Weldex WDR Series User manual

WDR
Software User Manual
Digital Video Recorder
WDR Series
Version 1.9.0, August 2008
24-10437-3 Revision A

Digital Video Recorder
WDR Series
WDR
Software User Manual
Version 1.9.0, August 2008
24-10437-3 Revision A
[phone]
www.weldex.com

Copyright 2008
Weldex Corporation
All Rights Reserved
No part of this document may be reproduced without the prior permission of Weldex Corporation.

Acknowledgment
Company and product names published in this manual are trademarks or registered trademarks of
their respective owners.
If this document is translated from the original English version by Weldex Corporation, all
reasonable endeavors will be used to ensure the accuracy of translation. Weldex Corporation shall
not be liable for any translation errors contained herein or for incidental or consequential damages
in connection with the furnishing or use of this translated material.
Due to continuous development of our products, the information in this document is subject to
change without notice. Weldex Corporation shall not be liable for errors contained herein or for
incidental or consequential damages in connection with furnishing or use of this material. Contents
of this publication may be preliminary and/or may be changed at any time without any obligation
to notify anyone of such revision or change, and shall not be regarded as a warranty.
Canadian Notice
This Class A digital apparatus complies with Canadian ICES-003.
Cet numérique de la classe A est conforme à la norme NMB-003 du Canada.
Declaration of Conformity
This product complies with the requirements of the European Council Electromagnetic
Compatibility Directive 2004/108/EEC and the Low Voltage Directive 2006/95/EEC.
This equipment must not be modified for any reason and it must be installed as stated in the
Manufacturer’s instruction.
If this shipment (or any part thereof) is supplied as second-hand equipment, equipment for sale
outside the European Economic Area or as spare parts for either a single unit or system, it is not
covered by the Directives.

DISCLAIMER
• While every effort has been made to ensure that the information contained in this guide is
accurate and complete, no liability can be accepted for any errors or omissions.
• Weldex Corporation reserves the right to change the specifications of the hardware and
software described herein at any time without prior notice.
• No part of this guide may be reproduced, transmitted, transcribed, stored in a retrieval system,
or translated into any language in any form, by any means, without prior written permission
of Weldex Corporation
• Weldex Corporation makes no warranties for damages resulting from corrupted or lost data
due to a mistaken operation or malfunction of the Digital Video Recorder, the software, the
hard drives, personal computers, peripheral devices, or unapproved / unsupported devices.
FCC NOTICE
Digital Video Recorder, Model WDR-4012, Model WDR-9012, Model WDR-9024,
Model WDR-1612, Model WDR-1624.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including interference that may cause
undesired operation.
Note: This equipment has been tested and found to comply with the limits for Class A digital
devices, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by on or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an on a circuit different from that to which the receiver is
connected.
• Consult the dealer or an experience radio/TV technician for help.
The hard disk provided with the digital video recorder must be used with this equipment in order to
comply with Class A limits in subpart B of Part 15 on FCC rules.
Do not make any changes or modifications to the equipment unless otherwise specified in the
manual. If such changes or modifications should be made, you could be required to stop operation
of the equipment.

24-10437-3 Rev. A v
TABLE OF CONTENTS
This document contains confidential and proprietary information of Weldex Corporation 9/10/08
Chapter 1: Introduction
Chapter Summaries.................................................................................................................................1-1
Package Contents....................................................................................................................................1-1
Note on Other Manufacturer’s Documentation ........................................................................................1-2
Technical Support....................................................................................................................................1-2
Manual Conventions................................................................................................................................1-2
Specifications...........................................................................................................................................1-3
Chapter 2: System Setup
Remote Identification...............................................................................................................................2-1
Virtual Keyboard/Calendar.......................................................................................................................2-2
Virtual Keyboard...............................................................................................................................2-3
Calendar ..........................................................................................................................................2-4
Main Menu...............................................................................................................................................2-5
System Menu...........................................................................................................................................2-6
General System Information............................................................................................................2-7
General Menu Field Definitions................................................................................................2-7
Spot Out...........................................................................................................................................2-8
On-Screen Display...........................................................................................................................2-9
Configuring Date and Time............................................................................................................2-10
Date/Time Field Definitions....................................................................................................2-11
System Information........................................................................................................................2-11
System Info Field Definitions..................................................................................................2-12
Viewing System Log.......................................................................................................................2-12
System Log Field Definitions..................................................................................................2-13
Upgrading the System....................................................................................................................2-14
Configuring HDD Options...............................................................................................................2-15
HDD Info Field Definitions......................................................................................................2-16
Restoring Factory Default Settings................................................................................................2-17
User Management..........................................................................................................................2-17
Adding/Editing User Groups...........................................................................................................2-19
Add Group Field Definitions...................................................................................................2-20
Adding/Editing System Users.........................................................................................................2-20
Export/Import Setup.......................................................................................................................2-21
Device Menu..........................................................................................................................................2-23
Configuring Cameras.....................................................................................................................2-24
Camera Field Definitions........................................................................................................2-24
Configuring PTZ Cameras, Presets, and Guard Tours..................................................................2-26
Configuring Audio...........................................................................................................................2-30

vi 24-10437-3 Rev. A
Table of Contents WDR Software User Manual
This document contains confidential and proprietary information of Weldex Corporation9/10/08
Configuring Sensor Alarms............................................................................................................2-30
Sensor In/Relay Out Field Definitions....................................................................................2-31
Configuring Motion Alarms.............................................................................................................2-33
Motion Alarm Field Definitions ...............................................................................................2-33
Configuring Other Alarms...............................................................................................................2-34
Extra Alarm Field Definitions..................................................................................................2-35
Alarm Notifications.........................................................................................................................2-36
Record Menu.........................................................................................................................................2-37
Configuring Camera Recording and Audio Options.......................................................................2-37
Camera Field Definitions........................................................................................................2-38
Configuring Recording Schedule...................................................................................................2-39
Schedule Setting Field Definitions .........................................................................................2-42
Tips on Using the Recording Matrix.......................................................................................2-43
Network Menu........................................................................................................................................2-45
Configuring Network Settings.........................................................................................................2-45
Network Field Definitions .......................................................................................................2-46
Configuring DDNS..........................................................................................................................2-47
DDNS Server Field Definitions...............................................................................................2-48
Setting Up Event Notification.........................................................................................................2-49
Event Notification Field Definitions.........................................................................................2-49
Copy Menu.............................................................................................................................................2-51
Copying Files.................................................................................................................................2-51
Manual Copy Field Definitions ...............................................................................................2-53
Chapter 3: Operation
System Startup and Shutdown ................................................................................................................3-1
System Startup.................................................................................................................................3-1
System Shutdown............................................................................................................................3-1
Abnormal Shutdown.........................................................................................................................3-2
Automatic File Testing and Recovery..............................................................................................3-2
System Login...........................................................................................................................................3-3
WDR Modes.............................................................................................................................................3-3
Channel Indicator.............................................................................................................................3-4
Fix to Taskbar..................................................................................................................................3-4
Live Mode ................................................................................................................................................3-5
Picture in Picture (PIP).....................................................................................................................3-6
Playback Mode........................................................................................................................................3-7
PTZ Mode................................................................................................................................................3-9
Pop-Up Menus.......................................................................................................................................3-10
Quick Access Pop-Up Menu..........................................................................................................3-10
Display Mode Pop-Up Menu..........................................................................................................3-11
Search Pop-Up Menu.....................................................................................................................3-11
Search Menus........................................................................................................................................3-11
Calendar Search............................................................................................................................3-11
Event Search .................................................................................................................................3-13

24-10437-3 Rev. A 1-1
Chapter 1
This document contains confidential and proprietary information of Weldex Corporation. 9/10/08
INTRODUCTION
The WDR series consist of 16-channel, 9-channel, and 4-channel Digital Video Recorders
(DVRs). This manual describes how to configure and use the WDR series devices.
For hardware information and related recommendations and precautions refer to the WDR
Quick Installation Guide.
NOTE
Certain setup and configuration details are different for 4-channel,
9-channel, and 16-channel DVRs. Generally in such cases details for a
16-channel DVR are presented, for example, a screen capture will
show-channels 1-8 and 9-16.
CHAPTER SUMMARIES
+Chapter 1: Introduction, describes the package contents, supported client software,
system architecture, and technical specifications. Manual conventions and technical
support information is also provided.
+Chapter 2: System Setup, describes system setup options and procedures.
+Chapter 3: Operation, this chapter introduces you to operation basics such as system
startup and shutdown, logging in, and display modes.
PACKAGE CONTENTS
Thank you for choosing the Weldex WDR.
Your package contains the following items:
+WDR DVR
+Installation CD (contains WDR software and user documentation)
+Mouse
+Power cable
+Plug-in connector block (WDR 4-channel models only)
+External connector
+Remote control

Introduction WDR Software User Manual
1-2 24-10437-3 Rev. A
This document contains confidential and proprietary information of Weldex Corporation.9/10/08
+Rack mount brackets (16-channel and 9-channel WDR only)
+Two AAA batteries
When you open the package:
+Carefully inspect the shipping containers as soon as you receive them (with the
delivery agent present). Some shipping companies want to have an agent present
when a damaged container is opened.
+If a container is damaged, open it immediately, inspect the contents, and have the
agent make note on the shipping document.
+Check the purchase order against the packing slips to ensure the order is complete.
+If the contents of a container are damaged in any way, notify the carrier and your
Weldex Corporation representative immediately.
+Report any discrepancies to your Weldex Corporation representative.
+Save the packing materials for possible return shipments.
NOTE ON OTHER MANUFACTURER’SDOCUMENTATION
Weldex Corporation does not duplicate documentation of other equipment manufacturers.
When necessary, as in this installation procedure, Weldex Corporation provides
documentation that supplements that of other manufacturers. When unpacking your
equipment, keep all original manufacturer documentation for future reference.
TECHNICAL SUPPORT
Technical assistance is provided to Weldex Corporation authorized dealer representatives
from 5 a.m. PST to 5 p.m. PST Monday through Friday. System users can get answers to
operator questions by calling the local Weldex Corporation sales/service office.
The authorized dealer representatives can also provide you with information on the
maintenance contracts and the on-site field service.
MANUAL CONVENTIONS
The following items are used throughout this manual to indicate special circumstances,
exceptions, important points regarding the equipment or personal safety, or to emphasize a
particular point.
NOTE
Notes indicate important points or exceptions to the information provided in
the main text.

!
CAUTION
Cautions remind you that certain actions, if not performed exactly as stated,
can cause damage to equipment, security problems, or cause the system
to operate incorrectly due to errors in system setup or programming.
WARNING
Warnings indicate that the possibility of personal injury exists if an
action or actions are not performed exactly as stated.
WDR Software User Manual Introduction
24-10437-3 Rev. A 1-3
This document contains confidential and proprietary information of Weldex Corporation. 9/10/08
SPECIFICATIONS
Tables 1-1 and 1-2 list technical specification and required environmental conditions for all
WDR models.
Table 1-1: WDR Technical Specifications
Specification 16-channel 9-channel 4-channel
Video Input 16 BNC 9 BNC 4 BNC
Loopthrough Yes
Analog Output 1 RCA Composite
1 S-Video
4 BNC Spot Monitor
Outputs
1 RCA Composite
1 S-Video
4 BNC Spot Monitor
Outputs
1 BNC Composite
1 S-Video
1 Spot Monitor Output
Audio Input 4 RCA
Audio Output 1 RCA (ADPCM format)
Video Format NTSC / PAL standards
Alarm Input 16 TTL (DC
5V/25mA), NO/NC
Programmable
9 TTL (DC 5V/25mA),
NO/NC
Programmable
4 TTL (DC 5V/25mA),
NO/NC
Programmable
Alarm Output 4 Relay Output
12 TTL
Open-Collector
4 Relay Output
5 TTL Open-Collector 2 Relay Output
Operator Interface VGA, S-Video, Composite Video
Internal Storage
Archive 250 GB / 500 GB / 1 TB 250 GB / 500 GB

Introduction WDR Software User Manual
1-4 24-10437-3 Rev. A
This document contains confidential and proprietary information of Weldex Corporation.9/10/08
Recording Rate and
Resolution NTSC (9024, 1624)
240 IPS at 352x240
120 IPS at 704x240
60 IPS at 704x480
NTSC (9012, 1612)
120 IPS at 352x240
60 IPS at 704x240
30 IPS at 704x480
NTSC
120 IPS at 352x240
60 IPS at 704x240
30 IPS at 704x480
PAL (9024, 1624)
200 IPS at 352x288
100 IPS at 704x288
50 IPS at 704x576
PAL (9012, 1612)
100 IPS at 352x288
50 IPS at 704x288
25 IPS at 704x576
PAL
100 IPS at 352x288
50 IPS at 704x288
25 IPS at 704x576
Live Frame Rate 480 IPS (NTSC), 400
IPS (PAL) 270 IPS (NTSC), 225 IPS (PAL) 120 IPS (NTSC), 100 IPS (PAL)
Live Resolution 720 x 480 (TV-NTSC), 720 x 576 (TV-PAL), 640 x 480 (CRT/LCD)
Live Display 1, 4, 9, 16, PIP 1, 4, 9, PIP 1, 4, PIP
Playback Display 1, 4, 9, 16, PIP 1, 4, 9, PIP 1, 4, PIP
IPS per Camera 1 to 30 (NTSC), 1 to 25 (PAL)
Video Compression MPEG4 ASP (Advanced Simple Profile)
USB Ports Four USB 2.0 ports One USB 1.0 (front
panel port) and one
USB 2.0 (back panel
port)
Ethernet Port 10/100 Mbps Full Duplex Ethernet
Recording Modes Continuous, Schedule, Alarm, Motion (no speed boost), Overwrite
Supports Recording Schedule per camera.
Alarm Notification Automatic e-mail (SMTP authentication is not currently supported),
External Alarm, Video Loss, Record Failure, HDD Failure, Shutdown,
Log-in.
Power Failure
Recovery Auto reboot while maintaining previous record setting
Communication Port USB, RS-232C (future use), RS-485 terminal block
User Interface USB Optical Mouse, Jog-Shuttle, Remote-Controller with ID
(ID 00 to 99)
Video Data Export*** DVD-RW, CD-RW, model dependent.
Table 1-1: WDR Technical Specifications
Specification 16-channel 9-channel 4-channel

WDR Software User Manual Introduction
24-10437-3 Rev. A 1-5
This document contains confidential and proprietary information of Weldex Corporation. 9/10/08
PTZ Control Pan / Tilt / Zoom / Focus / Iris / Preset / Guard-Tour / Auto-Scan (if
feature is available on camera, itself). 
Supported protocols: Weldex, HSDN, Ernitec, TBT Dome, Pelco P,
Pelco D, and SDM 100
Power Source AC 100 - 240V, 50/60Hz, Universal
Operating System Embedded Linux
Power Consumption 83W 81W 70W
Weight 19.8 lbs (9 kg) 13.2 lbs (6 kg)
Dimensions
(WxHxD) 17x3.5x17.7 in (430x89x450 mm) 15x2.9x16.5 in
(381x74x419 mm)
Standard
Certifications Class A: FCC, CE(EMCD/LVD)
UL Listing WDR-1612;
WDR-1624 WDR-9012;
WDR-9024 WDR-4012
* In some cases, such as recording at high/highest quality, or recording video that contains high amount of motion
activities, the IPS of recorded video can drop a few IPS below user specified value. The IPS drop is not visible
when watching live video; it is only visible during the playback of recorded video.
***Automatic video data backup is not available.
Table 1-2: WDR Environmental Conditions
Specification Value (All Models)
Operating temperature 32°F to 104°F (0°C to 40°C)
Operating humidity 20% to 80% relative humidity
Storage temperature -17°F to 140°F (-20°C to 60°C)
Storage humidity 20% to 90% relative humidity
Table 1-1: WDR Technical Specifications
Specification 16-channel 9-channel 4-channel

Introduction WDR Software User Manual
1-6 24-10437-3 Rev. A
This document contains confidential and proprietary information of Weldex Corporation.9/10/08

24-10437-3 Rev. A 2-1
Chapter 2
This document contains confidential and proprietary information of Weldex Corporation. 9/10/08
SYSTEM SETUP
This chapter describes system setup procedures as performed locally.
After the WWW Port has been set up (see page 2-47), users from the ADMIN user group can
configure non-system settings via the Internet. For more information on remote setup see the
SAgent Installation and Operation Manual.
REMOTE IDENTIFICATION
When using remote control, both the remote control unit and the DVR unit must have remote
identification set up. The setting on both units must match. The default ID number both on
the remote control and on the DVR unit is 0.
To set up/change remote identification on the remote control:
1. On the remote control, push the IDSEL button for 3 to 5 seconds.
2. Using the numeric buttons, enter the remote identification number. Input
range is 00 to 99. For proper functioning the number entered here must match
the “Remote Controller ID” number set during system setup (see page 2-7).
To set up/change remote identification on the DVR:
1. From the Main menu select System>General.
2. The General window opens. From the Remote Controller ID drop-down list
select the remote identification number.

System Setup WDR Software User Manual
2-2 24-10437-3 Rev. A
This document contains confidential and proprietary information of Weldex Corporation.9/10/08
3. Click Save.
4. Click Save.
VIRTUAL KEYBOARD/CALENDAR
When the configuration steps require you to enter numerical or alphabetical input, you will
be using a virtual keyboard. In other instances, you will need to use a calendar to select date
and/or time.
NOTE
Only English characters can be entered using the virtual keyboard.
The same icon is used to launch Virtual Keyboard and Calendar.Function of the icon
is specific to context. The kind of application (virtual keyboard or calendar) launched when
you click the icon is determined automatically and depends on the kind of input required.

WDR Software User Manual System Setup
24-10437-3 Rev. A 2-3
This document contains confidential and proprietary information of Weldex Corporation. 9/10/08
Virtual Keyboard
There are two types of virtual keyboards. When you need to enter letters, numbers,
and/or other characters, a full keyboard will be displayed.
Space
Numeric and
alphabetical
keys
Exit
Backspace
Enter
Shift
Shift Lock
Edit box
Caps Lock
When the allowed input is numbers only, a numeric keyboard will be displayed.
Edit box Exit
Enter
Backspace
To use the virtual keyboard:
1. Move the mouse pointer over a virtual key and click on it. Typed text will
appear in the Edit box.
2. To confirm the text you typed and exit click on Enter.
3. You can also close the keyboard without saving the text by clicking Exit.

System Setup WDR Software User Manual
2-4 24-10437-3 Rev. A
This document contains confidential and proprietary information of Weldex Corporation.9/10/08
Calendar
There are two types of calendars. When accessed from most windows, the calendar
displays and allows you to specify only the date.
Days of the
month
Year
Month
When accessed from the Date/Time window and from the Manual Copy window, in
addition to the date the calendar allows you to specify the time.
Time in the following format:
HH:MM:SS
Days of the
month
Year
Month
To use the calendar:
1. Use the arrows to select month and year.
2. Move the mouse pointer over a day you want to select and click on it.
3. If applicable, use the drop-down lists to set the time.
4. To save the selection click OK.
5. You can also close the keyboard without saving by clicking CANCEL.

WDR Software User Manual System Setup
24-10437-3 Rev. A 2-5
This document contains confidential and proprietary information of Weldex Corporation. 9/10/08
MAIN MENU
The Main menu gives you access to all configuration options. They are grouped under the
following categories:
+System - Use this menu to view/modify general system configuration, perform user
management, and to import/export settings between WDR devices
+Device - This menu allows you to configure camera options (including Guard Tour
and PTZ) and associated alarms.
+Record - Allows you to set up a recording schedule.
+Network - Use this menu to set up network connections and event notifications.
+Copy - Allows you to copy files.
You can access the Main menu in the following ways:
+Click the Menu button on the device’s front panel.
+When in the Live Mode, click the Menu button on the taskbar.
+Right-click on any channel area.
For login information see “System Login” on page 3-3.

System Setup WDR Software User Manual
2-6 24-10437-3 Rev. A
This document contains confidential and proprietary information of Weldex Corporation.9/10/08
SYSTEM MENU
This section describes options available in the Setup menu screens. The System menu has the
following structure:
System Menu
General Date/Time System Info
User
Management Export/Import
Setup
Log off
Spot Out
OSD
Date/Time Calendar
Factory
Default
System Log
HDD Info
System
Upgrade
Add/Edit
Group
Add User
Spotout
