Wenglor CSMH00 Series User manual

CSMH00x
1D/2D Handheld Scanners
Operating Instructions
Translation of the Original Operating Instruction
Subject to change without notice
Available as PDF version only
Version: 1.1.0
Status: 04.04.2019
www.wenglor.com
EN

2Table of contents
Table of Contents
1. General.....................................................................................................................................................6
1.1 Information Concerning these Instructions .......................................................................................... 6
1.2 Explanations of Symbols ...................................................................................................................... 6
1.3 Limitation of Liability.............................................................................................................................. 7
1.4 Copyrights............................................................................................................................................. 7
2. For Your Safety.........................................................................................................................................8
2.1 Use for Intended Purpose..................................................................................................................... 8
2.2 Use for Other than the Intended Purpose.............................................................................................9
2.3 Personnel Qualifications ....................................................................................................................... 9
2.4 Modification of Products ....................................................................................................................... 9
2.5 General Safety Precautions .................................................................................................................. 9
2.6 Approvals ............................................................................................................................................ 10
3. Technical Data........................................................................................................................................10
3.1 Scanning field / working distances..................................................................................................... 11
3.2 Housing Dimensions........................................................................................................................... 11
3.3 Accessory Products ............................................................................................................................ 12
3.4 Scope of Delivery ................................................................................................................................ 12
4. Transport and Storage...........................................................................................................................12
4.1 Transport ............................................................................................................................................. 12
4.2 Storage................................................................................................................................................ 12
5. Installation and Electrical Connection..................................................................................................13
5.1 Installation ........................................................................................................................................... 13
5.2 Electrical Connection .......................................................................................................................... 14
5.3 Diagnostics.......................................................................................................................................... 15
6. Functions Overview ...............................................................................................................................16
6.1 Default Settings ................................................................................................................................... 16
7. Installing the eazyScan software ..........................................................................................................17
7.1 Installation procedure ......................................................................................................................... 17
8. General setup of the eazyScan software..............................................................................................18
8.1 Start screen ......................................................................................................................................... 18
8.2 Operator interface ............................................................................................................................... 18
8.3 Establishing connection...................................................................................................................... 19
8.4 Firmware updates ............................................................................................................................... 20

3
1D/2D Handheld Scanners
8.5 Configuration....................................................................................................................................... 21
8.6 Image capturing .................................................................................................................................. 22
8.7 Data Matrix Code Generator ............................................................................................................... 23
9. Setup using data matrix code ...............................................................................................................24
9.1 USB port.............................................................................................................................................. 24
9.2 RS-232 Interface.................................................................................................................................. 25
9.3 Communications Mode....................................................................................................................... 28
9.4 Keyboard Mapping.............................................................................................................................. 29
9.5 Alternative operating systems............................................................................................................. 33
9.6 Scanning process ............................................................................................................................... 33
9.7 Dual scanning area ............................................................................................................................. 36
9.8 Mirroring .............................................................................................................................................. 37
9.9 Preamble and postamble.................................................................................................................... 38
9.10 Text Command.................................................................................................................................... 40
9.11 Beeper / Vibrator ................................................................................................................................ 40
9.12 Code settings ...................................................................................................................................... 42
9.12.1 Aztec Code............................................................................................................................ 42
9.12.2 Codabar ................................................................................................................................ 42
9.12.3 Code 11................................................................................................................................. 43
9.12.4 Code 32 (Italian Pharmacode).............................................................................................. 44
9.12.5 Code 39................................................................................................................................. 44
9.12.6 Code 49................................................................................................................................. 45
9.12.7 Trioptic Barcode.................................................................................................................... 45
9.12.8 Code 93................................................................................................................................. 46
9.12.9 Code 128............................................................................................................................... 46
9.12.10 Composite Barcode.............................................................................................................. 47
9.12.11 Data Matrix ............................................................................................................................ 47
9.12.12 Grid Matrix............................................................................................................................. 48
9.12.13 GoCode................................................................................................................................. 49
9.12.14 GS1 Databar ......................................................................................................................... 49
9.12.15 Interleaved 2 of 5 .................................................................................................................. 51
9.12.16 Maxicode............................................................................................................................... 51
9.12.17 Matrix 2 of 5........................................................................................................................... 52
9.12.18 PDF417 ................................................................................................................................. 52
9.12.19 MSI Plessey........................................................................................................................... 53
9.12.20 Hong Kong 2 of 5.................................................................................................................. 53
9.12.21 NEC 2 of 5............................................................................................................................. 53
9.12.22 QR Code ............................................................................................................................... 54
9.12.23 Telepen ................................................................................................................................. 54

4
9.12.24 UPC/EAN............................................................................................................................... 55
9.12.25 UK Plessey ............................................................................................................................ 58
9.12.26 Straight 2 of 5........................................................................................................................ 58
9.12.27 Han Xin.................................................................................................................................. 59
9.12.28 Pharmacode.......................................................................................................................... 59
9.12.29 Post Codes............................................................................................................................ 60
9.13 Other commands ................................................................................................................................ 62
10. Maintenance Instructions......................................................................................................................64
11. Proper Disposal .....................................................................................................................................64
12. Appendix ................................................................................................................................................65
12.1 List of Changes to Operating Instructions .......................................................................................... 65
12.2 Check list for initial start-up................................................................................................................. 65
12.3 EU Declaration of Conformity ............................................................................................................. 66
Table of contents

5
1D/2D Handheld Scanners

6General
1. General
1.1 Information Concerning these Instructions
• These instructions apply to the product with ID code CSMH00x.
• They make it possible to use the product safely and efficiently.
• These instructions are an integral part of the product and must be kept on hand for the entire duration of
its service life.
• Local accident prevention regulations and national work safety regulations must be complied with as well.
• The product is subject to further technical development, and thus the information contained in these
operating instructions may also be subject to change. The current version can be found at www.wenglor.
com in the product’s separate download area.
NOTE!
The operating instructions must be read carefully before using the product and must be
kept on hand for later reference.
1.2 Explanations of Symbols
• Safety precautions and warnings are emphasized by means of symbols and attention-getting words
• Safe use of the product is only possible if these safety precautions and warnings are adhered to
• The safety precautions and warnings are laid out in accordance with the following principle:
ATTENTION-GETTING WORD!
Type and Source of Danger!
Possible consequences in the event that the hazard is disregarded.
• Measures for averting the hazard.
The meanings of the attention-getting words, as well as the scope of the associated hazards, are listed below.
DANGER!
This word indicates a hazard with a high degree of risk which, if not avoided, results in
death or severe injury.
WARNING!
This word indicates a hazard with a medium degree of risk which, if not avoided, may result
in death or severe injury.
CAUTION!
This word indicates a hazard with a low degree of risk which, if not avoided, may result in
minor or moderate injury.

7
1D/2D Handheld Scanners
ATTENTION!
This word draws attention to a potentially hazardous situation which, if not avoided, may
result in property damage.
NOTE!
A note draws attention to useful tips and suggestions, as well as information regarding
efficient, error-free use.
1.3 Limitation of Liability
• The product has been developed in consideration of the current state-of-the-art and applicable standards
and guidelines. Subject to change without notice.
• A valid declaration of conformity can be accessed at www.wenglor.com in the product’s separate
download area.
• wenglor sensoric elektronische Geräte GmbH (hereinafter referred to as “wenglor”) excludes all liability in
the event of:
• Non-compliance with the instructions
• Use of the product for purposes other than those intended
• Use by untrained personnel
• Use of unapproved replacement parts
• Unapproved modification of products
• These operating instructions do not include any guarantees from wenglor with regard to the described
procedures or specific product characteristics.
• wenglor assumes no liability for printing errors or other inaccuracies contained in these operating
instructions, unless wenglor was verifiably aware of such errors at the point in time at which the operating
instructions were prepared.
1.4 Copyrights
• The contents of these instructions are protected by copyright law.
• All rights are reserved by wenglor.
• Commercial reproduction or any other commercial use of the provided content and information, in
particular graphics and images, is not permitted without previous written consent from wenglor.

8For Your Safety
2. For Your Safety
2.1 Use for Intended Purpose
This hand scanner is used to decode 1D/2D codes.
This product can be used in the following industry sectors:
• Automotive industry
• Food industry
• Packaging industry
• Pharmaceuticals industry
• Clothing industry
• Plastics industry
• Consumer goods industry
• Paper industry
• Electronics industry
• Glass industry
• Printing industry
• Special machinery manufacturing
• Heavy machinery manufacturing
• Logistics
• Woodworking industry
• Steel industry
• Aviation industry
• Construction industry
• Chemicals industry
• Agriculture Industry
• Alternative energy
• Raw materials extraction
•

9
1D/2D Handheld Scanners
2.2 Use for Other than the Intended Purpose
• Not a safety component in accordance with 2006/42/EC (Machinery Directive)
• The product is not suitable for use in potentially explosive atmospheres.
• The product may only be used with accessories supplied or approved by wenglor, or combined with
approved products. A list of approved accessories and combination products can be accessed at
www.wenglor.com on the product detail page.
DANGER!
Risk of personal injury or property damage in case of use for other than the intended
purpose!
Use for other than the intended purpose may lead to hazardous situations.
• Observe instructions regarding use for intended purpose.
2.3 Personnel Qualifications
• Suitable technical training is a prerequisite
• In-house electronics training is required
• Trained personnel must have uninterrupted access to the operating instructions
DANGER!
Risk of personal injury or property damage in case of incorrect initial start-up and
maintenance!
Personal injury and damage to equipment may occur.
• Adequate training and qualification of personnel.
2.4 Modification of Products
DANGER!
Risk of personal injury or property damage if the product is modified!
Personal injury and damage to equipment may occur. Non-observance may result in loss
of the CE marking and the guarantee may be rendered null and void.
• Modification of the product is impermissible.
2.5 General Safety Precautions
NOTE!
• These instructions are an integral part of the product and must be kept on hand for the
entire duration of its service life.
• In the event of possible changes, the respectively current version of the operating
instructions can be accessed at www.wenglor.com in the product’s download area.
• Read the operating instructions carefully before using the product.
• Protect the sensor against contamination and mechanical influences.

10 Technical Data
2.6 Approvals
3. Technical Data
Order Number
Technical Data
CSHM001 CSHM002 CSHM003 CSHM004
Optical data
Scanning distance 38...394 mm
Resolution 1280×960 pixels
Light source Red light
Max. permitted ambient light 97,000 lux
Electrical data
Supply voltage 5 V DC
Power consumption < 2250 mW
Temperature range –20…55 °C
Interface USB RS-232 USB RS-232
Acoustic signal Yes
Vibrational signal Yes
Visual signal Yes
Mechanical data
Housing material Plastic
Protection IP54
Weight 110 g
Connector type Cable
Cable length 180 cm
