WindowMaster MotorController WCC 310 Service manual

UK
[phone]
[email protected]
Other markets
[phone]
[email protected]
www.windowmaster.com
WCC 3xx STANDARD install 1711-Firmware v122 - UK ©WindowMaster 2016, 2017 ®WindowMaster is a registred trademark used under the license by WindowMaster International A/S
WindowMaster International A/S, Skelstedet 13, DK-2950 Vedbæk
WCC 310 & WCC 320
Standard versions
Installation instruction
MotorController
(Version 1711 –for firmware from version 1.22 (motorline card))
Save this installation instruction to the end user

2
1Safety information........................................................................................................................................................3
1.1 Safety................................................................................................................................................................ 3
1.2 230V AC............................................................................................................................................................ 3
1.3 Application......................................................................................................................................................... 3
1.4 Cable routing and electrical connection............................................................................................................. 3
2Structure of the MotorController ................................................................................................................................4
3Variants of MotorControllers.......................................................................................................................................4
3.1 MotorController versions................................................................................................................................... 5
3.2 Max numbers of actuators per motor line and MotorContoller ................................................................................ 5
4Accessories and spare parts ......................................................................................................................................6
5Technical data..............................................................................................................................................................7
6Mounting.......................................................................................................................................................................7
7Installation....................................................................................................................................................................8
7.1 Cable routing..................................................................................................................................................... 8
7.2 Cables into housing........................................................................................................................................... 8
7.3 Connection of safety earth wire and 230V AC................................................................................................... 8
7.4 Installation of the ventilation keypad.................................................................................................................. 8
7.5 Assembly instructions........................................................................................................................................ 8
8Cable dimensioning.....................................................................................................................................................9
8.1 Max. cable Length............................................................................................................................................. 9
8.1.1 Formula for the calculation of the maximum actuator cable length ...............................................................9
8.1.2 Max cable length –±24V standard actuators ................................................................................................9
8.1.3 Max cable length –actuators with MotorLink®...............................................................................................9
9Cable plan for connection to WCC 310 / 320 Standard version.............................................................................11
10 Description of cards and mains connection............................................................................................................12
10.1 WCC connection to mains and power supply units –WCA 3P3, WCA 3P5 and WCA 3P6 .............................12
10.2 Motor line card WCA 3M4 and WCA 3M8........................................................................................................13
10.3 Input card –WCA 3KI.......................................................................................................................................15
10.4 Power supply card –WCA 3P6........................................................................................................................17
11 Configuration of the MotorController.......................................................................................................................17
12 Fault detection via LED..............................................................................................................................................17
12.1 Fault detection on the MotorController.............................................................................................................17
13 Hardware error ...........................................................................................................................................................18
14 Commissioning and test run.....................................................................................................................................18
14.1 The MotorController is completely installed, without the operating voltage applied .........................................18
14.2 With mains voltage...........................................................................................................................................18
14.3 Ventilation keypad............................................................................................................................................18
14.4 Wind/rain detector............................................................................................................................................18
15 Maintenance ...............................................................................................................................................................19
15.1 Maintenance agreements.................................................................................................................................19
15.2 Replacement 3M4, 3M8 and 3KI card..............................................................................................................19
16 Declaration of Conformity.........................................................................................................................................19

3
1 Safety information
1.1 Safety
Only allow correspondingly trained, qualified and skilled personnel to carry out installation work.
Reliable operation and the avoidance of damage and hazards are only guaranteed if installation and settings are carried out
carefully in accordance with these instructions.
There may be personal danger by electrically operated windows:
- the forces occurring in the automatic mode can be such that parts of the body could get crushed
- when opened, actuators (spindles) could protrude into the room
For this reason, measures have to be taken prior to starting up the actuators, which exclude the danger of injury.
For safety reasons we recommend to install opening restrictors on bottom-hung windows.
In the event that windows are subjected to rain and/or high wind loads, we recommend connecting a wind/rain sensor to the
MotorController for the automatically closing of the windows.
The MotorController is to be located in a safe place, protected from the effects of fire and smoke.
The MotorController is to be surface mounted.
The MotorController is to be supplied with 230V AC.
The manufacturer does not assume any liability for possible damage resulting from inappropriate use.
1.2 230V AC
230V AC can cause death, severe injury or considerable damage to assets.
The connection of the MotorController is reserved for qualified personnel.
Disconnect all poles of the MotorController from the supply voltage prior to opening, installation or assembling.
Installation and use according to the national regulations.
1.3 Application
The MotorController is exclusively designed for the automatic opening and closing of windows, flaps or doors.
Always check that your system meets the valid national regulations.
Pay particular attention to the opening cross section, the opening time and opening speed.
The cable cross sections depend on the cable length and current consumption (amperage).
1.4 Cable routing and electrical connection
Fuse the 230V AC power supply cable separately on site.
Cable routing and connection - adhere to national regulations.
Establish the cable types, if necessary, with the local approval bodies.
Do not conceal flexible cables.
Junction box must be accessible for maintenance purposes.
Disconnect all poles of the mains voltage prior to starting maintenance work or making changes to the system.
Secure the system to prevent unintentional switching on again.
Route all low voltage cables (24V DC) separate from the power current cables.
Design cable types, lengths and cross sections in accordance with the technical information.
Cable specifications is a guide only, the overall responsibility resides with the electrical contractor on site.
Installation must be in accordance with the national electrical regulations.

4
2 Structure of the MotorController
Sizes & Versions
The WCC 310 and WCC 320 MotorControllers are available in two different versions namely a Standard and a Plus version.
This installation instruction only deals with the Standard versions. Please see separate installation instruction for the Plus
versions of WCC 310 and WCC 320.
Cards
Each MotorController contains a power supply unit (SMPS), either a WCA 3P3 or a WCA 3P5 for the 10A or 20A version
respectively, as well as a 5W auxiliary power supply for wind / rain sensor. Aside from the power supply units the Standard
version also includes a motorline card type WCA 3M4 or WCA 3M8 with 4 and 8 motor lines respectively and an input card
WCA 3KI with 10 inputs. Additionally, the Standard version is also available in a version with fieldbus interface for KNX.
If additional motor lines, inputs or fieldbus connection is required a Plus version of the MotorController is necessary.
Motor groups and motor lines
A motor group consists of one or more motor lines and all the motor lines are operated simultaneously.
All motor lines on the motor cards (WCA 3M4 & WCA 3M8) can be configured for either a ±24V standard actuators or
MotorLink®actuators. A motor group can contain motor lines with both ±24V standard actuators and MotorLink®actuators,
whereas a motor line only can have ±24V standard or MotorLink®actuators connected.
3 Variants of MotorControllers
Item composing
WCC 3
xx
x
xx
xx
xxx
01
01 = Product version number
Fieldbus card
” ” = No fieldbus card
KNX = Fieldbus card with interface to KNX
Input card
10 = Input card with 10 inputs
Motorline card
04 = Motor line card with 4 motor lines
08 = Motor line card with 8 motor lines
MotorController version
S = Standard
P = Plus
MotorController size
10 = 10A
20 = 20A
MotorController series 3

5
3.1 MotorController versions
Number of motor lines and other functions
Cards
Item number
WCC 310 versions
Standard version
4 motor lines
10 keypads / inputs
1 x WCA 3M4
1 x WCA 3KI
WCC 310 S 0410 01
Standard version
4 motor lines
10 keypads / inputs
KNX interface
1 x WCA 3M4
1 x WCA 3KI
1 x WCA 3FK
WCC 310 S 0410 KNX 01
WCC 320 versions
Standard version
8 motor lines
10 keypads / inputs
1 x WCA 3M8
1 x WCA 3KI
WCC 320 S 0810 01
Standard version
8 motor lines
10 keypads / inputs
KNX interface
1 x WCA 3M8
1 x WCA 3KI
1 x WCA 3FK
WCC 320 S 0810 KNX 01
3.2 Max numbers of actuators per motor line and MotorContoller
The table shows the maximum number of actuators, which can be connected per motor line and MotorController depending on the
type of the actuators, MotorController and connected cards. The total power consumption of all the connected actuators must not
exceed 10A or 20A depending on MotorController size.
Per motorline
Per 10A MotorController
Per 20A MotorController
± 24V
Actuators
MotorLink®
Actuators
± 24V
Actuators
MotorLink®
Actuators
(4 Motorlines)
± 24V
Actuators
MotorLink®
Actuators
(8 Motorlines)
WMS 306-1
10
4
10
10
20
20
WMS 306-2
10
2
10
8
20
16
WMS 306-3
9
3
9
9
18
18
WMS 306-4
8
4
8
8
20
20
WMS 309-1
10
4
10
10
20
20
WMS 309-2
10
2
10
8
20
16
WMS 309-3
9
3
9
9
18
18
WMS 309-4
8
4
8
8
20
20
WMS 409 xxxx 01
5
0
5
0
10
0
WMS 409-1
5
4
5
5
10
10
WMS 409-2
4
2
4
4
10
10
WMS 409-3
3
3
3
3
9
9
WMS 409-4
4
4
4
4
8
8
WMS 515
2
0
2
0
4
0
WMU 836-1
10
4
10
10
20
20
WMU 836-2
10
2
10
8
20
16
WMU 836-3
9
3
9
9
18
18
WMU 836-4
8
4
8
8
20
20
WMU 861-1
6
4
6
6
12
12
WMU 861-2
6
2
6
6
12
12
WMU 861-3
6
3
6
6
12
12
WMU 861-4
4
4
4
4
12
12
WMU 842 / 862 / 882-1
4
4
4
4
8
8
WMU 842 / 862 / 882-2
4
2
4
4
8
8
WMU 842 / 862 / 882-3
3
3
3
3
6
6
WMU 842 / 862 / 882-4
4
4
4
4
8
8
WMU 863 / 883-1
3
3
3
3
6
6
WMU 863 / 883-2
2
2
2
2
6
6

6
Per motor line
Per 10A MotorController
Per 20A MotorController
± 24V
Actuators
MotorLink®
Actuators
± 24V
Actuators
MotorLink®
Actuators
(4 Motor lines)
± 24V
Actuators
MotorLink®
Actuators
(8 Motor lines)
WMU 863 / 883-3
3
3
3
3
6
6
WMU 863 / 883-4
0
0
0
0
0
0
WMU 864 / 884-1
2
2
2
2
4
4
WMU 864 / 884-2
2
2
2
2
4
4
WMU 864 / 884-3
0
0
0
0
0
0
WMU 864 / 884-4
0
0
0
0
0
0
WMU 885 / 895-1
2
2
2
2
4
4
WMU 885 / 895-2
2
2
2
2
4
4
WMU 885 / 895-3
0
0
0
0
0
0
WMU 885 / 895-4
0
0
0
0
0
0
WMX 503 / 504 / 523 / 526-1
20
4
20
16
40
32
WMX 503 / 504 / 523 / 526-2
20
2
20
8
40
16
WMX 503 / 504 / 523 / 526-3
18
3
18
12
39
24
WMX 503 / 504 / 523 / 526-4
20
4
20
16
40
32
WMX 803 / 804 / 823 / 826-1
10
4
10
10
20
20
WMX 803 / 804 / 823 / 826-2
10
2
10
8
20
16
WMX 803 / 804 / 823 / 826-3
9
3
9
9
18
18
WMX 803 / 804 / 823 / 826-4
8
4
8
8
20
20
WML 820/825
10
0
10
0
20
0
WML 860-1
10
4
10
10
20
20
WML 860-2
10
2
10
8
20
16
WML 860-3
9
3
9
9
18
18
WML 860-4
8
4
8
8
20
20
WMB 801/802*
max. 4A connected to WMB
WMB 811/812 */**
10
2
10
8
20
16
* Do not exceed the total power consumption of the motor line
** When having two locking actuators per motor line, it must be one of each type: 1 x WMB 811 and 1 x WMB 812
4 Accessories and spare parts
Accessories
Rain sensor
WLA 331
Rain/wind speed sensor
WLA 330
Spare parts
10A power supply unit for WCC 310
WCA 3P3
20A power supply unit for WCC 320
WCA 3P5
5W 230 AC / 24V DC –24V AUX supply for sensors
WCA 3P6
Motor line card with 4 motor lines incl cover
WCA 3M4
Motor line card with 8 motor lines incl cover
WCA 3M8
Input card with 10 inputs for e.g. comfort keypad incl. cover
WCA 3KI

7
5 Technical data
Technical data
Output current (nominal)
WCC 310: 10A / WCC 320: 20A
Secondary voltage
Voltage 24V DC (±15%)
Open circuit voltage (no load) 27.6V DC @ 20°C
Ripple at max load max. 6% (3.5Vpp)
AUX
24V DC, 0.23A
Motor lines
WCC 310 0410: max 4, WCC 320 0810: max 8
a line can be either ±24V standard motor line or MotorLink®motor lines
Primary voltage
230V AC, 50Hz (85-264V AC, 47-63Hz)
Power consumption
Idle consumption:
WCC 310: min 1,1W1, typ. 3W2
WCC 320: min 1,1W1, typ. 3,5W3
1) min.: 1 actuator
2) typ.: 16 MotorLink®actuators + rain sensor
3) typ.: 32 MotorLink®actuators + rain sensor
Max:
WCC 310: At max load 305W
WCC 320: At max load 605W
Inrush current on primary site
70A<5ms. Max 3 x WCC 310/320 per 10 A supply group.
Circuit breaker “C” characteristic.
±24V change over time
min 500ms
LED message OK and fault
Green (flickering)
Yellow
CPU working
fault
Connection cable
Actuators
Other components
flexible max 6 mm² / solide max 10 mm²
min 0,2mm² / max 1,5mm²
Operating conditions
-5°C - +45°C, for indoor installation, the MotorController may not be covered
Max actuator activation duration (duty
cycle)
ED 40% (4min. per 10min.)
Number of motor lines
WCC 310: 4 x 10A motor line for ±24V standard or MotorLink®motors
WCC 320: 8 x 10A motor line for ±24V standard or MotorLink®motors
Material
Metal housing for surface mounting
Colour
White (RAL 9010)
Size
355 x 320 x 76 mm (WxHxD)
Weight
WCC 310: 4kg
WCC 320: 4.8kg
Protection class
IP 20
Delivery
MotorController
Note
We reserve the right to make technical changes
6 Mounting
The MotorController is fixed to the wall through the Ø6mm holes in the back plane
of the housing.
The MotorController is to be located in a safe place, protected from the effects of fire
and smoke.
With reference to the machinery directive EN 60204-1, the MotorController has to be
placed where it is only accessible to authorized persons and mounted where there is
no particular regard for dust and moisture.

8
7 Installation
7.1 Cable routing
See also chapter 8 “Cable dimensioning” in this instruction. Do not reduce the
cable cross sections specified in the cable lengths table.
All cables of the control (except the mains supply cable) carry 24V DC and
have to be routed separate from the mains supply cable.
Adhere to the pertinent national and local regulations when routing the cables.
Ensure that the mains cable can be switched via an external or customer-
supplied two-pole switch element or a switch element controlling all poles –
see drawing.
7.2 Cables into housing
All connection terminals (except the mains terminals) are of the plug-in type.
Connect the connection cables in accordance with the terminal plan. Ensure that the connections are made correctly.
Incorrect cable clamping, mixing up numbers or colours could lead to malfunctions of the control MotorController or of the
external components.
Ensure that the electrical cables are always routed according to the valid national and local regulations.
7.3 Connection of safety earth wire and 230V AC
See chapter 10 ‘Description of cards’, for further description.
7.4 Installation of the ventilation keypad
Ensure that the ventilation buttons are visible and well accessible. Do not install behind protruding walls, door panels or hidden
by the building structure
7.5 Assembly instructions
Always have assembly, installation, repair and maintenance of ventilation systems carried out by qualified personnel
trained for this purpose.
Rules to be adhered to for setting up and installation
The following safety relevant rules have to be adhered to when planning the use of a ventilation system and its set-up and
installation:
•The Provincial Building Ordinance of the provinces
Accident prevention regulations
Adhere to the general accident prevention regulations (APR), the APR for power operated windows and doors, and the
installation rules in your country.
CAUTION:
Live components are directly accessible after opening the system housing.
Prior to inserting / removing cards disconnect to the MotorController from the mains supply.
•adhere to the installation instructions and your local energy providers
•select the place of installation such that free access is guaranteed for maintenance purposes
•select cables according to regulations in this instruction - take the calculation of the actuator supply cable lengths
into account when laying the cables
•connect the cables in accordance with the drawings provided by the manufacturer
•route the cables in the building according to the regulations in this instruction
•check all system functions

9
8 Cable dimensioning
8.1 Max. cable Length
Maximum permissible cable length from the MotorController to the actuators taking into account the cable cross-section is
shown in the following tables for “± 24V standard actuators“and “MotorLink®actuators“.
8.1.1 Formula for the calculation of the maximum actuator cable length
Max. cable length = permissible voltage drop 2V (UL) x conductivity of copper(56) x cable cross section in mm2(a)
max. actuator current total in amps (I) x 2
For both ±24V standard actuators and actuators with MotorLink® the cross section of the cable must not be less than 0.75mm2
regardless of the result of above formula.
Maximum actuator cable length: Always measured from the MotorController to the last junction box + cable to the motor
Permissible max. voltage drop in the line: 2 Volt
Actuating current: Sum of all actuator power consumption per motor line
Note: do not use the PE wire / green/yellow wire in the motor cable for communication!
Example
Max actuator cable length with cable cross section 0.75mm2and actuator current 2A: (2 x 56 x 0.75) : (2 x 2) = 21m
8.1.2 Max cable length –±24V standard actuators
The actuator supply cable must have 2 wires. If cable monitoring is requested min. 3: 2 wires current carrying / 1 wire for
monitoring.
±24V standard Actuators
Do not use the PE wire / green/yellow wire!
cable cross
section [a]
Total
actuator current [I]
3 wire
0,75mm²
3 wire
1,50 mm²
5 wire
1,50 mm²
2 wire
parallel
3 wire
2,50 mm²
5 wire
2,50 mm²
2 wire
parallel
3 wire
4,00 mm²
1A
42m
84m
168m
140m
280m
224m
2A
21m
42m
84m
70m
140m
112m
3A
14m
28m
56m
47m
93m
75m
4A
11m
21m
42m
35m
70m
56m
5A
8m
17m
34m
28m
56m
45m
6A
7m
14m
28m
23m
47m
37m
7A
6m
12m
24m
20m
40m
32m
8A
5m
11m
21m
18m
35m
28m
9A
9m
18m
15m
31m
25m
10A
8m
16m
14m
28m
22m
20A
4m
8m
7m
14m
11m
8.1.3 Max cable length –actuators with MotorLink®
The actuator supply cable must have 3 wires: 2 wires current carrying / 1 wire for communication.
When a 5 wire cable is used for MotorLink®
It is not recommended to use parallel-wire.
ML-comm = MotorLink®communication

10
When using actuators with MotorLink®the max cable length is 50m regardless of the result of the above mentions formula.
Actuators with MotorLink®
Do not use the PE wire / green/yellow wire!
cable cross
section [a]
Total
actuator current [I]
3 wire
0,75mm²
3 wire
1,50 mm²
5 wire
1,50 mm²
2 wire
parallel
3 wire
2,50
mm²
5 wire
2,50 mm²
2 wire
parallel
3 wire
4,00 mm²
1A
42m
50m
2A
21m
40m
50m
3A
14m
28m
50m
47m
50m
4A
11m
21m
42m
35m
5A
8m
17m
34m
28m
50m
45m
6A
7m
14m
28m
23m
47m
37m
7A
6m
12m
24m
20m
40m
32m
8A
5m
11m
21m
18m
35m
28m
9A
9m
18m
15m
31m
25m
10A
8m
16m
14m
28m
22m
20A
4m
8m
7m
14m
11m

11
9 Cable plan for connection to WCC 310 / 320 Standard version
Above connection plan shows a WCC 320 MotorController

12
10 Description of cards and mains connection
Each MotorController includes a main power supply unit (SMPS), an auxiliary power supply (AUX), a motor line card and an
input card.
The size of the power supply unit determines the number and/or types of actuators, which can be connected to the
MotorController. See table with overview of max number of allowed actuators per motor line/ MotorController (chapter 3.2).
10.1 WCC connection to mains and power supply units –WCA 3P3, WCA 3P5
and WCA 3P6
The MotorController WCC 310, is supplied with a 305W SMPS power supply –WCA 3P3.
The MotorController WCC 320, is supplied with a 605W SMPS power supply –WCA 3P5
The power supply is, regardless of size, placed in the bottom of the MotorController beneath the motor line and input card.
An AUX –WCA 3P6 –to which mains is connected, is located to the right of the power supply.
Outlet to mains is in the top of the MotorController.
The MotorController is grounded by means of protective earth via the green screw next to WCA 3P6.

13
10.2 Motor line card WCA 3M4 and WCA 3M8
The motor line cards WCA 3M4 and
WCA 3M8, allows connection of 4
and 8 motor lines respectively either
±24V standard or MotorLink®.
WCA 3M8 –motor line card with 8 motorline
S2
X1 –X8
WCA 3M4 and WCA 3M8 has 4 and 8 motor lines respectively for connection of either ±24V standard or
MotorLink®actuators.
±24V standard actuators
x.1 24V / 0V
x.2
x.3 0V / 24V
MotorLink®actuator
x.1 0V
x.2 ML Communication
x.3 24V
The number of actuators per motor line depends on the actuator type, the total power consumption of actuators
connected to a motor line can max be 10A and the total max power consumption for both motor lines must not
exceed 10A or 20A depending on type of MotorController.
Besides actuators also locking actuators (espagnolettes actuators) type WMB 801/802 and WMB 811/812 can
be connected. The power consumption of the locking actuators are not to be included in the 10A / 20A as
actuators and locking actuators do not run at the same time.
All actuators on the same motor line will run/be operated simultaneously.
All actuators on the same motor line must be of the same type.
Connection / cable diameter: flexible max 6 mm² / solid max 10 mm².
Cable length: see the chapter "Cable dimensioning".

14
Standard ±24V actuators
Examples with 20A power
consumption
a) 20 pcs. WMX 826-1
b) 10 sets of 2 pcs. WMX 826-2
c) 4 pcs. WMU 885-1
d) 2 sets of 2 pcs. WMU 885-2
Connection of variants of standard actuators on motor line X1
MotorLink®actuators
Examples with actuators per
motor line
Ex. 1: 4 pcs. WMX 823-1
Ex. 2: 2 pcs. WMX 885-2
Ex. 3: 3 pcs. WMU 826-3
Allowed actuator combinations on a MotorLink®motor line
The eight motor lines on the motorline card can each be connected to one of the below shown combinations.
-1 (single): one window with one single window
actuator. Up to four windows each with one
single window actuator can be connected
-2 (double): one window with two double window
actuators.
-3 (triple): one window with three triple window
actuators.
-4 (quad): one window with four quad window
actuators.
Cable monitoring
When using actuators with MotorLink®, the actuators with MotorLink®are monitored by data communication.
When the team-size does not match, an error is indicated on the yellow diode.
J4
Connection for power supply
J6
Connection to input card WCA 3KI
J7
Connection to power supply

15
R / P
Reset / Programming (used for firmware updates)
LED
Shows the status of the MotorController
Yellow = fault
Green fast flickering = CPU working, Green constant = CPU communication stopped (possible reset or contact
WindowMaster)
10.3 Input card –WCA 3KI
The input card allows connection of
10 keypads.
The WCA 3KI is connected to WCA
3M4 / WCA 3M8 via cabel (J1 on
WCA 3KI and J6 på WCA 3M4 /
WCA 3M8).
S3
X1 –X8
For connection of comfort keypads.
For WCC 310 0410 with only 4 motorlines input X5-X8 have no function.
With the default values are input:
”Active” if the contact resistance is smaller than 2kΩ
”Inactive” if the contact resistance is bigger than 3kΩ.
Input has pull up current of approx. 0.8mA. (min 0.7mA, max 1mA )
Example: comfort keypad connected to input X3
Long push (>500ms): open / close actuator, the actuator runs to end stop
Short push: the actuator stops running
Data
x.1 Open x.1
x.2 Close x.2
x.3 GND / 0V
Open circuit (simplified)

16
S3
X9
Connection of wind / rain sensors type WLA 330 or rain sensor WLA 331.
Wind / rain sensor is connected to both WCA 3KI and WCA 3P6 on X9 and X2 respectively.
Data
9.1 close all / safety (all motor groups)
9.2 Momentary action / maintained action
9.3 GND / 0V
Momentary action: the actuator only runs for as long as the keypad is activated.
Maintained action: the keypad is activated shortly and the actuator runs until the
keypad is re-activated.
With the default values are input:
”Active” if the contact resistance is smaller than 4kΩ
”Inactive” if the contact resistance is bigger than 8kΩ.
For values between 4 and 8kΩ the result will depend on the supply voltage.
Input has pull up approx. 1mA. (min 0.7mA, max 1.4mA)
Connection of wind/rain and rain sensors
WLA 330 and WLA 331–the settings of the sensors are set on the sensor.
DIP switch 1-3 on WLA 330 must be set for wind speed tolerances. Please refer to the installation instruction for
WLA 330 for DIP switch settings.
If no wind / rain or rain sensor is connected to S3X9, a 10kΩresistor must be connected between S3X9.1 and
S3X9.3.
S3
X10
Data:
10.1 Open all
10.2 Close all
10.3 GND / 0V
X10.1 and X10.2 has lower priority than the individual inputs X1-X8.
X10.1 and X10.2 us blocked for a period of 30min after X1-X8 has received a command.
↓ ↑
Close / open all windows. When pressed together right after power has been connected the MotorController
configures / registers connected components.
J1
Connection for power supply
Input circuit (simplified)

17
10.4 Power supply card –WCA 3P6
Mains and protective earth is connected
to the MotorController via the power
supply card.
On the standard version of the
MotorController the power supply card
enables connection of weather station or
other sensor.
S4 X1
Connection to mains.
S4 X2
Connection to e.g. weather station. See ”S3 X9” under ”Input car – WCA 3KI” for description of connetion of wind
/ rain sensor.
S4 X3
Connection to power supply WCA 3P3 (10A), or WCA 3P5 (20A)
Protective earth (PE).
11 Configuration of the MotorController
The MotorController is configured by pressing the two keys ”↑” and ”↓” on the input card, at the same time for 10 seconds.
The MotorController must be configured
- After re-installation, changes, or change of actuators
- When / if MotorLink®actuators are connected
- If the cables have been moved
- When components are removed from the MotorController
Note, during reconfiguration actuator outputs can be activated in both directions.
If the yellow diode on the motor line card blinks after a configuration, an error has occurred in the configuration, see chaptor “Fault
detection via LED” for identification of errors.
Actuators are to be connected on the motor lines. ±24V standard actuators and actuators with MotorLink®can be connected to
all motor lines, but a motor line can only be connected to one type of actuators –either ±24V standard or MotorLink®actuators.
The MotorController will automatically detect the type of actuator, which is connected to the MotorController.
12 Fault detection via LED
12.1 Fault detection on the MotorController
In case of error on the MotorController, the yellow diode on the motor line card will blink and via blink sequence indicate an error
message. Depending on the type of error message will consist of 2 or 3 blink sequences, separated by a seconds pause. The first
blink in an error message has a duration of one second, and thereby indicating when the error message (1st blink sequence)
begins. The remaining blinks of the error message has a duration of 0.5 seconds. The error message is repeated until the error has
been rectified. Between 2 error messages there is a pause of 2 sec.

18
Example of an error message
”7 blinks –1sec. pause –2 blinks –1 sec. pause –1 blinks”.
1. There is an error on a local input
2. The error is on input X10.5, to which a rain sensor might be connected
3. The error is due to no connection to the sensor.
If there are more errors on the MotorController simultaneously, they are shown with priority, i.e. the error message for the most
critical error is shown first and repeated until rectified. Then the error message number 2 is shown and repeated as well until the
error is rectified etc. Below table, list the most common errors.
Error message
1. Blink sequence
2. Blink sequence
3. Blink sequence
Number
of blink
Error on
Number
of blink
Error on or error type
Number
of blink
Error type
1
System
1
Internal error (Watchdog
reset)
2
Internal error (Program
CRC)
5
Actuator
1-8
X1-X8 (actuator output)
1
Actuator configuration –check the actuators,
check the configuration, when using ±24V
standard actuators check the termination
2
Expected number of actuators, the found and
expected number of MotorLink®actuators
does not match –check actuator connections
4
Internal error
7
Local
input
17
X9.1 (rain sensor)
1
Termination –check connection of sensor as
well as termnation
10
Power
supply
1
Internal error
2
Mains –check connection
5
Internal error
If other errors or an “Internal error” are indicated, please contact WindowMaster.
13 Hardware error
If there are any hardware error on the MotorController it will be indicated by the diodes (yellow diode is lit).
14 Commissioning and test run
In case of hardware error please see chapter 13 “‘Hardware error”. To configure the MotorController press „↑“ and „↓“ (on the
input card) at the same time for 10 seconds, see chapter 11.
We recommend that the software of the MotorController is updated the annual maintenance check!
14.1 The MotorController is completely installed, without the operating voltage
applied
a) Check all mechanical and electrical components for damage.
b) Check all screw and plug connections for tightness and/or firm seating
c) Check that all external components are installed:
1) ±24V actuators: check polarity
14.2 With mains voltage
Adhere to the relevant regulations!
Connect the mains cables and reapply the mains voltage.
14.3 Ventilation keypad
Closely observe the actuators during opening and closing. They must not be impaired in any position by the building structure.
Observe that the actuator cables are not being subject to pulling or pinching. Check each ventilation keypad individually.
14.4 Wind/rain detector
a) Open the actuators with the comfort ventilation keypads.
b) Wet the rain sensor, the actuators will fully close.
c) While the actuators are running, press the Open button at the keypad. The actuators must neither open nor stop!
Exception: If a manual override time (Man. operation after auto comm.).
If the start-up was successful, mount the door of the MotorController.
If the start-up was unsuccessful (error with one of the test run processes), please see chapter 10 “Description of cards”.
If necessary, check the wiring in accordance with the cable plan –see chapter 9 “Cable plan for connection to WCC 3xx”.

19
15 Maintenance
The MotorController and ventilation system should be checked, serviced and, if necessary, repaired at least once per year by
the manufacturer or an authorized partner
Remove all soiling from the units of the ventilation system. Check fastening and clamping screws for firm seating.
Carry out a test run of the entire system (see chapter 14 ‘Commissioning and test run).
Only have defective units repaired in our factory. Only install original spare parts.
Check the operational condition at regular intervals. We recommend a WindowMaster service contract is taken out to ensure the
right function of the ventilation system.
We recommend that the software of the MotorController is updated the annual maintenance check!
The expected minimum lifetime for the MotorController is 10 years.
15.1 Maintenance agreements
WindowMaster offer maintenance agreements for the ventilation system. Contact our service department for further information:
telephone [phone] or [email protected]
15.2 Replacement 3M4, 3M8 and 3KI card
1. Disconnect the 230 V
2. Remove the old card
3. Insert the replacement card.
4. Turn on the 230 V.
5. The system will be ready again after approx. 2 seconds.
16 Declaration of Conformity
The MotorController is manufactured and tested accordingly to the European requirements.
The total system is not to be put into service until a declaration of conformity for the total system has been made.
The “Declaration of Conformity” is supplied with the MotorController as separate documents.
