Introduction
RETeval-DRTM Electroretinograph is designed as an aid in diagnosis and disease
management of visual pathway dysfunctions or ophthalmic disorders such as diabetic
retinopathy (DR). The DR Assessment Protocol has been clinically validated to match the
diagnosis from seven-field stereoscopic fundus images.
Test results are visible immediately on the device screen. The device automatically
creates PDF reports that include test results, patient information and your practice or
institution information. These PDF reports can be transferred to any PC via a USB cable.
Before using the device, read the sections of the manual that pertain to your use of the
RETeval-DR.
For information about any Welch Allyn product, contact Welch Allyn at
www.welchallyn.com/about/company/locations.
Intended use
The RETeval-DR device is intended to generate photic signals and measure and display
evoked responses generated by the retina and the visual nervous system.
The operators of the device are intended to be physicians, optometrists, medical
technicians, clinical medical assistants, nurses, and other health-care professionals.
Indications for use
RETeval-DR is indicated for use in the measurement of visual electrophysiological
potentials, including electroretinogram (ERG). RETeval is also indicated for use in the
measurement of pupil diameter.
RETeval-DR is intended as an aid in diagnosis and disease management in visual
pathway dysfunctions or ophthalmic disorders (e.g., diabetic retinopathy).
Contraindications
Use of the RETeval-DR device is contraindicated under these conditions:
•Do not use with patients diagnosed with photosensitive epilepsy.
• Do not use with patients who are allergic to the sensor strip gel.
• Avoid use when the orbit structure is damaged or surrounding soft tissue has an
open lesion.
1

Some patients may feel discomfort when viewing the flickering light that the RETeval-DR
device creates to test their eyes. This discomfort usually subsides quickly when the test
procedure completes.
Latex statement
The components of the RETeval-DR device that could contact the user or patient were
not made with natural rubber latex. This includes all items that could be contacted during
normal operation, and all other functions, such as user maintenance and cleaning, as are
defined in the Directions for use.
No internal components are known to be made with natural rubber latex.
Applicability
Regulatory and Safety requirements are occasionally revised. Please refer to the user
manual that originally accompanied your RETeval device for regulatory and safety
information relevant to that specific device.
2Introduction Welch Allyn®RETeval-DR™

Symbols and definitions
Documentation symbols
WARNING The warning statements in this manual identify conditions or practices that
could lead to illness, injury, or death. Warning statements appear with a grey background in
a black and white document.
CAUTION The caution statements in this manual identify conditions or practices that could
result in damage to the equipment or other property, or loss of data. This definition applies
to both yellow and black and white symbols.
Consult operating instructions/directions for use (DFU). A copy of the DFU is available on this
website. A printed copy of the DFU can be ordered from Welch Allyn for delivery within 7
calendar days.
Mandatory - Consult Directions for Use
Power symbols
Power button Direct current (DC)
Connectivity symbols
USB
3

Miscellaneous symbols
Manufacturer Date of manufacture
Product Identifier Reorder Number
Do not re-use By prescription or order of
physician
Type BF applied parts Meets essential requirements of
European Medical Device
Directive 93/42/EEC
ETL Listed mark indicating proof
of product compliance.
Conforms To:
AAMI Std ES 60601-1, CENELEC
EN Std 60601-1, IEC Std
60601-1-6, IEC Std 60601-1, IEC
Std 62366, ISO Std 15004-1, ISO
Std 15004-2, IEC 60601-2-40
Certified To:
CSA Std No. 60601-1
Temperature limit
Keep away from rain Lot Code
Expiration Date Global Trade Identification
Number
Do not dispose of in trash,
Contains Li-Metal batteries
Not made with natural rubber
latex
Serial Number Contains lithium-Ion. This symbol
indicates general recovery /
recyclable and must not be
disposed of as unsorted
municipal waste and must be
collected separately.
4Symbols and definitions Welch Allyn®RETeval-DR™

Equipment serial number
Each RETeval-DR device has a unique equipment serial number. The equipment serial
number may appear in one of two formats.
The serial number takes the form R # # # # # #.
RProduct code is R
# # # # # # Production sequence number (5 or 6 digits)
Locate the serial number on the device
1. Remove the battery cover.
2. Pivot the battery away from the device to locate the serial number.
The serial number begins with the letter "R."
Locate the serial number in Systems
1. Scroll to Settings and then press the joystick.
2. Scroll to System and then press the joystick.
The System Information screen appears showing the following information.
• The firmware version
• The serial number
• The number of tests completed
5

6Equipment serial number Welch Allyn®RETeval-DR™

About warnings and cautions
Warning and caution statements can appear on the Welch Allyn RETeval-DR device, the
packaging, the shipping container, or in this Directions for use.
The RETeval-DR is safe for patients and clinicians when used in accordance with the
instructions and the warning and caution statements presented in this Directions for use.
Before using the device, you must familiarize yourself with all warnings and cautions,
with the steps to power up the device, and with the sections of this directions for use
that pertain to your use of the device. In addition to reviewing the general warnings and
cautions presented in the next section, you must also review the more specific warnings
and cautions that appear throughout the manual in conjunction with setup/startup,
operation, and maintenance tasks.
•Failure to understand and observe any warning statement in this manual could lead
to patient injury or illness.
• Failure to understand and observe any caution statement in this manual could lead to
damage to the equipment or other property, or loss of patient data.
General warnings and cautions
WARNING Patient or operator injury risk. Use of accessories, transducers
and cables other than those specified or provided by the manufacturer of
this equipment could result in increased electromagnetic emissions or
decreased electromagnetic immunity of this equipment and result in
improper operation. Use of most commercial electrodes with leads 1 meter
or less in length should work.
WARNING Patient injury risk. Dispose of single-use components (for
example, sensor strips) after using them one time.
WARNING Patient injury risk. The eyecup should be cleaned after each
patient.
WARNING Fire and explosion hazard. Do not operate the monitor in the
presence of a flammable anesthetic mixture with air, oxygen, or nitrous
oxide; in oxygen-enriched environments; or in any other potentially
explosive environment.
WARNING Fire and explosion hazard. Do not use batteries from other
sources. This may result in excessive temperatures, fire, or explosion.
WARNING Patient injury risk. Reference intervals should only be changed
under physician direction.
7

CAUTION Do not sterilize the device or sensor strips.
CAUTION All servicing of this equipment is to be performed by Welch
Allyn, Inc. or by a center approved by Welch Allyn, Inc.
CAUTION This device needs to be installed and put into service according
to the EMC information provided herein.
CAUTION Portable and mobile RF communications equipment can affect
RETeval-DR performance.
CAUTION Input overload can occur in proximity to defibrillator or
electrocautery devices.
CAUTION This device is not protected against the ingress of water and
should not be used in the presence of liquids which may enter the device.
CAUTION Do not connect the RETeval-DR device to the docking station
while measuring a patient. This will compromise the quality of recordings
and subject isolation.
CAUTION Results deleted on the device cannot be recovered. Save
results you want to keep on a computer or laptop before deleting them
from the RETeval-DR device.
CAUTION Do not modify this equipment without authorization of the
manufacturer.
CAUTION Do not use the device in direct sunlight. Strong ambient light
may affect results.
CAUTION Use only the provided power brick described in Accessories.
CAUTION Only connect the RETeval-DR device to computers or laptops
that have passed the safety standard for information technology equipment
IEC 60950-1, EN 60950-1, UL 60950-1 to ensure the safety of the USB
electrical connection.
CAUTION Do not turn off the device while saving data from a patient test.
Turning off the device while saving patient data may delete the data.
CAUTION Do not use the device adjacent to or stacked with other
equipment. If the device is used adjacent or stacked with other equipment,
the device should be observed to verify normal operation in the
configuration in which it will be used.
CAUTION Do not submerge the device in liquid or allow liquid to enter the
interior of the device.
CAUTION Liquid cleaners may damage the LED lights and camera.
CAUTION Do not use automatic cleansing machines or sterilization.
CAUTION Consult the cleaning agent and germicidal cleaner agent
manufacturer instructions for their proper use and germicidal efficacy prior
to their use.
8About warnings and cautions Welch Allyn®RETeval-DR™

CAUTION Only use the cleaning or germicidal cleaner agent types listed or
damage may occur.
Directions for use About warnings and cautions 9

10 About warnings and cautions Welch Allyn®RETeval-DR™

Controls and connectors
No. Feature Description
1 RETeval-DR device Used to test for diabetic retinopathy
2 Docking station Charges RETeval-DR and enables data transfer to a PC. Connect
to an electrical outlet using the supplied power brick
3 LCD display Displays information for charging, testing, and adjustments to the
device
11

No. Feature Description
4 Power indicator When the light is steady, it indicates that the device is powered
on. When it is blinking, it indicates that the device is in the
process of shutting down.
5 Power button Push button to turn the device on and off
6 Thumb joystick Allows you to move through menus, perform functions, and select
parameters by moving the joystick up/down/right/left/select
7 Eyecup Blocks ambient light during testing
8 Bezel Area to which the eyecup attaches
9 Sensor strip lead connector Connects the RETeval-DR device to the sensor strip
10 Battery cover Covers the battery compartment
12 Controls and connectors Welch Allyn®RETeval-DR™

Setup
Unpack the system
The RETeval-DR device is packaged with the following items. Confirm that all items are
included.
Number Item Description
1 RETeval-DR device Used to test for diabetic retinopathy.
2 Sensor strip lead Connects the device to sensor strips for testing
3
Docking station Charges the RETeval-DR device and enables data transfer to a
computer or laptop. Connect to a mains outlet using the supplied
power brick.
13

Number Item Description
4 USB cable Connects the device to a computer or laptop to transfer results.
5 Mains outlet plates Mains outlet plate options that matches available mains outlets.
6 Power brick Connects the device to a mains outlet.
7 Sensor strips Used to test the eye for diabetic retinopathy.
Not shown Dust cover Protects the device from dust while not in use.
Not shown
RETeval-DR Directions for use This document. The Directions for use (DFU) is also available as a
portable document format (.pdf ) file located in the root directory
of the RETeval-DR device when the device is connected to a
computer or laptop via the USB cable.
If any item is missing, contact Welch Allyn Technical Support: www.welchallyn.com/
service. We recommend that you save the shipping box and packing materials in case
you need to store or ship the system.
Docking station
You can place the device in the docking station to charge the device or to connect and
transfer data to a computer or laptop.
Charge the battery
When the RETeval-DR device battery charge is low, a warning message is shown on the
device screen. Return the device to the docking station and let it charge. Do not attempt
to test a patient after this message appears.
The device is powered by an integrated, rechargeable lithium-ion battery. A full charge
permits testing of approximately 70 patients.
The battery icon in the upper-right corner of the screen displays the amount of charge
remaining. The amount of green in the battery icon indicates the remaining capacity.
Note Misalignment of the USB plug and socket can cause damage. The plug and
socket should be visually inspected prior to each installation of the charging
cable. If you see damage, contact Welch Allyn Technical Support:
www.welchallyn.com/service.
14 Setup Welch Allyn®RETeval-DR™

Connect the power cord
The RETeval-DR device is shipped with a partial charge. However, it is strongly
recommended that you fully charge the device prior to testing.
1. Attach the power brick plate that matches your mains outlet to the power brick
power plug.
2. Insert the power cord receptacle into the power brick port on the back of the docking
station.
3. Insert the power brick power plug into the mains outlet. The power supply accepts
100 – 240 VAC, 50/60 Hz.
Charge the battery using the power brick
The RETeval-DR lithium-ion battery charges when in the docking station from either the
computer or laptop via the USB cable or the power brick connection to a mains outlet. If
the power brick is connected, charging will be significantly faster than if a USB
connection is used. The charging status is shown on the display. If the display is blank,
press the power button to turn it on. The RETeval-DR device is shipped with a partial
charge.
1. Insert the power cord receptacle for the power brick into the power brick port on the
back of the docking station.
2. Insert the power brick plate that is appropriate for your location into the power brick
power plug.
3. Insert the power brick power plug into the mains outlet.
Charge the battery using the USB port
Charging the RETeval-DR device using the USB cable is significantly slower than
charging the device using the power brick and a mains outlet. The charging status is
shown on the display. If the display is blank, press the power button to turn it on. The
RETeval-DR device is shipped with a partial charge.
1. Insert the USB connector into the port on the back of the docking station.
2. Insert the USB connector into an available USB port on your computer or laptop.
Connect the sensor strip lead
The RETeval-DR sensor strip lead connection is above the battery compartment on the
front of the device.
Connect the sensor strip lead to the blue sensor strip lead connector.
Thumb joystick
The joystick provides a simple and intuitive user interface. Use your thumb to push the
joystick in the desired direction.
Directions for use Setup 15

Press the joystick... To...
UP Move the selection up
DOWN Move the selection down
LEFT when the cursor is at the left edge of the screen Go back one screen
RIGHT when the cursor is at the right edge of the screen Go forward one screen
CENTER Select a highlighted item
Device settings
The device menus enable you to change many of the device settings or functions. These
settings include:
• Language
• Date/Time
• Backlight
• Practice information
• Page size
• Memory
• System
Change the language
The LANGUAGE menu enables you to select the language used in the device.
1. Scroll to Settings > Language, and then press the joystick.
2. Scroll either up or down to advance to the desired language, and then press the
joystick.
3. Scroll left to return to the Main display.
Change the date and time
The device uses the date and time to label results and to compute the patient’s age. The
time appears in country-specific format.
1. Scroll down with the joystick to Settings > Date / Time, and then press the
joystick.
The Set Date menu appears.
2. Scroll up or down to select the Month, and then press the joystick.
The display advances to the Day field.
3. Scroll up or down to select the Day, and then press the joystick.
The display advances to the Year field.
4. Scroll up or down to select the Year, and then press the joystick.
The display advances to the Time screen.
16 Setup Welch Allyn®RETeval-DR™
