Westinghouse WHT0571 User manual

Page 1
1. READ these instructions carefully before installing and operating the
appliance. Keep them for further reference.
2. Record in the space below the “SERIAL/MODEL NUMBER” found on the back
or bottom of your appliance and retain this information for future reference.
SERIAL NUMBER:
MODEL NUMBER:
DATE OF PURCHASE:
Save and staple your sales receipt to your manual for warranty coverage.
User Manual
Ceramic Tower
Heater
MODEL: WHT0571

Page 2
CONTENTS
SAFETY INFORMATION
Important Safety Instructions..........................................................................................................................................3-4
Electrical Requirements..........................................................................................................................................................4
SET UP & USE
Parts & Features .........................................................................................................................................................................6
Control Panel ............................................................................................................................................................................... 7
Operation Guide......................................................................................................................................................................... 8
TROUBLESHOOTING & WARRANTY
Limited Warranty.......................................................................................................................................................................11

Page 3
IMPORTANT SAFETY INSTRUCTIONS
When using electrical appliances, basic precautions should always
be followed to reduce the risk of re, electric shock, and injury to
persons, including the following:
1. Read all instructions before using this heater.
2. This heater is hot when in use. To avoid burns, do not let bare
skin touch hot surfaces. If provided, use handles when moving
this heater. Keep combustible materials, such as furniture, pillows,
bedding, papers, clothes, and curtains at least 3 feet (0.9m) from
the front of the heater and keep them away from the sides and
rear.
3. Extreme caution is necessary when any heater is used by or near
children or invalids and whenever the heater is left operating and
unattended.
4. Always unplug heater when not in use.
5. Do not operate any heater with a damaged cord or plug or after
the heater malfunctions, has been dropped or damaged in any
manner. Discard heater or return heater to authorized service
facility for examination, electrical or mechanical adjustment, or
repair.
6. Do not use outdoors.
7. This heater is not intended for use in bathrooms, laundry areas
and similar indoor locations. Never locate heater where it may fall
into bathtub or other water container.
8. Do not run cord under carpeting. Do not cover cord with throw
rugs, runners, or similar coverings. Do not route cord under
furniture or appliances. Arrange cord away from trafc area and
where it will not be tripped over.
9. To disconnect heater, rst turn controls to off, then remove plug
from outlet.
WARNING
When using electrical appliances, basic safety precautions
should be followed, including the following
DANGER
DANGER - Immediate hazards
which WILL result in severe
personal injury or death
WARNING
WARNING - Hazards or unsafe
practices which COULD result in
severe personal injury or death
CAUTION
CAUTION - Hazards or unsafe
practices which COULD result in
minor personal injury
SAFETY INFORMATION

Page 4
10. Do not insert or allow foreign objects to enter any ventilation or
exhaust opening as this may cause an electric shock or re, or
damage the heater.
11. To prevent a possible re, do not block air intakes or exhaust
in any manner. Do not use on soft surfaces, like a bed, where
openings may become blocked.
12. A heater has hot and arcing or sparking parts inside. Do not use
it in the areas where gasoline, paint, or ammable liquids are
used or stored.
13. Use this heater only as described in this manual. Any other use
not recommended by the manufacturer may cause re, electric
shock, or injury to persons.
14. CAUTION: Always plug heaters directly into a wall outlet/
receptacle. Never use with an extension cord or relocatable
power tap (outlet/power strip).
15. This heater draws 12.5 amps during operation. To prevent
overloading a circuit, do not plug the heater into a circuit that
already has other appliances working.
16. The output of this heater may vary and its temperature may
become intense enough to burn exposed skin. Use of this heater is
not recommended for persons with reduced sensitivity to heat or an
inability to react to avoid burns.
17. Don’t leave the heater on unattended.
SAVE THESE INSTRUCTIONS
HOUSEHOLD USE ONLY
ELECTRICAL REQUIREMENTS
This appliance has a polarized plug (one blade is wider than the other). To
reduce the risk of electric shock, this plug is intended to t into a polarized outlet
only one way. If the plug does not t into the outlet, reverse the plug. If it still
does not t, contact a qualied electrician. Do not attempt to modify the plug in
any way.
NOTE: Neither Westinghouse nor the dealer can accept any liability for damage to the
product or personal injury resulting from failure to observe the electrical connection
procedures.
WARNING: To reduce the risk of electric shock, do not use with an extension cord.
SAFETY INFORMATION
SAFETY INFORMATION

Page 5
SAFETY INFORMATION
WARNING
It is normal for the power cord to feel warm to the touch; however, a
loose t between the outlet and the plug may cause overheating of
the plug. If this occurs, try inserting the plug into a different outlet.
Contact a qualied electrician to inspect the original outlet for
damage.
SAFETY FEATURES
Tip-Over Safety Feature
This heater is equipped with a tip-over safety feature. Once the heater is tipped
over, an internal switch will automatically shut the heater off. Once the heater is
restored an upright position, the heater will resume operation.
Overheat Safety Feature
This heater is equipped with an overheat safety feature. When the heaters
internal components reach a certain temperature that could cause overheating
and possible re, the heater will automatically shut off.

Page 6
PARTS & FEATURES
IN THE BOX
•CERAMIC TOWER HEATER
•USER MANUAL
Temperature Control Function Control
SET UP & USE
Air Outlet
Front Housing
Oscillation Base
Air Intake
Back Housing
WHT0571 CONTROL PANEL SILKSCREEN
GREY 20
MIN

Page 7
CONTROL PANEL
SET UP & USE
Temperature Control
Power Indicator Light
Power/Oscillation Control
WHT0571 CONTROL PANEL SILKSCREEN
GREY 20
MIN

Page 8
SET UP & USE
OPERATION INSTRUCTIONS
1. Plug in the heater into standard household electrical outlet.
2. Adjust the TEMPERATURE control dial clockwise past the “LO” until the power
indicator light illuminates. Continue moving clockwise until you reach your
desired temperature.
3. Adjust FUNCTION control to desired setting. If you want to use the heater with
the oscillation function, use the settings for “
WHT0571 CONTROL PANEL SILKSCREEN
GREY 20
MIN
” – fan only, “LO” heat, “HI” heat
located on the right side of the control. If you want to use the heater without
the oscillation function, use the settings for “
WHT0571 CONTROL PANEL SILKSCREEN
GREY 20
MIN
” – fan only, “LO” heat, “HI” heat
located on the left side of the control.
4. To turn off the heater, adjust the FUNCTION control to “0”position and the
TEMPERATURE control dial to “MIN” position. Then, unplug the unit.
NOTE: In low heat position, unit is operating at 1000w. In high heat position, unit
is operating at 1500w. Keep that in mind as you try and get the desired
heat output from your unit.
For “Fan Only” function, TEMPERATURE control still needs to be rotated
clockwise past the “LO” position until power indicator light illuminates.

Page 9
CLEANING AND CARE
MAINTENANCE
1. Turn off the power switch on the top of the unit.
2. Unplug the unit and let it cool completely.
3. To keep the heater clean, the outer shell may be cleaned with a soft, damp
cloth. You may use a mild detergent if necessary. After cleaning, dry the unit
with a soft cloth. CAUTION: DO NOT let liquid enter the heater.
4. DO NOT use alcohol, gasoline, abrasive powders, furniture polish, or rough
brushes to clean the heater. This may cause damage or deterioration to the
surface of the heater.
5. DO NOT immerse the heater in water.
6. Wait until the unit is completely dry before use.
7. If you do not use the heater for a long time, store in a safe, dry place.
STORAGE
Store the heater in a cool, dry location when not in use. To prevent dust and dirt
build-up, use the original packaging to repack the unit.

Page 10
BEFORE YOU CALL FOR SERVICE
IF THE APPLIANCE FAILS TO OPERATE:
A) Check to make sure that the appliance is plugged in securely. If it is not, remove
the plug from the outlet, wait 10 seconds and plug it in again securely.
B) Check for a blown circuit fuse or a tripped main circuit breaker. If these seem to
be operating properly, test the outlet with another appliance.
IF NONE OF THE ABOVE SOLVES THE PROBLEM, CONTACT CUSTOMER SERVICE.
DO NOT TRY TO ADJUST OR REPAIR THE APPLIANCE YOURSELF.
CUSTOMER SERVICE
IMPORTANT
DO NOT RETURN THIS PRODUCT TO THE STORE
If you have a problem with this product, please contact the W
Appliance Co. Customer Satisfaction Center at 1-855-855-0294.
DATED PROOF OF PURCHASE, MODEL # AND SERIAL #
REQUIRED FOR WARRANTY SERVICE
TROUBLESHOOTING
SPECIFICATIONS
• Voltage Rating: 120 V (60Hz)
• Power Consumption: 1500W
• Unit Dimensions (WxDxH): 6.85” x 6.2” x 18.74”
• Unit Weight: 3.75 lbs.
TROUBLE POSSIBLE CAUSE POSSIBLE REMEDY
Appliance does not turn on
Appliance is not plugged in Check that appliance is
plugged into a working outlet
Temp or power control in
wrong position
Turn controls to correct
position per manual
Fan works but no heat
Thermal cutout protector
activated because of
overheat condition
To reset protector, unplug fan
for several minutes and allow
to cool. Product should then
function normally
TROUBLESHOOTING & WARRANTY

Page 11
LIMITED WARRANTY
Westinghouse brand is used under license.
Any repair, replacement, or warranty service,
and all questions about this product should be
directed to W Appliance Co. at 1 (855) 855-
0294 from the USA or Puerto Rico.
W Appliance Co. warrants to the original purchaser
that the product will be free from defects in material,
parts and workmanship for the period designated for
this product. The warranty commences the day the
product is purchased and covers up to a period of
1 year (12 months) for labor/1 year (12 months) for
parts (manufacturing defects only)/carry in service.
W Appliance Co. agrees that it will, at its option,
replace the defective product with either a new or
remanufactured heater equivalent to your original
purchase during the warranty period.
Exclusions: This warranty does not apply to the
below:
1. If the appearance or exterior of
the product has been damaged or
defaced, altered or modied in design or
construction.
2. If the product’s original serial number
has been altered or removed or cannot
be readily determined.
3. If there is damage due to power line
surge, user damage to the AC power
cord or connection to improper voltage
source.
4. If damage is due to general misuse,
accidents or acts of God.
5. If repair attempts are done by
unauthorized service agents, use of
parts other than genuine parts or parts
obtained from persons other than
authorized service companies.
6. On units that have been transferred
from the original owner.
7. On products that have been purchased
as refurbished, like new, second-hand, in
a “As-Is” or “Final Sale” terms.
8. To products used in a commercial or
rental setting.
9. To products used in settings other than
ordinary household use or used other
than in accordance with the provided
instructions.
10. To damages for service calls for
improper installations.
11. To glass parts and other accessory
items that are included with the unit.
12. Transportation and shipping costs
associated with the replacement of
the unit.
13. Service calls to instruct you how to use
your heater.
14. Service calls to repair or replace the
house fuse, reset the circuit breaker or
correct the wiring in the house.
REPAIR OR REPLACEMENT AS PROVIDED UNDER
THIS WARRANTY IS THE EXCLUSIVE REMEDY OF
THE CUSTOMER; W Appliance Co. SHALL NOT BE
LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL
DAMAGES FOR BREACH OF ANY EXPRESS OR
IMPLIED WARRANTY ON THIS PRODUCT, EXCEPT
TO THE EXTENT PROHIBITED BY APPLICABLE LAW.
ANY IMPLIED WARRANTY OF MERCHANTABILITY
OF FITNESS FOR A PARTICULAR PURPOSE ON THIS
PRODUCT IS LIMITED TO THE DURATION OF THE
WARRANTY.
Some states do not allow the exclusion or limitations
of incidental or consequential damages, or limitations
on how long the warranty lasts. In these cases the
above exclusions or limitations may not apply to you.
This warranty gives you specic legal rights and you
may also have other rights which vary from state to
state.
Obtaining Service: To obtain service, product
literature, supplies or accessories please call
1 [phone] to create a ticket for exchange/
repair. Please make sure to provide the date of
purchase, model number and a brief description of the
problem. Our customer service representative
will contact you or send detailed return instructions.
W Appliance Co. does not warrant that the appliance will work
properly in all environmental conditions, and makes no warranty
and representation, either implied or expressed, with respect
to the quality, performance, merchantability, or tness for a
particular purpose other than the purpose identied within this
user manual. W Appliance Co. has made every effort to ensure
that this user manual is accurate and disclaims liability for any
inaccuracies or omissions that may have occurred. Information
in this user manual is subject to change without notice and does
not represent a commitment on the part of W Appliance Co. W
Appliance Co. reserves the right to make improvements to this
user manual and/or to the products described in this user manual
at any time without notice. If you nd information in this manual
that is incorrect, misleading, or incomplete, please contact us at
1- 855-855-0294.
W Appliance Co.,
1356 Broadway
New York, NY 10018
TROUBLESHOOTING & WARRANTY

Page 12
, WESTINGHOUSE, and INNOVATION YOU CAN BE SURE OF
are trademarks of Westinghouse Electric Corporation. Used under
license by W Appliance Company. All Rights Reserved.
090617
