Wolf CT36EU User manual

36" Unframed Ele tri Cooktop
With Wolf’s unframed ele tri ooktops
there’s no stainless steel trim, just the
sophisti ated, minimalist exterior subtly
patterned design to hide any unsightly
s rat hes. Four heating elements with nine
zones offer ex eptional ontrol of tempera-
ture for ooking utensils of every size. A
bridge onne ts two elements for a 7-in h
by 16-in h, 4400 watt heating area. All
elements offer true simmer along with one
element that enables you to set the
temperature for melting.
Touch controls.
Model CT36EU
Translucent surface.
FEATURES
•Can be mounted flush with top of counter-
top or as a frameless installation sitting on
top of the countertop surface.
•Easy-to-clean black ceramic glass surface
is resistant to scratching, staining, impact
and heat—translucent surface allows you
to see the glow of hot elements.
•High-frequency pulsation elements
improve cooking performance and control.
•Four heating elements with nine zones.
•Bridge-zone element connects two
elements to provide a larger cooking area.
•Temperature limiter to ensure that safe
operating temperature of ceramic glass is
never exceeded.
•Illuminated touch controls with graduated
control lighting.
•True simmer setting on all elements.
•Melt setting on one element.
•Hot-surface indicator light in control panel.
•Lock mode—cooktop can be locked so
that no elements can be turned on.
•Universal OFF turns all elements off.
•Countdown timer with 1 to 99 minute
range and adjustable sound frequency
and volume.
Model CT36EU i flush mou ted i stallatio .
MAXIMUM ELEMENT POWER
•Triple-zone element power:
1050 W/2200 W/2700 W.
•Dual-zone element power:
700 W/2200 W.
•ingle element power: 1200 W.
•Bridge-zone element power—
(2) 1800 W single elements with 800 W
bridge: 4400 W. This appliance is certified by tar-K
to meet strict religious regulations in
conjunction with specific instructions
found on www.star-k.org.

18" (457) min
36" (914)
FLOOR TO
COUNTERTOP
30" (762) min
COUNTERTOP
TO COMBUSTIBLE
MATERIALS
41/2" (114)
10" (254)
31/2" (89) E
SEE COUNTERTOP
CUT-OUT BELOW
343/8" (873)
CUT-OUT WIDTH
COUNTERTOP CUT-OUTRECESS FOR FLUSH INSTALLATION
FRONT
193/8" (492)
CUT-OUT
DEPTH
27/16" ( 6 2) m i n
211/8" (537)
RECESS
FOR FLUSH
INSTALLATION
19/16" (40)
2" (51) TO
COMBUSTIBLE*
2" (51) TO
COMBUSTIBLE*
SIDE
CABINET
13" (330)
max
5/16" (8)
7/8"
(22) max
COUNTERTOP
PROFILE
15/16" (33)
RADIUS
7/16" (11) RADIUS
361/8" (918)
RECESS FOR FLUSH INSTALLATION
2" (51) min*
FRONT VIEWSIDE VIEW
*Minimum clearance from cooktop cut-out to combustible materials up to 18" (457) above countertop.
NOTE: Electrical location applies only to installation with built-in oven.
Uit dime sio s may vary by ± 1/8".
SPECIFICATIONS
Overall Width 36"
Overall Height 41/4"
Overall Depth 21"
Heating Zone Outer Diameter
(1) Triple 12"
(1) Dual 81/4"
(3) ingle (2) 7" and 61/2"
Bridge Element Dimensions 7" x 16"
Countertop Cut-Out 343/8" W x 193/8" D
Electrical 240/208 V AC, 60 Hz
Requirements 50 amp service
Conduit 4' flexible 3-wire
Electric Rating 10.5 kW at 240 V AC
7.9 kW at 208 V AC
hipping Weight 60 lbs
INSTALLATION SPECIFICATIONS
OVERALL DIMENSIONS
36" Unframed Ele tri Cooktop
Dime sio s i pare theses are i
millimeters u less otherwise specified.
36" (914)
41/4" (108)
11/4" (32) 7/8" (22)
ALL SIDES
CONDUIT
21" (533)
INSTALLATION NOTES
Complete installation specifications can be
found on our website, wolfappliance.com.
©Wolf Applia ce, I c. all rights reserved. Features a d specificatio s are subject to cha ge at a y time without otice. 12/11
