weintek cMT-iV5 series User manual

User
Manual
cMT-iV5 Startup Guide

Table of Contents
Chapter1. Overview........................................................................................................................................ 1
1.1. Specification....................................................................................................................................... 1
1.2. Dimensions......................................................................................................................................... 2
1.3. Ethernet port...................................................................................................................................... 3
1.4. CR1225 battery .................................................................................................................................. 3
1.5. Power connection .............................................................................................................................. 3
1.6. Requirements..................................................................................................................................... 3
Chapter2. System Setting ............................................................................................................................... 4
2.1. Information ........................................................................................................................................ 4
2.2. General............................................................................................................................................... 5
2.3. Language ............................................................................................................................................ 5
2.4. Input Method ..................................................................................................................................... 5
2.5. Time/Date .......................................................................................................................................... 6
2.6. Network.............................................................................................................................................. 6
2.7. cMT-SVR System Setting .................................................................................................................... 6
Chapter3. CloudHMI App................................................................................................................................ 8
3.1. Introduction of icons.......................................................................................................................... 8
3.2. How to load project file to cMT-iV5................................................................................................... 9
3.3. How to switch between cMT-SVR projects...................................................................................... 11
Chapter4. Updating Firmware, OS................................................................................................................ 12
4.1. Updating CloudHMI.......................................................................................................................... 12
4.2. Updating OS ..................................................................................................................................... 13

cMT-SVR Startup Guide
V1.00
1
Chapter1. Overview
1.1. Specification
Cloud Human Machine Interface
Features
One Gigabit Ethernet Port
Built-in 512MB Flash Memory
Built-in 1000MB RAM
Fan-less Cooling System
Power Isolator Inside
Built-in mono speaker
Designed for connecting cMT-SVR
Display
Display
9.7” TFT
Resolution (WxH dots)
1024 x 768
Brightness cd/m2
350
Contrast Ratio
500:1
Backlight Type
LED
Backlight Life Time
>30,000 hrs.
Colors
262K
Touch Panel
Type
Tempered Glass, Capacitive Type
Accuracy
Active Area Length(X)±2%, Width(Y)±2%
Memory
Storage
512 MB
RAM
1GB
Processor
32 bits RISC Cortex-A9 1GHz
I/O Port
Ethernet
10/100/1000M
Audio Output
Built-in Mono Speaker
Video Input
N/A
RTC
Built-in
Power
Input Power
24±20%VDC
Power Isolation
Built-in
Power Consumption
900mA@24VDC
Voltage Resistance
500VAC (1 min)
Isolation Resistance
Exceed 50Mat 500VDC
Vibration Endurance
10 to 25Hz(X,Y,Z direction 2G 30 minutes)
Specification
Enclosure
Plastic
Dimensions WxHxD
257.2 x 199.7 x 32.7mm
Panel Cutout
248.5 x 191 mm
Weight
Approx.0.76 kg
Environment
Protection Structure
NEMA4 / IP65
Storage Temperature
-20°~60°C (-4°~ 140°F)
Operating Temperature
0°~ 50°C (32°~ 122°F)
Relative Humidity
10% ~ 90% @ 40°C (non-condensing)
PCB Coating
Yes
Certificate
CE marked
Language
Display
English, French, Italian, Spanish, Russian, Simplified
Chinese, Traditional Chinese, Korean, Deutsch
Input Methods
English, French, Italian, Spanish, German, Russian, Pinyin,
Zhuyin

cMT-SVR Startup Guide
V1.00
2
1.2. Dimensions
257.2mm [10.13"]
199.7mm [7.86"]
247.7mm [9.75"]
190.2mm [7.49"]
32.7mm [1.29"]
248.5mm [9.78"] W x 191mm [7.52"] H
248.5mm [9.78"]
191mm [7.52"]
R16mm [R0.63"]
a
bc
a
a a
7.9mm [0.31"]
a
VESA 75mm screw holes
c
Ethernet Port
b
Power Connector

cMT-SVR Startup Guide
V1.00
3
1.3. Ethernet port
The unit has one 10/100/1000M Gigabit Ethernet port.
The LED indicators on the Ethernet port indicate:
Orange LED: LAN link status
Green LED: Active communication status
To connect Ethernet, please use a CAT-6 Ethernet cable.
1.4. CR1225 battery
The cMT-iV5 requires a CR1225 coin type lithium battery to keep the RTC running.
Battery type: CR1225 3V lithium battery
1.5. Power connection
Power: The unit can be powered by DC power only, voltage range: 24±20% Volts DC, compatible
with most controller DC systems. The power conditioning circuitry inside the unit is accomplished
by a switching power supply. The peak starting current can be as high as 500mA.
Note: Connect positive DC line to the‘+’terminal and the DC ground to the‘-’terminal.
1.6. Requirements
1. CloudHMI: Built-in app for connecting cMT-SVR.
2. Supported HMI model: cMT-SVR.
3. One cMT-iV5 can log in and operate three cMT-SVRs simultaneously.

cMT-SVR Startup Guide
V1.00
4
Chapter2. System Setting
Startup cMT-iV5 and run the built-in CloudHMI app.
Tap the Start Button in the upper-left corner of the screen to open the setting page.
Tapping the checkerboard area returns to the previously used project screen.
2.1. Information
Tap Setting > Information to view the information about this cMT-iV5.
The information includes: Machine type, HMI name, IP address, Subnet mask, Gateway, Mac
address, App. version, and OS. version.

cMT-SVR Startup Guide
V1.00
5
2.2. General
In General tab, screen brightness and audio volume can be adjusted, and password can be changed.
After entering the password, the HMI name can be viewed and changed. Tap the Direction icon to
change the display direction.
2.3. Language
In Language tab, select an interface language. The options are: English, French, Italian, Spanish,
Russian, Simplified Chinese, Traditional Chinese, Korean, and German.
2.4. Input Method
Add in keyboards of different languages. The options are: English, French, Italian, Spanish, Russian,
Simplified Chinese (Pinyin), Traditional Chinese (Zhuyin), and German.
Tap icon in the upper-left corner (a cMT-iV5 password is required). Enter the password and

cMT-SVR Startup Guide
V1.00
6
click OK, the Time/Date and Network setting tabs will be enabled.
2.5. Time/Date
In Time/Date tab, set the current system time and date.
2.6. Network
In Network tab, enable [Obtain an IP address automatically] or manually enter IP address, Subnet
mask, Gateway, and DNS.
2.7. cMT-SVR System Setting
The system information of cMT-SVR can be set from CloudHMI in cMT-iV5. Tap Search, find the

cMT-SVR Startup Guide
V1.00
7
cMT-SVR and tap to open cMT-SVR setting page.
See cMT-SVR User Manual for more information:
http://www.weintek.com/Download/cMT/eng/UserManual/cMT_SVR_UserManual_eng.pdf

cMT-SVR Startup Guide
V1.00
8
Chapter3. CloudHMI App
3.1. Introduction of icons
Icon
Description
When running CloudHMI, tap the Start Button to configure the settings.
Project tab lists the logged in cMT-SVRs. Each cMT-iV5 can control three
cMT-SVRs simultaneously.
Search tab lists all the cMT-SVRs on the same network.
History tab lists the cMT-SVRs previously logged in.
System tab is used to adjust the brightness and volume, or view information.
Tap this icon to make cMT-SVR CPU LED (green) blink for identify the cMT-SVR.
Tap this icon to load cMT-SVR project to cMT-iV5 and run the project.
Tap this icon to configure cMT-SVR system settings.
In Search tab, sort cMT-SVRs according to IP address.
In Search tab, sort cMT-SVRs according to HMI name.
In History tab, clear all the login records.
Tap this icon to understand more information about the features and
operations.
