WiSilica lumos CONTROLS Ldrive 36W User manual

Dual-channel constant current LED driver
Ldrive 36W
WARNING AND GUIDELINES!!!
DO NOT INSTALL DAMAGED PRODUCT! This product has been properly packed so that
no parts should have been damaged during transit. Inspect to confirm. Any part
damaged or broken during or after assembly should be replaced.
Required Tools & Supplies
Read and follow all safety instructions!!
Method of installation varies based on the luminaire manufacturer
Do’s
Installation should be performed by a
qualified electrician
Dont's
Don't use outdoors
Installation shall be in accordance with
all applicable local and NEC codes
Avoid input voltage exceeding
maximum rating
Turn the power OFF at circuit breakers
before wiring
Don't dissemble the products
Observe the correct polarity of output
terminal
-
Check the polarity of the output terminals
The LED wiring should be kept as short as possible to ensure good EMI behavior
Sensor integration can be done using the 0-10V input and 12V auxiliary output
Secondary switching is not permitted
Incorrect wiring can damage the LED module
Installation steps
Wiring instructions
Turn the power o at the circuit breaker before wiring
Install the driver into the fixture using the screws
INSTALLATION AND QUICK START SHEET
PRODUCT OVERVIEW
Ldrive 36W is a dual-channel constant current LED driver with programmable output
current. It is a part of Lumos Controls ecosystem which includes controllers, sensors,
switches, modules, drivers, gateways, and analytical dashboards.
Prior to mounting, turn on power and test
connection to ensure system is operating properly.
Turn o power again before mounting.
Specifications Value Remarks
Input voltage 120-277VAC _
_
_
Input current 0.35A
0.5WPower consumption
Typical eciency 85% 120VAC/50Hz/full load
120VAC/50Hz/full loadPower factor 0.95
Output current 450-800mA 800/700/550/450
Adjusted by dip switch
Output voltage 42VDC _
Conductive
Ambient temperature -20 to 45ºC(-4 to 113ºF) @Life-time 50,000h
Turn on delay <500ms
Lifetime 50,000h @50ºC
Tx power 8dBm
Dimensions 324 x 30 x 21mm
(12.8 x 1.2 x 0.8in)
L x W x H
THD <15% 120VAC/50Hz/full load
INSTALLATION INSTRUCTIONS
WARNING : TURN THE POWER OFF AT THE CIRCUIT
BREAKER BEFORE WIRING
Electrostatic Discharge (ESD): ESD can damage product(s). Personal grounding
equipment should be worn during all installation or servicing of the unit
Do not stretch or use cable sets that are too short or are of insucient length
Do not modify the product
Do not mount near gas or electric heater
Do not change or alter internal wiring or installation circuitry
Do not use product for anything other than its intended use
WARNING: Risk of Product Damage
Dip Switch
Configuration
Power the driver connecting the Line and Neutral wires from the mains supply
Connect Warm, Cool channel from the LEDs to the driver
Head: CSK Slotted Length
38mm 8.3mm 3.7mm
Head Diameter Screw Diameter
Screwdriver Screws
Verify that supply voltage is correct by comparing it with the product
information
Make all electrical and grounded connections in accordance with the National
Electrical Code (NEC) and any applicable local code requirements
All wiring connections should be capped with UL approved recognized wire
connectors
WARNING - Risk of Electric Shock
Dip Switch
12V
Aux
WW+
WW-
CW+
CW-
ADC
0-10V
GND
N
L
PE
LDRIVE-36W
L
N
SENSOR
LED
ON
1
2
Dip Switch
lout 1
-
ON
ON ON
800mA
700mA
550mA
450mA
ON-
-
-
2

Please visit Help center
for more details
COMMISSIONING
LUMOS CONTROLS
APPLICATION
5-year limited warranty
Please find warranty terms and conditions
Note: Specifications may change without notice
Actual performance can vary due to end-user environment and application
WARRANTY Download the ‘Lumos Controls’ application
from Play Store or App Store
OR
Scan the QR codes to download the
‘Lumos Controls’ application
The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by WiSilica Inc. is under license. Other trademarks and trade names are those of their respective owners.
All Rights Reserved WiSilica Inc
www.lumoscontrols.com
20321 Lake Forest Dr D6,
Lake Forest, CA 92630
[phone]
Ver 1.0 Oct 2022
TROUBLESHOOTING
Once powered up, the device will be ready to be commissioned via the Lumos Controls
mobile app available for free download on iOS and Android. To begin commissioning, click
the ‘+’ icon from the top of the ‘Devices’ tab. The app allows you to preset certain
configurations which will be loaded after the device is added. The pre-configurations made
using 'Commissioning Settings' will be sent to the devices being commissioned. Once
commissioned, the device will be displayed in the ‘Devices’ tab and you can perform
individual operations like ON/OFF/dimming on it from this tab.
Short circuit behavior
In case of a short circuit on the secondary side (LED) the LED Driver switches o. After
elimination of the short-circuit fault, the LED Driver will recover automatically.
The LED Driver works in burst working mode to provide a constant output voltage
regulation which allows the application to be able to work safely when LED string opens
due to a failure.
PROTECTION
Overload protection
If the output voltage range is exceeded the LED Driver will protect itself and the output
current will decrease till LED flicker. After elimination of the overload, the nominal
operation is restored automatically.
The cabling, wiring and mounting of LED driver depends on the design and
manufacturer of the LED module. Therefore, the instruction provided here
should not be viewed as a comprehensive instruction for installation.
Read the documentation provided by the lamp manufacturer and follow
the guidelines provided
Observe all relevant standards and follow the instructions given
For detailed information
Wiring type and cross section
The wiring can be in stranded wires with ferrules or solid
with a cross section of 15-18AWG (Input) and 20-22AWG(Output).
Strip 8.5–9.5 mm of insulation from the cables to ensure
perfect operation of the push-wire terminals.
Use one wire for each terminal connector. 8.5-9.5mm
Wire: 20-22 AWG
When returning from a
Power Outage, lights go
back to ON state.
The device will return to its previous state after
the power is restored, as configured using the
Lumos Controls mobile app.
Device doesn't operate
immediately after power ON
Check whether you have set up a
transition time
Lights flickering The connection is not appropriate
The wires are not secured firmly with
connectors
Lights did not turn ON Circuit breaker tripped
Fuse has blown
Inappropriate wiring
8.5-9.5mm
Wire: 15-18 AWG
Input
Output
Press down the "push button" and remove the cable from front
Release of the wires
