THE DT392/392i
8
BASIC OPERATION GUIDE
DT 392/392i
signage dtri com
Mobile Tablet
INTRODUCTION
Thank you for acquiring the latest addition to DT
Research’s line of mobile tablets— the DT392/392i.
Featuring an IP54 or IP64-rated, slim yet robust enclosure,
the two-pound DT392/392i with 8.9” TFT display is powered by the Intel®Atom™
processor, offering optimal combinations of performance and power savings. An
external battery expansion option provides approximately 3-4 hours of additional battery
operation for up to eight hours of mobile usage.
The DT392/392i is available with Microsoft®Windows®Embedded Standard 7,
Windows®7 Professional, Windows®XP Embedded, Windows®XP Pro for Embedded
Systems or Linux operating systems. Each software operating system features web
browser, client/server computing software, media player, accessories, and applications
support.
PACKAGE CONTENTS
DT392/392i with Internal Battery Pack, Stylus and Bumpers•
AC-DC Power Adapter with Power Cord•
Basic Operation Guide•
Major options, depending on conguration:
Desktop Charging Cradle with DC-in Power Jack and Ethernet/ USB Ports•
External Battery Pack•
External Battery Charger Kit•
Vehicle/ Wall Mount Cradle•
5-System Gang Charger•
* If your DT392contains MSR, camera or scanner module, please refer to the POS
module operation guide for detailed operation.
DT392392iENG
SPECIFICATIONS
Model Item DT392 DT392i
System
Display 8.9” (diag.) TFT LCD with Resistive Touch and LED
backlight; outdoor-viewable option
Display Resolution 1024 x 600 (WSVGA)
Processor Intel®Atom™ processor Z530 1.6GHz
Memory (RAM) 1GB to 2GB DDR2 533MHZ
Storage 2GB to 16GB Internal Flash Module,
32GB to 64GB SSD
Operating Systems
Microsoft®Windows®Embedded Standard
7, Windows®7 Professional, Windows®XP
Embedded, Windows®XP Pro for Embedded
Systems or Linux
Network Interface WiFi 802.11a/b/g/n, Bluetooth 2.1
Input and Control
Buttons
1 Power button, 7 Front buttons and
1 Trigger button
Indicator 1 Power/ Battery status LED and 1 WLAN active LED
Input/Output Ports 1 DC-in Jack; 1 USB 2.0 port
1 Headphone-out Jack combined with microphone;
Audio/Microphone Built-in speakers; built-in internal microphone
Mechanical
Enclosure ABS + PC Plastic
Protective Grips Rubber with handstrap
Dimensions
(H x W x D)
7.7 x 10 x 1.25 (in);
196 x 256 x 32 (mm)
Weight 2.43 lbs (1.1 kg)
Battery Pack Internal (2S2P; 7.4V, 3760mAh)
Optional: External (2S2P; 7.2V, 3900mAh)
AC/DC Adapter Input: 100 – 240V AC
Output: 19V [email protected]
Power Cords North America, EU, UK, China and Japan
Stylus Non-electronic tip
Environmental
Water and Dust
Resistance IP54 IP64
Shock and
Vibration Protection MIL-STD-810G
Regulatory FCC Class B, CE, C-Tick, RoHS compliant
Operating
Temperature
Operation: 0°C - 40°C
Storage: 0°C - 60°C
Operation: -20°C - 50°C
Storage: -20°C - 60°C
Humidity 0% - 90% non-condensing

THE DT392/392i
23
Button Functions (with Windows XP Operating System)
BUTTON ACTION
Programmable
Programmable, launch soft (on-screen) keyboard (default)
Launch SAS (Secure Attention Sequence)
GenerateCtrl+Alt+Delkeystoinvokethesecuritywindowsdenedunder
Windows XP
Programmable,
Change display orientation (portrait/ landscape) (default)
Programmable, system utility menu (default)
Programmable,
As scanner trigger when equipped with the scanner module
Power on,
Push/release typically enters Standby mode, or Push/release exits Standby
mode or restarts device (software dependent)
Push and hold (over 4 seconds) invokes hardware shutdown
The DT 392/ 392i (with Windows XP Operating System)
Battery/Power LED
Wireless LEDMicrophone
Stylus
Button Management
Wireless Network Settings
Calibration
Power/Battery LED Status:
Blue indicates the battery is 25% to 100% charged•
Blinking blue indicates the battery is charging•
Orange indicates that the battery is between 11% to 25%•
Blinking Orange indicates that the battery is below 10%•
Precautions
Always exercise care when operating and handling the DT392/392i.
•
Do NOT apply excessive pressure to the display screen.
•
We recommend using the Stylus provided to keep the screen clean.
•
Avoid prolonged exposure of the display panel to any strong heat source. Wherever
•
possible, the DT392/392i should face away from direct light to reduce glare.
If the AC-DC power adapter is used to recharge or power the device, do NOT use
•
any AC-DC adapter other than the one provided with the device or acquired from
the manufacturer or its partners.
In the unlikely event that smoke, abnormal noise, or strange odor is present,
•
immediately power off the DT392/392i and disconnect all power sources.
Report the problem to your device provider immediately.
Never attempt to disassemble the DT392/392i, as this will void the warranty.
•
THE DT392/392i
Basic Features
The DT392/392iwireless tablet integrates a bright and responsive touch display,
1 USB port, and embedded networking elements such as wireless LAN, Bluetooth or
optional 3G. The primary device is complemented by a suite of accessories, including
battery expansion, docking cradles, and carrying cases, for a comprehensive user
experience.
A DT392/392i typically integrates an 802.11a/b/g/n wireless LAN (WLAN) adapter
that may connect to other wireless devices or access points. If your DT392/392i
does not come with such a network adapter, please consult your device provider to
establish the desired network connectivity.
1
8
9
2 3
4
5
6
8
9
7
Input/ Output Ports
Headphone Jack
USB Port
DC Power Input
A
C
B
A
B
C
1234567
Battery and Power Meter

THE DT392/392i
45
OPERATION
Internal Battery
Warning!
The Internal battery pack should only be replaced by an authorized DT service
representative. Please contact your product and/or service provider for internal battery
replacement service.
Powering ON and OFF
To activate the DT392/392i, push and quickly release the Power Button to the
right side of the front bezel. The display will come on in a few seconds. To put the
DT392/392i in Standby mode, push and quickly release the Power Button. To
turn the DT392/392i off for extended storage, power off the device safely using
any software function that “shuts down computer” provided in the software operating
system.
NOTE: The battery packs shipped with your device may be low in power—please use
theAC-DCadapterwiththeDT392/392iwhensettingupthedevicefortherst
time to fully charge the internal battery pack. You may charge the external battery
pack with it attached to the DT392/392i, or with the optional external battery
charger kit.
NOTE: When the battery pack(s) is (are) charging, the blue-colored Battery LED
should blink slowly. If plugging in the AC-DC adapter does not trigger this blinking
activity and the LED stays dark, the battery pack(s) may have been drained
substantially. Try unplugging/ replugging the AC-DC adapter to the DT392/392i
a few times to activate the charging process.
NOTE: To conserve power, use (push and quick release) the Power Button to put the
devicein“Standby”modewhilenotinuse.Pushingbrieyonthesamebuttonwill
wake up the system within seconds.
NOTE: Avoid using the Power Button (“hold 4+ seconds” feature) to turn off the
device—this form of hardware shutdown is intended to be a means of recovery from
device lockups, and not as normal operation.
Start Up
If the power up (from Standby or otherwise) is successful, the appropriate interface will be
displayed after a launch sequence of several seconds. The wireless LAN connection may
take 10-15 seconds to be established.
Conguring the DT392/392i
Thedevicemaybeconguredusingtheutilitiesandmethodsdictatedbythe
softwareoperatingsystem.TheDT392/392ishouldbecongurableforvarious
propertiessuchasuserproles,networkfeatures,andseveralsystemelements.
Calibration
The touch display for the DT392/392i is calibrated before shipping. In the event
thatthecalibrationhasbeenmodiedorisunsatisfactory,therespectivecalibration
routines (e.g., PenMount (PM) for Windows XP) to calibrate the touch interface may
be used. Such applications are typically executed through touch input via Stylus or
through mouse click via a USB mouse.
Wireless Networking
Wireless LAN
The DT392/392i is often delivered with an embedded (user-inaccessible)
802.11a/b/g/n WLAN adapter equipped with a hidden custom antenna.
T
• hrough the support of typical WLAN adapters, the DT392/392i should be
able to detect all 802.11 access points in the vicinity for you to select the access
point of your choice for connection.
T
• he SSID and WEP/WPA/WPA2 (if enabled) parameters on the DT392/392i
and the access points have to match. The SSID is case-sensitive and it is recom-
mended that you enable WEP/WPA/WPA2 encryption (or advanced alternatives)
for secure access.
W
• hen WEP/WPA/WPA2 is enabled, you may need to consult your network admin-
istratororyournetworkingequipmentliteraturetoproperlycongureassociated
settings such as Authentication mode, etc.
R
• efer to the access point operating manuals for setting up the 802.11 access
points.
!

THE DT392/392i
67
Bluetooth
The DT392/392i features a built-in Bluetooth adapter that operates on the
MicrosoftWindowsBluetoothprotocol.TheBluetoothcongurationapplicationis
invoked from the System Tray or from the Control Panel for Windows XP. Follow
theinstructionsandoptionsprovidedwithintheapplicationtocongureandinvoke
Bluetooth connectivity with the corresponding peripherals.
NOTE: Bluetooth devices or accessories that are not compatible with the Microsoft
Windows Bluetooth protocol may not work with the DT392/392i.
Button Management
Where supported by software, many of the hard buttons on the DT392/392i are
programmable to perform a function of the user’s choice. The exception is the Power
Button and the SAS Button. To activate the button re-assignment application, invoke
the Button Agent application, e.g., in Windows XP Embedded.
Brightness Control
Wheresupportedbydevicermwareandsoftware,ahardbuttonmaybeengagedto
manipulate the display brightness. Press the System Menu button (Button 7) on the
front of the DT392/392i. The System screen will display a Brightness control
section with up and down arrows that can be activated with the stylus.
Battery and Power Management
The DT392/ 392i is equipped with an internal 3760mAh Li-Ion battery pack that
is capable of supporting approximately 3 - 4 hours of continuous operation. With the
internal battery and an external battery pack that clips (hot-pluggable) onto the back
of the device, the maximum period of continuous operation will be approximately 6 - 8
hours.Theperiodbetweenbatteryrechargescanbesignicantlylengthenedbyputting
the device into Standby mode through the Power Button (see Buttons Function Table)
whenever the device is not in use. Depending on the operating software, the DT
392/392imayalsobeconguredtoentervariouspower-savingmodesviathePower
Button or through timed entry.
Desktop Cradle
The DT 392/392i is complemented by an optional Desktop Cradle for support,
pass-through charging, and connection to a range of USB peripherals, including
keyboard and mouse. The Cradle offers the following interfaces: a DC-in port for the
AC-DC adapter, an Ethernet port, and USB ports. Always seat the DT392/392i
securely onto the cradle. The cradle must be powered by the AC-DC adapter for
the Ethernet and USB ports to function. The battery packs on the DT392/392i
may be recharged by connecting the AC-DC adapter directly to the DC-in port on the
DT392/392i or through the DC-in port on the Desktop Cradle while the DT392/392i
is docked to the Cradle.
USING THE DT392/392i
Memory & Storage conguration
TheDT392/392iisavailablewith1GBor2GBmemorycongurations.Storage
optionscurrentlyrangefrom:2GBto16GBashmemoryor32GBto64GBSSD.
Peripherals Support
Through its USB ports, the DT392/392i supports a wide range of USB-based
peripherals. These peripherals are applicable for software installation, applications
storage, data storage, and system software recovery and updates. The DT392/
392i is also compatible with custom mountable cradle options. These securable and
mountable cradles provide an interface to VESA mounts and arms, and to ports that
may include USB, Ethernet and pass-through power.
WETIF Industrie EDV Telefon DE [phone]
Senserstraße 3 Telefon AT [phone]
D - 82140 Olching [email protected] www.wetif.com
Techn. Änderungen ohne Vorankündigung und Irrtum vorbehalten. Alle Rechte geschützt.
