Winmate FM12Q User manual

Please read these instructions carefully before using this product, and save this manual for future use.
Vehicle Mounted Computer
Qualcomm Snapdragon™ 660 octa-core, 2.2 GHz
FM12Q
User Manual
Version 1.2
Document Part No. 9152111I109J

1
12.1" Vehicle Mount Computer FM12Q Product Reference Guide
Contents
Preface............................................................................................................................................3
Chapter 1: Introduction .................................................................................................................9
1.1 About This Guide....................................................................................................................9
1.2 Package Contents ..................................................................................................................9
1.3 OptionalAccessories ............................................................................................................10
1.4 Components .........................................................................................................................11
Chapter 2: Hardware....................................................................................................................14
2.1 System Hardware .................................................................................................................14
2.2 Central Processing Unit........................................................................................................14
2.3 Input and Output Connectors................................................................................................14
2.4 System Memory....................................................................................................................15
2.5 Audio Interface......................................................................................................................15
2.6 Memory Card........................................................................................................................15
2.7 WWAN..................................................................................................................................15
2.8 Power ...................................................................................................................................15
2.8.1 Vehicle DC Power Supply ............................................................................................15
2.8.2 External AC Power Supply (Optional)...........................................................................15
2.9 Power Management Modes..................................................................................................16
2.9.1 Turn On........................................................................................................................16
2.9.2 Suspend.......................................................................................................................17
2.9.3 Wake Up.......................................................................................................................17
2.9.4 Turn Off........................................................................................................................17
2.10 Power Control.....................................................................................................................17
2.10.1 Power Switch..............................................................................................................17
2.10.2 Power Button..............................................................................................................17
2.11 Ignition Control....................................................................................................................18
2.12 Battery ................................................................................................................................18
2.12.1 UPS Battery................................................................................................................19
2.12.2 Backup Battery...........................................................................................................19
2.13 External Connectors ...........................................................................................................20
2.13.1 Connector Pin Assignment.........................................................................................21
2.14 CANBus Cable Installation Reference................................................................................27
2.15 Antenna Connections..........................................................................................................28
2.16 External/ Vehicle Remote Antenna......................................................................................28
2.17 Keyboard Options...............................................................................................................29
2.17.1 Integrated Keypad......................................................................................................29
2.17.2 USB Keyboard/ Mouse...............................................................................................30
2.18 LED Function......................................................................................................................30
2.19 Display................................................................................................................................31
2.19.1 Touch Screen.............................................................................................................31
2.19.2 Display BacklightControl............................................................................................31
Chapter 3: Software.....................................................................................................................32
3.1 Introduction...........................................................................................................................32
3.1.1 Operating System.........................................................................................................32
3.1.2 About Android 9.0.........................................................................................................32
3.2 Setting up the Device............................................................................................................32
3.2.1 Home Screen ...............................................................................................................32
3.2.2 Quick Settings..............................................................................................................34
3.3 Status and Notification Icons................................................................................................35
3.3.1 Status Icons..................................................................................................................35

2
12.1" Vehicle Mount Computer FM12Q Product Reference Guide
3.3.2 Notification Icons..........................................................................................................35
3.4 Control Panel........................................................................................................................36
3.4.1 Using the Touch Screen ...............................................................................................36
3.4.2 System Settings ...........................................................................................................37
3.5 Ethernet................................................................................................................................43
3.5.1 Configuring Ethernet Settings.......................................................................................44
3.5.2 Checking the Ethernet Settings....................................................................................45
3.6 Winset...................................................................................................................................46
3.6.1 Winset Application........................................................................................................46
3.6.2 Ignition Control .............................................................................................................47
3.6.3 Screen Blanking ...........................................................................................................48
3.6.4 Function Buttons ..........................................................................................................49
3.6.5 Defroster (Optioanl)......................................................................................................50
3.7 Winmate® Home Manager (WHM).......................................................................................52
3.7.1 How to Lock Applications .............................................................................................52
3.7.2 How to Reset WHM Settings........................................................................................55
3.7.3 How to Change WHM Password..................................................................................56
3.8 WDC.....................................................................................................................................57
3.9 BT.........................................................................................................................................58
3.10 Connecting to WLAN Networks ..........................................................................................60
3.11 WWAN................................................................................................................................63
3.12 Camera Features................................................................................................................64
3.12.1 Taking Pictures...........................................................................................................64
3.12.2 Making Videos............................................................................................................66
3.12.3 Camera Settings.........................................................................................................67
3.13 Software Update.................................................................................................................67
3.13.1 Image Tool Download.................................................................................................67
3.13.2 OTA Update Guide.....................................................................................................68
3.14 Transfer Files via USB........................................................................................................72
3.15 Changing Touchscreen Modes...........................................................................................76
Chapter 4: Accessories Installation ...........................................................................................78
4.1 Installing a SIM Card ............................................................................................................78
4.2 Installing a Micro SD Card....................................................................................................79
4.3 Installing a Stylus with the holder..........................................................................................80
Chapter 5: Vehicle Mounting.......................................................................................................81
5.1 Introduction...........................................................................................................................81
5.2 Vehicle Mount Instruction .....................................................................................................81
5.3 RAM Mount Installation.........................................................................................................82
5.3.1 Mounting Kit 1 –No Drill Solution.................................................................................82
5.3.2 Mounting Kit 2 –Drill Solution ......................................................................................83
5.3.3 RAM Mount Assembly..................................................................................................84
5.3.4 Mounting Kit 3 –Keyboard Mounting Installation .........................................................84
5.3.5 Keyboard Assembly......................................................................................................85
5.4 Docking and Undocking the Device......................................................................................87
5.5 Power Cable Installation.......................................................................................................88
5.5.1 Wiring the Power Cable................................................................................................88
5.5.2 Connecting the Power Cable for Testing......................................................................88
5.5.3 Connecting the Power Cable for Installation on the Vehicle.........................................89
5.4.4 Power Cable Routing....................................................................................................91
Appendix.......................................................................................................................................92
Appendix A: Product Specifications............................................................................................92
Appendix B: Order Information ...................................................................................................93

3
Preface
Preface
Copyright
No part of this manual may be reproduced, copied, translated, or transmitted in any form or any
means, electronic or mechanical, for any purpose, without the written permission of Winmate Inc.
Trademarks
Brand and product names are trademarks or registered trademarks of their respective owners.
Note:
Display images shown may vary slightly from actual display. Information in this manual
is subject to change without prior notification.
Note:
FM12Q Computer has to be used together with the docking station.
Use the device when located at least 20 cm (7.9 inches) away from the human body.
Disclaimer
Winmate Inc. reserves the right to make any product changes without notice, including circuits
and/or software described or contained in this manual in order to improve design and/or
performance. Winmate Inc. assumes no responsibility or liability for the use of the described product
(s), conveys no license or title under any patent, copyright, or masks work rights to these products,
and makes no representations or warranties that these products are free from patent, copyright, or
mask work right infringement, unless otherwise specified. Applications that are described in this
guide are for illustration purposes only.Winmate Inc. makes no representation or warranty that such
application will be suitable for the specified use without further testing or modification.
Warranty
Winmate Inc. warrants that each of its products is free from material and workmanship defect for a
period of one year starting from the invoice date. If the customer discovers a defect, Winmate Inc.
will, at its option, repair or replace the defective product at no charge to the customer, provided it is
returned during the warranty period, with transportation charges prepaid. The returned product must
be properly packaged in its original packaging to obtain warrantyservice.

4
12.1" Vehicle Mount Computer FM12Q Product Reference Guide
Advisory Conventions
Four types of advisories are used throughout the user manual to provide helpful information or to
alert you to the potential for hardware damage or personal injury. These are Notes, Important,
Cautions, and Warnings. The following is an example of each type of advisory.
Note: A note is used to emphasize helpful information
Important: An important note indicates information that is important for you to
know.
Caution A Caution alert indicates potential damage to hardware and explains
how to avoid the potential problem.
Attention Une alerte d’attention indique un dommage possible à l’équipement
et explique comment éviter le problème potentiel.
Warning! An Electrical Shock Warning indicates the potential harm from
electrical hazards and how to avoid the potential problem.
Avertissement! Un Avertissement de Choc Électrique indique le potentiel de
chocs sur des emplacements électriques et comment éviter ces problèmes.
FCC Regulations
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
This device has been tested and found tocomply with the limits for a Class Bdigital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in residential installation. This equipment generates uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that interference will
not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
• Consult the dealer or an experienced technician for help.
Changes or modifications not expressly approved by the party responsible for compliance could void
the user‘s authority to operate the equipment.
Operation on the 5.15-5.25GHz frequency band is restricted to indoor use only. The FCC requires
indoor use for the 5.15-5.25GHz band to reduce the potential for harmful interference to co-channel
Mobile Satellite Systems. Therefore, it will only transmit on the 5.25-5.35 GHz, 5.47-5.725 GHz and
5.725 –5.850 GHz band when associated with an access point (AP).

5
Preface
CE Notice (European Union)
This device has been tested and found to conform to the limits set for a Class B product.
• EN 55022 —“Limits and Methods of Measurement of Radio Interference Characteristics of
Information Technology Equipment”
• EN 55024 —“Information technology equipment - Immunity characteristics - Limits and
methods of measurement”
• EN 61000-3-2 —“Electromagnetic compatibility (EMC) - Part 3: Limits - Section 2”
• EN 61000-3-3 —“Electromagnetic compatibility (EMC) - Part 3: Limits - Section 3”
• EN 60950 —“Safety of Information Technology Equipment”.
• EN 55022 Emissions requirements
RF Exposure Information (SAR)
This device is compliance with SAR for general population /uncontrolled exposure limits in
ANSI/IEEE C95.1-1999 and had been tested in accordance with the measurement methods and
procedures specified in OET Bulletin 65 Supplement C.
This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled
environment. This device was tested for operations with the device contacted directly to the human
body to the back side of the EUT. To maintain compliance with FCC RF exposure compliance
requirements, avoid direct contact to the transmitted antenna during transmitting.
IC Regulations
Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio
exempts de licence. L’exploitation est autorisée aux deux conditions suivantes:
(1) l’appareil ne doit pas produire de brouillage, et
(2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage
est susceptible d’en compromettre le fonctionnement.”
This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject
to the following two conditions:
(1) This device may not cause interference, and
(2) This device must accept any interference, including interference that may cause undesired
operation of the Device.
This Class B Digital Apparatus Complies with Canadian ICES-003
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
The device could automatically discontinue transmission in case of absence of information to
transmit, or operational failure. Note that this is not intended to prohibit transmission of control or
signaling information or the use of repetitive codes where required by the technology.
The device for the band 5150-5250 MHz is only for indoor usage to reduce potential for harmful
interference to co- channel mobile satellite systems; the maximum antenna gain permitted (for
devices in the bands 5250-5350 MHz and 5470-5725 MHz) to comply with the e.i.r.p. limit; and The
maximum antenna gain permitted (for devices in the band 5725-5850 MHz) to comply with the e.i.r.p.
limits specified for point-to-point and non-point-to-point operation as appropriate, as stated in section
A9.2(3). In addition, High-power radars are allocated as primary users (meaning they have priority)
of the band 5250-5350 MHz and this radar could cause interference and/or damage to LE-LAN
devices.
The County Code Selection feature is disabled forproducts marketed in the US/Canada. Forproduct

6
12.1" Vehicle Mount Computer FM12Q Product Reference Guide
available in the USA/ Canada markets, only channel 1~11 can be operated. Selection of other
channels is not possible.
IC Radiation Exposure Statement
This EUT is compliance with SAR for general population/uncontrolled exposure limits in IC RSS-
102 and had been tested in accordance with the measurement methods and procedures specified
in IEEE 1528.
Read Me First
Attention: Pour réduire le risque d’incendie ou de choc électrique ne pas exposer
l’appareil à la pluie ou à l’humidité. VERIFIER que le cordon électrique est la prise
murale pour un delai d’inactivite prolongé. Pour arrêter complètement l’alimentation
de l’appareil, débranchez le cordon d’alimentation de la prise AC. N’enlever ni le
capot arrière ni les pièces internes de l’appareil. Contactez un personnel qualifié si
nécessaire.
SA1965
Electrique Avertissement
Utilisé pour les instructions destinés à alerter l’utilisateur d’un CHOC ÉLECTRIQUE
mortel ou de blessure grave en cas d’utilisation incorrecte de l’unité.
SA1966
Avertissement Utilisé pour les instructions destinés à alerter l’utilisateur d’un
risque mortel ou de blessure grave en cas d’utilisation incorrecte de l’unité.
Attention: Pour réduire le risque d’incendie ou de choc electrique ne pas exposer
l’appareil à la pluie ou à l’humidité FAIRE le cordon électrique est DÉBRANCHÉ DE
LA PRISE MURALE DANS UN DELAI DE PROLONGER INACTIVITÉ. De se
désengager totalement LE POUVOIR DE L’UNITE, S’IL VOUS PLAÎT
DEBRANCHER LE CORDON D’ALIMENTATION DE LA PRISE AC. NE PAS
Romove le capot arrière, pas de PIÈCES À L’INTÉRIEUR. Contactez un personnel
qualifié S’il faut le réparer.
SA1965
Electrique Avertissement
Sert aux instructions destin es alerter l’utilisateur d’un CHOC ÉLECTRIQUE mortel
ou de blessure grave en cas d’utilisation incorrecte de l’unit.
SA1966
Avertissement Sert aux instructions destin es alerter l’utilisateur d’un risque
mortel ou de blessure grave en cas d’utilisation incorrecte de l’unit .

7
Preface
Informations de sécurité (FR)
Suivez et respectez tous les avertissements et instructions figurant sur l’écran. Pour votre sécurité,
s’il vous plaît lire toutes les consignes de sécurité et de fonctionnement avant d’utiliser le device.
Gardez ce manuel pour référence future.
1. Lire avec attention toutes les recommandations et precautions d’emploi avant d’utiliser ce
produit.
2. Veuillez conserver ces recommandations et précautions pour référence future.
3. Lire et comprendre tous les avertissements énumérés dans les précautions d’emploi.
4. Suivre toutesles précautions d’emploi pour utiliser ce produit.
5. Utiliser exclusivement un chiffon sec pour nettoyer ce produit.
6. Ne pas placer le produit près de toute source de chaeur telle que radiateurs, arrivées d’air
chaud, fourneaux ou autres appareils générant de la chaleur (incluant les amplificateurs
producteurs de chaleur) .
7. Ne pas négliger la sécurité que procure un branchement polarisé ou avec raccordement à la
terre, Un branchement polarisé comprend deux fiches dont l’une est plus large que l’autre. Un
branchement à la terre comprend deux fiches plus une troisième reliée à la terre. Si la fiche
secteur fournie ne s’insert pas dans votre prise de courant. consulter un ‘électricien afin de
remplacer votre prise obsolète.
8. Protéger le cordon d’alimentation de tout écrasement ou pincement, particulièrement au niveau
des fiches, des réceptacles utilisés et à l’endroit de sortie de l’appareil. Ne pas casser la fiche
de terre du cordon d’alimentation.
9. Utiliser uniquement les accessoires spécifiés par le constructeur.
10. Utilisez seulement des accessoires spécifiés par le manufacturier ou vendus avec le
produit.
11. Débrancher cet appareil lors d’orages ou s’il n’est pas utilize pendant une longue période.
12. Faire exécuter le service par du personnel qualifié. Une intervention technique est requise
lorsque l’appareil a été endommagé ou n’opère pas normalement.
Safety Information (EN)
Follow and adhere to all warnings and instructions on the screen. For your safety, please read all
safety and operating instructions before using the device. Keep this manual for future reference.
1. Carefully read all recommendations and precautions for use before using this product.
2. Retain all recommendations and precautions for future reference as necessary.
3. Read and be sure to understand all warnings listed in the precautions.
4. Follow all operating precautions when using thisproduct.
5. Use only a dry cloth to clean this product.
6. Do not place the product near any heat sources such as radiators, warm air intakes, stoves or
other heat- generating devices (including amplifiers or other heat producing equipment).
7. Do not disregard the safety that a polarized or grounded connection can provide. A polarized
connection consists of two plugs, one of which is larger than the other. A grounded connection
has two blades and a third one that is grounded. If the main plug provided cannot be inserted
into your outlet, consult an electrician to replace your obsolete outlet.
8. Protect the power cord from being crushed or pinched, particularly in the area of the plugs, any
receptacles used, and the point of exit from the apparatus. Do not break off the ground pin of
the power cord.
9. Use only accessories specified by the manufacturer.
10. Use only with accessories specified by the manufacturer or sold with the product.
11. Unplug this apparatus during lightning storms or when it is not being used for long
periods.
12. Refer all servicing to qualified service personnel. A technical intervention is required when the
apparatushas been damaged in any way or does not operate normally.

8
12.1" Vehicle Mount Computer FM12Q Product Reference Guide
About the Adapter
•Use only the supplied AC adapter (Rating: Input DC 10-60V DC). Use of another type of AC
adapter will resultin malfunction and/or danger.
•Do not use the adapter in a high moisture environment. Never touch the adapter when your
hands or feet are wet.
•Allow adequate ventilation around the adapter when using it to operate the device or charge the
battery. Do not cover the AC adapter with paper or other objects that will reduce cooling. Do not
use the AC adapter while it is inside a carrying case.
•Connect the adapter to a proper power source. The voltage requirements are found on the
product case and/or packaging.
•Do not use the adapter if the cord becomes damaged.
•Do not attempt to service the unit. There are no serviceable parts inside. Replace the unit if it is
damaged or
•exposed to excess moisture.
Li-Ion Battery
Your device has UPS battery. When disposing UPS battery, follow local rules and regulations.
Warning! Do not dispose the battery with general waste materials.
Avertissement! Ne jetez pas la batterie avec les déchets ordinaires.
The following precautions on battery recycling should be observed:
•The battery should be disposed properly according to local regulations;
•The battery should not be damaged or crushed;
•The battery should not be heated or exposed to direct sunlight.
If you are not aware of local regulations on disposing the battery pack, contact our Service Center
or sales representatives for more information.
Important: This hot-swap battery is soft-packed. It may have up to 8% inflation in
dimensions under the usage in normal conditions. The mechanical design of the device
reserves the space for this normal inflation.
Warning! If you observe the internal hot-swap battery has been inflated more than
normal condition (or the blotch of panel and touch caused by inflated battery), contact
our Service Center or sales representative for replacing the battery immediately.
Avertissement! Si vous constatez que la batterie interne remplaçable à chaud a été
gonflée plus que dans des conditions normales (ou la tache du panneau et le toucher
causés par une batterie gonflée), contactez notre centre de service ou notre
représentant commercial pour remplacer la batterie immédiatement.
Important: The battery is consumable part. Therefore, it is recommended to replace
the battery pack every two years with a new one recommended by Winmate. Contact
our Service Center or sales representatives for more information on replacing the
battery pack.
General Guideline
It is recommended to reboot the device when some functions are defect or inactive. If it still can't
solve the problems, please contact your dealer or agent.

9
Chapter 1: Introduction
Chapter 1: Introduction
The FM12Q is an Android-based rugged vehicle-mounted computer that ships with a high-
performance Qualcomm Snapdragon™ 660 octa-core 2.2 GHz CPU. The computer showcases
enterprise mobility in a VMC form factor thanks to its rich I/O ports, versatile wireless connectivity
options, as well as the high flexibility brought by the design of the dock with a one-click top latch,
which allows for easy removal of the device. Engineered to fit seamlessly into forklifts and other
warehouse vehicles with its wide range of power input with power isolation, the FM12Q will help
minimize errors, streamline inventory management, and improve operational efficiencies.
This vehicle-mount computer is built to endure the rigors of the warehouse, and designed to fit
seamlessly into forklifts and other warehouse vehicles.
Note:
Contact our technical support for information on the latest firmware upgrade for your
device.
1.1 About This Guide
This Product Reference Guide provides instruction for the system administrator to follow when
configuring and using the FM12Q Vehicle Mount Computer. This Product Reference Guide has been
developed for a FM12Q with Android 9.0 operating system.
1.2 Package Contents
Before using this device, make sure that all the items listed below are included inyour package:
Computer
FM12Q
Dock + Latch
Locking Key
Power Cable
with Fuse
USB Cable
84W Adapter
with Power
Cable
Quick Start
Guide
WLAN Antenna
Power
Converter
Cable
External
Antenna Fixing
Bracket
Power Cord
Stylus Kit
Note: Two WLAN antennas are included in the standard package.
Note: Please order one bracket for one antenna. For example, if you plan to use two antennas, please order two
brackets.

10
12.1" Vehicle Mount Computer FM12Q Product Reference Guide
1.3 Optional Accessories
Your package may include the following items based on your order:
DC Jack Power
Cable
RS232 Cable
Audio Cable
LAN Cable
WWAN
Antenna
Fuse Kit
Spare Key for
Vehicle Dock
CANBus Cable
CANBus cable
(w/o DIDO)
Note: Notice that only one antenna is included in the package. If you plan to use WWAN function please order two
WWAN antennas.
Note: Notice that in order to have sound; you have to plug in the audio cable first than connect to docking.

11
Chapter 1: Introduction
1.4 Components
Front View
No
Item
Description
1
12.1” Touch Screen
Acts as one of the inputs for thedevice
2
Camera and
Microphone
2 Megapixel front camera with a microphone for voice
communication and voice recording
3
Light Sensor and
LED indicators
Wireless communication indicators
Defroster indicator
(Defroster is a customized feature available by request)
UPS battery indicators
HDD indicators
Light sensor
4
Power Button and
Indicator
Press and hold the button for 3 second to turn on the device
5
Function buttons
Programmable function keys that can be configured by using the
Win-Set® Utility
Digital Microphone
For voice communication and voice recording
6
Speaker
Emits Sound

12
12.1" Vehicle Mount Computer FM12Q Product Reference Guide
Rear View with Vehicle Dock
No
Item
Description
1
Release Latch
Press to release the device and thedocking
2
VESA Mount Hole
VESA 75, 100, and RAM Mount
3
Kensington Lock
Connect to a security lock, protecting your device from beingstolen
4
Power switch
Set the switch to on (I) to provide the supply power to the device and
it will automatically connect to the ignition system of thevehicle
Top and Bottom View
No
Item
Description
1
Lock
Lock the tablet in place
2
Reading Light
Use to provide illumination in darkenvironment

13
Chapter 1: Introduction
Side View with Vehicle Dock
Left Side
Right Side
No
Item
Description
1
WLAN Antenna Connector
Connect a WLAN external antenna and allow the device
to be remotely mounted on the vehicle.
2
GPS Antenna Connector
Connect a GPS external antenna and allow the device to
be remotely mounted on the vehicle.
3
WWAN AntennaConnector
Connect a WWAN external antenna and allow the device
to be remotely mounted on the vehicle.
4
Wide Range Power Input
Connect a 10-60V DC IN wide range power input
5
SD Card Slot
Service window to insert MicroSD card.
6
Dual Nano SIM Card Slot*
Service window to insert Nano SIM cards.
7
USB Type-C
A high-speed USB port connects to USB devices.
8
Power Input**
Connect a 12V DC IN power input.
9
COM1 and COM2
Connect a peripheral device such as a printer or scanner
with serialport.
10
USB Type-A x 2
Connect USB peripheral devices such as USB Flash
drive, mouse, keyboard, printer, etc.
11
CAN Bus / Audio
Connect to a vehicle, allowing access to wide range of
vehicledata/ Connects headphone or other audio output
devices.
12
LAN Port
Connect to a local area network (LAN) using an Ethernet
cable and provide optional POE with 48V.
Note:
* Only Sierra Module can support dual SIM single standby function.
**For the defroster function please connect a device to a power supply.

14
12.1" Vehicle Mount Computer FM12Q Product Reference Guide
Chapter 2: Hardware
2.1 System Hardware
2.2 Central Processing Unit
The FM12Q is running on Qualcomm Snapdragon™ 660 octa-core 2.2 GHz CPU, and Android 9.0
operating system.
2.3 Input and Output Connectors
The FM12Q device supports the following I/O connectors:
•1 x Dual-Nano SIM Card Slot
•1 x Micro SD Card Slot
•1 x USB 3.0 Type C (OTG)
•1 x 12 V DC in power input jack
Note:
Only Sierra Module can support dual SIM single standby function.
The Vehicle Dock of the FM12Q device supports the following I/O connectors:
•2 x COM
•1 x DB9 Connector for 2 x USB 2.0 Port
•1 x CANBus or 1 x Audio (In and Out)
•1 x Gigabit LAN port
•1 x Power connector
•5 x SMA Connectors (female) for external antennas (WLAN, GPS, WWAN)

15
Chapter 2: Hardware
2.4 System Memory
The main system memory is 3 GB LPDDR4.
2.5 Audio Interface
Your device is equipped with two speakers which are located on the bottom of the vehicle dock. A
microphone is also available for voice communication and voice recording.
As an alternative, you can use a headset adapter cable that provides a connection for headset
operation. When headset is plugged in to the adapter cable, the main speakers or internal
microphone will be disabled.
2.6 Memory Card
Your device has a memory card slot which accepts an SD memory card. The memory card is hot
swappable. Your device has an 802.11 a/b/g/n/ac network card that can be used with internal or
externalantennas.
2.7 WWAN
Using a SIM card for network connection, your device supports Wireless Wide Area Networking
(WWAN).
2.8 Power
2.8.1 Vehicle DC Power Supply
The Power input voltage range for the vehicle dock is between 10 to 60V DC, without the need to
perform any manual operation within the vehicle dock.
This dock provides conditioned power output for the device. By using a specified DC to DC adapter,
the input voltage of 100-240 V DC nominal can be accepted.
2.8.2 External AC Power Supply (Optional)
If the DC power is not available, you can use an optional external UPS (Universal Input Power
Supply) to convert AC power to an appropriate DC level.
Using an external UPS and adapter cable, the AC to DC power input for the device is transferred to
the vehicle dock. To perform the connection, simply plug one end of the adapter cable to the dock
and then plug the other end of the adapter cable to the DC output cable from adapter. For Details,
refer to the connection diagram shown below:

16
12.1" Vehicle Mount Computer FM12Q Product Reference Guide
No
Item
1
AC Input Cable
2
DC Output Cable
3
ToDC Output Cable
4
To FM12Q
2.9 Power Management Modes
The FM12Q has four power modes: Turn On, Suspend, Wake up, and Turn Off.
Action
Button
LED Indicator
Turn On
Press the On button for “3 seconds” until the
blanking indicator located on the right side On (solid
red), and then release the button.
On
Suspend
Press the On button for “1 seconds” until the screen
On and then release the button. The battery
indicator will Off after the screen is Off, the system
is already in the standby / sleep mode.
Off
Wake
Up
Press the On button for “1 second” until the screen
On and then release the button.
Off
Turn Off
Press the On button for “2 second” until the system
is turns Off and then releases the button.
Off
2.9.1 Turn On
When the FM12Q is attached to either vehicle power or an external power supply, or it is operating
from the UPS battery and the power button is pressed, the device is in the “ON” mode. In this mode,
the keypad, touch screen and any attached peripherals will function normally. The display remains
ON until the display, standby or suspend timer expires. When the device is in ON mode, the power
LED indicators isoff.

17
Chapter 2: Hardware
2.9.2 Suspend
When the device is in Suspend Mode, all LEDs are off. Press the power button to wake up the device
back to ON mode.
2.9.3 Wake Up
When the device is in Wake Up Mode, all LEDs are off.
2.9.4 Turn Off
By default, the FM12Q turns off if the user turns off the device through the system or presses the
power button for 10 seconds with a critical shut down. The FM12Q will also be off when there is no
connection to a power source or the UPS battery is depleted. However, the internal RTC will keep
maintaining the date and time while the device is off.
2.10 Power Control
2.10.1 Power Switch
Power switch is located on the rear side of the
vehicle dock. When the dock is connected to
the external power and the power switch is ON,
the dock delivers power to the FM12Q and the
device can be powered on.
2.10.2 Power Button
Power button is located at the lower right side
of the FM12Q. If the device is OFF, pressing the
power button will start the power up sequence.
Note:
• The FM12Q has to be docked in a powered vehicle docking station or UPS battery
has to have a sufficient charge to power the device.
• If no external power available and the UPS battery do not have enough charge,
pressing the power button will cause no action.

18
12.1" Vehicle Mount Computer FM12Q Product Reference Guide
2.11 Ignition Control
The FM12Q Vehicle Mount Computer has ignition control feature thatenabled by software. For more
details, please refer to Winset, Ignition Control section of this user guide.
2.12 Battery
Follow all the instructions in this user manual to prolong the battery life-cycle.
Warning! Recharge the battery pack according to the instructions in this usermanual.
Avertissement! Rechargez la batterie conformément aux instructions de ce manuel
d'utilisation.
Warning! There is a risk of an explosion caused by incorrect installation or
misapplication of the battery pack.
To avoid possible injury:
•Use only the type of the battery recommended by Winmate.
•Follow battery pack installation instructions in this user manual.
•Keep the battery away from fire.
•Store in a cool dry place.
•Do not expose to heat, water and rain.
Avertissement! Il existe un risque d'explosion causé par une installation incorrecte
ou une mauvaise utilisation de la batterie.
Pour éviter d'éventuelles blessures:
•Utilisez uniquement le type de batterie recommandé par Winmate.
•Suivez les instructions d'installation de la batterie dans ce manuel d'utilisation.
•Gardez la batterie à l'écart du feu.
•À conserver dans un endroit frais et sec.
•Ne l'exposez pas à la chaleur, à l'eau et à la pluie.
Warning! Do not drop, puncture, and crush the battery unit. If you notice any
damages on the battery, stop using the battery and replace it.
Avertissement! Ne laissez pas tomber, ne percez pas et n'écrasez pas la batterie.
Si vous remarquez des dommages sur la batterie, arrêtez d'utiliser la batterie et
remplacez-la.
Important: When the battery level reaches 0%, the FM12Q will automatically shut
down.
