Westinghouse WSHPTCNSK52 User manual

34” DIGITAL CERAMIC TOWER
HEATER + FLAME EFFECT/
RADIATEUR VERTICAL
NUMÉRIQUE À CÉRAMIQUE
34PO+ EFFET DE FLAMME
Instruction Manual / Manuel d’instructions
WSHPTCNSK52

3
EN
CONTENT
SAFETY INFORMATION
IMPORTANT SAFEGUARDS....................................................................... 4
POWER SUPPLY............................................................................................. 6
HOW TO USE
DESCRIPTION OF PARTS ........................................................................... 9
BEFORE FIRST USE ...................................................................................... 10
OPERATING INSTRUCTIONS..................................................................... 10
SETTING UP THE HEATER ......................................................................... 11
SETTING UP THE REMOTE CONTROL ................................................. 12
CHANGING THE BATTERY......................................................................... 12
USING THE HEATER ..................................................................................... 13
CLEANING AND CARE ........................................................................ 15
TROUBLESHOOTING ........................................................................... 15
DISPOSAL............................................................................................... 16
INFORMATION AND SERVICE........................................................... 17

4
EN
SAFETY INFORMATION
Read this instruction manual carefully before using the appliance
and keep it for future reference.
1. Use the appliance only for its intended purpose. Improper
use may result in an electric shock, fire or serious injury and
may void the warranty.
2. This appliance is for household use only. It is not suitable for
commercial, industrial, or outdoor use.
3. This appliance is intended to be used in households and similar
applications such as:
- sta kitchen areas in shops, oces and other working
environments;
- farm houses;
- by customers in hotels, motels, and other residential type
environments;
- bed and breakfast type environments.
4. Do not use the appliance if it is damaged or not working
properly.
5. This appliance can be used by children aged 8 years and above
if they have been given supervision or instruction concerning
use of the appliance in a safe way and if they understand the
hazards involved. Cleaning, maintenance or connecting the
appliance to the power supply must not be done by children
unless they are older than 8 years of age and supervised by an
adult.
6. Children under the age of 3 must be constantly supervised if
they are in the same vicinity as the appliance while it is in use
or cooling down after use.
IMPORTANT SAFEGUARDS
DANGER
DANGER – Immediate hazards
which WILL result in severe
personal injury or death
WARNING
WARNING – Hazards or unsafe
practices which COULD result in
severe personal injury or death
WARNING
When using electrical appliances, basic safety precautions
should always be followed, including the following
CAUTION
CAUTION – Hazards or unsafe
practices which COULD result in
minor personal injury

5
EN
SAFETY INFORMATION
7. Keep the appliance and its power cord out of the reach of
children when it is in operation.
8. Children should be supervised to ensure that they do not
play with the appliance.
9. Never leave the appliance unattended while it is in
operation.
10. Never connect this appliance to an external timer or remote
control system.
11. Do not connect the appliance to a circuit that is regularly
turned on and o by your electricity provider.
12. Never cover the heater or the air outlets/inlets or vents as this
could cause a fire.
13. All covers are intended to prevent direct access to the heating
elements and must be in place when using the appliance.
14. CAUTION: Parts of this appliance may become very hot and
cause burns. Make sure that children or persons of reduced
physical, sensory, or mental abilities are supervised and
protected from accidental burns. In order to avoid any injury
or burn, do not touch the heater directly. Use gloves or other
means.
15. Position the appliance upright on a firm, level, heat-resistant
surface near a power socket and out of reach of children.
16. Do not touch the hot surfaces. Only use the handles, knobs, or
buttons.
17. Always unplug the appliance when unattended and after use.
Let it cool down before cleaning and storing.
18. When using the appliance, allow adequate air space above and
on all sides for air circulation.
19. Place the appliance at least 3 feet away from any combustible
items, such as furniture, curtains, bedding, clothes, and papers.
20. Do not place this product on a carpet.
21. Do not place the appliance on or near open flames, an electric
or gas burner, or a heated oven.
22. Do not use the appliance in places such as garages or
warehouses where dangerous flammable products are stored
such as paints, thinners, alcohol etc.).
23. The appliance must not be placed below an electrical socket.

6
EN
SAFETY INFORMATION
24. Do not use the heater in a bathroom, laundry, humid
environment, or near to a body of water such as a swimming
pool. Maintain a distance of at least 5 feet away from water. Do
not immerse the appliance in water or any other liquid or place
it under running water (see CLEANING AND CARE).
25. Keep the heater clean. Do not allow objects to enter the air
vents as this may cause an electric shock, fire, or damage.
26. The use of accessories or fittings other than the original parts
supplied with this appliance may result in an injury, fire or
damages and will void the warranty.
27. Do not under any circumstances attempt to open, dismantle,
or repair the appliance. For servicing and repairs, contact the
retail outlet, the manufacturer, or an authorized service center.
28. Make sure no small piece of packaging, such as polystyrene,
has been left on or fallen into the air inlets or outlets.
29. RISK OF SUFFOCATION! KEEP OUT OF REACH CHILDREN
- Keep all packaging materials out of the reach of babies and
children.
POWER SUPPLY
1. Before first use, make sure the power voltage matches the
information on the appliance rating label.
2. Only connect the appliance to an earthed wall socket.
3. To avoid a fire or electric shock, plug the unit directly into
a120V AC electrical outlet.
4. A short power cord (or detachable power cord) should be used
to reduce the risk of becoming entangled in or tripping over
the cord.
5. Always plug the appliance directly into the wall socket. Do not
use multi-plugs, adapters, or extension cords.
6. Always fully unwind the power cord before using the appliance.
7. Do not twist the power cord.
8. Check there are no heavy items on the power cord, including
carpets.
9. Make sure there is no pressure on the cord where it connects to
the heater.

7
EN
SAFETY INFORMATION
10. Never carry the heater by the power cord.
11. The cord should be arranged so that it does not touch hot
surfaces, is not draped over a countertop or tabletop where it
may be pulled on by children or tripped over unintentionally.
12. Never use the appliance with a damaged power cord or plug,
or if the appliance has malfunctioned in any way. If the power
cord, plug, or appliance is damaged, the appliance must be
returned or replaced by the manufacturer, an authorized
service agent or a similarly qualified person.
13. Removing the power plug is the only way to separate the
appliance completely from the power supply. Make sure the
power plug is accessible.
14. When disconnecting the appliance from the power supply, pull
the power plug instead of the power cord.
15. Keep the power cord away from hot surfaces. Do not plug in
the power cord or operate the appliance with wet hands or
when standing in water.
16. If the appliance falls into water, quickly turn it o at the wall
socket and unplug it immediately. Make sure you are not
standing on wet ground or have wet hands when touching the
wall socket or plug.
17. Keep the appliance and power cord away from hotplates, hobs,
and burners.
18. It is normal for the plug to get warm while the appliance is
being used. This appliance has a polarized plug (one blade is
wider than the other). To reduce the risk of electric shock, this
plug is intended to fit into a polarized outlet in one orientation.
If the plug does not fit fully into the outlet, reverse the plug. If it
still does not fit, overheating and/or melting of the plug could
occur. If the connection is loose, contact a qualified electrician.
Do not attempt to modify the plug in any way.
WARNING:
19. Keep new and used batteries out of children’s reach.
20. Do not leave batteries lying around; there is a risk that they
could be swallowed by children or pets. If swallowed, consult
adoctor immediately.

8
EN
SAFETY INFORMATION
21. Leaking or damaged batteries can burn skin. Use a cloth or
protective gloves to remove the batteries and dispose of them
in accordance with local regulations. If you do get battery acid
on your skin, wash with soap and water immediately. Neutralize
with lemon juice, vinegar, or other mild acid.
22. If battery acid gets into your eyes, consult a doctor
immediately.
23. Batteries cannot not be reactivated, disassembled, burned,
buried, or short-circuited. There is a risk of explosion!
24. Do not recharge normal, non-rechargeable batteries. There is
arisk of explosion! Only charge rechargeable batteries that are
intended for this purpose; use suitable rechargeable battery
chargers.
25. The batteries must be replaced correctly using an identical or
equivalent battery.
26. The batteries must be inserted with the correct polarity
(+and-).
27. Dispose of batteries in accordance with local regulations.
28. Do not expose batteries to heat sources such as sunlight or
naked flames. Keep at room temperature.
29. Do not throw batteries into a fire as they could burst or release
toxic substances.
30. If the battery compartment does not close correctly, stop using
the unit and keep it out of children’s reach.
31. Always remove batteries before cleaning, inspecting, or
performing any maintenance on the appliance.
32. Remove used batteries immediately from the unit and discard
them in accordance with local regulations.
33. Remove the batteries when you are not using the unit for
along time.
RETAIN THESE INSTRUCTIONS
FOR HOUSEHOLD USE ONLY

9
EN
HOW TO USE
DESCRIPTION OF PARTS
1
2
3
4
5
6
7
8
9
12
16
13
11
14
15
REMOTE CONTROL
12
11
10
16
15
14
13
1. Infrared sensor
2. Air outlet
3. Flame eect
4. Base
5. Tip-over sensor (on the bottom)
6. Control panel
7. Handle (can be used to store the remote control)
8. Air inlet (on the back)
9. POWER switch
10. LED screen (temperature / hours) and function indicator lights:
Heater low power
Heater high power
Heater economy mode

10
EN
Fan
Timer
Oscillating
Power on / o
11. ON/OFF button
12. OSCILLATING button
13. UP/DOWN button
14. MODE button
15. FLAME EFFECT ON/OFF button
16. TIMER button
NOTE: All images shown are for illustrative purposes only and may
not be an exact representation of the product model.
BEFORE FIRST USE
• Remove all packaging from the appliance.
• Unpack all parts and check for damage that may have occurred
during transportation. If any parts are damaged or missing,
do not use the appliance and return it to your retail outlet
immediately.
OPERATING INSTRUCTIONS
NOTE:
• It is normal when heaters are turned on for the first time, or if
they have not been used for some time, to emit some smell and
fumes. This will disappear after a short time (approx. 2 hours).
• It is also normal for the heater to emit small crackling sounds
when you first turn it on.
• This heater is designed for occasional or intermittent use and
should not be left on for prolonged periods of time.
HOW TO USE

11
EN
CAUTION:
• The heater must always be placed in an upright position on a
horizontal surface. Never turn the heater upside down when in
use as it could cause irreparable damage.
• The heater does not have a device to control the room
temperature. Do not use the heater in small rooms occupied
by persons incapable of leaving the room on their own, unless
constant supervision is provided.
SETTING UP THE HEATER
1. To assemble the base, slot both halves of the base together.
Insert the 4 screws (included) in the holes on the underside of
the base and tighten to firmly secure the base halves together.
2. Place the heater upside down on a surface, such as a carpet or
cloth, that will not scratch the top. Unscrew the base connector
on the bottom of the heater counterclockwise and remove it.
3. Feed the power cord through the power cord slot.
4. Put the base onto the thread on the bottom of the heater.
Screw the base connector clockwise until it is firmly fixed into
place.
5. Turn the heater upright and place it on a firm, level, heat-
resistant and non-combustible floor surface. Do not place the
heater on a carpet.
6. Place the appliance at least 3 feet away from any combustible
items, such as furniture, curtains, bedding, clothes, and papers,
and 2 feet away from walls.
7. Do not place the heater next to a shower, bath, swimming pool
or other body of water. Maintain a distance of at least 5 feet to
water. Do not use the heater in wet or humid conditions.
8. Before plugging in the heater, check the POWER switch (9) is
in the o position Oand the red power indicator light is o.
9. Check the heater’s rating plate matches the mains socket
voltage. Connect the heater to the mains power supply.
HOW TO USE

12
EN
SETTING UP THE REMOTE
CONTROL
• Pull the plastic film from the battery compartment. The battery
is now active, and you can use the remote control.
• Operating range of the remote control: Point the remote
control at the heater making sure there are no obstacles
between the remote control and the heater’s infrared sensor.
The remote control can connect to the heater within 10 to 16.5
feet / 3 to 5 meters. The range may vary depending on the
brightness of the room.
CHANGING THE BATTERY
1. Push the release button inwards and pull the battery casing
out. Remove the old battery.
Remote control Battery cover
PULL
Battery
PUSH
2. Insert 1 x CR2025 3V battery into the battery casing ensuring
you follow the polarity (+ and -) marked on the casing.
3. Slide the battery casing back into the remote control until you
hear it click firmly into place.
WARNING: Do not expose the infrared remote sensor to direct
sunlight or other strong light, such as a florescent light.
NOTE: Make sure there are no obstacles between the remote
control and heater’s infrared sensor on the control panel.
HOW TO USE

13
EN
HOW TO USE
USING THE HEATER
NOTE: The buttons for operating the heater on the heater control
panel and the remote control are the same. The indicator light will
illuminate the icon of the function that is selected.
1. Press the POWER switch (1) to the on position I. The switch’s
red indicator light will illuminate and OF appears on the screen.
2. Press the ON/OFF button (11) on. The fan mode will start, the
indicator light will illuminate the fan icon , FA appears on
the screen.
3. Press the MODE button (14) repeatedly to select one of the
following options:
• LO – Heater low (750W)
• HI – Heater high (1500W)
• 25 – Economy – The heater will adjust the power level to
maintain the set temperature. The default temperature for this
mode is 25°C / 77°F.
NOTE: The indicator light will illuminate the icon of the function
that is selected. The fan remains on during all heater modes.
4. You can only set the temperature in economy mode. To set
the temperature, press the UP/DOWN buttons (13) to increase
or decrease the temperature to your desired level. The
temperature range is from 15°C to 35°C / 59°F to 95°F. The fan
and heater will turn on and o to keep the room at the set level.
NOTE: In economy mode, the heater must be set to a temperature
level that is at least a few degrees higher than the room
temperature for the heating function to be activated. If the heater
does not appear to be working, increase the temperature until the
heating function turns on.
5. To oscillate (swing) the heater through 60 degrees, press the
OSCILLATING button (12). The oscillating icon illuminates
when this function is on.
6. To stop the swing while the appliance is oscillating, wait
until the airflow is in the desired position and press the
OSCILLATING button (12).

14
EN
HOW TO USE
7. The timer can be set to turn the heater o in 1 to 12 hours.
When the heater is running, press the TIMER button (16)
repeatedly to set the hours. The timer icon illuminates
when this function is on. To turn the timer o, press the TIMER
button (16) repeatedly until 00 appears.
NOTE: When you are not changing the time or temperature
settings, the current room temperature will display.
8. Press the FLAME EFFECT ON/OFF button (15) repeatedly to
turn the flame eect on or o.
NOTE: The flame eect will turn on automatically when the heater
power is turned on.
9. To turn the heater o, press the ON/OFF button (11), OF will
display. The fan will run for 30 seconds to 1 minute to cool the
heater. The fan indicator light will flash. Then the screen and
indicator light will turn o. Press the POWER switch (9) to the
o position O.
10. Unplug the heater from the mains power supply when it is not
in use.
NOTE:
• Do not cover the heater or the air outlets/inlets/vents at any
time while it is turned on. There is a risk of fire if the heater is
covered.
• For safety reasons, this heater is equipped with a tip-over
sensor. This sensor automatically shuts down the heater if it is
not in an upright position while in operation. To resume normal
operation, check the heater is cool enough to handle, turn it
upright and turn it on again.
• The heater has a built-in overheating protection mechanism.
The safety mechanism will turn o the power if the heater
overheats. Press the ON/OFF button (11) to turn the heater
o and pull the mains plug from the socket. Wait 10 minutes
for the heater to cool down. Remove the cause of overheating
i.e. excessive dust and turn on the heater. If for any reason the
heater does not turn on, take it to your local service center for
repair.
• The heater is designed to be used at temperatures above
-20°C/ -4°F. If it is exposed to temperatures below this, allow it
warm up to this temperature before turning it on.

15
EN
CLEANING AND CARE
1. CAUTION: Always unplug the appliance from the mains
power supply and let it cool down before cleaning.
2. Wipe the outside of the heater and remote control with a soft,
damp cloth and dry thoroughly. Do not let any liquid enter the
heater or the remote control.
3. Remove the air inlet filter by lifting up the tabs at the bottom
of the filter and pulling it away from the appliance. Clean
under running water. Dry thoroughly before reassembling the
appliance.
NOTE:
• Do not use solvents, chemical or abrasive cleaning agents, wire
brushes, sharp objects or scouring pads to clean the product.
• Never immerse the appliance in water.
• Always clean the appliance before storing it for a long time.
• If you are not using the appliance for a long period, store
the appliance in its original packaging or in a dust-free, dry
environment.
TROUBLESHOOTING
Problem Possible Cause Solution
The appliance
will not turn on.
• The plug is loose
or not connected.
• Check the fuse
for the main
electricity supply
has not blown.
• Check the power
cord and make sure it
is firmly connected to
the mains socket.
• Replace the fuse. If
it is still not working,
try plugging in
to another mains
socket. If the
problem persists,
take the appliance
to a nearby service
center.

16
EN
DISPOSAL
Proper disposal of this product.
This symbol indicates that this appliance may not be treated
as household waste. Instead, it should be taken to the
appropriate collection point for recycling electrical and
electronic equipment.
Please use the return or collections services available in your
community or contact the retailer where you purchased this
product.
TROUBLESHOOTING
Problem Possible Cause Solution
Strong
vibrations or
noise.
• The appliance
is not on a flat,
stable surface.
• The appliance
may be
damaged.
• Move the heater to a
solid and even floor
surface.
• If the heater is
damaged, take the
appliance to a nearby
service center.

17
EN
INFORMATION AND SERVICE
If you have questions or concerns about your product, please visit
our website: www.westinghousehomeware.com, or contact our
overseas oces/agents.
In line with our policy of continuous product development,
we reserve the right to change the product, packaging and
documentation specifications without prior notice.
Model: WSHPTCNSK52
Heater
Voltage: 120V, 60Hz
Current: 12.5 Amps
Power: Low – 750W
High – 1500W
Weight: 6.61lbs
Size in inches (W x D x H): 11.02 x 11.02 x 34.05
Remote control
Battery: CR2025 3V x 1 (included)
Operating range: 10 to 16.5 feet (3 to 5 meters)

18
FR
TABLE DES MATIÈRES
CONSIGNES DE SÉCURITÉ
PRÉCAUTIONS DE SÉCURITÉ IMPORTANTES................................... 19
SOURCE D’ALIMENTATION........................................................................ 22
UTILISATION
DESCRIPTION DES PIÈCES........................................................................ 25
AVANT LA PREMIÈRE UTILISATION ...................................................... 26
INSTRUCTIONS DE FONCTIONNEMENT ............................................. 26
INSTALLATION DU RADIATEUR .............................................................. 27
INSTALLATION DE LA TÉLÉCOMMANDE. .......................................... 28
REMPLACEMENT DE LA PILE................................................................... 28
UTILISATION DU RADIATEUR .................................................................. 29
NETTOYAGE ET ENTRETIEN.............................................................. 31
GUIDE DE DÉPANNAGE...................................................................... 32
MISE AU REBUT .................................................................................... 33
INFORMATIONS ET SERVICE APRÈS-VENTE................................ 34

19
FR
CONSIGNES DE SÉCURITÉ
Lisez attentivement ce manuel d’instructions avant d’utiliser
l’appareil et conservez-le pour vous y référer ultérieurement.
1. Utilisez l'appareil uniquement pour l'usage auquel il est
destiné. Une utilisation incorrecte peut entraîner un choc
électrique, un incendie ou des blessures graves et peut annuler
la garantie.
2. Cet appareil est destiné uniquement à un usage domestique.
Ilne convient pas à un usage commercial, industriel ou
extérieur.
3. Cet appareil est destiné à une utilisation domestique et aux
applications similaires telles que :
- Dans les cuisines de personnel des boutiques, des bureaux et
autres lieux de travail ;
- Dans les habitations des fermes ;
- Par les clients des hôtels, des motels et autres
environnements de type résidentiel.
- Par les clients de logements de type chambres d'hôtes.
4. N'utilisez pas l'appareil s'il est endommagé ou ne fonctionne
pas correctement.
5. Cet appareil peut être utilisé par des enfants âgés de 8 ans
et plus s'ils sont surveillés ou s’ils ont reçu des instructions
concernant l'utilisation de l'appareil en toute sécurité et s'ils
comprennent les dangers impliqués. Le nettoyage et l’entretien
par l'utilisateur ne doivent pas être eectués par des enfants,
sauf s'ils sont âgés de plus de 8 ans et qu’ils sont surveillés par
un adulte.
PRÉCAUTIONS DE SÉCURITÉ
IMPORTANTES
DANGER
DANGER – Danger immédiat qui
CAUSERA des blessures graves
ou la mort.
AVERTISSEMENT
AVERTISSEMENT – Dangers ou pratiques
dangereuses POUVANT provoquer des
blessures graves, voire mortelles.
AVERTISSEMENT
Lors de l'utilisation d'appareils électriques, des précautions de sécurité
de base doivent toujours être suivies, y compris les suivantes :
MISE EN GARDE
MISE EN GARDE – Dangers ou
pratiques peu sécuritaires POUVANT
causer des blessures légères.

20
FR
CONSIGNES DE SÉCURITÉ
6. Les enfants de moins de 3 ans doivent être surveillés en
permanence s'ils se trouvent à proximité de l'appareil pendant
son utilisation ou lors de son refroidissement après l’utilisation.
7. Gardez l’appareil et son câble d’alimentation hors de la portée
des enfants lors de son fonctionnement.
8. Les enfants doivent être surveillés pour s'assurer qu'ils ne
jouent pas avec l'appareil.
9. Ne laissez jamais l’appareil sans surveillance lorsqu'il est en
marche.
10. Ne connectez pas cet appareil à une minuterie externe ou à un
système de télécommande.
11. Ne connectez pas l'appareil à un circuit qui est régulièrement
activé et désactivé par votre fournisseur d'électricité.
12. Ne couvrez jamais le radiateur ou les bouches d'aération car
cela pourrait causer un incendie.
13. Toutes les pièces couvrantes sont destinées à empêcher l'accès
direct aux éléments chauants et doivent être en place lors de
l'utilisation de l'appareil.
14. MISE EN GARDE : Certaines parties de cet appareil peuvent
devenir très chaudes et provoquer des brûlures. Assurez-vous
que les enfants ou les personnes aux capacités physiques,
sensorielles ou mentales réduites sont surveillés et protégés
contre les brûlures accidentelles. Afin d'éviter toute blessure ou
brûlure, ne touchez pas directement le radiateur. Utilisez des
gants ou d'autres moyens pour vous protéger.
15. Placez l'appareil en position verticale sur une surface ferme,
plane et résistante à la chaleur, près d'une prise de courant et
hors de portée des enfants.
16. Ne touchez pas les surfaces chaudes. Utilisez uniquement les
poignées ou les boutons.
17. Débranchez toujours l'appareil lorsqu’il est laissé sans
surveillance et après son utilisation. Laissez-le refroidir avant de
le nettoyer et de le ranger.
18. Lorsque vous utilisez l'appareil, laissez un espace susant au-
dessus et sur tous les côtés pour permettre la circulation de
l'air.
