Wen JT3062 User manual
6-INCH TWO-BLADE
BENCHTOP JOINTER
Instruction Manual
IMPORTANT: Your new tool has been engineered and manufactured to WEN’s highest standards for dependability,
ease of operation, and operator safety. When properly cared for, this product will supply you years of rugged,
trouble-free performance. Pay close attention to the rules for safe operation, warnings, and cautions. If you use
your tool properly and for its intended purpose, you will enjoy years of safe, reliable service.
NEED HELP? CONTACT US!
Have product questions? Need technical support? Please feel free to contact us:
For replacement parts and the most up-to-date instruction manuals, visit WENPRODUCTS.COM
MODEL JT3062
CONTENTS
WELCOME 3
Introduction ..................................................................................................... 3
Specifications................................................................................................... 3
SAFETY 4
General Safety Rules........................................................................................ 4
Jointer Safety Warnings................................................................................... 6
Electrical Information....................................................................................... 8
BEFORE OPERATING 9
Unpacking & Packing List.................................................................................9
Know Your Jointer ......................................................................................... 10
Assembly & Adjustments............................................................................... 11
OPERATION & MAINTENANCE 14
Operation ....................................................................................................... 14
Maintenance....................................................................................................17
Troubleshooting Guide................................................................................... 19
Exploded View & Parts List.............................................................................20
Warranty Statement ........................................................................................23
2
To purchase accessories for your tool, visit WENPRODUCTS.COM
Replacement Blades (Part No. JT3062B)
SPECIFICATIONS
INTRODUCTION
Thanks for purchasing the WEN Benchtop Jointer. We know you are excited to put your tool to work, but first, please
take a moment to read through the manual. Safe operation of this tool requires that you read and understand this
operator’s manual and all the labels affixed to the tool. This manual provides information regarding potential safety
concerns, as well as helpful assembly and operating instructions for your tool.
NOTE: The following safety information is not meant to cover all possible conditions and situations that may occur.
WEN reserves the right to change this product and specifications at any time without prior notice.
At WEN, we are continuously improving our products. If you find that your tool does not exactly match this manual,
please visit wenproducts.com for the most up-to-date manual or contact our customer service at 1-800-232-1195.
Keep this manual available to all users during the entire life of the tool and review it frequently to maximize
safety for both yourself and others.
Indicates danger, warning, or caution. The safety symbols and the explanations with them deserve your
careful attention and understanding. Always follow the safety precautions to reduce the risk of fire, electric shock
or personal injury. However, please note that these instructions and warnings are not substitutes for proper ac-
cident prevention measures.
3
Motor 120V, 60 Hz, 10A
Cutterhead Rotation Speed 11,000 RPM
Max Cutting Width 6 Inches
Max Cutting Depth 1/8 Inch
Recommended Cutting Depth* 1/32 Inch
Number of Blades 2
Table Size 30 in. x 6-3/16 in.
Fence Size 4-1/4 in. x 19-3/4 in.
Dust Port Diameter 2-1/2 Inches
Fence Bevel 90-135°
Product Dimensions 30 in. x 17.5 in. x 12.5 in.
Weight 41.1 lbs
*When jointing boards over 6 inches long, reduce maximum cutting depth by 1/32 inch per inch of length.
GENERAL SAFETY RULES
WORK AREA SAFETY
1. Keep work area clean and well lit. Cluttered or dark
areas invite accidents.
2. Do not operate power tools in explosive atmo-
spheres, such as in the presence of flammable liquids,
gases or dust. Power tools create sparks which may ig-
nite the dust or fumes.
3. Keep children and bystanders away while operating
a power tool. Distractions can cause you to lose control.
ELECTRICAL SAFETY
1. Power tool plugs must match the outlet. Never mod-
ify the plug in any way. Do not use any adapter plugs
with earthed (grounded) power tools. Unmodified plugs
and matching outlets will reduce risk of electric shock.
2. Avoid body contact with earthed or grounded surfac-
es such as pipes, radiators, ranges and refrigerators.
There is an increased risk of electric shock if your body
is earthed or grounded.
3. Do not expose power tools to rain or wet conditions.
Water entering a power tool will increase the risk of elec-
tric shock.
4. Do not abuse the cord. Never use the cord for car-
rying, pulling or unplugging the power tool. Keep cord
away from heat, oil, sharp edges or moving parts.
Damaged or entangled cords increase the risk of electric
shock.
5. When operating a power tool outdoors, use an ex-
tension cord suitable for outdoor use. Use of a cord
suitable for outdoor use reduces the risk of electric
shock.
6. If operating a power tool in a damp location is un-
avoidable, use a ground fault circuit interrupter (GFCI)
protected supply. Use of a GFCI reduces the risk of elec-
tric shock.
PERSONAL SAFETY
1. Stay alert, watch what you are doing and use com-
mon sense when operating a power tool. Do not use a
power tool while you are tired or under the influence
of drugs, alcohol or medication. A moment of inatten-
tion while operating power tools may result in serious
personal injury.
2. Use personal protective equipment. Always wear
eye protection. Protective equipment such as a respira-
tory mask, non-skid safety shoes and hearing protection
used for appropriate conditions will reduce the risk of
personal injury.
3. Prevent unintentional starting. Ensure the switch is
in the off-position before connecting to power source
and/or battery pack, picking up or carrying the tool.
Carrying power tools with your finger on the switch or
energizing power tools that have the switch on invites
accidents.
4. Remove any adjusting key or wrench before turning
the power tool on. A wrench or a key left attached to a
rotating part of the power tool may result in personal
injury.
5. Do not overreach. Keep proper footing and balance
at all times. This enables better control of the power
tool in unexpected situations.
6. Dress properly. Do not wear loose clothing or jew-
elry. Keep your hair and clothing away from moving
parts. Loose clothes, jewelry or long hair can be caught
in moving parts.
Safety is a combination of common sense, staying alert and knowing how your item works. The term “power tool”
in the warnings refers to your mains-operated (corded) power tool or battery-operated (cordless) power tool.
SAVE THESE SAFETY INSTRUCTIONS.
WARNING! Read all safety warnings and all instructions. Failure to follow the warnings and instructions may
result in electric shock, fire and/or serious injury.
4
GENERAL SAFETY RULES
7. If devices are provided for the connection of dust
extraction and collection facilities, ensure these are
connected and properly used. Use of dust collection
can reduce dust-related hazards.
POWER TOOL USE AND CARE
1. Do not force the power tool. Use the correct power
tool for your application. The correct power tool will
do the job better and safer at the rate for which it was
designed.
2. Do not use the power tool if the switch does not turn
it on and off. Any power tool that cannot be controlled
with the switch is dangerous and must be repaired.
3. Disconnect the plug from the power source and/or
the battery pack from the power tool before making
any adjustments, changing accessories, or storing
power tools. Such preventive safety measures reduce
the risk of starting the power tool accidentally.
4. Store idle power tools out of the reach of children
and do not allow persons unfamiliar with the power
tool or these instructions to operate the power tool.
Power tools are dangerous in the hands of untrained us-
ers.
5. Maintain power tools. Check for misalignment or
binding of moving parts, breakage of parts and any
other condition that may affect the power tool’s opera-
tion. If damaged, have the power tool repaired before
use. Many accidents are caused by poorly maintained
power tools.
6. Keep cutting tools sharp and clean. Properly main-
tained cutting tools with sharp cutting edges are less
likely to bind and are easier to control.
7. Use the power tool, accessories and tool bits, etc.
in accordance with these instructions, taking into ac-
count the working conditions and the work to be per-
formed. Use of the power tool for operations different
from those intended could result in a hazardous situa-
tion.
8. Use clamps to secure your workpiece to a stable
surface. Holding a workpiece by hand or using your
body to support it may lead to loss of control.
9. KEEP GUARDS IN PLACE and in working order.
SERVICE
1. Have your power tool serviced by a qualified repair
person using only identical replacement parts. This
will ensure that the safety of the power tool is main-
tained.
CALIFORNIA PROPOSITION 65 WARNING
Some dust created by power sanding, sawing, grinding,
drilling, and other construction activities may contain
chemicals, including lead, known to the State of Califor-
nia to cause cancer, birth defects, or other reproductive
harm. Wash hands after handling. Some examples of
these chemicals are:
• Lead from lead-based paints.
• Crystalline silica from bricks, cement, and other
masonry products.
• Arsenic and chromium from chemically treated
lumber.
Your risk from these exposures varies depending on
how often you do this type of work. To reduce your ex-
posure to these chemicals, work in a well-ventilated area
with approved safety equipment such as dust masks
specially designed to filter out microscopic particles.
Safety is a combination of common sense, staying alert and knowing how your item works. The term “power tool”
in the warnings refers to your mains-operated (corded) power tool or battery-operated (cordless) power tool.
SAVE THESE SAFETY INSTRUCTIONS.
WARNING! Read all safety warnings and all instructions. Failure to follow the warnings and instructions may
result in electric shock, fire and/or serious injury.
5
JOINTER SAFETY WARNINGS
JOINTER SAFETY
1. TOOL PURPOSE
This jointer is designed for creating flat surfaces on
wood or wood-like products only. Smoothing other
materials could result in fire, injury, or damage to
the workpiece. Using the machine for any other
purpose for which it is not designed may result in
serious injuries, machine damage and voiding of the
warranty.
2. MACHINE MOUNTING
For the operator’s safety, the jointer must be securely
mounted onto a flat and stable surface or stand.
3. PERSONAL SAFETY
•
Always wear ANSI Z87.1-approved glasses with
side shields, hearing protection, and a dust mask.
•
Do not wear loose clothing or jewelry, as they
might get drawn in by the tool. Tie back long hair.
•
DO NOT wear gloves while operating this machine.
4. ELECTRIC CORDS
Keep cords away from heat, oil, sharp edges, and
moving parts of the tool. Have an electrician replace
or repair damaged or worn cords immediately.
5. TOOL & ACCESSORIES INSPECTION
Before operation, check the tool and accessories
for any damage or missing parts. Do not use the
tool if any part is missing or damaged. Make sure
all adjustments are correct and all connections are
tight. Keep all guards in place. Make sure all moving
parts are free from interference.
6. JOINTER ACCESSORIES
• Do not use blades, or any accessories that are
damaged or worn. Replace blades as they become
damaged or dull.
• Make sure all blades and accessories are sharp
enough for the task at hand before using them.
• Make sure blades are aligned and properly attached
to the cutterhead before using your planer.
• Always turn off and unplug the unit before doing any
cleaning or maintenance. Use a brush or compressed
air to remove chips or debris. Never use your hands
to remove excess material and debris.
7. Allow the jointer to come to full speed before using
the machine.
8. WORKPIECE REQUIREMENTS
Check the workpiece carefully for splits, knots, nails,
or other obstructions. These types of blemishes may
cause a safety risk during smoothing.
9. USE HIGH QUALITY LUMBER
Blades last longer and cuts are smoother with higher
quality wood.
10. DO NOT joint material shorter than 8-1/8”,
narrower than 3/4”, or thinner than 1/4”. Never make
a jointing cut deeper than 1/8”. Use a push block or
push stick for jointing material narrower or thinner
than 3”.
11. PREVENTING ACCIDENTAL STARTING
Make sure the power switch is in the OFF position
prior to plugging in the machine. Always make sure
the power switch is in the OFF position and the
machine is unplugged when doing any cleaning,
assembly, setup operations, or when not in use.
12. SUPPORT THE WORKPIECE adequately at all
times during operation; maintain control of the
workpiece.
13. DO NOT back workpiece toward the infeed table.
14. If gluing a workpiece, always use a high quality
glue that meets the needs of the particular workpiece.
15. Take precautions against KICKBACK. DO NOT
permit anyone to stand or cross in line of the
cutterhead’s rotation. Kickback or thrown debris will
travel in this direction.
16. Do not operate this tool until it is completely
assembled and installed according to the instructions.
17. Remove scrap pieces and other objects from the
table and work area before turning ON the jointer.
18. Do not touch moving pieces. Keep hands away
from all moving parts and cutting surfaces.
WARNING! Do not let comfort or familiarity with the product replace strict adherence to product safety rules.
Failure to follow the safety instructions may result in serious personal injury.
6
JOINTER SAFETY WARNINGS
WARNING! Do not let comfort or familiarity with the product replace strict adherence to product safety rules.
Failure to follow the safety instructions may result in serious personal injury.
19. Never perform layout, assembly or set-up work
on the table while the jointer is operating.
20. Always turn off and unplug the machine
before cleaning, making adjustments or changing
attachments. Accidental start-ups may occur if the
tool is plugged in during an accessory change or
adjustment.
21. CLEANING
Never use solvents to clean plastic parts. Solvents
could dissolve or otherwise damage the material.
Use only a soft damp cloth to clean plastic parts.
22. REPLACEMENTS
Should any component of your jointer be missing/
damaged or fail in any way, shut off the switch
and remove the plug from power supply outlet.
Replace the missing, damaged, or failed parts using
only identical replacement parts before resuming
operation.
These safety instructions can’t possibly warn of
every scenario that may arise with this tool,
always make sure to stay alert and use com-
mon sense during operation.
7
ELECTRICAL INFORMATION
AMPERAGE REQUIRED GAUGE FOR EXTENSION CORDS
25 ft. 50 ft. 100 ft. 150 ft.
10A 14 gauge 12 gauge 10 gauge 8 gauge
3. Check
with a licensed electrician or service personnel if you do not completely
understand the grounding instructions or whether the tool is properly grounded.
4. Use only three-wire extension cords
that have three-pronged plugs and outlets
that accept the tool’s plug. Repair or replace a damaged or worn cord immediately.
CAUTION!
In all cases, make certain the outlet in question is properly grounded. If
you are not sure, have a licensed electrician check the outlet.
GUIDELINES AND RECOMMENDATIONS FOR EXTENSION CORDS
When using an extension cord, be sure to use one heavy enough to carry the current your
GROUNDING INSTRUCTIONS
In the event of a malfunction or breakdown
, grounding provides the path of least resistance for an electric
current and reduces the risk of electric shock. This tool is equipped with an electric cord that has an
equipment grounding conductor and a grounding plug. The plug MUST be plugged into a matching outlet
that is properly installed and grounded in accordance with ALL local codes and ordinances.
1. Do not modify the plug provided.
If it will not fit the outlet, have the proper outlet installed by a licensed
electrician.
2. Improper connection
of the equipment grounding conductor can result in electric shock. The conductor
with the green insulation (with or without yellow stripes) is the equipment grounding conductor. If repair or
replacement of the electric cord or plug is necessary, DO NOT connect the equipment grounding conductor
to a live terminal.
1. Examine extension cord before use. Make sure your extension cord is properly wired and in good condition.
Always replace a damaged extension cord or have it repaired by a qualified person before using it.
2. Do not abuse extension cord. Do not pull on cord to disconnect from receptacle; always disconnect by pulling on
plug. Disconnect the extension cord from the receptacle before disconnecting the product from the extension cord.
Protect your extension cords from sharp objects, excessive heat and damp/wet areas.
3. Use a separate electrical circuit for your tool. This circuit must not be less than a 12-gauge wire and should be
protected with a 15A time-delayed fuse. Before connecting the motor to the power line, make sure the switch is in
the OFF position and the electric current is rated the same as the current stamped on the motor nameplate. Running
at a lower voltage will damage the motor.
product will draw. An undersized cord will cause a drop in line voltage resulting in loss of power and overheating.
The table below shows the correct size to be used according to cord length and ampere rating. When in doubt, use
a heavier cord. The smaller the gauge number, the heavier the cord.
Fig. 1
8
Tools & Accessories
9
UNPACKING
With the help of a friend or trustworthy foe, such as one of your in-laws, carefully remove the jointer from the
packaging and place it on a sturdy, flat surface. Make sure to take out all contents and accessories. Do not discard
the packaging until everything is removed. Check the packing list below to make sure you have all of the parts and
accessories. If any part is missing or broken, please contact customer service at 1-800-232-1195 (M-F 8-5 CST),
UNPACKING & PACKING LIST
PACKING LIST
Tools & Accessories
Jointer
HARDWARE BAG
• Fence Locking Handle (1)
• M6x16 Socket Head Screw (2)
• Square Nut (2)
• 8mm Flat Washer (1)
• 2.5mm Hex Wrench (1)
• 4mm Hex Wrench (1)
• Cutterhead Lock (1)
• Fence Nut (1)
Fence (1)
Fence Sliding Bracket (1)
Dust Port (1)
Fence Bracket (1)
Push Block (2)
TOOL PURPOSE
Resurface boards, flatten workpieces, and much more with your WEN Jointer. Refer to the diagram below to be-
come familiarized with the parts and controls of your jointer.
KNOW YOUR JOINTER
10
ON / OFF Safety Switch
NOTE: A protective coating of lubricating oil has been applied during assembly to protect against rust. Wipe down all
components thoroughly. Apply a light coat of good-quality paste wax to the table and fence to protect the surfaces
and make boards slide smoothly.
Dust Port
Outfeed Table
Infeed Table
Fence
Cutterhead Guard
Depth of Cut Adjustment Knob
Depth of Cut Lock Knob
Depth of Cut Scale
Fence Support Locking Handle
Fence Bracket Locking Handle
Cutterhead Lock
11
ASSEMBLY & ADJUSTMENTS
ATTACH THE FENCE
1. Attach the fence support bracket (Fig. 2 - 1) to the jointer with
four socket head bolts (Fig. 2 - 2)
2. Assemble the fence sliding bracket (Fig. 3 - 1) to the fence
(Fig. 3 - 2). Insert the two socket head bolts (Fig. 3 - 3) through
the top of the fence sliding bracket and screw the square nuts
(Fig. 3 - 4) onto the bolts but do not tighten.
3. Slide the square nuts into the grooves on the back of the
fence and position the fence sliding bracket to the middle of the
fence. Tighten the socket head screws (Fig. 3 - 3) once the slid-
ing fence bracket is correctly positioned.
NOTE: Use the fence cutout (Fig 4 - 1) to position the fence slid-
ing bracket in the center of the fence.
4. Place the upper fence assembly (Fig. 4 - 2) on top of the
fence support bracket. Insert the fence locking handle (Fig. 4
- 3) through the flat washer (Fig. 4 - 4), through the sliding
bracket, and then though the support bracket.
5. Hold the rectangular nut under the fence support bracket so
that it fits snugly into the groove with the flat side up. Thread
the fence locking handle through the nut until it is tight and the
fence is secured.
NOTE: The fence locking handle and fence bevel handle are
spring-loaded and can be re-positioned as need be. Pull out on
the handle, re-position it, and let it spring back in place.
NOTE: The stop limits on the fence bracket have been set at the
factory, but should be checked with an angle gauge to measure
exactly 90° and 135° between the fence and the table top at each
stop limit, respectively. The stop limits can be modified by tight-
ening or loosening the set screws if the angles are not precise.
INSTALL THE DUST CHUTE
1. Remove the two M6x12 screws (Fig. 5 - 1) from the body of
the jointer and the two self tapping screws (Fig. 5 - 2) from the
feet of the jointer.
2. Position the dust port (Fig. 5 - 3) and reinstall all four screws.
Be sure not to over-tighten the screws as doing so might dam-
age the dust port.
Fig. 2
1
2
Fig. 3
1
23
4
Fig. 4
Fig. 5
1
2 3
4
1
2
3
ASSEMBLY & ADJUSTMENTS
WARNING! Do not plug in or turn on the tool until it is fully assembled according to these instructions.
Failure to follow the safety instructions may result in serious personal injury.
ADJUST THE DEPTH OF CUT
The depth of cut is adjusted by the relative positioning of the
infeed table with respect to the cutterhead. The infeed table (Fig.
6 - 1) can be raised or lowered using the infeed adjustment knob
(Fig. 6 - 2). Turning the knob counterclockwise will raise the
infeed table, causing less wood to be removed from the work-
piece, as seen on the depth of cut scale (Fig. 6 - 3). Turning the
hand wheel clockwise will lower the infeed table, causing more
wood to be removed from the workpiece. Always make sure that
the front lock knob (Fig. 6 - 4) is loosened before changing the
depth of cut and tightened after the desired change has been
made so that the depth of cut does not differ between cuts. Do
not make jointing cuts deeper than 1/8 of an inch.
NOTE: For a smooth finish, it is recommended to do multiple passes at a lower depth. We recommend using a depth
of 1/32”. Always using a depth of 1/8” will shorten the lifespan of your jointer and give you a rougher finish.
BEVEL THE FENCE
NOTE: The fence can easily be set to 0° and 45° using the limit stops (Fig. 7 - 2) on the fence. However, it is always
advisable to check the angles with a piece of scrap wood before jointing your final workpiece. Adjust the set screws
that act as limit stops if they are not exact or have moved from shipping or use.
The fence can be positioned to joint the wood at any angle from 0° to 45°.
1. Before adjusting the fence’s angle, make sure that the unit is unplugged and the power switch is in the OFF posi-
tion.
2. Turn the fence bevel handle counterclockwise to loosen it. If you find it necessary to reposition the handle in order
to loosen it, pull it outwards, turn the handle to the new position, and release it.
3. Manually tilt the fence to desired angle; use an angle gauge block (not included) to see the current angle.
4. Once the desired angle has been achieved, tighten the bevel handle.
Fig. 6
1
2
4
3
12
ASSEMBLY & ADJUSTMENTS
MOVE THE FENCE
1. Before adjusting the fence’s position, make sure that the unit is un-
plugged and the power switch is in the OFF position.
2. Loosen the fence sliding handle (Fig. 7 - 1).
3. Slide the fence to the desired position. The fence can be positioned
over the blade so that only the desired width of the blade is exposed.
Make sure the exposed width matches that of the workpiece.
4. Tighten the fence sliding handle so that the fence is secure.
Fig. 7
1
AVOID DAMAGE TO BLADES
Jointers are a precision woodworking machine and should be used on quality lumber only. Do not join dirty boards;
dirt and small stones are abrasive and will wear out the blades.
For proper operation, attach a dust collection system to the dust port, on the left of the jointer. Attaching a dust col-
lection system is very important when taking deeper cuts to prevent wood chips clogging the unit.
Remove nails and staples. Only use the jointer to cut wood. Avoid knots. Heavily cross-grained wood makes knots
hard. Knots can come loose and jam blades.
Assess the value of badly warped boards. You may be tempted to take a deep cut to square the boards quickly, when
a better approach is to use several passes with a shallower cut.
2
2
Fig. 8
INSTALL THE CUTTERHEAD LOCK
1. Make sure the switch is in the OFF position and the jointer is un-
plugged.
2. Use a hex wrench to loosen the two screws holding the blade guard
mounting bracket (Fig. 8 - 1). Then remove the blade guard assembly.
3. Remove the bottom screw from the bearing holder assembly (Fig.
8 - 2). Then install the cutterhead lock (Fig. 8 - 3).
4. Reinstall the blade guard assembly.
5. The cutterhead lock is shown in figure 8, engaged with the cutter-
head. MAKE SURE THE CUTTERHEAD LOCK IS DISENGAGED FROM
THE CUTTERHEAD BEFORE JOINTING ANY WORKPIECES. The ONLY
time the cutterhead lock should be engaged is when adjusting or chang-
ing blades.
1
3
13
OPERATION
FEED
Rotation
Against the Grain
FEED
Rotation
With the Grain
4. Cut with the grain whenever possible (Fig. 12). Do not feed against the end
grain (Fig. 13), otherwise the workpiece may split and shatter. If the nature of
the workpiece requires you to joint against the grain, take extremely light cuts
and feed slowly. When using long work pieces, use extra supports at both
ends of the jointer.
BEVEL AND CHAMFER
The fence on the jointer is adjustable from 0° to 45°. Adjust the fence to the
desired angle and tighten the bevel handle.
Beveling refers to cutting the entire edge of a board at an angle. Beveling may
require several passes due to the depth of the cut needed. See Fig. 14.
Chamfering refers to removing only the corner of the edge of a board. Nor-
mally a chamfer is made in one pass; so a 1/16-inch deep cut is made. See
Fig. 14.
FEED A WORKPIECE
Feed rate refers to the rate at which wood is passed over the blades. An even feed rate produces a uniform finish.
1. Hold the work piece firmly down on the feed table and against the fence.
2. Feed the work piece at an even rate over the cutterhead. Any hesitation or stopping will cause a “step” to be cut
in the work piece. See Figs. 9 - 11 for different feeding methods.
3. As your trailing hand passes over the cutterhead, remove your leading hand and place behind your trailing hand
and repeat until the entire length of the workpiece has been cut. Use a push block (Fig. 11 - 1) to hold and feed the
workpiece when jointing wood that is narrower than 3 inches or thinner than 3 inches.
Directions continue on the next page.
Fig. 9 Fig. 11
1
OPERATION
Fig. 10
Fig. 12
Fig. 13
Fig. 14
Chamfer
Edge
Bevel
Edge
14
ATTACH A VACUUM HOSE
A 2-1/2” dust collection hose can be attached to the dust port underneath the
outfeed table. The jointer will perform properly at all depths of cuts up to 1/8”
when using a dust collection system.
NOTE: Make sure the jointer and dust collection system are on separate elec-
trical circuits. This will prevent circuits from overloading.
1. Make sure the switch is in the OFF position and that the cord is unplugged
before attaching the vacuum hose.
2. Attach the dust collection hose to the dust port (Fig. 15 - 1).
OPERATION
Fig. 15
1
2
3. Turn the dust collection system ON before starting the jointer. Periodically replace and empty the bag in the col-
lection system according to the manufacturer’s instructions.
ON/OFF SWITCH
The ON/OFF switch (Fig. 15 - 2) is located on the front of the jointer.
1. To turn the jointer ON, move the switch to the up position.
2. To turn the jointer OFF, move the switch to the down position.
3. Remove the yellow tab to engage the child-safety lock and prevent unwanted start-ups.
ADJUST THE BLADE HEIGHT
The blades have been adjusted at the factory to ensure proper opera-
tion and should require no adjustment. However, shipping and handling
may have caused slight misalignment. For accurate cutting, the cutting
edges of the blades should be flush with the outfeed table.
1. Make sure the switch is in the OFF position and that the cord is un-
plugged before checking the blades.
2. Loosen the two screws holding the base of the blade guard and
then remove the blade guard.
3. Keep the cutterhead disengaged from the cutterhead lock. Carefully
turn the cutterhead so the blade-mounting screws face up. Loosen
them slightly (about 1/2 turn).
CAUTION! The cutterhead blades are extremely sharp. To avoid
injury, do not let your fingers contact the cutting edge.
4. Turn the cutterhead and engage the cutterhead lock on the cutterhead
shaft. This will keep the cutterhead in the proper position for leveling
the blades.
Fig. 16
Fig. 17
Blade Lock
Screw
Cutterhead
Blade Gib Screw
Blade
Clamp
Cutterhead
Steel Straight Edge
Outfeed
Table
Infeed
Table
15
5. Place a straight-edge over the outfeed table and the blade. The straight edge must touch evenly on the outfeed
table at both ends of the blade. See Fig. 16.
6. The blades should just touch the straight-edge. If a blade is too low or too high at either end, adjust the blade
height. Using a hex wrench, adjust the gib screws to re-position the blade. Disengage the cutterhead lock and then
fully tighten the locking screws once the adjustments have been made (Fig. 17).
7. Reinstall the blade guard. Make sure cutterhead lock is disengaged from the cutterhead shaft before operating.
MAINTENANCE
ROUTINE INSPECTION
Before each use, inspect the general condition of the tool. If any of the following conditions exist, do not use until
parts are replaced or the jointer is properly repaired.
Check for:
• Loose hardware or improper mounting,
• Misalignment or binding of moving parts,
• Damaged cord/electrical wiring,
• Worn or damaged blades,
• Cracked or broken parts, and
• Any other condition that may affect its safe operation
CHECK FOR WORN BLADES
The condition of blades will affect the precision of the cuts. Observe the quality of the cut that the jointer produces
to check the condition of the blades. Dull blades will tear wood fibers and produce fuzzy surfaces. Raised grain will
occur when dull blades pound on wood that has varying density. Raised edges will also be produced where the
blades have been nicked. Blades on this jointer should always replaced as a matched set. Keeping a spare set of
blades on hand is recommended. Replacement blades (part no. JT3062B) can be ordered from wenproducts.com.
NOTE: The blades on this jointer are NOT reversible.
WARNING! To avoid accidents, turn OFF and unplug the tool from the electrical outlet before cleaning, ad-
justing, or performing any maintenance or lubrication work.
WARNING! Any attempt to repair or replace electrical parts on this tool may be hazardous. Servicing of the
tool must be performed by a qualified technician. When servicing, use only identical WEN replacement parts.
Use of other parts may be hazardous or induce product failure.
WARNING! To avoid cuts, wear cut-proof or cut-resistant gloves when performing maintenance work. Re-
move the gloves before operating the jointer.
16
MAINTENANCE
WARNING! To avoid cuts, wear cut-proof or cut-resistant gloves when performing maintenance work on the
blades. Remove the gloves before operating the jointer.
REPLACING BLADES
1. Make sure the switch is in the OFF position and that the cord is un-
plugged before replacing the blades.
2. Loosen the two screws holding the base of the blade guard and then
remove the blade guard (Fig. 18 - 1).
3. Loosen and remove the four blade lock screws (Fig. 18 - 1) securing
the blade (Fig. 18 - 2) and the blade clamp (Fig. 18 - 3).
4. Lift the blade and the blade clamp from the cutterhead, cleaning any
sawdust and resin buildup from the cutterhead, the blade and the blade
clamp.
5. Place the new blade against the blade clamp and replace it in the
cutterhead, securing it in place with the four blade lock screws. Do not
tighten the blade lock screws until you have checked that the blade
height is level and properly aligned.
Fig. 18
1
3
2
17
6. Adjust as required, using a straight edge as described in “Adjust the
Blade Height” on p. 15 of this manual. Tighten the blade lock screws, check the blade adjustment, and make sure
the blade is still level with the outfeed table. Repeat this procedure to replace the other blade.
7. Replace the blade guard. Make sure the cutterhead lock is disengaged from the cutterhead.
CLEANING & STORAGE
1. After every operation, use a vacuum to remove dust and chips from the tool surfaces, motor housing and work
area. Keep the ventilation openings free from dust and debris to prevent the motor from overheating.
2. Wipe the tool surfaces clean with a soft cloth or brush. Make sure water does not get into the tool.
3. Lubricate the table bracket and locking knobs if they become difficult to use.
PROBLEM CAUSE SOLUTION
Motor does not start.
Jointer is not plugged in. Plug jointer in.
Wrong choice of extension cord. Choose proper size of extension cord.
Defective switch. Contact customer service at 1-800-
232-1195, M - F, 8 - 5 CST.
Defective motor. Contact customer service at 1-800-
232-1195, M - F, 8 - 5 CST.
Worn carbon brushes. Replace carbon brushes.
Low line voltage. Correct low line voltage condition.
Motor starts slowly or fails to
come to full speed.
Defective motor windings. Contact customer service at 1-800-
232-1195, M - F, 8 - 5 CST.
Clogged wood chips.
Make a shallower cut and attach a
dust collection device to the dust port.
Inspect the chip blower assembly and
the fan belt.
Motor is running too hot.
Motor overloaded. Reduce the load on the motor (take
shallower cuts).
Restricted air circulation due to dust
accumulation.
Clean out the dust and restore normal
air circulation.
Snipe
(gouging at end of boards)
Dull blades. Replace or sharpen blades.
Inadequate support of long boards. Support long boards.
Uneven feed. Feed the workpiece at a consistent
rate.
Poor dust extraction. 1) Dust extraction manifold is clogged.
2) The fan belt is bad.
1) Clean inside of jointer and manifold.
2) Replace the belt.
The cutterhead is not
spinning. Bad drive belt. Replace drive belt.
NOTE: Carbon brush life depends on the amount of load being taken on by the motor. Regularly inspect the
brushes after 50 hours of use.
TROUBLESHOOTING GUIDE
WARNING! Stop using the tool immediately if any of the following problems occur. Repairs and replace-
ments should only be performed by an authorized technician. For any questions, please contact our customer
18
Other manuals for JT3062
1
Table of contents
Other Wen Power Tools manuals
