Wilson Electronics WEBOOST DRIVE X OTR User manual

Cellular Booster For Trucks
DRIVE X OTR
A WILSON ELECTRONICS BRAND
NEED HELP? support.weboost.com
Use our weBoost App to guide you through the installation.
See inside page for more details.
1-866-294-1660
Installation Guide

Download the weBoost App
Use our app to guide you through setting up a weBoost cell phone
signal booster in your home, business, or vehicle. Boost every
network, including 5G, right away.
Download the weBoost App
Videos to guide you
through installation
Antenna positioning guide
for optimal performance
Before and after cell
signal readings

______
Index
Package Contents 1
STEP 1: Select Mounting Location & Assemble the Antenna 2
STEP 2: Mount Outside Antenna 5
STEP 3: Mount Inside Antenna 6
STEP 4: Connect Coax Cables To Booster 7
STEP 5: Connect Power Supply To Booster 8
Light Patterns 10
Troubleshooting 11
Safety Guidelines 13
Specifications 14
Warranty 15

1VEHICLE SIGNAL BOOSTER DRIVE X OTR
________
Package
Contents
Booster
& Bracket
Outside
Antenna
(311229)
Inside
Antenna
(314401)
Power
Supply
(859913)
Mast Extensions
& Side Exit Adapter
(991113, 991129,
990061)
3- Way Antenna
Mount
(901104)
Antenna
Spring
(901206)
Thread Lock
Packets
Cable
Adapter
Typical Antenna
Mounting Points

DRIVE X OTR VEHICLE SIGNAL BOOSTER 2
______
Step 1: Select Mounting
Location & Assemble The
Antenna
Depending on the type of truck, there may be built-in antenna
mounting points. If the vehicle does not have built-in mounting
points, the antenna includes a 3-way mount that will work on
vehicles with mirror rails. The antenna will also work with third
party CB antenna mounts.
Select mounting location on vehicle. The antenna can be
mounted in any CB mount or antenna mounting point on the
vehicle. For best performance mount the antenna above the
metal cab (it does not need to be above cab wind deflector).
Typical Antenna
Mounting Points
NOTE: Mount at least 12 inches from any other antennas. Free of obstructions.
NOTE: If the vehicle is using two CB antennas co-phase wiring, removing one
antenna will cause reduced performance of the remaining CB antenna.

3VEHICLE SIGNAL BOOSTER DRIVE X OTR
Mast
Extension
Mast
Extension
Mast
Extension
OR
Antenna
Side Exit
Adapter
cable
cable
from antenna
OTR
Antenna
Thread Lock
Thread Lock
Once you have determined the
best location for the antenna
and have determined if mast
extensions are needed, insert
cable through mast.
If using mast extension(s) add
thread locker (packets provided)
to thread point(s). Screw into
place.
Add thread locker (packets
provided) to thread point and
screw on the side exit adapter.
NOTE: Mast Extensions may not be
needed depending on your mounting
point.
NOTE: Be sure the antenna is the correct
height before applying thread locker.
NOTE: When adding the side exit adapter
hold the antenna vertically and screw the
adapter from the bottom up. This reduces
cable twisting.
______
(STEP 1 cont.)

DRIVE X OTR VEHICLE SIGNAL BOOSTER 4
______
(STEP 1 cont.)
c
a
b
l
e
c
a
b
l
e
c
a
b
l
e
13 in.
Mast
13 in.
Mast
13 in.
Mast
18 in.
Mast
Side Exit
Adapter
Antenna Spring
(can be used
optionally)
DO NOT USE
Antenna Spring
with 2 Mast Extensions

5VEHICLE SIGNAL BOOSTER DRIVE X OTR
______
Step 2: Mount Outside
Antenna
3-Way
Antenna Mount
Mount disc washer
with lip in the
DOWN position
Fasten nut with lip
in the UP position
mirror rail
or bird perch mount
Side Exit
Adapter
Mast
The cable is strong enough
that it may be shut in most
vehicle doors without
damaging the cable.
These are some typical antenna mounting points. If the vehicle
does not have built-in mounting points, a 3-way mount is
included that will work on vehicles with mirror rails.
Top of Mirror Mirror ArmUpper Side
3-Way Mount
on bird perch

DRIVE X OTR VEHICLE SIGNAL BOOSTER 6
______
Step 3: Mount Inside Antenna
Identify a place to mount the in-vehicle antenna, either on the
side of the seat or on the dash and mount. The location should
be at least 18 inches but no more than 36 inches from where
the cellular device will be used. Use the Velcro® adhesive
strip/adhesive strip provided and attach to
desired location.
In-Vehicle
Antenna
In-Vehicle
Antenna
Velcro®
Velcro®

7VEHICLE SIGNAL BOOSTER DRIVE X OTR
______
Step 4: Connect Coax Cables
To Booster
Connect the cable from the outside antenna to the port labeled
“Outside Antenna” on the Drive X OTR booster.
Connect the cable from the in-vehicle antenna to the port
labeled “Inside Antenna” on the booster.
from Outside Antenna
from Inside Antenna
NOTE: Bracket can be used to fasten booster in a specific location if desired.

DRIVE X OTR VEHICLE SIGNAL BOOSTER 8
______
Step 5: Connect Power
Supply To Booster
Connect the power supply cord to the end of the Drive X OTR
labeled “Power.”
NOTE: Do NOT connect the power to the signal booster until you have
connected both cables from the Inside and outside antennas.
Power Supply

9VEHICLE SIGNAL BOOSTER DRIVE X OTR
Plug the power adapter into vehicle’s 12V DC power supply.
Power up your Drive X OTR by flipping the switch on the
back of the DC power adapter on and and watch your signal
increase!
NOTE: If your Drive X OTR is working correctly, the light on the power adapter
will be red, and the light on the booster will be green.
DC Power Adapter
Power Supply
______
(STEP 5 cont.)

DRIVE X OTR VEHICLE SIGNAL BOOSTER 10
______
Light Patterns
Solid Green
This indicates that your booster is functioning properly and there are no issues with
installation.
Blinking Red, Then Solid Green
This indicates that one or more of the booster bands has reduced power due
to a feedback loop condition called oscillation. This is a built in safety feature
to prevent harmful interference with a nearby cell tower. If you are already
experiencing the desired signal boost, then no further adjustments are necessary.
If you are not experiencing the desired boost in coverage then refer to the
Troubleshooting section below.
Solid Red
This is due to a feedback loop condition called oscillation. This is a built in safety
feature that causes a band to shut off to prevent harmful interference with a nearby
cell tower. Refer to Troubleshooting section below.
Light O
If the Drive X OTR Signal booster’s light is off, verify your power supply has power.
NOTE: The signal booster can be reset by disconnecting and reconnecting
the power supply.
After troubleshooting you must initiate a new power cycle by disconnecting and
then reconnecting power to the booster.
NEED HELP? support.weboost.com 1-866-294-1660

11 VEHICLE SIGNAL BOOSTER DRIVE X OTR
FREQUENTLY ASKED QUESTIONS
What hours can I contact customer support?
Customer Support can be reached Monday thru Friday by calling 1-866-294-1660, or
through our support site at support.weboost.com.
Why do I need to create distance between the booster and the antenna?
Antennas connected to a booster create spheres of signal. When these spheres
overlap, a condition called oscillation occurs. Oscillation can be thought of as noise,
which causes the booster to scale down it’s power or shut down to prevent damage.
The best way to keep these spheres of signal from overlapping is to maximize
separation between the inside and outside antennas.
______
Troubleshooting
FIXING BLINKING OR SOLID RED ISSUES
This section is only applicable if the booster is red or blinking red and you are not
experiencing the desired signal boost.
1
2
3
Unplug the booster’s power supply.
Relocate the inside and outside antenna further from each other. The objective
is to increase the separation distance between them, so that they will not
create this feedback condition discussed before.
Plug power supply back in.
Monitor the indicator light on your booster. If, after a few seconds of ‘power
on’, a solid or blinking red light appears, repeat steps 1 through 3. Increase the
separation distance until the condition is corrected and/or desired coverage
area is achieved. Note: Horizontal separation of the two antennas typically
requires a shorter separation distance than perpendicular separation.
If you are having any diculties while testing or installing your booster, contact
our weBoost Customer Support team for assistance (1-866-294-1660).
4
5

DRIVE X OTR VEHICLE SIGNAL BOOSTER 12
______
Antenna Kit Options
The following accessories are certified by the FCC to be used with the Drive X OTR.
This radio transmitter 4726A-460021 has been approved by innovation, Science and
Economic Development Canada to operate with the antenna types listed below, with the
maximum gain indicated. Antenna types not included in this list that have a gain greater than
the maximum gain indicated for any type listed are strictly prohibited for use with this device.
Outside antenna maximum permissible
antenna gain (dBi) 50
Inside antenna maximum permissible
antenna gain (dBi) 50
4.5 4.2 4.6
4.16 4.16 6.09 6.66 9.77
BAND 12/17 BAND 13 BAND 5 BAND 4 BAND 25/2
3.81 4.74
Ω
50
50
50
50
Antenna Type
Mini-Mag Antenna SMA
OTR Antenna Truck Edition
12” Mag Mount
NMO Vehicle Antenna
Coax Type
LMR-100
LMR195
RG-174
RG-58
Kit #
301126
311229
311125
314405
Ln(ft)
10
15
12.5
14
MOBILE OUTSIDE ANTENNA KIT OPTIONS
Ω
50
Antenna Type
Low Profile In-Vehicle SMA
Coax Type
LMR-100
Kit #
314401
Ln(ft)
10
MOBILE INSIDE ANTENNA KIT OPTIONS

13 VEHICLE SIGNAL BOOSTER DRIVE X OTR
______
Safety Guidelines
Use only the power supply provided in this package. Use of a non-weBoost product may damage
your equipment.
The Signal Booster unit is designed for use in an indoor, temperature-controlled environment
(less than 150 degrees Fahrenheit). It is not intended for use in attics or similar locations subject to
temperatures in excess of that range.
All inside panel and dome antennas must have at least 6’ of separation distance from all active users,
and low profile antennas must have at least 1.5’ separation distance from all active users.
Connecting the Signal Booster directly to the cell phone with use of an adapter will damage the
cell phone.
RF Safety Warning: Any antenna used with this device must be located at least 8 inches from
all persons.
FOR MORE INFORMATION ON REGISTERING YOUR SIGNAL BOOSTER WITH YOUR
WIRELESS PROVIDER, PLEASE SEE BELOW:
T-Mobile/Sprint/MetroPCS: https://www.t-mobile.com/support/coverage/register-a-signal-booster
Verizon Wireless: http://www.verizonwireless.com/wcms/consumer/register-signal-booster.html
AT&T: https://securec45.securewebsession.com/attsignalbooster.com/
U.S. Cellular: http://www.uscellular.com/uscellular/support/fcc-booster-registration.jsp
This is a CONSUMER device.
BEFORE USE, you MUST REGISTER THIS DEVICE with your wireless provider and have your
provider’s consent. Most wireless providers consent to the use of signal boosters. Some providers
may not consent to the use of this device on their network. If you are unsure, contact your
provider.
In Canada, BEFORE USE you must meet all requirements set out in ISED CPC-2-1-05.
You MUST operate this device with approved antennas and cables as specified by the
manufacturer. Antennas MUST be installed at least 20 cm (8 inches) from (i.e., MUST NOT be
installed within 20 cm of) any person.
You MUST cease operating this device immediately if requested by the FCC (or ISED in Canada) or
licensed wireless service provider.
WARNING. E911 location information may not be provided or may be inaccurate for calls served by
using this device.
FOR MORE INFORMATION ON REQUIREMENTS SET OUT IN ISED CPC-2-1-05,
SEE BELOW:
http://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf08942.html

DRIVE X OTR VEHICLE SIGNAL BOOSTER 14
Drive X OTR
Model Number 460021
FCC ID: PWO460021
IC 4726A-460021
Connectors SMA-Female
Antenna Impedance 50 Ohms
Frequency 699-716 MHz, 729-756 MHz, 777-786 MHz, 824-894 MHz, 1850-1995 MHz, 1710-1755 MHz/2110-2155 MHz
Maximum Power
Power output for single cell
phone (Uplink) dBm
700 MHz
Band 12/17
24.84
700 MHz
Band 13
24.35
800 MHz
Band 5
23.4
1700 MHz
Band 4
21.3
1900 MHz
Band 2
24.43
Power output for single cell
phone (Downlink) dBm
700 MHz
Band 12/17
2.87
700 MHz
Band 13
2.79
800 MHz
Band 5
2.8
2100 MHz
Band 4
2.0
1900 MHz
Band 2
1.92
Noise Figure 5 dB nominal
Isolation > 90 dB
Power Requirements 6 V 2 A
______
Specifications
Each Signal Booster is individually tested and factory set to ensure FCC compliance. The Signal Booster cannot be adjusted without
factory reprogramming or disabling the hardware. The Signal Booster will amplify, but not alter incoming and outgoing signals in order
to increase coverage of authorized frequency bands only. If the Signal Booster is not in use for five minutes, it will reduce gain until a
signal is detected. If a detected signal is too high in a frequency band, or if the Signal Booster detects an oscillation, the Signal Booster
will automatically turn the power o on that band. For a detected oscillation the Signal Booster will automatically resume normal
operation after a minimum of 1 minute. After 5 (five) such automatic restarts, any problematic bands are permanently shut o until the
Signal Booster has been manually restarted by momentarily removing power from the Signal Booster. Noise power, gain, and linearity
are maintained by the Signal Booster’s microprocessor.
The term “IC” before the radio certification number only signifies that Industry Canada technical specifications were met. This device
complies with Part 15 of FCC rules. This device contains licence-exempt transmitter(s)/receiver(s that comply with Innovation, Science
and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions: (1) This device may
not cause interference, and (2)) This device must accept any interference, including interference that may cause undesired operation of
the device. Changes or modifications not expressly approved by weBoost could void the authority to operate this equipment.

15 VEHICLE SIGNAL BOOSTER DRIVE X OTR
2 YEAR WARRANTY
weBoost Signal Boosters are warranted for two (2) years against defects in
workmanship and/or materials. Warranty cases may be resolved by returning the
product directly to the reseller with a dated proof of purchase.
Signal Boosters may also be returned directly to the manufacturer at the
consumer’s expense, with a dated proof of purchase and a Returned Material
Authorization (RMA) number supplied by weoost. weBoost shall, at its option,
either repair or replace the product.
This warranty does not apply to any Signal Boosters determined by weBoost
to have been subjected to misuse, abuse, neglect, or mishandling that alters or
damages physical or electronic properties.
Replacement products may include refurbished weBoost products that have been
recertified to conform with product specifications.
RMA numbers may be obtained by contacting Customer Support
DISCLAIMER: The information provided by weBoost is believed to be complete
and accurate. However, no responsibility is assumed by weBoost for any business
or personal losses arising from its use, or for any infringements of patents or other
rights of third parties that may result from its use.
NEED HELP? support.weboost.com 1-866-294-1660

DRIVE X OTR VEHICLE SIGNAL BOOSTER 16
Notes
NEED HELP? support.weboost.com 1-866-294-1660

3301 East Deseret Drive, St. George, UT
1.866.294.1660 www.weboost.com support.weboost.com
Copyright © 2017 weBoost. All rights reserved.
weBoost products covered by U.S. patent(s) and pending application(s)
For patents go to: weboost.com/us/patents or weboost.ca/patents
NOT AFFILIATED WITH WILSON ANTENNA GDE000468_Rev01_03.14.22
