WNC IMQ5 User manual

1/38
User Manual
□Normal □Internal Use Confidential □Restricted Confidential
User Manual
Project Name: IMQ5 Module
Author: Wistron NeWeb Corporation
Revision: 0.5
Revision Date: 2020/03/06

2/38
User Manual
□Normal □Internal Use Confidential □Restricted Confidential
Contact Information
Technical Support website
https://SupportIoT.wnc.com.tw
Company Website
www.wnc.com.tw
Revision History
Rev. #
Author
Summary of Changes
Date
0.1
WNC
Draft release
2019/11/28
0.2
WNC
Update operating voltage
2019/11/29
0.3
WNC
Add FCC IC Statement
2020/02/20
0.4
WNC
Delete interface and Extended operating
temperature range
2020/02/28
0.5
WNC
Update operating temperature
2020/03/06

3/38
User Manual
□Normal □Internal Use Confidential □Restricted Confidential
© Wistron NeWeb Corporation
THIS DOCUMENT AND THE INFORMATION CONTAINED HEREIN IS PROPRIETARY AND IS THE
EXCLUSIVE PROPERTY OF WNC AND SHALL NOT BE DISTRIBUTED, REPRODUCED, OR
DISCLOSED IN WHOLE OR IN PART WITHOUT PRIOR WRITTEN PERMISSION FROM WNC.
LIMITATION OF LIABILITY
THIS DOCUMENT AND THE INFORMATION CONTAINED HEREIN IS PURELY FOR DESIGN
REFERENCE AND SUBJECT TO REVISION BY WNC AT ANY TIME. NOTHING IN THIS
DOCUMENT SHALL BE CONSTRUED AS GRANTING ANY WARRANTY OR RIGHT TO USE THE
MATERIAL CONTAINED HEREIN WITHOUT WNC’S PRIOR EXPRESS WRITTEN CONSENT. WNC
SHALL NOT BE LIABLE FOR ANY USE, APPLICATION OR DEVELOPMENT DERIVED FROM THE
MATERIAL WITHOUT SUCH PRIOR EXPRESS WRITTEN CONSENT.

4/38
User Manual
□Normal □Internal Use Confidential □Restricted Confidential
Contents
Contact Information................................................................................................................. 2
Revision History........................................................................................................................ 2
Contents.................................................................................................................................... 4
1. Introduction.......................................................................................................................... 6
1.1. RF band support........................................................................................................6
1.2. Features.................................................................................................................... 6
1.3. Architecture.............................................................................................................. 7
1.4. Connection Interface................................................................................................ 8
1.5. Environmental Specifications and Certifications...................................................... 8
1.5.1. Environmental Specifications........................................................................8
1.5.2. Certifications................................................................................................. 8
1.5.3. Green Product Compliance........................................................................... 8
2. Pin Definitions...................................................................................................................... 9
2.1. LGA Module Pin Diagram..........................................................................................9
2.2. LGA Module Pin Definitions....................................................................................10
3. Electrical Specifications...................................................................................................... 14
3.1. Power supply.......................................................................................................... 14
3.2. RF Specifications..................................................................................................... 14
3.2.1. Band support...............................................................................................14
3.2.2. Bandwidth support..................................................................................... 15
3.2.3. RF transmit specifications........................................................................... 15
3.2.4. RF receiver specifications............................................................................16

5/38
User Manual
□Normal □Internal Use Confidential □Restricted Confidential
3.2.5. GNSS receiver specifications....................................................................... 16
4. Software Interface.............................................................................................................. 16
4.1. Support tools.......................................................................................................... 16
4.2. USB interface.......................................................................................................... 17
5. Mechanical..........................................................................................................................17
5.1. PCBA Form Factor................................................................................................... 17
6. Design Guide.......................................................................................................................20
6.1. Power supply...........................................................................................................20
6.2. RF connection......................................................................................................... 21
6.3. Reflow..................................................................................................................... 24
7. Labeling and Packaging...................................................................................................... 27
7.1. Labeling...................................................................................................................27
7.2. Packaging................................................................................................................ 27
7.3. MSL level.................................................................................................................29
8. Safety Recommendation.................................................................................................... 30
Initialisms................................................................................................................................36

6/38
User Manual
□Normal □Internal Use Confidential □Restricted Confidential
1. Introduction
The WNC IMQ5 module includes the Qualcomm MDM9205 Cat. M1 baseband, a complete
LTE RF front-end, memory, and required circuitry to fulfill requirements of 3GPP E-UTRA
(Long Term Evolution - LTE, Rel-14 specifications). The IMQ5 module provides a variety of
interfaces including USB, SPI, UART, GPIO, PCM, I2C, and USIM.
1.1. RF band support
This section lists the main features and functions that the IMQ5 module supports. Table 1-1
specifies wireless technologies supported.
Module
LTE CAT M1
LTE CAT NB2
GPRS/EGPRS
GNSS
IMQ5
√
×
×
√
Table 1-1. IMQ5 module overview
Note: √= supported, ×= not supported
1.2. Features
Feature list:
LTE 3GPP release 14
3GPP category support: LTE Cat. M1 with 1.2 Mbps for UL, 375 Kbps for DL
LTE Support Bands:B2/4/12/13/25/26
Power Class 5: 20dBm
GNSS: GPS, GLONASS
Cortex A7 microprocessor (performance enhanced)
IPv4/IPv6-supported
AT command set

7/38
User Manual
□Normal □Internal Use Confidential □Restricted Confidential
LwM2M, FOTA
SMS over NAS
Interfaces
HS USB 2.0 with integrated PHY
Dual UART interfaces (4 bit and 2 bit) for data transfer and diagnostic tools
I2C/SPI interface
USIM interface
GPIOs
ADC
PCM/I2S
1.3. Architecture
The architecture of the IMQ5 is presented in Figure 1-1 as an LGA function block diagram.
Figure 1-1. LGA function block diagram

8/38
User Manual
□Normal □Internal Use Confidential □Restricted Confidential
1.4. Connection Interface
The IMQ5 module is LGA device. All electrical and mechanical connections are made
through the 80 pads on the bottom side of a PCB.
1.5. Environmental Specifications and Certifications
1.5.1. Environmental Specifications
The environmental specifications for both operating and storage conditions are defined in
the Table below.
Condition
Temperature Range
Remark
Normal operating
temperature range
–20 °C to 60 °C
Fully functional and in compliance with 3GPP
specifications
Extended operating
temperature range
–40 °C to 85°C
RF performance may be affected outside the
normal range, but the module will still function.
Storage
–40 °C to 85 °C
Table 1-2. Temperature range
Note: All temperatures above refer to ambient temperatures.
1.5.2. Certifications
The IMQ5 module is certified to be compliant with PTCRB, GCF, FCC, IC and
ATT/VZ/SPN/TMO (TBD) regulations and standards.
1.5.3. Green Product Compliance
RoHS (2011/65/EU)

9/38
User Manual
□Normal □Internal Use Confidential □Restricted Confidential
2. Pin Definitions
2.1. LGA Module Pin Diagram
The IMQ5 LGA module pin layout is illustrated below.

10 /38
User Manual
□Normal □Internal Use Confidential □Restricted Confidential
Figure 2-1. LGA pad diagram (top view)
2.2. LGA Module Pin Definitions
A complete list with related details for the module pinout are listed in the Table below:
Pin No.
Pin definition/type
Voltage Level (V)
Min.
Typ.
Max.
13
GND
-
0
-
14
GND
-
0
-
15
RF_1(LTE TRX)
-
-
-
16
GND
-
0
-
17
GND
-
0
-
18
GND
-
0
-
19
GND
-
0
-
20
GND
-
0
-
21
RF_2(ANSS)
-
-
-
22
GND
-
0
-
23
GND
-
0
-
24
GND
-
0
-
37
VCC1
2.85
3.8
4.5
38
VCC2
2.85
3.8
4.5
39
VCC3
2.85
3.8
4.5
40
VCC4
2.85
3.8
4.5

11 /38
User Manual
□Normal □Internal Use Confidential □Restricted Confidential
41
VCC5
2.85
3.8
4.5
42
VCC6
2.85
3.8
4.5
43
NC
-
-
-
44
GND
-
0
-
45
GND
-
0
-
46
PCM_SYNC/GPIO46
1.7
1.8
1.9
47
PCM_DIN/GPIO47
1.7
1.8
1.9
48
PCM_DOUT/GPIO48
1.7
1.8
1.9
49
PCM_CLK/GPIO49
1.7
1.8
1.9
50
GND
-
0
-
51
GND
-
0
-
52
GPIO01
1.7
1.8
1.9
53
GPIO02
1.7
1.8
1.9
86
USB_Dp
-
Note6
-
87
USB Detect
1.7
1.8
1.9
88
USB_Dn
-
Note6
-
89
UART2_RTS
1.7
1.8
1.9
90
NC
-
-
-
91
UART2_CTS
1.7
1.8
1.9
92
UART0_CTS
1.7
1.8
1.9
93
UART0_TX
1.7
1.8
1.9
94
UART2_TX
1.7
1.8
1.9
95
UART0_RX
1.7
1.8
1.9

12 /38
User Manual
□Normal □Internal Use Confidential □Restricted Confidential
96
UART2_RX
1.7
1.8
1.9
97
UART0_RTS
1.7
1.8
1.9
130
GPIO06/vGPIO Data In/AUX_ADC1
1.7
1.8
1.9
131
GPIO07/vGPIO Clock/AUX_ADC2
1.7
1.8
1.9
132
GNSS_EN/GPIO08
1.7
1.8
1.9
133
UIM_VCC/1.8V
1.7
1.8
1.9
134
UIM DATA
1.7
1.8
1.9
135
UIM CLK
1.7
1.8
1.9
136
UIM RESET
1.7
1.8
1.9
137
UIM DETECT
1.7
1.8
1.9
138
RFFE3_CLK/GPIO138
1.7
1.8
1.9
139
GND
-
0
-
140
RFFE3_DATA/GPIO140
1.7
1.8
1.9
141
WWAN_STATE
1.7
1.8
1.9
142
Power on
1.7
1.8
1.9
143
WAKEUP_OUT
1.7
1.8
1.9
144
WAKEUP_IN
1.7
1.8
1.9
145
RESET
1.7
1.8
1.9
146
VREF
1.7
1.8
1.9
208
SPI_EN
1.7
1.8
1.9
209
SPI_CLK
1.7
1.8
1.9
210
SPI_MOSI
1.7
1.8
1.9
211
SPI_MISO
1.7
1.8
1.9

13 /38
User Manual
□Normal □Internal Use Confidential □Restricted Confidential
212
GND
-
0
-
213
GND
-
0
-
214
GND
-
0
-
215
GND
-
0
-
216
GND
-
0
-
217
GND
-
0
-
218
GND
-
0
-
219
GND
-
0
-
220
PS_HOLD
1.7
1.8
1.9
221
Force usb boot
1.7
1.8
1.9
222
UART1_RX (UART 1)
1.7
1.8
1.9
223
UART1_TX (UART 1)
1.7
1.8
1.9
Table 2-1. Module pin definitions

14 /38
User Manual
□Normal □Internal Use Confidential □Restricted Confidential
3. Electrical Specifications
3.1. Power supply
The IMQ5 module receives and supplies power with the following potentials:
Direction
Vmin
Typical
Vmax
Power (37–42)
In
2.85 V
3.8 V
4.5 V
VREF
Out
1.71 V
1.8 V
1.89 V
UIM_VCC
Out
1.71 V
1.8 V
1.89 V
Table 3-1. Power supply

15 /38
User Manual
□Normal □Internal Use Confidential □Restricted Confidential
3.2. RF Specifications
3.2.1. Band support
LTE CAT M1
Uplink (MHz)
Downlink (MHz)
LTE Band 2
1,850–1,910
1,930–1,990
LTE Band 4
1,710–1,755
2,110–2,155
LTE Band 12
699–716
729–746
LTE Band 13
777-787
746-756
LTE Band 25
1,850–1,915
1,930–1,995
LTE Band 26
814-849
859-894
Table 3-2. Band support
3.2.2. Bandwidth support
Band
Bandwidth
1.4 MHz
3 MHz
5 MHz
10 MHz
15 MHz
20 MHz
LTE Band 2






LTE Band 4






LTE Band 12




-
-
LTE Band 13
-
-


-
-
LTE Band 25






LTE Band 26





-
Table 3-3. LTE CAT-M1 Bandwidth support

16 /38
User Manual
□Normal □Internal Use Confidential □Restricted Confidential
3.2.3. RF transmit specifications
LTE CATM1 band
Items
Parameter
Unit
Min.
Typ.
Max.
LTE Band 2
Max. TX Power
10 MHz 4 RBs/QPSK
dBm
17.3
20
22.7
LTE Band 4
Max. TX Power
10 MHz 4 RBs/QPSK
dBm
17.3
20
22.7
LTE Band 12
Max. TX Power
10 MHz 4 RBs/QPSK
dBm
17.3
20
22.7
LTE Band 13
Max. TX Power
10 MHz 4 RBs/QPSK
dBm
17.3
20
22.7
LTE Band 25
Max. TX Power
10 MHz 4 RBs/QPSK
dBm
17.3
20
22.7
LTE Band 26
Max. TX Power
10 MHz 4 RBs/QPSK
dBm
17.3
20
22.7
Table 3-4. Conductive Tx output power
Note: 1. RF transmitter specifications are defined at the LGA pad.
2. The IMQ5 series meets 3GPP TS 36.521-1/TS 51.010-1 test standards.
3.2.4. RF receiver specifications
LTE CATM1 band
Items
Parameter
Unit
Typ.
3GPP limit
LTE Band 2
RX Sensitivity
5 MHz with 4 RBs
dBm
–100.3
LTE Band 4
RX Sensitivity
5 MHz with 4 RBs
dBm
–102.3
LTE Band 12
RX Sensitivity
5 MHz with 4 RBs
dBm
–99.3
LTE Band 13
RX Sensitivity
5 MHz with 4 RBs
dBm
–99.3
LTE Band 25
RX Sensitivity
5 MHz with 4 RBs
dBm
–98.8
LTE Band 26
RX Sensitivity
5 MHz with 4 RBs
dBm
–100.3
Table 3-5. Conductive Rx sensitivity-3GPP
Note: 1. RF receiver specifications are defined at the LGA pad.
2. The IMQ5 series meets 3GPP TS 36.521-1/TS 34.121-1 test standards.

17 /38
User Manual
□Normal □Internal Use Confidential □Restricted Confidential
3.2.5. GNSS receiver specifications
One GNSS SAW filter, LNA need to be used between the module and antenna. in
4. Software Interface
4.1. Support tools
The IMQ5 module is compatible with the following support tools:
WNC IMQ5 Connection Manager (WNCCM) (TBD)
4.2. USB interface
The IMQ5 module supports 3GPP’s standard AT commands and proprietary AT commands.
5. Mechanical
5.1. PCBA Form Factor
The IMQ5 module has the same dimensions as the PCBA:
15.5 mm (typ.) × 15.5 mm (typ.) × 2.36 mm (typ.)

18 /38
User Manual
□Normal □Internal Use Confidential □Restricted Confidential
Figure 5-1. PCBA dimensions

19 /38
User Manual
□Normal □Internal Use Confidential □Restricted Confidential
Figure 5-2. Pad dimensions (bottom view)

20 /38
User Manual
□Normal □Internal Use Confidential □Restricted Confidential
Figure 5-3. Recommend PCB footprint
