Westinghouse WHT2401 User manual

Page 1
1. READ these instructions carefully before installing and operating the
appliance. Keep them for further reference.
2. Record in the space below the “SERIAL/MODEL NUMBER” found on the back
or bottom of your appliance and retain this information for future reference.
SERIAL NUMBER:
MODEL NUMBER:
DATE OF PURCHASE:
Save and staple your sales receipt to your manual for warranty coverage.
User Manual
Digital Ceramic
Tower Heater
MODEL: WHT2401

Page 2
CONTENTS
SAFETY INFORMATION
Important Safety Instructions..........................................................................................................................................3-5
Electrical Requirements..........................................................................................................................................................4
SET UP & USE
Parts & Features .........................................................................................................................................................................6
Control Panel ...............................................................................................................................................................................6
Operation Guide.....................................................................................................................................................................7-8
CLEANING & CARE............................................................................................................................................... 9
TROUBLESHOOTING & WARRANTY
Limited Warranty................................................................................................................................................................ 10-11

Page 3
IMPORTANT SAFETY INSTRUCTIONS
When using electrical appliances, basic precautions should always
be followed to reduce the risk of re, electric shock, and injury to
persons, including the following:
1. Read all instructions before using this heater.
2. This heater is hot when in use. To avoid burns, do not let bare
skin touch hot surfaces. If provided, use handles when moving
this heater. Keep combustible materials, such as furniture, pillows,
bedding, papers, clothes, and curtains at least 3 feet (0.9 m) from
the front of the heater and keep them away from the sides and
rear.
3. Extreme caution is necessary when any heater is used by or near
children or invalids and whenever the heater is left operating and
unattended.
4. Always unplug heater when not in use.
5. Do not operate any heater with a damaged cord or plug or after
the heater malfunctions, has been dropped or damaged in any
manner. Discard heater or return heater to authorized service
facility for examination, electrical or mechanical adjustment, or
repair.
6. Do not use outdoors.
7. This heater is not intended for use in bathrooms, laundry areas
and similar indoor locations. Never locate heater where it may fall
into bathtub or other water container.
8. Do not run cord under carpeting. Do not cover cord with throw
rugs, runners, or similar coverings. Do not route cord under
furniture or appliances. Arrange cord away from trafc area and
where it will not be tripped over.
9. To disconnect heater, rst turn controls to off, then remove plug
from outlet.
WARNING
When using electrical appliances, basic safety precautions
should be followed, including the following
DANGER
DANGER - Immediate hazards
which WILL result in severe
personal injury or death
WARNING
WARNING - Hazards or unsafe
practices which COULD result in
severe personal injury or death
CAUTION
CAUTION - Hazards or unsafe
practices which COULD result in
minor personal injury
SAFETY INFORMATION

Page 4
10. Do not insert or allow foreign objects to enter any ventilation or
exhaust opening as this may cause an electric shock or re, or
damage the heater.
11. To prevent a possible re, do not block air intakes or exhaust
in any manner. Do not use on soft surfaces, like a bed, where
openings may become blocked.
12. A heater has hot and arcing or sparking parts inside. Do not use
it in the areas where gasoline, paint, or ammable liquids are
used or stored.
13. Use this heater only as described in this manual. Any other use
not recommended by the manufacturer may cause re, electric
shock, or injury to persons.
14. CAUTION: Always plug heaters directly into a wall outlet/
receptacle. Never use with an extension cord or relocatable
power tap (outlet/power strip).
15. This heater draws 12.5 amps during operation. To prevent
overloading a circuit, do not plug the heater into a circuit that
already has other appliances working.
16. The output of this heater may vary and its temperature may
become intense enough to burn exposed skin. Use of this heater is
not recommended for persons with reduced sensitivity to heat or an
inability to react to avoid burns.
17. Don’t leave the heater on unattended.
SAVE THESE INSTRUCTIONS
HOUSEHOLD USE ONLY
ELECTRICAL REQUIREMENTS
This appliance has a polarized plug (one blade is wider than the other). To
reduce the risk of electric shock, this plug is intended to t into a polarized outlet
only one way. If the plug does not t into the outlet, reverse the plug. If it still
does not t, contact a qualied electrician. Do not attempt to modify the plug in
any way.
NOTE: Neither Westinghouse nor the dealer can accept any liability for damage to the
product or personal injury resulting from failure to observe the electrical connection
procedures.
WARNING: To reduce the risk of electric shock, do not use with an extension cord.
SAFETY INFORMATION
SAFETY INFORMATION

Page 5
SAFETY INFORMATION
SAFETY FEATURES
TIP-OVER SAFETY FEATURE
This heater is equipped with a tip-over safety feature. Once the heater is tipped over,
an internal switch will automatically shut the heater off. Once the heater is restored
an upright position, the heater will reset. To continue operation, turn on the heater
using the supplied remote control or the control panel on the heater.
OVERHEAT SAFETY FEATURE
This heater is equipped with a overheat safety feature. When the heaters internal
components reach a certain temperature that could cause overheating and possible
re, the heater will automatically shut off.
BATTERY INFORMATION
• KEEP OUT OF REACH OF CHILDREN. Swallowing may lead to serious injury
or death. Severe burns can occur within 2 hours of ingestion. Immediately see
a doctor and have the doctor phone [phone] collect. Keep in original
package until ready to use. Dispose of used batteries immediately. Risk of
injury due to re, explosion or leakage. Do not disassemble, charge, crush or
expose to re or high temperatures.
• LITHIUM COIN CELL SAFETY NOTICE: Keep lithium coin batteries out of the
reach of small children; coin cell batteries can be accidentally ingested. If
ingested, these batteries may leak harmful contents causing chemical burns,
perforation of soft tissue, and in severe cases may cause death. Lithium coin
batteries must be removed immediately if swallowed. Seek medical attention
immediately. If you or your doctor suspects that a battery has been ingested
for assistance in the US call the NATIONAL BATTERY INGESTION HOTLINE any
time at [phone]: in Canada call 416-813-5900.
• Do not dispose of batteries in re. Batteries may explode or leak.
• Remove the battery if the remote control is not used for a long period of time.
WARNING
It is normal for the power cord to feel warm to the touch; however, a loose
t between the outlet and the plug may cause overheating of the plug. If
this occurs, try inserting the plug into a different outlet. Contact a qualied
electrician to inspect the original outlet for damage.

Page 6
OSCILLATE
TIMER
TEMP + TEMP -
POWER
MODE
OSCILLATE
TIMER
TEMP + TEMP -
POWER
MODE
PARTS & FEATURES
CONTROL PANEL
DISPLAY WINDOW
OscillatePower
Power Indicator
Timer Indicator
Oscillate Indicator
Remote Control Signal Receiver
Temp /
Hour Timer
Celsius /
Fahrenheit
Indicators
High Heat
Mode Indicator
Low Heat
Mode Indicator
ECO Mode Indicator
Timer
Mode
Temp+ Temp-
SET UP & USE
OSCILLATE
TIMER
TEMP + TEMP -
POWER
MODE
Display Window
Control Panel
Base
Air Output Grill
Remote Control
Oscillate Power
Timer Mode
Temp+ Temp-
Handle
(In back, not shown)
OSCILLATE
TIMER
TEMP + TEMP -
POWER
MODE
OSCILLATE
TIMER
TEMP + TEMP -
POWER
MODE
Air Input Grill
(In back, not shown)

Page 7
SET UP & USE
PREPARATION FOR USE
Place the heater on a rm, level surface and plug the unit directly into a 120v AC
electrical outlet. Pull out the insulating lm from the battery compartment of the
remote control as shown below.
OPERATING INSTRUCTIONS
POWERING AND SELECTING WORK MODE
Turn the heater on by pressing the POWER button on the remote control or
control panel.
NOTE: Once you power off, heating element will stop but fan will continue
for an additional 3 minutes.
Select a heat mode by pressing the MODE
button to toggle between the three heat
settings (HIGH HEAT / LOW HEAT / ECO).
HIGH Mode uses 1500W; LOW Mode uses
1000W. ECO mode is an energy saving
function. When ECO mode is chosen, the heater will manage itself from less to more
heating power (wattage) in an attempt to maintain a constant temperature of 68˚F
(20˚C).
SETTING DESIRED TEMPERATURE
Adjust the desired temperature by pressing the TEMP+ and
TEMP- arrows on the control panel or remote control.
Desired temperature options vary from 59˚F -
86˚F (15˚C - 30˚C). Once you have chosen the
desired temperature, the heater will remain on
until the room temperature increases to the
temperature shown on the digital display.
Once desired temperature is reached, heater will
cycle on and off to maintain the desired room
temperature.
NOTE: Pushing the “MODE” button for more than 3 seconds will allow you
to switch between ˚C and ˚F
The Fahrenheit LED indicator will light when the
temperature is displayed in Fahrenheit. The Celsius
LED indicator will light when the temperature is
displayed in Celsius.
NOTE: For the heater to function properly, the desired temperature on
the heater must be set a few degrees higher than the temperature
in the room. If the seems to not be heating, increase the desired
temperature on the heater to engage the heating elements.
OSCILLATE
TIMER
TEMP + TEMP -
POWER
MODE
OSCILLATE
TIMER
TEMP + TEMP -
POWER
MODE
OSCILLATE
TIMER
TEMP + TEMP -
POWER
MODE
OSCILLATE
TIMER
TEMP + TEMP -
POWER
MODE
OSCILLATE
TIMER
TEMP + TEMP -
POWER
MODE

Page 8
SETTING THE AUTO SHUTOFF TIMER FUNCTION
The Auto Shutoff Function allows for the heater to automatically power off
after a certain set time.
NOTE: Timer can only be set while heater is on.Turn the heater on and press
the Timer button on the heater’s control panel or the remote control.
The digital display changes from the “temperature”
to the “hours” option for the timer. Continue to
press the timer button to change the number
of hours you would like the heater to run before
powering itself off .The hour options for the timer are from 0 to 12 hrs. in one hour
increments.
The selected hour increments will ash for a few seconds then revert back to the set
desired temperature. The timer indicator light will remain lit as long as the timer is set.
The heater will power off when the internal heater clock counts down to the amount
of auto shutoff time selected.
SETTING THE AUTO ON FUNCTION
The Auto On Function allows for the heater to power on automatically after a
certain set time.
NOTE: Time can only be set while the heater is off.Turn the heater to the off
position and press the Timer button on the heater’s control panel or
the remote control.
The digital display shows the “hours” option for the
timer. Continue to press the timer button to change
the number of hours you would like the heater’s
internal clock to count down before powering itself
on .The hour options for the timer are from 0 to 12 hrs. in one hour increments.
The Timer indicator light will remain lit as long as the timer is set. The heater will
power itself ON when the internal heater clock counts to the amount of auto on time
selected.
SETTING SWING/OSCILLATION FUNCTION
Select this function mode by pushing the OSCILLATE button on control panel
or remote control.
When the heater is on and oscillating function is working indicator will light.
Press the OSCILLATE button again to shut off and indicator light will turn off.
SETTING CHILD LOCK FUNCTION
The Child Lock can help avoid the heater from being accidentally engaged by
children. The locking mechanism can be set in both the ON and OFF modes.
Press TEMP+ and TEMP- buttons on the heater control panel
at the same time for 3 seconds. Locking is complete when you
hear a beep. When locked, the functions of the control panel
and remote control cannot be used.
When you need to unlock it, press TEMP+ and TEMP- buttons on the heater control
panel at the same time for 3 seconds. You will hear a beep .The control panel and
remote control will become functional again.
NOTE: Child Lock function can not be activated from the remote control.
SET UP & USE
OSCILLATE
TIMER
TEMP + TEMP -
POWER
MODE
OSCILLATE
TIMER
TEMP + TEMP -
POWER
MODE
OSCILLATE
TIMER
TEMP + TEMP -
POWER
MODE
OSCILLATE
TIMER
TEMP + TEMP -
POWER
MODE

Page 9
CLEANING & CARE
1. Unplug the unit and let it cool completely.
2. To keep the heater clean, the outer shell may be cleaned with a soft, damp cloth.
You may use a mild detergent if necessary. After cleaning, dry the unit with a soft
cloth. CAUTION: DO NOT let liquid enter the heater.
3. DO NOT use alcohol, gasoline, abrasive powders, furniture polish, or rough
brushes to clean the heater. This may cause damage or deterioration to the
surface of the heater.
4. DO NOT immerse the heater in water.
5. Wait until the unit is completely dry before use.
6. If you do not use the heater for a long time, take out the battery as shown below
to avoid corrosion. Store the remote control in a safe place. Follow same steps for
battery replacement.
STORAGE
Store the heater in a cool, dry location when not in use. To prevent dust and dirt
build-up, use the original packaging to repack the unit.
PUSH
BATTERY
BATTERY COVER
PULL
SPECIFICATIONS
Voltage Rating: 120 V (60Hz)
Power Consumption: 1500W
Unit Size WxDxH: 7.2” x 8.2” x 23.4”
Unit Weight: 5.1 lbs

Page 10
TROUBLESHOOTING & WARRANTY
CUSTOMER SERVICE
IMPORTANT
DO NOT RETURN THIS PRODUCT TO THE STORE
If you have a problem with this product, please contact the W
Appliance Co. Customer Satisfaction Center at 1-855-855-0294.
DATED PROOF OF PURCHASE, MODEL # AND SERIAL #
REQUIRED FOR WARRANTY SERVICE
BEFORE YOU CALL FOR SERVICE
IF THE PRODUCT FAILS TO OPERATE:
A) Check to make sure that the unti is plugged in securely. If it is not, remove
the plug from the outlet, wait 10 seconds and plug it in again securely.
B) Check for a blown circuit fuse or a tripped main circuit breaker. If these seem to
be operating properly, test the outlet with another appliance.
IF NONE OF THE ABOVE SOLVES THE PROBLEM, CONTACT CUSTOMER SERVICE.
DO NOT TRY TO ADJUST OR REPAIR THE UNIT YOURSELF.
TROUBLESHOOTING
TROUBLE POSSIBLE CAUSE POSSIBLE REMEDY
Unit does not
turn on
Unit is not plugged in Check that unit is plugged into a
working outlet
Remote does
not work.
Battery not set correctly or low
on power.
Check that the battery has been
placed in the remote control properly
and is in good working condition.

Page 11
LIMITED WARRANTY
Westinghouse brand is used under license.
Any repair, replacement, or warranty service,
and all questions about this product should be
directed to W Appliance Co. at 1 (855) 855-
0294 from the USA or Puerto Rico.
W Appliance Co. warrants to the original purchaser
that the product will be free from defects in material,
parts and workmanship for the period designated for
this product. The warranty commences the day the
product is purchased and covers up to a period of
1 year (12 months) for labor/1 year (12 months) for
parts (manufacturing defects only)/carry in service.
W Appliance Co. agrees that it will, at its option,
replace the defective product with either a new or
remanufactured heater equivalent to your original
purchase during the warranty period.
Exclusions: This warranty does not apply to the
below:
1. If the appearance or exterior of
the product has been damaged or
defaced, altered or modied in design or
construction.
2. If the product’s original serial number
has been altered or removed or cannot
be readily determined.
3. If there is damage due to power line
surge, user damage to the AC power
cord or connection to improper voltage
source.
4. If damage is due to general misuse,
accidents or acts of God.
5. If repair attempts are done by
unauthorized service agents, use of
parts other than genuine parts or parts
obtained from persons other than
authorized service companies.
6. On units that have been transferred
from the original owner.
7. On products that have been purchased
as refurbished, like new, second-hand, in
a “As-Is” or “Final Sale” terms.
8. To products used in a commercial or
rental setting.
9. To products used in settings other than
ordinary household use or used other
than in accordance with the provided
instructions.
10. To damages for service calls for
improper installations.
11. To glass parts and other accessory
items that are included with the unit.
12. Transportation and shipping costs
associated with the replacement of
the unit.
13. Service calls to instruct you how to use
your heater.
14. Service calls to repair or replace the
house fuse, reset the circuit breaker or
correct the wiring in the house.
REPAIR OR REPLACEMENT AS PROVIDED UNDER
THIS WARRANTY IS THE EXCLUSIVE REMEDY OF
THE CUSTOMER; W Appliance Co. SHALL NOT BE
LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL
DAMAGES FOR BREACH OF ANY EXPRESS OR
IMPLIED WARRANTY ON THIS PRODUCT, EXCEPT
TO THE EXTENT PROHIBITED BY APPLICABLE LAW.
ANY IMPLIED WARRANTY OF MERCHANTABILITY
OF FITNESS FOR A PARTICULAR PURPOSE ON THIS
PRODUCT IS LIMITED TO THE DURATION OF THE
WARRANTY.
Some states do not allow the exclusion or limitations
of incidental or consequential damages, or limitations
on how long the warranty lasts. In these cases the
above exclusions or limitations may not apply to you.
This warranty gives you specic legal rights and you
may also have other rights which vary from state to
state.
Obtaining Service: To obtain service, product
literature, supplies or accessories please call
1 [phone] to create a ticket for exchange/
repair. Please make sure to provide the date of
purchase, model number and a brief description of the
problem. Our customer service representative
will contact you or send detailed return instructions.
W Appliance Co. does not warrant that the appliance will work
properly in all environmental conditions, and makes no warranty
and representation, either implied or expressed, with respect
to the quality, performance, merchantability, or tness for a
particular purpose other than the purpose identied within this
user manual. W Appliance Co. has made every effort to ensure
that this user manual is accurate and disclaims liability for any
inaccuracies or omissions that may have occurred. Information
in this user manual is subject to change without notice and does
not represent a commitment on the part of W Appliance Co. W
Appliance Co. reserves the right to make improvements to this
user manual and/or to the products described in this user manual
at any time without notice. If you nd information in this manual
that is incorrect, misleading, or incomplete, please contact us at
1- 855-855-0294.
W Appliance Co.,
1356 Broadway
New York, NY 10018
TROUBLESHOOTING & WARRANTY

Page 12
, WESTINGHOUSE, and INNOVATION YOU CAN BE SURE OF
are trademarks of Westinghouse Electric Corporation. Used under
license by W Appliance Company. All Rights Reserved.
090617
