QTY CONTENTS - CONTENIDO - CONTENU TOOLS - HERRAMIENTA
- OUTILS
ITEM
AUTOMOTIVE PRODUCTS, INC.
MOUNT KIT
EQUIPO DE MONTAJE
TROUSSE DE MONTAGE
22-1815
CHROME/CROMADO/CHROME
22-0050, 22-5050
BLACK/NEGRO/NOIR
22-0055, 22-5055
345
INSTRUCTIONS-INSTRUCCIONES-CONSIGNES
75-0850 REVISION B W11-0062 11/28/11
1,2 2 OVAL TUBE, PASSENGER (1) AND DRIVER (2) (PURCHASED
SEPARATELY)
3 2 FRONT BRACKET
4,5 2 REAR BRACKET, PASSENGER (4) AND DRIVER (5)
6 8 3/8-16 BRIDGE WELD NUT
7 8 3/8-16 X 1.25” HEX HEAD BOLT
8 8 3/8” FLAT WASHER
9 8 3/8” LOCK WASHER
10 8 3/8-16 HEX NUT
11
14 8 PLASTIC WASHER
4 M6 BOLT PLATES (INCLUDED WITH STEP TUBES)
12 16 M6 FLAT WASHER (INCLUDED WITH STEP TUBES)
13 16 M6 NYLOCK NUTS (INLCLUDED WITH STEP TUBES)
(1) (2)
(4) (5)
1,2 2 ESTRIBOS, ACOMPAÑANTE Y CONDUCTOR
3 2 SOPORTES DELANTERAS
4,5 2 SOPORTES , ACOMPAÑANTE Y CONDUCTOR
6 8 SUELDE NUEZ 3/8-16
7 8 PERNOS CON CABEZA HEXAGONAL DE 3/8-16 X 1,25”
8 8 ARANDELAS PLANAS DE 3/8”
9 8 ARANDELAS DE PRESIÓN DE 3/8”
10 8 TUERCAS HEXAGONALES DE 3/8-16
ARANDELA DE PLÁSTICO
(SE COMPRA
SEPARADO)
11 4 PERNOS CON CABEZA EN T DE M6 (INCLUIDO CON TUBOS DE PASO)
12 16 ARANDELAS PLANAS DE M6 (INCLUIDO CON TUBOS DE PASO)
13 16
TRASERAS
TUERCA DE FIJACIÓN HEXAGONAL M6 (INCLUIDO CON TUBOS DE PASO)
14 8
(1) CONDUCTEUR (2)
(5) CONDUCTEUR (6)
6 8 SOUDER LA NAUX 3/8-16
BOULON A TETE HEXAGONALE DE PO
RONDELLE PLATE DE 3/8 PO
9 8 RONDELLE A FREIM DE 3/8 PO
10 8 ÉCROUS HEXAGONAUX 3/8-16
1,2 2 MARCHE-PIEDS, PASSAGER ET
3 2 SUPPORTS AVANT
4,5 2 , PASSAGER ET
7 8 3/8-16 X 1,25
8 8
(ACHETE
SEPAREMENT)
11 4 BOULONS A TETE-T M6 (INCLUS AVEC DES TUBES ÉTAPE)
12 16 RONDELLES PLATES M6 (INCLUS AVEC DES TUBES ÉTAPE)
13 16
SUPPORTS ARRIERE
M6 ÉCROU DE BLOCAGE SIX PANS ( INCLUS AVEC DES TUBES ÉTAPE)
14 8 RONDELLE DE PLASTIQUE
DADO DE
DADO DE
9/16”
10MM
MANERAL
LLAVE DE TORQUE
DOUILLE 9/16 PO
DOUILLE 10MM
CLIQUET
CLEF DE COUPLE
9/16” SOCKET
10MM SOCKET
RATCHET
TORQUE WRENCH
1
2
APPLICATION: 2007-12 HYUNDAI SANTA FE
APLICACIÓN: , MOD. 2007-12HYUNDAI SANTA FE
APPLICATION: HYUNDAI SANTA FE 2007-12
STEP 1. Remove the contents from box and check for damage. Verify all parts are present. Read instructions
completely before beginning.
STEP 2. Remove rubber plugs from vehicle body.
STEP 3. Thread 3/8-16 x 1.25” hex head bolts through bridge weld nuts, insert into holes, and use plastic washers
to hold in place. SEE FIGURES 1 AND 2.
FINISH PROTECTION
Westin products have a high quality finish that must be cared for like any other exposed finish on the vehicle. Protect the finish with a non-abrasive automotive wax,
(e.g. Pure Carnauba) on a regular basis. The use of any soap, polish or wax that contains an abrasive is detrimental, as the compounds scratch the finish and open it
PASO 1. Retire el contenido de la caja y verifique que ninguna pieza se haya dañado. Verifique que no falte
ninguna
pieza. Lea las instrucciones completamente antes de comenzar.
libras-pies a
los sujetadores de 1/4.
PASO 2. Retire los tapones de hule de la carrocería del vehículo.
PASO 3. Enrosque pernos con cabeza hexagonal de 3/8-16 x 1,25” a través de las tuercas soldadas de puente,
insértelos en los agujeros y use arandelas de plástico para sujetarlos en el lugar. VEA LAS FIGURAS 1 Y 2.
PASO 4. Instale los soportes del lado del conductor a la placa de pernos de 3/8” anteriormente armada con cuatro
arandelas planas de 3/8”, arandelas de presión de 3/8” y tuercas hexagonales de 3/8-16 como se muestra
VEA LAS FIGURAS 1 Y 2.
PASO 5. Adjuntar barras de paso utilizando incluidos M6 hardware como se muestra en las Figuras 3, 4 y 5
PASO 6. Asegúrese de que el estribo y los soportes estén alineados correctamente y que los sujetadores estén
apretados. Los valores de torque recomendados son 26 libras-pies para los pernos de 3/8 y 7
PROTECCIÓN DEL ACABADO
Los productos Westin tienen un acabado de alta calidad que requiere del mismo cuidado que cualquier otro acabado expuesto del vehículo. Proteja el acabado con
una cera no abrasiva para automóviles (por ejemplo, Pure Carnauba) regularmente. El uso de cualquier jabón, pulidor o cera que contenga un abrasivo es nocivo,
STEP 1. Remove the contents from box and check for damage. Verify all parts are present. Read instructions
completely before beginning.
STEP 2. Remove rubber plugs from vehicle body.
STEP 3. Thread 3/8-16 x 1.25” hex head bolts through bridge weld nuts, insert into holes, and use plastic washers
to hold in place. SEE FIGURES 1 AND 2.
STEP 4. Attach driver side brackets to the previously assembled 3/8” bolt plate using four 3/8” flat washers, 3/8”
ETAPE 1. Enlevez le contenu de la boîte et vérifiez pour tout dommage. Vérifiez que toutes les pièces y sont. Lisez
complètement les instructions avant de commencer.
ÉTAPE 2. Retirer les bouchons en caoutchouc de la carosserie du véhicule.
ÉTAPE 3. Enfiler les boulons à tête hexagonale de 3/8-16 x 1,25 po. dans les écrous à souder, les introduire dans les
trous, et utiliser les rondelles en plastique pour les tenir en place. VOIR FIGURES 1 ET 2.
ÉTAPE 4. Fixer les supports côté conducteur sur la plaquette de boulon de 3/8 po. déjà montée au moyen de quatre
rondelles plates de 3/8 po., quatre rondelles frein de 3/8 po. et quatre écrous hexagonaux de 3/8-16 tel
qu'illustré. VOIR FIGURES 1 ET 2.
ÉTAPE 5. Fixez les barres étape en utilisant du matériel inclus M6 comme indiqué dans les figures 3, 4 et 5
ÉTAPE 8. Assurez-vous que le marchepied et les supports sont correctement alignés et ensuite serrez les attaches.
Les valeurs de couple recommandées sont de 26 pieds livres de 3/8 po et 7 pieds livres pour les attaches de
1/4 po.
PROTECTION DE LA FINISSION
Les produits Westin ont une finission de haute qualité qui requiert des soins, comme toute autre finission du véhicule exposée aux éléments. Protégez la finission à
l’aide d’une cire non-abrasive (par exemple, Pure Carnauba) de façon régulière. L’usage de tout savon, pâte à polir ou cire contenant un abrasif est nuisible, puisque
Thank You for choosing Westin products
For additional installation assistance please call
Customer service (800) 793-7846 or www.westinautomotive.com
Westin Automotive Products, Inc.
5200 N. Irwindale Ave. Suite 220
Irwindale, Ca. 91706
6
7
6
7
14
14
8910
8910
3
8910
8910
14
14
7
6
5
7
6
FORWARD
DELANTERA
AVANT
FIGURE 2 INSTALLATION OF FRONT DRIVER SIDE SHOWN.
PASSENGER SIDE OPPOSITE.
FIGURA 2: INSTALACIÓN DE LA PARTE DELANTERA, LADO DEL CONDUCTOR.
LADO DEL ACOMPAÑANTE (OPUESTO)
FIGURE 2 ILLUSTRATION DE L'INSTALLATION DU CÔTÉ CONDUCTEUR AVANT.
CÔTÉ PASSAGER INVERSÉ.
FIGURE 1 INSTALLATION OF REAR DRIVER SIDE SHOWN.
PASSENGER REAR OPPOSITE
FIGURA 1: INSTALACIÓN DE LA PARTE TRASERA, LADO DEL CONDUCTOR.
LADO DEL ACOMPAÑANTE (TRASERO, OPUESTO)
FIGURE 1 ILLUSTRATION DE L'INSTALLATION DU CÔTÉ CONDUCTEUR ARRIÈRE.
CÔTÉ PASSAGER INVERSÉ.
FIGURE 3 FIGURE 4
FIGURE 5
11
12 13
