Weston 16-0701-W User manual

CHERRY PITTER
16-0701-W
DUE TO CONSTANT FACTORY IMPROVEMENTS, THE PRODUCT PICTURED MIGHT DIFFER
SLIGHTLY FROM THE PRODUCT IN THIS BOX. 060115

TABLE OF CONTENTS / ÍNDICE / TABLE DES MATIÈRES
2
COMPONENT LIST
CLEANING INSTRUCTIONS
ASSEMBLY INSTRUCTIONS
OPERATING INSTRUCTIONS
WARRANTY
LISTA DE COMPONENTES
INSTRUCCIONES DE LIMPIEZA
INSTRUCCIONES DE ENSAMBLADO
INSTRUCCIONES DE OPERACIÓN
INFORMACIÓN DE GARANTÍA WESTON
DESCRIPTION DE LA PIÈCE
INSTRUCTIONS DE NETTOYAGE
DIRECTIVES POUR L’ASSEMBLAGE
INSTRUCTIONS D’UTILISATION
INFORMATION SUR LA GARANTIE
3
4
4-5
5
6
8
9
9-10
10
12
14
15
15-16
16
19

3
ENGLISH INSTRUCTIONS
5
COMPONENT LIST
DIAGRAM NUMBER PART DESCRIPTION PART NUMBER
N/A RUBBER GASKET REPLACEMENT PART (2
RUBBER GASKETS)
16-0702
1 RUBBER GASKET (1) N/A
2 PIT CONTAINER BASE N/A
3 HOPPER N/A
4 SHAFT HOLDER N/A
5 SPRING N/A
6 PLUNGER SHAFT N/A
7 PLUNGER KNOB N/A
8 CHUTE N/A
If any components of this unit are broken, the unit does not operate properly or you
need a replacement instruction manual, visit us on the web at
WestonProducts.com
Or call Weston Brands LLC Toll Free at 1-800-814-4895
Monday thru Friday 8:00am-5:00pm ET. Outside the U.S. call 001-440-638-3131
2
3
7
4
6
8
1

1. Make sure the Rubber Gasket is
inserted into the underside of the
Hopper. The concave side of the gasket
should be facing up. FIGURE 1/1A
2. Align the Hopper with the Pit
Container Base, making sure the notch
and slit snap into place. FIGURE 2/2A
ENGLISH INSTRUCTIONS
4
ASSEMBLY INSTRUCTIONS
CLEANING INSTRUCTIONS
Prior to use, wash all parts in warm soapy water.
NOTE: SOME parts are dishwasher safe. Please do not put the Spring,
Rubber Gaskets or Pit Container Base in the dishwasher.
CLEANING INSTRUCTIONS
FIGURE 1
FIGURE 1A
FIGURE 2 FIGURE 2A

OPERATING INSTRUCTIONS
Place a bowl beneath the Chute to catch pitted fruit. Once the Cherry Pitter is
assembled, load cherries into the Hopper. Cherries will roll into place beneath
the Plunger Shaft. Push down the Plunger Knob to expel the pits into the
Pit Container Base. The pitted fruit will slide down the Chute and into your
container/bowl.
CLEANING INSTRUCTIONS
ENGLISH INSTRUCTIONS
5
3. Line up the posts on the Shaft
Holder with the slots on the
Hopper. FIGURE 3
4. Insert the Spring into the
opening of the Shaft Holder.
FIGURE 4
5. Insert the Plunger Shaft
through the Spring and into the
opening of the shaft holder,
aligning the Plunger with the
“X” shaped opening in the Shaft
Holder. FIGURE 5
6. Secure the Plunger Shaft
by twisting the white plastic
piece below the Plunger Knob
clockwise. FIGURE 6
7. On a clean dry surface, ip
the Suction Cup Lever back to
secure the Cherry Pitter to the
table or counter. FIGURE 7
FIGURE 3
FIGURE 4
FIGURE 5
FIGURE 6 FIGURE 7
