Vendo VDI 100 User manual

Instruction forinstallation,
maintenance technician
and final user.
VENDINGMACHINE Rev. 00
Models: VDI 100 – 189 – 217 - 254 Pag. 1 di 46
VENDING MACHINE
Mod. VDI 100-189-217-254

Instruction forinstallation,
maintenance technician
and final user.
VENDINGMACHINE Rev. 00
Models: VDI 100 – 189 – 217 - 254 Pag. 2 di 46
INDEX
1GENERALWARNINGS......................................................................................................................3
1.1 Purposeofthis manual........................................................................................................................3
1.2 To whomthis manual is addressed.....................................................................................................3
1.3 Responsibility.......................................................................................................................................3
1.4 Manufacturer........................................................................................................................................3
1.5 Service centres....................................................................................................................................4
1.6 Warranty..............................................................................................................................................5
1.7 General safetywarnings......................................................................................................................5
1.8 Symbols...............................................................................................................................................6
2MACHINEPARTICULARS.................................................................................................................7
2.1 Technical particulars............................................................................................................................7
2.2 Description ofcomponents..................................................................................................................9
2.3 Coinintroduction selection panel....................................................................................................11
2.4 Control box ........................................................................................................................................11
2.5 Cooling system ..................................................................................................................................12
2.6 Vending mechanism..........................................................................................................................13
3INSTALLATION ................................................................................................................................14
3.1 Transport and positioning..................................................................................................................14
3.2 Installationenvironment characteristics.............................................................................................15
3.3 Removing the wooden bases............................................................................................................15
3.4 Levelling.............................................................................................................................................16
3.5 Connection to the power mains.........................................................................................................16
3.6 Installing the coin mechanism ...........................................................................................................18
3.7 Control settings..................................................................................................................................19
3.8 Price setting.......................................................................................................................................19
3.9 Labelinstallation................................................................................................................................20
4ACCESS TO THE INTERNAL PART ...............................................................................................21
4.1 Access to vendingmotors and product deliveryarea........................................................................21
5USING THE VENDING MACHINE....................................................................................................22
5.1 Warnings............................................................................................................................................22
5.2 Final check.........................................................................................................................................29
5.3 Control settings..................................................................................................................................29
5.4 Start up ..............................................................................................................................................29
6MAINTENANCE................................................................................................................................31
6.1 Preventive maintenance....................................................................................................................31
6.2 Preventive maintenance....................................................................................................................31
6.3 Replacing neon lamps.......................................................................................................................32
6.4 Cleaning the vending machine..........................................................................................................33
6.5 Warnings............................................................................................................................................34
6.6 General cleaning operation ...............................................................................................................35
6.7 Recommended cleaning products.....................................................................................................37
6.8 Cleaning safetydevice.......................................................................................................................37
7INFORMATION DANGER SIGNS .................................................................................................38
8TROUBLESHOOTING......................................................................................................................40
9STORAGE AND DISPOSAL.............................................................................................................44
9.1 Storage ..............................................................................................................................................44
9.2 Disposal.............................................................................................................................................44
9.3 Person in charge ofdisposal.............................................................................................................45
9.4 Sanctions...........................................................................................................................................46

Instruction forinstallation,
maintenance technician
and final user.
VENDINGMACHINE Rev. 00
Models: VDI 100 – 189 – 217 - 254 Pag. 3 di 46
GENERAL WARNINGS
0.1 Purpose of this manual
The manual contains thecorrect procedures for the loading, use, routine / special maintenance and
installation oftheVending Machine. This manual is anintegralpart ofthe machine andmust therefore be
kept intact and available to handfor the machine“sentire productive life.
KEEP INSIDE THE MACHINE
0.2 Towhomthis manual is addressed
This manual is addressed to those persons in chargeofloading, cleaning, androutine maintenance ofthe
machine (Filling Attendant), to the final user ofthe vending machine (User)andto thosepersons in charge
ofinstallation, adjustment, specialmaintenanceofthe vending machine (Installer/maintenance
technician).It is compulsorythat all personnel in charge ofthese operations are familiar withtheinstructions
and abide bythe procedures contained inthis manual.
0.3 Responsibility
The manufacturer,sresponsibilityis confined to thecorrect use of the vending machine, in thelimits
indicatedin this manual. The company ”SandenVendoáreserves the rightsto makechanges toits vending
machine without anyprior warning, furthermore declares that the vendingmachine, the subject matter ofthis
manual, complies with the requirements indicatedbyMachine Directive 98/37/EC (EC Marking Directive).
”SandenVendodeclines all responsibilityfor anydamages caused to persons and/or things as the result of:
-Incorrect installation
-Use ofunoriginal spare parts
-Execution ofchanges unforeseen /unauthorisedbythe manufacturer
-Improper use ofthe machine
-Connection to inadequate supplysystems and not in conformity with the regulations in force
0.4 Manufacturer
“ SandenVendo”has over twenty years experiencein constructingbeverage vending machine andit is
precisely the technologicalknow-how ithas developed over many years ofresearch workingclosely with the
production and international marketing, which is the best guarantee that SandenVendo can offer.

Instruction forinstallation,
maintenance technician
and final user.
VENDINGMACHINE Rev. 00
Models: VDI 100 – 189 – 217 - 254 Pag. 4 di 46
0.5 Servicecentres
”SandenVendoáis represented byavalidand prepared sales networkin bothItalyand Europe.
SandenVendo Europe S.p.A.
Casella Postale 9
I 15033 Casale Monf. (AL)
Italy
Tel.:+ 39 0142 335111
Fax.:+ 39 0142 562348
e-mail: [e-mail]
www.sandenvendo.com
SandenVendo GmbH
Spangerstrasse 22
D40599 Dusseldorf
Germany
Tel.: + 49 (0) 211 740390
Fax: + 49 (0) 211 7488541
e-mail: [e-mail]
SandenVendo France SAS
4 Avenue de la Baltique
SILIC506
F-91946CourtaboeufCedex - France
Tel. : [phone]
Fax : [phone]
e-mail: [e-mail]
SandenVendo Iberia S.A.
PoligonoIndustrial la Almeda
C/. Sant Ferran, no. 92
E-08940 Cornella (Barcelona) - Spain
Tel. : [phone]
Fax : [phone]
e-mail: [e-mail]
SandenVendo Benelux S.A.
Avenue A. Van Oss 1
Boıte 21
B- 1120 Bruxelles - Belgium
Tel.: [phone]
Fax :[phone]
e-mail: [e-mail]
SandenVendo (UK) Ltd.
Vendo House
Kingsclere Road
Basingstoke
Hampshire, RG21 5UG - Great Britain
Tel. :[phone]
Fax :[phone]
e-mail: [e-mail]

Instruction forinstallation,
maintenance technician
and final user.
VENDINGMACHINE Rev. 00
Models: VDI 100 – 189 – 217 - 254 Pag. 5 di 46
Warranty
The warranty onthe Vending Machine components, startingfromthe dateshownonthedelivery note, is for
24 months for the cooling system.
The warranty includes exclusively the parts replaced, with labour excluded.
TheWarranty does notinclude, damages to the vending machine caused by:
•Transport and/or handling
•Operator errors
•Lack of maintenance contemplatedfor in this manual
•Failures and/or breakages not due to malfunction of the vendingmachine
0.6 General safety warnings
§Carefully read the manual before starting or loading the vendingmachine
§Protect the vending machine against weather conditions
§Only maintenance technicians should remove the protective covers
§Always read the programming manual before operatingthe electronic board settings
§Never position the vendingmachine in direct sunlight
§Never sell theproducts with thedoor open
§Refer totheroutinemaintenance chapter to clean the vending machine
§Disconnect the power cable before giving assistance or unblocking a blockedproduct
§Use a special protection system
§Install the appliance so thatthe electrical plug can be easily accessed afterwards
§If thepower cable is damaged, it must be replaced by the manufacturer or by one of its technical
assistance service or in any case by a personwith similar qualifications, in orderto prevent all risks
§This machine is unsuitable for installation in areas where water jets areused
§This machine is unsuitable for outside installation
§To preventhazards due tomachine instability, secure the machine accordingto the instructions
§In case ofa failure and/or poor operation, only seek help of the qualified personnel of our service
centres.
§Use only spare parts authorised by the manufacturer
§Shouldthis manual be lost or damaged, youmay ask for a copy from the manufacturer: enclose the
serial number ofyour vending machine with your request.
CAUTION: FAILURE TO ABIDE BY THE INSTRUCTIONS CONTAINEDIN THIS MANUALMAY INVOLVE DAMAGES
TO THE MACHINE AND/OR PERSONNEL

Instruction forinstallation,
maintenance technician
and final user.
VENDINGMACHINE Rev. 00
Models: VDI 100 – 189 – 217 - 254 Pag. 6 di 46
Symbols
In the manual and/oron the machine, dangerous areas areshown withsigns, plates,symbols and icons that
indicatedanger or obligationin each case.
Here are the symbols usedin the manual andon the vending machine:
SYMBOL MEANING COMMENT
Compulsory Compulsory for all personnel involved
Compulsory Compulsory for all personnel involved towear protective
gloves during maintenance of the vending machine
Compulsory Compulsory for all personnel involved toprotective clothing
during maintenance.
iAdditional
information Additionalinformation is given.
Manual Before carrying out this operation, refer to the Instruction
Manual.
Maintenance
operations
In case ofspecial operations and/or anomalies, a particular
mechanical adjustment and/or electrical setting may be
required.
Warning Indicates a warning, failure to comply may involve damages
to the vending machine.
Danger Extreme care must be given whilst operatingthecoin
mechanisms.
Danger Extreme care must be given whilst handling electric cables.
Danger Indicates information regarding personnel safety and
machine integrity.
Danger/prohibition
Indicates the danger of electric shocks and mechanical
risks.
Never remove this safety guard.
Only SandenVendo Europe technicians or authorised
personnel canopen this safety guard.
Disposal Dispose in conformity with recycling procedures.
Recycling Recycling this product goestoward reducing the needof
new materials and the accumulation of waste.

Instruction forinstallation,
maintenance technician
and final user.
VENDINGMACHINE Rev. 00
Models: VDI 100 – 189 – 217 - 254 Pag. 7 di 46
1MACHINE PARTICULARS
1.1 Technical particulars
FIG. 2.1 - DIMENSIONS

Instruction forinstallation,
maintenance technician
and final user.
VENDINGMACHINE Rev. 00
Models: VDI 100 – 189 – 217 - 254 Pag. 8 di 46
MODELS 100 189 217 254
Dimensions
Height (A) 1425mm 1830mm 1830mm 1830mm
Width (B) 705 mm 705 mm 853 mm 1010mm
Depth(C) 745 mm 745 mm 745 mm 745 mm
Weight 186 Kg 235 Kg 264 Kg 294 Kg
Electricalparticulars
Nominal voltage 230/240 Vac 230/240 Vac 230/240 Vac 230/240 Vac
Nominal frequency 50 Hz 50 Hz 50 Hz 50 Hz
Installedpower 450 W 600 W 450 W 450 W
Machinery noise Lower than 70 dB Lower than 70 dB Lower than 70 dB Lower than 70 dB
Cooling system
Compressor 5,67 cm³ 8,85 cm³ 8,85 cm³ 8,85 cm³
Refrigerator power 260 W 260 W 474 W 474 W (-5°C -
+55°C)
Expansion Direct with capillary Direct with capillary Direct with capillary Direct with capillary
Cooling Forced circulation by
means of one fan Forced circulation by means of one fan Forced circulation by means of one fan Forced circulation by means of two fans
Working range 10°C / 32°C
65% RH
10°C / 32°C
65% RH
10°C / 32°C
65% RH
10°C / 32°C
65% RH
Settable temperature
range 0°C y15 °C 0 °C y15 °C 0 °C y15 °C 0 °C y15 °C
Coolant R134A R134A R134A R134A
Load 0,200 Kg 0,220 Kg 0,220 Kg 0,220 Kg

Instruction forinstallation,
maintenance technician
and final user.
VENDINGMACHINE Rev. 00
Models: VDI 100 – 189 – 217 - 254 Pag. 9 di 46
1.2 Description of components
1 CABINET
2 DOOR
3 LUMINOUS ADVERTISING PANEL
4 COINS INSERT
5 SELECTIONS PUSH BUTTONS
6 DOOR LOCK
7 COIN RETURN CUP
8 DELIVERYEYELET
FIG. 2.2

Instruction forinstallation,
maintenance technician
and final user.
VENDINGMACHINE Rev. 00
Models: VDI 100 – 189 – 217 - 254 Pag. 10 di 46
1 CONTROL BOX
2 COIN CHUTE
3 COIN MECHANISM
SUPPORT
4 BALLAST BOX
5 LIGHT SWITCH
6 COIN BOX
7 CROWN BOX
8 NEON
9 STARTER
10 TRANSFORMER BOX
11 MICRO SWITCH
12 MAIN SWITCH
13 INNER DOOR
14 COOLING SYSTEM
15 PROTECTIVE BACK
GRILLE
16 CHUTE
17 VENDING MECHANISM
AREA
18 PRODUCT COLUMNS
FIG. 2.3

Instruction forinstallation,
maintenance technician
and final user.
VENDINGMACHINE Rev. 00
Models: VDI 100 – 189 – 217 - 254 Pag. 11 di 46
1.3 Coin introduction – selectionpanel
1 PRICE AND MESSAGE DISPLAY
2 RED LED LAMP
3 COIN RETURN BUTTON
4 PRODUCTS LABEL
5 SELECTION BUTTON
6 SOLD OUT RED LAMP
7 DISPLAY FOR USER MESSAGES
FIG. 2.4
1.4 Control box
1 PROGRAMMING BUTTON
2 CONTROL BOARD S COVER
3 COIN MECHANISMCONNECTION
FIG.2.5

Instruction forinstallation,
maintenance technician
and final user.
VENDINGMACHINE Rev. 00
Models: VDI 100 – 189 – 217 - 254 Pag. 12 di 46
The control board coordinates the link with the coinageand drives thevending motors, constantly monitoring
the situationofthemechanisms and selections micro switch.For further details refer to theprogramming
manual.
1.5 Cooling system
1 CONDENSER
2 CONDENSER FAN MOTOR
3 FANS
4 EVAPORATOR
5 EVAPORATOR FAN MOTOR
6 THERMOSTAT
7 COMPRESSOR
8 CONDENSER PAN
FIG.2.6
The coolingsystem stats working when the machineis connectedto the electrical supply. The compressor
stops when it reaches the temperature set on the thermostat. Itautomatically re-starts when the temperature
lowers of2 or 3 degrees.
Caution: when you open thefrontaldoor the coolingsystem doesn’t stop

Instruction forinstallation,
maintenance technician
and final user.
VENDINGMACHINE Rev. 00
Models: VDI 100 – 189 – 217 - 254 Pag. 13 di 46
1.6 Vend mechanism
1 MOTOR
2 MOTOR CAM
3 CAMCOVER
4 MOTOR CARRIER SWITCH
5 LOWERING SHELVES
6 ROLLER BEARING
7 BAIL
8 ECCENTRIC BEARING
9 LINK ASSEMBLY
10 SHIMS
FIG.2.7

Instruction forinstallation,
maintenance technician
and final user.
VENDINGMACHINE Rev. 00
Models: VDI 100 – 189 – 217 - 254 Pag. 14 di 46
2INSTALLATION
2.1 Transportandpositioning
FIG. 3.1
To transport andhandlethevending machine carefully follow theinstructions below.
•Use atrans pallet/lift truck with minimumcarrying capacity of 400 Kg,the woodenbases (A)allow for
grippingof the 4 sides of the vendingmachine(fig. 3.1)
•Should you not wish to install themachine immediately, positionthe vending machine vertically and
in adry andprotected room.
•CAUTION: it is absolutely forbidden to transport and/or position the vending machine horizontally.
•In the event that themachineis mistakenly laidhorizontally,re-position in theworking position
(vertically) and waitat least12hours before startingit,otherwiseyou may cause damages and
anomalies tothecooling system
•Position the vending machinein theinstallation area, work carefully, avoid manouvres that may
suddenly jolt andcrash the machine.
•Remove all packaging fromthe vending machine, extract the power cable fromthe rear protective
grille and carefully moveit to its final position.

Instruction forinstallation,
maintenance technician
and final user.
VENDINGMACHINE Rev. 00
Models: VDI 100 – 189 – 217 - 254 Pag. 15 di 46
2.2 Installationenvironment characteristics
CAUTION: THE APPLIANCE IN UNSUITABLE FOR INSTALLATION OUTSIDE
CAUTION: DONOTUSE WATER JETS TOCLEAN THEVENDINGMACHINE, IT ISUNSUITABLETO INSTALL IT IN
ENVIRONMENTS WHERE WATER JETS ARE USED
Environments conditions for installing thevending machine
•The vendingmachine models describedinthis documentmust beinstalledin environment/area
where the temperature does not exceed 32 °C or fall below 10°C. failing this the electrical parts
(compressor) may be subject to overheating or may work not properly.
•Air circulationis crucial for cooling system: check that there is at least a10 cm gapbetween therear
of the vending machine and any obstacle(ex. a wall).
•Make sure thatthecapacity loadofthesurfaceonwhich the vendingmachineis positioned is
adequate to support the weightdeclared by the manufacturer.
2.3 Removing the wooden bases
FIG. 3.2
Toremove thewooden bases,work as follows:
•With a trans pallet, lift the vending machine from the floor (holding it from the front)
•Withasize 10 adjustable spanner (we recommend using aratchet wrench) unscrew the screws that
fasten thewoodenbasestothemachine; 2screws forthe righthand baseand2 screws for theleft
handbase
•Fit the 4 feet onto the base of the machine
•Rest themachineon the floor

Instruction forinstallation,
maintenance technician
and final user.
VENDINGMACHINE Rev. 00
Models: VDI 100 – 189 – 217 - 254 Pag. 16 di 46
2.4 Levelling
In order for the vending machine to runperfectly, position it on aperfectly levelsurface. Any irregularities in
the floor canbecompensateadjustingthescrew-onfeet onthe vendingmachinein order toobtainaperfect
level and guarantee stability.
i
THE VENDING MACHINE WILL OPERATE PERFECTLY WHEN POSITIONED ON A HORIZONTAL SURFACE
2.5 Connectiontothe power mains
SERVICE CORDINSTALLATION
CASE ”A–
(WITH METAL GRILLE)
CASE ”B–
(WITH PLASTIC GRILLE)
FIG. 3.3
CAUTION: BEFORE DOINGTHE ELECTRICALCONNECTION MAKE THE FOLLOWING CHECKS

Instruction forinstallation,
maintenance technician
and final user.
VENDINGMACHINE Rev. 00
Models: VDI 100 – 189 – 217 - 254 Pag. 17 di 46
Makesure that the particulars of the power mains (tension and frequency) are the sameas those
indicatedon the machine’srating plate: this vending machine must beconnectedto a230 V,50
Hz power mains, eachvoltage below 207 V or over 253 V can causes failure.
Makesure that the supplyoutlet is groundedandthat, after makingthe connection, the entire
appliance is ground connected.
Makesure that the appliance is positioned so that the plug connectingit to the power mains can
be easily accessed after installation.
Make sure that the neutralwire is blue; otherwise, youmust invert the poles.
CAUTION: shouldyoufind anyanomalieswith thesupplycableorshoulditbe damaged,itmust
bereplaced.For thesafety ofpersonnelandtopreventall risks ofdamages tothemachinenever
replace the supply cable, contact themanufacturer or the technicalassistance service.
CAUTION: NEVERUSE EXTENSION LEADS
Youmay now connectthemachine tothe power mains, the neonadvertisingpanel and all the signallamps
of the empty columns should lightup andthecooling system should start.

Instruction forinstallation,
maintenance technician
and final user.
VENDINGMACHINE Rev. 00
Models: VDI 100 – 189 – 217 - 254 Pag. 18 di 46
2.6 Installing the coinmechanism
Hook the coin mechanism on 3 screws suitably placed(E) on the door (F) (fig. 3.4).
Check thatthecoin mechanism has thecoin entrancein line withtheexitof thecurved channel(G)and that
the distancebetween the two parts is around 10 mmmaximum.
The mentioneddistance is simply adjustableby looseningthe3fasteningscrews (H)on thedoor and
therefore moving it upwards or downwards. After doing this operation remember to tighten the screws again.
FIG 3.4
It is possible to changethe coinage position in the two direction ofthehorizontalplaneto adapt theproducts
ofsomemanufacturers that donot followexactlythe international standards.Todo this,applythe3
supporting screws in the holes (L) and move fromright to left.
It is also possible to move the coin mechanismup and downinstalling spacers (washers) (I) between the
coinage door and the bottomofthe coinage box.
Once the setting is done remove the selector and tighten the 3 supporting screws(E).
(These operations are not necessaryif you use a coinage mechanismsuggested bySandenVendo).
Actuate the coin return button (M) and checkthat the mechanismworks properly:make sure that theselector
opens as much as possible. Ifthis doesn“thappen, youwill have toadjust again the height ofthe coinage
door.
Connect thecoinmechanism to the connector,which is above the control box.
i
THE COIN BOXES WITH EXECUTIVE PROTOCOL HAVE 2CONNECTORS, A POWER SUPPLYCONNECTOR THAT
COMES DIRECTLY FROM THETRANSFORMER BOX, AND ACOMMUNICATION CONNECTOR FROMTHE MAIN
BOARD.

Instruction forinstallation,
maintenance technician
and final user.
VENDINGMACHINE Rev. 00
Models: VDI 100 – 189 – 217 - 254 Pag. 19 di 46
Control settings
All themachine’scontrol and operation settings can beset throughtheprogrammingroutineof the
electronic board.
The programmingroutineof theelectronic board is described in the PROGRAMMING MANUAL supplied
with the vending machine.
i
REFER TOTHE PROGRAMMING MANUAL
2.7 Pricesetting
For setting price refer totheprogrammingmanual of the control board. This vending machine allows you to
use different prices for eachsingle selectionand tomake any kind ofpairing between columnand selection
button.
i
SANDENVENDO ALWAYS SUPPLIES VENDING MACHINE WITH ALL THE SELECTION SETON SAME PRICE AND WITH
COLUMNS PAIRED AS FOLLOWS
FIG. 3.5

Instruction forinstallation,
maintenance technician
and final user.
VENDINGMACHINE Rev. 00
Models: VDI 100 – 189 – 217 - 254 Pag. 20 di 46
2.8 Label installation
FIG. 3.6
Unscrew thescrew fromthe coin mechanismdoor, openitandinstall thelabel (U)from thetopofeach
window (T)inserting thembetween the two plastic parts. Remember that thefirst part remember that the first
buttonon the topactuates the first column onthe right and so on up to thelastbutton on the bottom that
actuates the last column onthe left.
Close the coin mechanism door.
