WilTec TeichTip Sunsun CMP-28000 User manual

Operation Manual
SunSun CMP-28000 High-performance Pond Pump
52022
Illustration similar, may vary depending on model
Read and follow the operating instructions and safety information before using for the first time.
Technical changes reserved!
Due to further developments, illustrations, functioning steps and technical data can differ insignificantly.
Updating the documentation
If you have suggestions for improvement or have found any irregularities, please contact us.

© by WilTec Wildanger Technik GmbH Item 52022 Page 2
http://www.WilTec.de
http://www.aoyue.eu 09 2021-1
http://www.teichtip.de
The information contained in this document may alter at any time without previous notice. It is prohibited
to copy or spread any parts of this document in any way without prior written allowance. All rights re-
served.
The WilTec Wildanger Technik GmbH cannot be held accountable for any possible mistakes in this
operating manual, nor in the diagrams and figures shown.
Even though, the WilTec Wildanger Technik GmbH has undergone biggest possible efforts to ensure
that the operating manual is complete, faultless and up to date, mistakes cannot be entirely avoided.
If you should find a mistake or wish to make a suggestion for improvement, we look forward to hearing
from you.
Send an e-mail to:
[email protected]
or use our contact form:
https://www.wiltec.de/contacts/
The most recent version of this manual in various languages can be found in our online shop via:
https://www.wiltec.de/docsearch
Our postal address is:
WilTec Wildanger Technik GmbH
Königsbenden 12
52249 Eschweiler
Germany
Do you wish to pick goods up? Our pick-up address is:
WilTec Wildanger Technik GmbH
Königsbenden 28
52249 Eschweiler
Germany
To shorten the waiting time and allow for a rapid on-site transaction, we ask you to call us previously or
placing your order via the webshop.
E-mail: [e-mail]
Tel:[phone]
Fax: [phone]
To return orders for exchange, repair or for other purposes, please use the following address. Attention!
To allow for a smooth execution of your complaint or return, it is important to contact our customer
service team before returning the goods.
Returns Department
WilTec Wildanger Technik GmbH
Königsbenden 28
52249 Eschweiler
E-mail: [email protected]o
Tel:[phone]
Fax: [phone]

© by WilTec Wildanger Technik GmbH Item 52022 Page 3
http://www.WilTec.de
http://www.aoyue.eu 09 2021-1
http://www.teichtip.de
Introduction
Thank you for purchasing this quality product. To minimize the risk of injury we urge that our clients
take some basic safety precautions when using this device. Please read the operation instruc-
tions carefully and make sure you have understood its content.
Keep these operation instructions safe.
Safety guidelines
Beware
•The use of this device is only allowed in standing water bodies, garden ponds or swimming
ponds and their surrounding areas with a fault current protection-switch with a triggering nominal
current up to 30 mA (according to VDE 0100 Article 702 and 738).
•The device is not suitable for use in swimming pools, paddling pools and other water bodies,
where people might be during operation. Operating the device while people are within the dan-
ger zone is not allowed. Ask your electrician!
•The device is not intended for use by people (including children) with impaired or limited physi-
cal, sensory and mental abilities or lack of experience and/or knowledge, unless they are su-
pervised by a person responsible for their safety or follow the instructions stated by this person
on how to use the device correctly.
•Children should be supervised to make sure that they do not play with the device.
Attention!
•Run a visual inspection of the device before every use. Do not use the device if the safety
appliances are damaged or worn out. Never override safety regulations.
•Use the device exclusively according to the intended purpose stated in these instructions.
•You are responsible for the safety of the working environment.
•If the cable or the plug is damaged due to external influences the cable must not be repaired! It
has to be replaced with a new one. This work may only be carried out by an electrician.
•The voltage indicated on the type label of the device of 230 V AC has to correspond to the
existent mains voltage.
•Never lift, carry, or fix the device by its power cable.
•Make sure that the electrical plug connection is protected from flood and moisture.
•Before working on the pond pump, disconnect the appliance by taking the plug out of the socket.
•Avoid exposing the appliance to a direct water jet or rain.
•The user is responsible for the compliance with local specific safety and installing regulations.
(Ask an electrician.)
•Damage arising from flooded rooms caused by dysfunctions of the appliance must be avoided
by means of the appropriate measures (e.g., by installing an alarm system, a reserve pump).
•In case of malfunction, the repair work can only be carried out by a qualified electrician.
•The appliance must not run dry or with a completely closed intake line. The manufacturer’s
warranty is no longer valid if the damage is caused by dry running.
•The appliance must not be used for swimming pools.
•The device cannot be employed for potable water circuits.
Note! In the event of an overload (e.g., if the impeller jams), the internal thermal protection automatically
switches off the pump. After disconnecting and reconnecting the power supply, the pump can be re-
started.
Warning! Read all safety notes and the instructions thoroughly. Non-compliance with the safety rules
and regulations can lead to an electric shock, fire and/ or serious injury. Keep the instructions and the
safety notes in a safe place for future reference.

© by WilTec Wildanger Technik GmbH Item 52022 Page 4
http://www.WilTec.de
http://www.aoyue.eu 09 2021-1
http://www.teichtip.de
Applications
•You can pump pond water with a temperature of +4 ℃to +35 ℃.
•The pump can be used in the following places:
1. Filtration systems in garden ponds
2. Aquaculture of seafood
3. Operation of a waterfall
4. Implementation in garden ponds and koi ponds or fish ponds
Features
1. High flow rate, low energy consumption, energy saving and environmental protection.
2. Stable and quiet operation, excellent performance and long service life.
3. With built-in heat protection.
4. High quality ceramic shaft core and ceramic sleeve provides higher wear resistance.
5. Ergonomic handle for easy transport.
6. Outlet can be adjusted in three angles of 0°, 90° and 180° to meet different requirements (as
shown in the picture).

© by WilTec Wildanger Technik GmbH Item 52022 Page 5
http://www.WilTec.de
http://www.aoyue.eu 09 2021-1
http://www.teichtip.de
Commissioning
1. Read and understand the safety instructions before operating the unit.
2. Pass a rope through the handle and secure it to pull the pump out of the water if necessary.
3. Make the necessary hose connections (if required) or install a fountain attachment. After instal-
lation, make sure that there are no air bubbles in the hose system (lay hose lines at an angle).
4. Install the pump horizontally on a firm base and at least 20 cm below the water surface. Observe
the maximum permissible immersion depth.
5. Do not place the pump directly in the mud of the pond bottom, but on a raised surface.
6. Lay the mains cable in a protected location to avoid the possibility of damage.
7. Connect the mains plug of the pump to the mains.
Important notes!
•Never operate the pump without the filter basket. The filter basket protects the pump from coarse
dirt that can lead to clogging of the pump.
•Never operate the pump without water, otherwise the pump bearing will be destroyed.
Additional installation notes
The indicated capacities are always measured directly at the pump outlet (without hose connection and
accessories). To achieve the highest possible pump performance, hose connections should be kept as
short as possible. Bends, elbows and other connecting elements should be kept to a minimum as they
reduce the pump performance.
Maintenance and cleaning
•Clean the filter housing with a soft brush under running water every month or when the pump
output is reduced.
•In case of frequent use, the pump should also be cleaned regularly.
Technical data
Model
CMP-28000
Energy supply
220–240 / 50
Power (W)
580
Max. immersion depth (m)
7.5
Flow rate (ℓ⁄h)
28.000
Outlet (㎜)
38 / 50
Cable length (m)
10
Dimensions (㎜)
360 × 159 x 248

© by WilTec Wildanger Technik GmbH Item 52022 Page 6
http://www.WilTec.de
http://www.aoyue.eu 09 2021-1
http://www.teichtip.de
Exploded view and parts list
№
Name
№
Name
1
Filter basket
7
Rubber pads
2
Screw
8
Handle
3
Impeller Chamber
9
Gasket
4
Impeller
10
38 mm (1½″) outlet
5
O-Ring
11
50 mm (2″) outlet
6
Motor
12
Outlet fixing nut
Winter care
1. Remove the pump from the water.
2. Clean the pump thoroughly.
3. Check the pump for damage.
4. Store the pump frost-free, if possible, in a container with water.
Caution! The connection plug must not be immersed.
Troubleshooting
Malfunction
Possible cause
Possible solution
Pump does not turn on
There is no power
Check electrical circuit.
Pump does not displace water
1. Filter basket blocked
1. Clean filter basket.
2. Impeller blocked
2. Clean pump.
Insufficient water displace-
ment
1. Filter basket is blocked
1. Clean filter basket.
2. Excessive loss in the supply
lines
2. Reduce hose lengths to the
minimum required, do not use
unnecessary connecting parts.
The pump turns off after run-
ning for a short time
1. Water temperature too high
1. Ensure that the water temper-
ature does not exceed +35 ℃.
2.Impeller stuck
2. Unplug and plug the power
supply of the pump.

© by WilTec Wildanger Technik GmbH Item 52022 Page 7
http://www.WilTec.de
http://www.aoyue.eu 09 2021-1
http://www.teichtip.de

© by WilTec Wildanger Technik GmbH Item 52022 Page 8
http://www.WilTec.de
http://www.aoyue.eu 09 2021-1
http://www.teichtip.de
Disposal regulations
EU guidelines regarding the disposal of scrap electric appliances (WEEE, 2012/19/EU) were imple-
mented in the law related to electrical and electronic equipment and appliances.
All WilTec electric devices that fall under the WEEE regulations are labelled with the crossed-out
wheeled waste bin logo. This logo indicates that this electric equipment must not be disposed with the
domestic waste.
The company WilTec Technik GmbH has been registered in the German registry EAR under the WEEE-
registration number DE45283704.
Disposal of used electrical and electronic appliances
(intended for use in the countries of the European Un-
ion and other European countries with a separate col-
lection system for these appliances).
The logo on the article or on its packaging points out
that this article must not be treated as normal house-
hold waste but must be disposed to a recycling collec-
tion point for electronic and electrical waste equipment.
By contributing to the correct disposal of this article you
protect the environment and the health of your fellow
men. Environment and health are threatened by inap-
propriate disposal.
Material recycling helps reduce the consumption of raw materials.
Additional information on recycling this article can be provided by your local community, municipal waste
disposal facilities or the store where you purchased the article.
