Pleasereadtheseinstructionscarefullybeforeusing thisproduct, andsavethismanualforfutureuse.
M101M4TabletPC
Quick StartGuideV1.0

M101M4Quick StartGuide 1
Getting Started
Congratulationson purchasing thisruggedTabletComputer. The ruggeddesign allowsyou to
useitinharshoutdoorenvironments.
Thisquick start guidetellsyou step bystep howtoget the Tablet Computerup andrunning.You
willfind instructionsforthe following procedures:
•Unpacking
•Description of Parts
•First TimeOperations
•TurningOn/Off
Unpacking
Check andidentifythesuppliedaccessories:
•Tablet Computer •StandardBattery
•12VPowerAdapterwithPowerCord •Quick StartGuide
•CapacitiveTouchStylus

M101M4Quick StartGuide 2
DescriptionOfParts
Front: Right:
No
Item Description
1 Front Camera 2 Mega pixelWebcam
2 LEDIndicators: Showthecurrent statusof
theTablet Computer
Orange: Charging
Green: Full Charge
Blue: DataReceiving
3 TouchScreen Displays andactasoneof
theinputsfortheTablet
Computer
4 Back Button Back topreviouspage
5 HomeButton Back toDesktop
6PowerButton Turnson/off tablet
FrontLEDIndicatorsDetail:
No Item Description
7 I/O Cover ProtectsI/O ports
8 MicroUSB
OTG High speed USB port connectstoPCorUSB
devicessuchasmouse,
keyboard,etc.
Note:
ThisUSBportwon twork
whenthetabletis
connectedtotheoptional
docking. Pleaseusethe
USBportsonthedocking.
9 MicIn/LineOut
Headsetorheadphone
can beconnected
10 PowerJack DC-INpowerinput jack
11 MicroSDCard
Reader Memorycardreader portforMicroSDCard
SideI/O Details:
FrontButtonsDetails:

M101M4Quick StartGuide 3
Rear: Bottom:
No Item Description
14 Kensington
Lock Provideslockaccess for KensingtonLock.
15 Optional
Barcode BarcodeScannerfor reading of1D/2D
barcode.
16 OptionalRFID RFIDreaderforreading
ofRFIDtags.
17 RearCamera 8MPAutofocusCamera.
Capturesphotosand
videos.
18 CameraFlash LEDcameraflashto
provideflashlighting
whenusewithcamera.
19 Menu Button OpentheMenu
20 VolumeButtons
(OptionalBarcode
Reader/ RFID
TriggerButton)
VolumeControl.
(+)Raisesvolume,
(-) Lowersvolume.
21 BatteryLock
Latch Latchtolock thebattery inplaceoncebatteryis
inserted.Notspring-
loaded.
22 BatteryRelease
Slider Spring-loadedsliderthat latchesthebatteryin.
23 TouchPenSlot Penholderslottostore
touchpen
24 SIMcardslot Servicewindowtoinsert
MicroSIMcard.
25 Speakers Emitssounds.
No Item Description
26 Docking
Connector Port todockingsolutions suchasvehicledocking
toprovidepowerand
extensionIOports
Docking ConnectorDetail:
RearButtons
Detail:
BatteryLockLatch
Detail:

M101M4Quick StartGuide 4
First-timeOperation
InsertSIMcard(For3G)
The Tablet Computersupportsdataconnectionusing 3G SIMcardsand fitsaMicro-SIMcard.
Performthe followingtoinstallthe SIMcardintoyourTablet Computer:
1.Removethe servicewindowintherearbyunscrewing the fourscrews.
2.Insert the3G SIMcardintothe slotlocatednearthe right sideof theservicewindow.
3.Reposition theremoved servicewindowscrewtosecurethe servicewindow.
Inserting BatteryPack
Toinsert the included standardbatterypack intothe Tablet Computer:
1.Disconnect anycordsconnectedtothetabletcomputer.
2.Turnthe tablet computerover,back facingup.
3.LocatetheBatteryLock Latchand pushit tothe Unlocked”position.
4.LocatetheBatteryReleaseSliderthatisspring-loaded. Pullback andhold.
5.Insert thebatterywiththeconnector-pinsside first, and then lowerthe batteryintothe
batterycompartment. Continuetoholdthe BatteryReleaseSlideruntilthebatteryisfully
inserted.
6.Makesurethe batteryiscompletelylowered intothe compartment beforelettinggo ofthe
BatteryReleaseSlider. Batterywillbeflat against the housing oncefullyinserted

M101M4Quick StartGuide 5
RemovingtheBatteryPack
1.Shut downthe tablet computer(orputit tosleep). Disconnect anycordsconnectedtothe
computer.
2.Turnthe tablet computerover,back facingup.
3.LocatetheBatteryLock Latchand pushit tothe Unlocked”position.
4.LocatetheBatteryReleaseSliderthatisspring-loaded. Pullback andhold.
5.Lift the batteryout usingthe opening on side of batterycompartment.
ConnectingtoPowerSupply
The Tablet Computeroperateseitheron externalACpowerorinternalbatterypower. It is
recommended touseACpowerwhen you start up theTablet Computerforthe firsttime.
Caution UseonlytheACadapterincludedwithyourTabletComputer. Using
otherACadaptersmaydamagetheTabletComputerand theBattery.
Performthe followingtoconnect theTablet computertoACPower:
1.Onthe side of the Tablet computer, liftthe I/O protectivecoverbypulling onthe latch
2.Plug theDC cordof the ACadapterintothe PowerJack of the tablet computer.
3.Plug theACpowercordintothe ACadapter.
4.Finally, Plug the ACpowercordintothe electricaloutlet.

M101M4Quick StartGuide 6
Whenthe ACAdapterisconnected, the batterypack startscharging. The batteryLEDindicator
on the tablet computerwillshowdifferent states. Pleaserefertodescriptionof theLEDindicator
inthe Description of Parts.
Turning On / Off
TurningOn
Press and holdthe powerswitchfor3secondstoturnon thetablet.
Note:
•Press the powerswitchagaintoput thetablettosleep
TurningOff
Performthe followingproceduretoshutdownthe Tablet Computer:
1.Press and holdthe powerswitchfor3secondsuntilthe pop-upmenu shows
2. Tap on ShutDown.
3.Wait fortheTablet Computertopoweroff.

M101M4Quick StartGuide 7
Using theOptionalBarcodeReaderfeature
Toenablethe Barcode Readerfeature, perform the followingprocedure:
1.Pulldownfromthe top of thescreentoget thenotificationsarea.
2.Tipthe icontochange the physicalvolumebuttons”function
3.Makesurethe wording beside theicon shows Sound Volumeas scanbutton”
(Tipthe icon againtochange back to normal use”todisableBarcodeReader)
4.Open the applicationwherebarcode readerwillbe displaying thescanned barcode.
5.Press the volumebuttonstotriggerthe Barcode Scanner
Item Status Description
volumebutton as
normal use Barcode Readerisdisabled.
volumebutton as
scanbutton Barcode Readerisenabled. Reading willneedto
be triggered manuallythruVolumebuttons.
Volume
buttons

M101M4Quick StartGuide 8
Using theOptionalRFIDReaderfeature
Toenablethe RFIDReaderfeature,performthe following procedure:
1.Pulldownfromthe top of the screen toget thenotificationsarea.
2.Tipthe icontochange the function of physicalvolumebuttons”
3.Makesurethe wording beside theicon shows Sound Volumeas scanbutton”
(Tipthe icon againtochangeback to normal use”todisableBarcodeReader)
Item Status Description
volumebutton as
normal use Barcode Readerisdisabled.
volumebutton as
scanbutton Barcode Readerisenabled. Reading willneedto
be triggered manuallythruVolumebuttons.
4.Open the applicationwhereRFIDreaderwillbedisplaying thescannedRFIDtag.
5.Press the volumebuttonstotriggerthe RFIDReader

M101M4Quick StartGuide 9
