WiSilica Lumos Controls Radiar D10 User manual

2 Channel DC Powered 0-10V Fixture Controller
Radiar D10
WARNING AND GUIDELINES!!!
DO NOT INSTALL DAMAGED PRODUCT! This product has been properly packed so that
no parts should have been damaged during transit. Inspect to confirm. Any part
damaged or broken during or after assembly should be replaced.
WARNING : TURN THE POWER OFF AT THE CIRCUIT
BREAKER BEFORE WIRING
Required tools &
supplies
INSTALLATION INSTRUCTIONS
Installation Steps
Read and follow all safety instructions!!
Do’s
Installation should be performed by a
qualified electrician
Don'ts
Don't use outdoors
Installation shall be in accordance with
all applicable local and NEC codes
Avoid input voltage exceeding
maximum rating
Turn the power OFF at circuit breakers
before wiring
Don't disassemble the products
Observe the correct polarity of output
terminal
-
Electrostatic Discharge (ESD): ESD can damage product(s). Personal grounding
equipment should be worn during all installation or servicing of the unit
Do not stretch or use cable sets that are too short or are of insucient length
Do not modify the product
Do not mount near gas or electric heater
Do not change or alter internal wiring or installation circuitry
Do not use product for anything other than its intended use
WARNING: Risk of Product Damage
Screwdriver Wirenuts
Verify that supply voltage is correct by comparing it with the product
information
Make all electrical and grounded connections in accordance with the National
Electrical Code (NEC) and any applicable local code requirements
All wiring connections should be capped with UL approved recognized wire
connectors
All unused wiring must be capped
WARNING - Risk of Electric Shock
Specifications
Input voltage
Input current
Output current
0-100%
linear (default) /
logarithmic
18mA
12-24VDC
Dimming output
0-10VDC
15mA
Dimming range
Dimming curve
Frequency range 2402 - 2480MHz
Operating temperature -20 to 55°C(-4 to 131°F)
UL 94 5VA
Max output power 7dBm
Relative humidity 85%
Dimensions
Flammability rating
2.6 x 1.15 x 0.9in
(66.7 X 29.2 X 22.4mm)
INSTALLATION AND QUICK START SHEET
Product Overview
Radiar D10 is a 2 Channel
DC-powered 0-10V Fixture Controller
that provides advanced automation
to select preset scenes, schedule
combinations of light levels, dimming,
motion sensing, task tuning, and
more. It is compact, making it easy to
mount inside the lighting fixtures.
It is a part of the Lumos Controls
ecosystem, including controllers,
sensors, switches, modules, drivers,
gateways, and analytical dashboards.
1. Turn o the power before wiring and installing the device
2. The controller with a compact formfactor can be installed anywhere within the light fixtures, or within junction boxes. The screw hole available on the controller can be
used to fix it firmly.
3. To power the controller, connect the Vin (Red) and Neutral (White color) of the controller to the he 12-24V DC and ground wires from power supply/ aux output of the driver
4. Connect the dimming wires of the controller to the dimming wires of the 0-10V driver
FCC ID: 2AG4N-WCD2CS
Value Remarks
Rated input voltage
Typical current @12VDC
Tolerance: ±0.2V
Source current per channel
Conductive
L X W X H

0-10V DRIVER
0-10V DRIVER
Installing within a light fixture
CH-1 (0-10V) DIM(Purple)
CH-2 (0-10V) CCT(Blue)
GND(Gray)
Vin 12-24V(Red)
On the extrusion or on top of the fixture
Recessed
Linear Recessed Troffer
Pendant
Downlight
High Bay

There are 2 options for Radiar D10 wiring
1. With Powerpack
2. Without Powerpack
Wiring
Dashed Line = 2x4 ft Fixture
110-277 VAC
L
N
LED +
LED -
Neutral
Line
P.E
GND
DIM2 +
DIM1 +
LED DRIVER
Radiar D10- 0-10V DC Controller
12V DC
CATRON V CATRON IV MOBILE APP
GND
VDC
CH2
CH1
Input Neutral
Input Line
LED DRIVER
WCD2CS
PSC-AC-PP-700C
SINGLE CHANNEL
LED -
LED +
CH1+
CH1
CH-1 (0-10V) DIM
MOTION HIGH (Yellow)
V- (Black)
Load (Blue)
COM (White)
Ground (Green)
120-277V (Black) 12V+ (Red)
CH-2 (0-10V) CCT
Ground
Vin 12-24V DC
L
N
G
Dashed Line = 2x4 ft Fixture
Radiar D10- 0-10V DC Controller
CATRON V CATRON IV MOBILE APP
GND
VDC
CH2
CH1
WCD2CS
CH-1 (0-10V) DIM
CH-2 (0-10V) CCT Ground
Vin 12-24V DC

Application
Radiar D10
WCD2CS
LED fixture
Driver
Please visit Help center
for more details
When returning from a
Power Outage, lights go
back to ON state.
This is normal operation. Our device has a
fail-safe feature forcing the device to go to 50%
or 100% and 0-10V at the full output on the loss of
power. Alternatively, the device will return to its
previous state after the power is restored, as
configured using the Lumos Controls mobile app
needs to be updated to Alternatively, the device
will return to the previous state or a custom state
as configured using the Lumos Controls mobile
app after the power is restored
Once powered up, the device will be ready to be commissioned via the Lumos Controls mobile app,
available for free download on iOS and Android. To begin commissioning, click the ‘+’ icon from the
top of the ‘Devices’ tab. The app allows you to preset certain configurations which will be loaded after
the device is added. The pre-configurations made using 'Commissioning Settings' will be sent to the
devices being commissioned.
Once commissioned, the device will be displayed in the ‘Devices’ tab and you can perform individual
operations like ON/OFF/dimming on it from this tab.
Note: The ‘Output Channel Configuration’ will be ‘Single Channel’ by default. To configure dual
channel settings, go to ‘Additional Settings’ and click ‘Output Channel Settings’. Then select
‘Controller based color tuning’ or ‘Driver based color tuning’ based on the connected driver.
Commissioning
Lumos Controls Application
Troubleshooting
There is a delay for the
device to turn on/o/dim
Check whether you have set up a
transition time
Lights flickering Check whether connection is as per wiring diagram
Check for loose connections
Lights did not turn ON Check whether circuit breaker has tripped
Check whether fuse has blown
Check for loose connections
5-year limited warranty
Please find warranty terms and conditions
Note: Specifications may change without notice
Actual performance can vary due to end-user environment and application
Warranty
Download the ‘Lumos Controls’ application
from Play Store or App Store
OR
Scan the QR codes to download the
‘Lumos Controls’ application
The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by WiSilica Inc. is under license. Other trademarks and trade names are those of their respective owners.
All Rights Reserved WiSilica Inc
www.lumoscontrols.com
20321 Lake Forest Dr D6,
Lake Forest, CA 92630
[phone]
Ver 1.1 Jul 2022
