WATSON Rapid Charger User manual

Owner's
Manual Please read
before using
this equipment.
8-Bay
Rapid Charger
for AA/AAA Ni-MH & Ni-Cd
Rechargeable Batteries
O
w
n
e
r
'
s
O
n
'
Ple
ase
re
ad
r
d

Thank you for
purchasing the
Watson 8-Bay
Rapid Charger.
Browse through
this manual for
information and
useful tips on how
to use your new
equipment.
>

THE WATSON 8-BAY LCD
BATTERY CHARGER'S
FEATURES INCLUDE:
1. Eight Charging Indicators - 8
individual LCD indicators show the
charging status of each battery.
2. Patented Technology allows
you to charge different size or
different capacity batteries
simultaneously.
3. Automatic Charge Current
Selection automatically selects
charging current for AA and AAA
batteries.
4. Reverse Polarity Protection,
Alkaline and Bad Battery
Protection protect your batteries
and the charger from damage
when batteries are installed
incorrectly.
4 | Charger Features
.
0
$

5. Automatic Timer Shut-Off - The
special automatic shut-off circuit
senses when batteries are fully
charged and automatically stops
charging.
6. AC Adapter and DC Cord -
Powered by an external AC
adapter for indoor use or by a
cigarette lighter plug from 12V
car DC while you are traveling.
7. Microprocessor - Intelligent
microprocessor control can fully
charge batteries and prevents
overcharging.
8. Delta Voltage Protection allows
you to charge batteries fully.
9. Safety Timer also prevents
batteries from overcharging.
10. A Unique Discharge Function
allows you to refresh the
batteries before charging.
Charger Features | 5
7
5

6 | Charger Operation
You can charge up to 8 AA/AAA Ni-MH/Ni-Cd
batteries fully. Multiple-battery design accommodates
both AA and AAA Ni-MH batteries. This is an economical
power solution for high-tech, battery-operated devices.
The batteries can be charged at least 1.000 times,
and provide high performance for high-drain devices.
The universal 100-240V AC and 12-24 V DC inputs
are perfect for traveling and charging anywhere.
RAPID CHARGER
OPERATION:
(A) Power Input
For indoor usage,
1Connect the supplied AC adapter's
barrel plug into the charger's rear
power input jack.
2Plug the AC adapter into a standard AC
outlet.
Or, for in-car usage,
1Plug the optional DC car cord into your
vehicle's cigarette lighter, without the
charger attached.
2Connect the charger to the connector
end of the DC car cord.

Charger Operation | 7
(B) Battery Charging
1Insert 1 -8 AA/AAA batteries into the
battery chambers as indicated by the
polarity symbols (+ and -) marked inside
each chamber.
2Press DISCHARGE once to discharge
AA/AAA batteries. The battery icon will
shift up and down while discharging.
3When the batteries are fully discharged,
the battery icon stops shifting. It will
then display the battery capacity while
charging.
4However, a flashing full-battery icon
indicates an abnormality, such as the
presence of bad batteies or alkaline
batteries, and the charger will stop
charging.
5When batteries are fully charged, the
full-battery icon lights.
6When charging is completed, unplug
the charger from the outlet and then
remove the batteries from the charger.

*Actual charging time may vary depending on the cell's discharge
level, capacity, and condition. Longer charging time may occur
when the charger is used in temperatures above 35°C (95°F).
CHARGING TIME*: (approximate)
DISCHARGING TIME: (approximate)
Safety Guard Protection Time: AA/AAA - 6 hours
8 | Charging Time
Type
Ni-MH Capacity Left/Right 1-2 Cells
Left/Right
3-4 Cells
AAA 850 mA 0.8 hours 1.6 hours
1000 mA 1 hour 2 hours
AA
1800 mA 1.8 hours 3.6 hours
2000 mA 2 hours 4 hours
2300 mA 2.3 hours 4.6 hours
Type
Ni-MH Capacity Current (mA) 1-8 cells
AAA 850 mA
200
4.25 hours
1000 mA 5 hours
AA
1800 mA 9 hours
2000 mA 10 hours
2300 mA 11.5 hours

Charging Time | 9
Connect the AC or
DC Adapter here
Polarity
Symbols
Charging
Chamber
AA
Tab
LCD AAA
Tab
Discharge
Button
AC Adapter
DC Adapter

10 | Charger Specifications
SPECIFICATIONS:
Power Adapter: Input 100~240V AC, 50/60 Hz;
Output 12V 1.3A
Rapid Battery Input 12V DC, 1.3A;
Charger Output 1.5V
AA=500mA, AAA=250mA (max.)
Automatic Negative Delta V
Shut-off
Approvals: Adapter: RoHS/FCC/ETL/CE
Charger: CE/RoHS
Dimensions: 7.8 x 3.1 x 1.2 (200 x 80 x 33 mm)
Weight: 4.2 oz (120g) (Charger unit)
Specifications are typical; individual units may vary.
Specifications are subject to change and improvement
without notice. The actual product may vary from the
product pictured in this document.

IMPORTANT SAFETY
INSTRUCTIONS:
SAVE THESE INSTRUCTIONS
Be sure to observe the following important
precautions whenever using the charger and
adapter. Never try to open the case of the
charger or attempt your own repairs. High-
voltage internal components present the risk of
electric shock when exposed.
Keep the charger and adapter away from
water and other liquids. Never let them
get wet. Moisture can cause fire and
electric shock.
Should you ever notice smoke or a
strange odor coming out of the charger,
immediately unplug the AC adapter
from the power outlet. Using the charger
under these conditions can cause fire and
electric shock.
Unplug the AC adapter from the power
outlet and clean the area around the
prongs of the plug when necessary. Dust
around the prongs can cause fire.
Safety Instructions | 11

AC ADAPTER PRECAUTIONS
Never use an electrical outlet whose
voltage is outside the rating marked on
the AC adapter. Doing so can cause fire
or electic shock. Use only the supplied AC
adapter or DC car cord (optional) for the
charger.
Do not allow the AC adapter power
cord to be cut or damaged, and do not
place heavy objects on it. A damaged AC
adapter cord can cause fire or electric
shock.
Never try to modify the AC adapter
power cord, or subject it to severe
bending, twisting, or pulling. Doing so can
cause the risk of fire and electric shock.
Never touch the AC adapter while your
hands are wet. Doing so can cause electric
shock.
Do not overload extension cords or wall
outlets. Doing so can cause fire and
electric shock.
12 | Safety Instructions

Indoor use only. Do not expose the
charger to rain or snow.
To reduce the risk of damage to the
electrical plug and cord, disconnect by
pulling the plug, not the cord.
Make sure the cord is located properly
so that it will not be stepped on, tripped
over, or subjected to damage.
To reduce the risk of electric shock,
unplug the charger from the outlet before
attempting cleaning, or when not in use.
Do not use solvents to clean the unit.
They may damage the surface and the
plastic parts of the unit. Clean the unit
gently with soft dry cloth only.
Not recommended for use by children.
BATTERY HANDLING PRECAUTIONS
Incorrect handling or misuse of bateries can
cause them to leak or burst and damage your
charger. Be sure to note the following important
precautions to avoid problems with batteries.
Use only Ni-MH or Ni-Cd dry cell batteries
with the charger. Do not charge any other
Safety Instructions | 13

kind of batteries, as they may burst and
cause personal injury and damage.
Always make sure that the plus (+} and
minus (-) terminals of the batteries are
facing correctly, corresponding to the
markings on the charger itself. Improper
loading of batteries creates the danger
of personal injury or damaging objects
nearby.
Do not expose batteries to direct heat or
dispose of them by burning. Doing so can
cause an explosion.
Do not operate the charger in an
environment with temperatures over
40°C (104°F) due to the risk of electrolyte
leakage, over-heating, and battery
damage.
The batteries that power the equipment
normally become warm as they discharge.
If electrolyte material touches your eyes,
immediately wash eyes with running cold
water, and get medical attention.
Please recycle the dead batteries, and
preserve our environment.
14 | Safety Instructions

LIMITED ONE-YEAR WARRANTY
Watson provides a limited warranty that this
product is free from defects in materials and
workmanship to the original purchaser under
normal use for a period of one (1) year from the
original purchase date. Watson's responsibility
with respect to this limited warranty shall be
limited solely to repair or replacement, at its
option, of any product which fails during normal
consumer use. This warranty does not extend
to damage or failure which results from misuse,
neglect, accident, alteration, abuse, improper
installation or maintenance. EXCEPT AS
PROVIDED HEREIN, WATSON MAKES NEITHER
ANY EXPRESS WARRANTIES NOR ANY IMPLIED
WARRANTIES, INCLUDING BUT NOT LIMITED TO
ANY IMPLIED WARRANTY OF MERCHANTABILITY
OR FITNESS FOR A PARTICULAR PURPOSE. To
obtain a replacement during the time of this
warranty please return the defective Item with
proof of purchase along with an RMA number to
the place of purchase. This warranty gives you
specific legal rights, and you may also have other
rights which vary from state to state.
Warranty | 15
