West Elm Harmony Series User manual

Harmony Collection
assembly instructions
! Do not throw away packaging material until assembly is complete
! Assemble this item on a soft surface, such as cardboard or carpet, to protect finish
! Proper assembly of this item requires 2 people
Reg. Leg SS-5377 (Req:2x Long Bolts)
Harmony Deep Reg Leg SS-5380
Shelf Leg SS-5378 (Req:2x Short Bolts)
Harmony Deep Shelf Leg SS-5381
Corner Leg A SS-5379 (Req:2x Long Bolts)
Long Bolt 4 ½” SS-5233
Short Bolt 2 ½” SS-5232
Corner Leg B SS-5379 (Req:2x Long Bolts)
Hex Key SS-5234
Washer SS-1113
Corner Leg A & B may also come
preassembled. Please follow same
instructions for assembly
1. Choose the proper leg that matches the collection piece using the chart on back side.
2. Remove temporary shipping leg and layout wrapped legs from packaging.
3. Attach each leg by aligning it on the pre-drilled holes underneath the frame. Insert bolt with washer into the frame. Hand
tighten bolts. Warning! Do not tighten until all bolts are secured.
4. Once all bolts are in, tighten completely using the hex key provided.
Additional information: Shelf Legs can be turned inwards to hide shelf or turned outwards to be used as a support for a sectional piece.
See image below.
Warning! Armless Pieces need to be locked together using brackets and properly resting on shared leg.
A. Visible shelf leg and sectional brackets for connecting B. Invisible shelf leg for stand-alone unit

Harmony Collection
assembly instructions
Chart 1. Harmony Leg Placement
Sofa 82”, Chair and Half, Apt Sofa, & Grand Sofa
Armless Double Sofa & Ottoman
2 Reg. Legs
2 Shelf Legs
4 Long Bolts, 4 Washers, 1 Hex Key
4 Short Bolts, 4 Washers, 1 Hex Key
Place bolts in pre-drilled holes, hand tighten then use hex key to
tighten completely.
1: Shelf visible for support
2: Shelf hidden for stand-alone unit
1-Arm Chair, 1-Arm Sofa, 1-Arm 2.5 Sofa
Corner
1 Reg. Leg + 1 Shelf Leg
Corner Component (1 Long Leg (A) +1 Short Leg (B))
2 Long Bolts, 2 Short Bolts, 4 Washers, 1 Hex Key
4 Long Bolts, 4 Washers, 1 Hex Key
1: Regular Leg positioned under Arm Side
2: Shelf visible for support. Use Interlocking connectors.
5”
1: Short Leg sits against Long Leg
2: Distance from hole to end of leg is 5” (for both A and B)
Terminal Chaise ONLY
Chaise
1 Reg. Leg + Corner Component (1 Long Leg (A) +1 Short Leg (B))
2 Reg. Legs
6 Long Bolts, 6 Washers, 1 Hex Key
4 Long Bolts, 4 Washers, 1 Hex Key
1: Repeat procedure for Corner Leg Assembly
2: Place bolts in pre-drilled holes, hand tighten then use hex key
to tighten completely.
1: Regular Leg along arm side of chaise
2: Regular Leg at the front of chaise
1
2
1
2
1
2
1
1
2
