Delay
On
If time is correctly set, after three seconds the current time reappears
with “Delay” in the display. “Delay” indicates the delay time function is
activated. To deactivate delay time function, press “Delay” button twice
within a period of three seconds, or press “Delay” button once while in
delay mode. After completion, “Delay” will not appear next to time in the
display window.
Check Delay Time Status
Press the “Delay” button once. Delay Start Time appears in display
window with “Delay” in the display. After three seconds the current time
reappears.
Switching the Purifier On/Off
To turn Purifier on or off, press the “Start/Stop” button. When turning
Purifier on, “On” appears in the display window and the “On” (red) light
illuminates (fig. B). After turning Purifier off, the “On” light turns off.
Carafe Indicator
If carafe is not in correct position, or is removed from base unit during
operation, “Carafe” indicator will appear in display window for 90 seconds.
After 90 seconds the unit will shut off. To restart, place carafe in position
and press “Start/Stop.”
Kettle Indicator
If the kettle is not correctly positioned when you turn the Purifier on,
the “On” light (fig. B) will blink and the unit will shut off. If the kettle is
removed during a cycle, the unit will shut off.
Carbon Filter Indicator
The Carbon Filter Indicator shows four status bars to indicate filter life (fig.
B). Four bars indicate a new filter and zero bars indicate that filter needs
to be changed. In addition to bars the “Filter” indicator will flash in the
display when filter needs to be changed. To reset Filter Status Bars to new
filter status, press and hold “Delay” button for seven seconds.
6Waterwise 8800 Purifier Use & Care Guide
On Light
Figure B
Carbon Filter Indicator

PREPARING FOR FIRST TIME USE
CleanKettle
• Remove kettle from base unit
• Remove kettle cover by twisting counterclockwise, then lift
• Wash inside of kettle with soap and water
• Rinse thoroughly
CleanCarafe
• Remove carafe from base unit
• Pull tab to release carbon compartment cover (fig. D)
• Wash carafe and cover with soap and warm water
• Rinse thoroughly
Carbon Filter Preparation
Purifier uses a carbon filter in the carafe cover as a final “polishing” treat-
ment to remove traces of odors before purified water is collected in carafe.
Unit may be operated
with or without carbon
fi l t e r .
• Remove filter from
plastic bag
• Wash your hands with
soap and warm water
• Fill a clean container
with distilled or
boiled tap water
• Slowly immerse a
narrow end of the
filter bag into the
water.
Waterwise 8800 Purifier Use & Care Guide 7
Carbon
Compartment
Cover
Carbon
Filter
Housing
Figure D
Carbon
Filter
Carafe
Lid
Tab
Figure C
Carafe
with Lid
Base
Unit
Kettle
with Cover
“Start/Stop”
Button

Once the bottom quarter (1/4) is wet, slowly immerse entire bag,
squeezing gently to remove air. If the bag “puffs up,” you are immers-
ing it too quickly.
• Once the bag has been immersed, remove from the water and rinse it
by pouring more distilled water over bag to remove any carbon fines
(dust).
Install Filter
Be sure carbon is evenly distributed within bag, then place bag in filter
housing (fig. D). Replace cover on housing and place lid on carafe.
Replace Filter
The filter should be replaced as inicated by filter status bar (every two to
three months). Replace more often should the distilled water begin to have
an unwanted taste or odor. Reset the filter status bar by pressing and hold-
ing the “Delay” button (fig. A) for seven seconds. Discard first gallon of
distilled water as it may contain small, harmless carbon fines. Order re-
placement filters from the outlet where you purchased your Purifier.
USING THE COUNTERTOP PURIFIER
Operational maintenance and replacement requirements are essential for
this product to perform as advertised.
1.SetPurifier on a dry, level, well-supported, stable surface.
2. Rinse and fill kettle to “MAX” lines with approximately 1 gallon ordi-
nary tap water. DO NOT fill above “MAX” fill lines (fig. D).
3. Replace kettle cover. Twist clockwise to lock. slide kettle into base unit
andpressfirmly to ensure kettle is properly placed (fig. C).
4. Place carafe on base unit and plug power cord into a GROUNDED
120 VOLT outlet.
5. Press the ”Start/Stop” button to turn Purifier on (fig. C). The “On”
light will illuminate.
6. After the cycle is complete (approximately four hours) the Purifier turns
offautomatically.AFTER THE FAN MOTOR STOPS, WAIT AT
LEAST 30 MINUTES BEFORE REMOVING KETTLE COVER.
8Waterwise 8800 Purifier Use & Care Guide
“MAX” Fill Lines Kettle Lid
Kettle
Gasket
Kettle
Figure D

Waterwise 8800 Purifier Use & Care Guide 9
CAUTION: NEVER REMOVE THE KETTLE WHILE THE FAN
MOTOR IS RUNNING OR FOR 30 MINUTES AFTER IT STOPS,
SEVERE BURNS CAN RESULT FROM BOILING WATER OR
STEAM.
7.Discardfirst gallon of distilled water as it may contain some harmless
matter from manufacturing and/or packaging.
8. Rinse kettle thoroughly before refilling.
9. To pour water from carafe, open spout by pulling on center strip in
direction of arrow indicator near thumb position.
10. Store carafe filled with purified water in the refrigerator.
PURIFIER MAINTENANCE
WARNING: ALWAYS BE SURE TO UNPLUG POWER CORD
FROM ELECTRICAL OUTLET BEFORE CLEANING OR
SERVICINGPURIFIER.
Cleaning Kettle
Before every distillation cycle, rinse the inside with lukewarm tap water
and remove any loose residue. Clean by wiping out the inside of the kettle
with a damp cloth and rinse. If scale starts to form at the bottom, use an
approved cleaner/descaler such as KLEENWISE to remove deposits. White
vinegar or automatic coffee pot cleaner can also be used. Residue buildup
on the bottom of the kettle will prevent the system from purifying a
complete batch of water.Remove kettle from base unit. Fill kettle with
hot water and follow the instructions on the cleaner. Use a soft plastic or
nylon scouring pad if needed. DO NOT use abrasive cleansers, caustic
acids, steel wool pads, or metal utensils. Rinse thoroughly after cleaning.
DO NOT operate Purifier with cleaning solution in kettle.
Cleaning Carafe
Clean with mild dish detergent and soft cloth. Rinse thoroughly. DO NOT
use carafe to store liquids other than purified water. Other liquids may
transfer a taste or odor.
Cleaning Exterior Surfaces
To keep your Purifier looking new, periodically clean the exterior plastic
surfaces with a soft, damp cloth. DO NOT use any caustic cleaning solu-
tions, scouring pads or powders because they will damage the plastic finish.
continued

IMPORTANT:DO NOT IMMERSE BASE UNIT OR KETTLE IN
WATER.There are NO user serviceable parts inside Distiller. Contact
qualified service personnel for repair if the troubleshooting tips (below) fail.
TROUBLESHOOTING
Not making purified water
1.Purifier power cord not plugged into electrical outlet.
2. No power to electrical outlet.
3. Kettle not plugged into base unit receptacle.
4. Did not press “Start/Stop” button to start cycle.
5. Did not fill the kettle with water.
6. Carafe is not in place.
7. Kettle bottom has residue buildup.
Not making enough water each batch
1. Did not fill kettle with water to “MAX” lines.
2. Carafe is not in correct position.
3. Kettle cover is not locked into position (page 8).
4. Kettle bottom has residue buildup.
Flashing Indicator
1.“Carafe”flashing in display indicates carafe is not in position.
2. Flashing “On” light indicates kettle is not in position.
3.“Filter”flashing in display: replace filter and reset Filter Status Bars.
4.Timeflashing in display indicates power supply has been interrupted.
Water Leaks
1. Water receptacle in carafe lid is not open.
2. Kettle cover is not locked into position (page 8).
3. Kettle gasket damaged or missing.
4. Fan not working.
5.Airflow restricted around Purifier.
6. Kettle filled above “MAX” lines (page 8).
REPLACEMENT PARTS & ACCESSORIES
Description Part #
1 Gallon Replacement Carafe 8850
Carbon Filter Replacement Single 8601
Carbon Filter Replacement 6 Pack 8606
KleenwiseCleaner/Descaler 1003
Gasket for Kettle 8646
10 Waterwise 8800 Purifier Use & Care Guide

PRACTICAL USES
FOR CLEAN DISTILLED WATER
Drinking…
it’s healthy and delicious
Complexion Care…
daily cleansing without pore clogging impurities
Cooking…
enhances natural taste and appearance without unsavory chemicals
Aquariums…
fish thrive in a clean, clear, chlorine-free tank
Houseplants…
eliminate brown tips on foliage and salt deposits on flower pots—
enjoy blooms longer
Coffee, Tea & Cocoa…
you’ll enjoy truer, richer flavors while using less
Fruit Juices…
experience the freshly squeezed, natural flavor
Low Sodium Diets…
up to 99.9% sodium free
Steam Irons & Humidifiers…
no damaging scale buildup means longer product life
Ice Cubes…
crystal clear and sparkling—won’t spoil your drink
Pet Care…
pets will enjoy the same benefits people do
Baby Formulas…
pure enough for formulas, inhalation therapy and herbal tinctures
and many other uses you’ll discover…
Waterwise 8800 Purifier Use & Care Guide 11

WARRANTY REGISTRATION CARD
Please fill out and return the enclosed registration card or register online at
http://www.waterwise.com/customers/customers.asp
Registration will not affect warranty coverage, but may expedite processing of your
warranty. Registration is the only way to guarantee you will be notified by Waterwise
of any issues that arise concerning this product.
OWNER’S LIMITED WARRANTY
Waterwise warrants, to the original purchaser, this product against defects in materials
and workmanship, excluding the disposable carbon filter and gasket, for a period of
one (1) year from the date of purchase. Defects or failures due to shipping/handling,
improper use or maintenance, including abuse or neglect, normal wear, water condi-
tions, accidents, alterations or modifications, or unauthorized repair are specifically
excluded from this warranty. No dealer, distributor, agent, representative, or other
person is authorized to extend or expand this warranty.
Waterwise is not responsible or liable for personal injury, property damage, or inciden-
tal or consequential damages arising out of, or in connection with, the use or perfor-
mance of the product or other damages with respect to loss of use, or costs of removal,
installation, or reinstallation.
Waterwise will, at its option, replace or repair the defective part(s) without charge,
provided they are returned, transportation prepaid by owner, to an authorized service
facility or to the address below. Enclose a letter describing the problem, copy of dated
proof of purchase, and your name, address and daytime telephone number.
This limited warranty does not guarantee uninterrupted service. Repair or replace-
ment as provided under this warranty is the exclusive remedy of the purchaser. This
limited warranty is in lieu of all other warranties, expressed or implied, including, but
not limited to, any implied warranty of merchantability or fitness for a particular use
or purpose. This warranty gives you specific legal rights and you may also have other
rights which vary from state to state or province to province.
Outside the United States, a different warranty may apply. For details, please contact
your authorized Waterwise distributor.
3608 Parkway Blvd • Leesburg Florida 34748-9399 • [phone] • Fax: [phone]
www.waterwise.com • E-mail: [e-mail]
© 2002 Waterwise Inc Printed in USA Form 8722 •7252064 (Rev E)
